Pro-Form PRO 7000 User manual

www.proform.com
Model No. PFTL17112.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.-Fri. 6 a.m.-6 p.m. MT
Sat. 8 a.m.-4 p.m. MT
Please do not contact the store.
®
;ER'S A UAL

TABLE OF CONTENTS
WARNING DECAL PLACEMENT ............................................................... 2
IMPORTANT PRECAUTIONS .................................................................. 3
BEFORE YOU BEGIN ........................................................................ 7
PART IDENTIFICATION CHART ................................................................ 8
ASSEMBLY ................................................................................ 9
THE CHEST HEART RATE MONITOR .......................................................... 18
OPERATION AND ADJUSTMENT ............................................................. 19
HOW TO MOVE THE TREADMILL ............................................................ 30
TROUBLESHOOTING ...................................................................... 31
EXERCISE GUIDELINES .................................................................... 34
PART LIST ................................................................................ 35
EXPLODED DRAWING ...................................................................... 36
ORDERING REPLACEMENT PARTS ................................................... Back Cover
LIMITED WARRANTY ............................................................... Back Cover
WARNING DECAL PLACEMENT
This drawing shows the location of the warning decal. If the decal is
missing or illegible, call the telephone number on the front cover of
this manual and request a free replacement decal. Apply the decal in
the location shown. Note: The decal is not shown at actual size.
_I'4i_ Protect yourself and others from risk of serious injury. Read the user's manua, _] |
or obtain proper instruction before use ana: J
_i Stand only on s_de rails when starting or .............. • Never allow children on or • Keep clothing, fingers, and hair_
stopping treadmill, around treadmill, away from moving belt.
Ch........ d*.... ,,............. _...... koywh...... _....... N...........d_..... ......
Hold handrails to prevent falling, and always belt while it is moving.
wear the safety clip while operating treadmill. Always wear athletic shoes
.Stop if you feel faint, dizzy, or short of breath, while operating treadmill
PROFORM is a registered trademark of iCON IP, inc.
2

iMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read
all important precautions and instructions in this manual and all warnings on your treadmill before
using your treadmill. ICON assumes no responsibility for personal injury or property damage sus-
tained by or through the use of this product.
1. it is the responsibility of the owner to ensure 12.
that all users of this treadmill are adequately
informed of all warnings and precautions.
.Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or persons
with pre-existing health problems.
Plug the power cord into asurge suppressor
(not included), and plug the surge suppres-
sor into an appropriate outlet (see page 19).
To avoid overloading the circuit, do not plug
other electrical devices, except for low-power
devices such as cell phone chargers, into
the surge suppressor or into an outlet on the
same circuit.
.
.
Use the treadmill only as described in this
manual
The treadmill is intended for home use only.
Do not use the treadmill in any commercial,
rental, or institutional setting.
13. Use only a surge suppressor that meets al! of
the specifications described on page 19. To
purchase a surge suppressor, see your local
PROFORNI dealer, call the telephone number
on the front cover of this manual, or see your
local electronics store.
.
.
.
.
.
10.
11.
Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
Place the treadmill on alevel surface, with
at least 8 ft. (2.4 m) of clearance behind it
and 2 ft. (0.6 m) on each side. Do not place
the treadmill on any surface that b!ocks air
openings. To protect the floor or carpet from
damage, place a mat under the treadmill.
Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
Keep children under age 12 and pets away
from the treadmill at all times.
The treadmill should be used only by per-
sons weighing 375 Ibs. (170 kg) or less.
Never allow more than one person on the
treadmill at a time.
Wear appropriate exercise clothes while
using the treadmill. Do not wear loose
clothes that could become caught in the
treadmill. Athletic support clothes are recom-
mended for both men and women. Always
wear athletic shoes. Never use the treadmill
with bare feet, wearing only stockings, or in
sandals.
14.
15.
16.
17.
18.
19.
Failure to use a properly functioning surge
suppressor could result in damage to the
control system of the treadmill, if the control
system is damaged, the walking belt may
slow, accelerate, or stop unexpectedly, which
may result in a fall and serious injury.
Keep the power cord and the surge suppres-
sor away from heated surfaces.
Never move the walking belt while the power
is turned off. Do not operate the treadmill
if the power cord or plug is damaged, or if
the treadmill is not working properly. (See
TROUBLESHOOTING on page 31 if the tread-
mill is not working properly.)
Read, understand, and test the emergency
stop procedure before using the treadmill
(see HOW TO TURN ON THE POWER on
page 21).
Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
3

