Pro-Form FTL59106.0 User manual

Serial Number Decal
Model No. PFTL59106.0
Serial No.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction.If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.proformservice.com
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
V

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
2
PROFORM is a registered trademark of ICON IP, Inc.

1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least eight feet of clearance behind it and two
feet on each side. Do not place the treadmill
on any surface that blocks air openings. To
protect the floor or carpet from damage, place
amat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 300 pounds or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women.
Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page
12), plug the power cord into a surge sup-
pressor (not included) and plug the surge
suppressor into a grounded circuit capable of
carrying 15 or more amps. No other appliance
should be on the same circuit. Do not use an
extension cord.
11. Use only a single-outlet surge suppressor
that meets all of the specifications described
on page 12. To purchase a surge suppressor,
see your local PROFORM dealer or call the
toll-free telephone number on the front cover
of this manual and order part number 146148,
or see your local electronics store.
12. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may change
speed, accelerate, or stop unexpectedly,
which may result in a fall and serious injury.
13. Keep the power cord and the surge suppres-
sor away from heated surfaces.
14. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLESHOOTING on page 22 if the treadmill is
not working properly.)
15. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 14).
16. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
17. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
18. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
WARNING: Toreduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
IMPORTANT PRECAUTIONS
3

4
The decals shown here have been placed on the treadmill. If
adecal is missing, or if it is illegible, call the toll-free tele-
phone number on the front cover of this manual and order a
free replacement decal. Apply the decal in the location
shown.
19. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the reset/off cir-
cuit breaker to the off position when the
treadmill is not in use. (See the drawing on
page 5 for the location of the circuit breaker.)
20. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 20.)
You must be able to safely lift 45 pounds (20
kg) to raise, lower, or move the treadmill.
21. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
22. Never insert any object into any opening on
the treadmill.
23. Inspect and properly tighten all parts of the
treadmill regularly.
24. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorized ser-
vice representative. Servicing other than the
procedures in this manual should be performed
by an authorized service representative only.
25. This treadmill is intended for in-home use
only. Do not use this treadmill in a commer-
cial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS

5
Thank you for selecting the revolutionary PROFORM®
645 treadmill. The 645 treadmill offers an impressive
array of features designed to make your workouts at
home more enjoyable and effective. And when you’re
not exercising, the unique 645 treadmill can be folded
up, requiring less than half the floor space of other
treadmills.
For your benefit, read this manual carefully before
you use the treadmill. If you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model num-
ber and serial number before contacting us. The model
number of the treadmill is PFTL59106.0. The serial
number can be found on a decal attached to the tread-
mill (see the front cover of this manual for the location).
To avoid a registration fee for any service needed
under warranty, you must register the treadmill at
www.proformservice.com/registration.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail
Upright
Storage Latch
Key/Clip
Reset/Off
Circuit Breaker
Walking Belt
Cushioned Walking Platform
for maximum exercise comfort
Foot Rail
Power Cord
RIGHT SIDE
Rear Roller
Adjustment Bolts
Console
*No water bottle is included
Fan
Water Bottle Holder*
Handgrip Pulse Sensor
BACK

1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its left side as shown. Partially
fold the Frame (26) so that the treadmill is more
stable. Do not fully fold the Frame until the
treadmill is completely assembled.
Identify the Right Upright (76) which has a
RIGHT sticker. Hold the Right Upright near the
Base (81). Insert the Upright Wire (75) into the
Right Upright until the Upright Wire is extending
from the upper end of the Right Upright. Note:
Make sure that the Upright Wire is extending
from the side of the post as shown in the inset
drawing. Remove the tie from the Upright Wire.
Thread a 2 3/4" Upright Bolt (85) and a 1" Upright
Bolt (84) with 3/8" Star Washers (83) into the
Base (81) and the bottom of the Right Upright
(76). Do not tighten the Upright Bolts yet.
6
ASSEMBLY
Tohire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480.
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the
top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included hex key and your own phillips screwdriver .
Use the drawings below to identify the hardware used during assembly. Note: If a part is not in the parts bag,
check to see if it has been preattached to one of the parts to be assembled. To avoid damaging plastic
parts, do not use power tools for assembly.
26
75
76
85
84
83
81
3/4" Screw (23)–6 Cover