20. The heart rate monitor is not a medical 24.
device. Various factors, including the user's
movement, may affect the accuracy of heart
rate readings. The heart rate monitor is 25.
intended only as an exercise aid in determin-
ing heart rate trends in general.
21. Never leave the treadmill unattended while
it is running. Always remove the key, press
the power switch into the off position (see
the drawing on page 7 for the location of the
power switch), and unplug the power cord
when the treadmill is not in use.
inspect and properly tighten all parts of the
treadmill regularly.
DANGER: A waysunp ogthepower
cord immediately after use, before clean=
ing the treadmill, and before performing the
maintenance and adjustment procedures
described in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized ser-
vice representative only.
22. Do not attempt to move the treadmill until it
is properly assembled. (See ASSEMBLY on
page 9, and HOW TO MOVE THE TREADMILL
on page 30.) You must be able to safely lift 45
Ibs. (20 kg) to move the treadmill.
26. Over exercising may result in serious injury
or death, if you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
23. Never insert any object into any opening on
the treadmill.
SAVE THESE iNSTRUCTiONS
4

DO MORS JUST WORK OUT
iFit ® is the most powerful training tool avaiLabLe to heLp gou accompLish aLL of your fitness goaLs.
From weight Loss and performance to personalized training programs, iFit ® is the key to getting
more out of everything you do. Some features require paid subscription.
DLOSE WEIGHT Q
Stay on track and motivated with
progressive weight Lossprograms
with our trainers, including
JiWan MichaeLs.
PSRSONAL|ZL:D
EVEIIT T_iN|liO
5k, 1Ok, half or full. marathon
training wiLL hel.p you prepare
for your event.
MAP YOUR ROUTS
With Goog[e Maps TM,your fitness
equipment wiLL simulate the
earth's terrain while dispLaging
Street View during your workout.
COMPETE WITH OTHERS
Push yourself to new Limits
with reaL-time virtual races.
GO IVIOB|LS
Track your workout anywhere
you go with iFit ® mobile apps.
$HARS YOUR PROGRSS$
Inspire others, motivate yoursel.f and
share routes, workouts and more.
5

Your new fitness equipment is not an ordinary purchase; it is an
investment in your health and well being for years to come.
As the leading provider of manufacturer's extended service plans,
ICON strives to protect your equipment and your future.
Please review the following service plans and find one that best fits your needs.
PREVENTIVE MAINTENANCE SERVICEPLANS
Equipment Price
50.00 to $1000.00
$1001.00 to 51500.00
51501.00 to 52500.00
(Bikes/Systems Only)
50.00 to 52500.00
3-Year Plan
'$339'99
Features:
• Includes an annual preventive
maintenance and performance
check at your convenience
• Unlimited in-home repairs;
no shipping required
• Covers parts and labor on all
manufacturer's defects, as well as
wear and tear on parts
• Up to S years of coverage available
STANDARD SERVICE PLANS
Equipment Price
50.00 to
5300.00
5301.00 to
$1000.00
$! O01.00 to
52000.00
52001.00 to
53000.00
i-Year Plan
5109199
$179199
Features:
•Unlimited in-home repairs;
no shipping required
• Covers parts and labor on all
manufacturer's defects, as
well as wear and tear parts
• Up to 5 years of
coverage available
6

BEFORE YOU BEGIN
Thank you for selecting the revolutionary
PROFORM _ PRO 7000 treadmill. The PRO 7000
treadmill offers an impressive selection of features
designed to make your workouts at home more enjoy-
able and effective.
For your benefit, read this manual carefully before
using the treadmill, ifyou have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, please note the product
model number and serial number before contacting us.
The model number and the location of the serial num-
ber decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
Length: 6 ft. 5 in. (196 cm)
Width: 3 ft. 3 in. (99 cm) iPad Holder
Tray
Handrail
Upright
Walking Belt
Foot Rail
Idler Roller c!
Adjustment S ws
Console
Heart Rate Monitor
Key/Clip
Power Switch
Power Cord
Platform Cushion
7

PART iDENTiFiCATiON CHART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see if it is preat=
tached. Extra parts may be included.
o O
5/16" Star
Washer (10)-8 3/8" Star 3/8" Flat
Washer (9)-4 Washer (29)-4
#8 x 1/2" #8 x 3/4" Screw #10 x 3/4" Screw
Screw (4)-6 (5)-12 (7)-4
5/16" x 5/8"
Screw (3)-8
3/8" x 2 3/4" Bolt (1)-2
3/8" x 4 1/4" Screw (2)-2
3/8" Nut (8)-2
1/4" x 1/2"
Screw (6)-2
8

ASSEMBLY
To hire an authorized service technician
to assemble your exercise equipment, call
1-800-445-2480.
Assembly requires two persons.
Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
After shipping, there may be an oily substance
on the exterior of the treadmill. This is normal, if
there is an oily substance on the treadmill, wipe
it off with a soft cloth and a mild, non-abrasive
cleaner.
Left parts are marked "L" or "Left" and right parts
are marked "R" or "Right."
To identify small parts, see page 8.
Assembly requires the following tools:
the included hex key
one adjustable wrench
one Phillips screwdriver
To avoid damaging parts, do not use power tools.
.Go to www.proformservice.com/registration
on your computer and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have Internet access, call
CUSTOMER CARE (see the front cover of this
manual) to register your product.
9

2. Make sure that the power cord is unplugged.
Identify the Right Upright (81). Have a second
person hold the Right Upright near the
Frame (51).
See the inset drawing. Tie the wire tie in the
Right Upright (81) securely around the end of the
Upright Wire (78). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Right Upright.
2
51
Wire
Wire 78
Tie
.Hold the Right Upright (81) against the Frame
(51). Be careful not to pinch the wires. Start a
3/8" x 4 1/4" Screw (2) with a 3/8" Star Washer
(9) into the Right Upright and into the Frame; do
not fully tighten the Screw yet.
Insert a 3/8" x 2 3/4" Bolt (1) with two 3/8" Flat
Washers (29) and a 3/8" Star Washer (9) into the
Frame (51). Tighten a 3/8" Nut (8) onto the end
of the Bolt; do not fully tighten the Bolt yet.
Attach the Left Upright (not shown) in the
same way. Note: There are no wires on the left
side.
3
51
81
29 1
2
10

Hold the right handrail assembly (B) near the
Right Upright (81). Insert the Upright Wire (78)
into the large hole in the bottom of the right
handrail, and pull it out of the front of the right
handrail.
Set the right handrail assembly (B) onto the
Right Upright (81), and attach the right handrail
with two 5/16" x 5/8" Screws (3) and two 5/16"
Star Washers (10). Do not tighten the Screws
yet.
Attach the left handrail assembly (C) as
described above. Note: There is not a wire in
the Left Upright (80).
Remove and discard the four indicated screws
(D) from the Left and Right Handrail Assemblies
(C, B).
D
78 B
,Set the console assembly face-down on a soft
surface to avoid scratching the console.
Attach the Left and Right Trays (97, 98) to the
console assembly with six #8 x 1/2" Screws (4).
Do not overtighten the Screws.
11

6. 6
Remove and discard the four screws (E). Next,
lift off the Pulse Bar Bottom (77).
Remove and discard the four 5/16" x 5/8"
Screws (3).
Console
Assembly
3
77
.Slide the Pulse Bar Bottom (77) onto the right
and left handrail assemblies (B, C) as far as pos-
sible in the direction shown. If necessary, loosen
the 3/8" x 2 3/4" Bolts (1) and the 3/8" x 4 1/4"
Screws (2) (only one side is shown).
Attach the Pulse Bar Bottom (77) with four #10
x 3/4" Screws (7). Start all four Screws, and
then tighten them.
Remove the wire tie from the Upright Wire (78).
7
7
77
78
Tie
2
12

.With the help of a second person, hold the con-
sole assembly near the Right Upright (81) and
the Left Upright (not shown). Insert the Upright
Wire (78) through the looped plastic ties on the
bottom of the console assembly.
Connect the Upright Wire (78) to the console
wire. See the inset drawing. The connectors
should slide together easily and snap into
place. If they do not, turn one connector and try
again. IF YOU DO NOT CONNECT THE CON-
NECTORS PROPERLY, THE CONSOLE MAY
BECOME DAMAGED WHEN YOU TURN ON
THE POWER.
Console
Assembly
/
Ties
/'_ %// _ _- Console
/J -- 78 Wire
.Route the Upright Wire (78) as shown so that
it doesn't get pinched as you set the console
assembly onto the right handrail assembly (B)
and left handrail assembly (not shown).
78
Console
Assembly
13

10. Tighten four #8 x 3/4" Screws (5) into the bottom
of the Pulse Bar Bottom (77). 10 Console
Assembly
77 5
11. Attach the console assembly with four 5/16" x
5/8" Screws (3) and four 5/16" Star Washers
(10). Start all four Screws, and then tighten
them.
Then, tighten the four other 5/16" x 5/8"
Screws (3).
11 Console
Assembly
14

12. Attach the Right Handrail Bottom (74) to the bot-
tom of the right handrail assembly (B) with two
#8 x 3/4" Screws (5).
Attach the Left Handrail Bottom (73) to the bot-
tom of the left handrail assembly (C) with two #8
x 3/4" Screws (5).
12
C
13. Attach the Center Tray (79) to the tray brackets
on the Right Upright (81) and the Left Upright
(80) with four #8 x 3/4" Screws (5). Start all four
Screws, and then tighten them.
13
79
5
15

14. Firmly tighten the 3/8" x 2 3/4" Bolt (1) and the
3/8" x 4 1/4" Screw (2) on each side of the tread-
mill (only one side is shown).
14
15. Identify the Right Outside Cover (83) and the
Right Inside Cover (85).
Slide the Right Inside Cover (85) onto the
bracket between the Motor Hood (59) and the
Right Upright (81).
Press the Right Outside Cover (83) against the
Right Inside Cover (85) and the Right Upright
(81) until the two Covers snap together.
Repeat this step on the left side with the Left
inside and Outside Covers (not shown).
15
85 59
83
16

16. Slide the iPad Holder Cover (91) up on the iPad
Holder (92). Attach the iPad Holder to the con-
sole assembly with two 1/4" x 1/2" Screws (6).
Slide the iPad Holder Cover (91) down against
the console assembly.
16
Console
Assembly
17. See HOW TO MOVE THE TREADMILL on page
30. Move the treadmill to the desired location.
Make sure that the leveling feet rest firmly on the
floor. If the treadmill rocks even slightly, loosen
one of the nuts, turn the leveling foot clockwise
or counterclockwise until the rocking motion is
eliminated, and then retighten the nut.
17
_r /'_ Nuts
Leveling Feet
18. Make sure that all parts are properly tightened before you use the treadmill, if there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
Note: Extra parts may be included. Keep the included hex keys in a secure place; one of the hex keys is used
to adjust the walking belt (see pages 32 and 33).
17

THE CHEST HEART RATE MONITOR
HOW TO PUT ON THE HEART RATE MONITOR
The heart rate
monitor consists of
a chest strap and a
sensor. Insert the
tab on one end of
the chest strap into
the hole in one end
of the sensor as
shown. Then, press
the end of the sen-
sor under the buckle
on the chest strap.
The tab should be
flush with the front of
the sensor.
The heart rate moni-
tor must be worn
under your clothes,
tight against your
skin. Wrap the heart
rate monitor around
your chest in the
location shown.
Make sure that
the logo is right-
side-up. Then, attach the other end of the chest strap
to the sensor. Adjust the length of the chest strap, if
necessary.
Sensor Buckle
Pull the sensor away from your body a few inches and
locate the two electrode areas, which are covered by
shallow ridges. Using saline solution such as saliva or
contact lens solution, wet the electrode areas. Then,
return the sensor to a position against your chest.
CARE AND MAINTENANCE
• Thoroughly dry the sensor with a soft towel after
each use. Moisture may keep the sensor activated,
shortening the life of the battery.
• Store the heart rate monitor in a warm, dry place. Do
not store the heart rate monitor in a plastic bag or
other container that may trap moisture.
Do not expose the heart rate monitor to direct sun-
light for extended periods of time; do not expose it to
temperatures above 122 ° F (50° C) or below 14° F
(-10° C).
Do not excessively bend or stretch the sensor when
using or storing the heart rate monitor.
To clean the sensor, use a damp cloth and a small
amount of mild soap. Then, wipe the sensor with a
damp cloth and thoroughly dry it with a soft towel.
Never use alcohol, abrasives, or chemicals to clean
the sensor. Hand wash and air dry the chest strap.
TROUBLESHOOTING
If the heart rate monitor does not function properly, try
the steps below.
Make sure that you are wearing the heart rate moni-
tor as described at the left. If the heart rate monitor
does not function when positioned as described,
move it slightly lower or higher on your chest.
• If heart rate readings are not displayed until you
begin perspiring, rewet the electrode areas.
• For the console to display heart rate readings, you
must be within arm's length of the console.
• Ifthere is a battery cover on the back of the sensor,
replace the battery with a new battery of the same
type.
The heart rate monitor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical condi-
tions such as premature ventricular contractions
(pvcs), tachycardia bursts, and arrhythmia.
The operation of the heart rate monitor can be
affected by magnetic interference from high power
lines or other sources. If you suspect that magnetic
interference is causing a problem, try relocating the
fitness equipment.
18

OPERATION AND ADJUSTMENT
HOW TO CONNECT THE POWER CORD
Use aSurge Suppressor
Your treadmill, like other electronic equipment, can be
damaged by sudden voltage changes in your home's
power. Voltage surges, spikes, and noise interfer-
ence can result from weather conditions or from other
appliances being turned on or off. To decrease the
risk of damaging the treadmill, always use a surge
suppressor with the treadmill. To purchase asurge
suppressor, see precaution 13 on page 3.
Use only a surge suppressor that is UL 1449 listed as a
transient voltage surge suppressor (TVSS). The surge
suppressor must have a UL suppressed voltage rating
of 400 volts or less and a minimum surge dissipation of
450 joules. The surge suppressor must also be electri-
cally rated for 120 volts AC and 15 amps. There must
be a monitoring light on the surge suppressor to indi-
cate whether it is functioning properly. Failure to use a
properly functioning surge suppressor could result
in damage to the control system of the treadmill
and serious injury to users.
Plug in the Power Cord
The treadmill must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. The treadmill power cord has a plug with a
grounding pin (see drawing 1 on this page).
Plug the power cord into a surge suppressor, and plug
the surge suppressor into an appropriate outlet that is
properly installed and grounded in accordance with all
local codes and ordinances. The outlet must be on a
nominal 120=volt circuit capable of carrying 15 or
more amps. To avoid overloading the circuit, do
not plug other electrical devices, except for low=
power devices such as cell phone chargers, into
the surge suppressor or into an outlet on the same
circuit. IMPORTANT: The treadmill is not compat=
ible with GFCl-equipped outlets and may not be
compatible with AFCl=equipped outlets.
Grounded Outlet
Grounding Pin
Grounding
Surge
Suppressor
A temporary
adapter may
be used to
connect the
surge sup-
pressor to
a 2-pole
receptacle
if a properly
grounded
outlet is not
available.
)ole Receptacle
Adapter
Metal
Screw
The lug or wire extending from the adapter must
be connected with a metal screw to a permanent
ground such as a properly grounded outlet box cover.
Some 2=pole receptacle outlet box covers are not
grounded. Before using an adapter, contact a quali-
fied electrician to determine whether the outlet box
cover is grounded. The temporary adapter should
be used only until a properly grounded outlet can
be installed by a qualified electrician.
19

CONSOLE
DIAGRAM
/
AccuRa_
\
DIStaLly HOME V A ENTEm
J
(., o: .... ,,))
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features designed to make your workouts more effec-
tive and enjoyable. When you use the manual mode,
you can change the speed and incline of the treadmill
with the touch of a button. As you exercise, the console
will display instant exercise feedback. You can even
measure your heart rate using the handgrip heart rate
monitor or the chest heart rate monitor.
In addition, the console features thirty-six onboard
workouts--nine calorie workouts, nine timed workouts,
nine performance workouts, and nine distance work-
outs. Each workout automatically controls the speed
and incline of the treadmill as it guides you through an
effective exercise session.
The console also features an iFit mode that enables
the treadmill to communicate with your wireless
network. With the iFit mode, you can download per-
sonalized workouts, create your own workouts, track
your workout results, race against other iFit users, and
access many other features.
You can even listen to your favorite workout music or
audio books with the console's stereo sound system
while you exercise.
To turn on the power, see page 21. To use the
manual mode, see page 21. To use the stereo
sound system, see page 23. To use an onboard
workout, see page 24. To use a set=a=goal work-
out, see page 25. To use an iFit workout, see
page 26. To change console settings, see page
27. To use the iPad holder, see page 29.
Note: The console can display speed and distance
in either miles or kilometers. To find which unit of
measurement is selected, see HOW TO CHANGE
CONSOLE SETTINGS on page 27. For simplicity,
all instructions in this manual refer to miles.
IMPORTANT: If there are sheets of plastic on the
console, remove the plastic. To prevent damage
to the walking platform, wear clean athletic shoes
while using the treadmill. The first time you use
the treadmill, observe the alignment of the walking
belt, and center the walking belt if necessary (see
page 33).
2O
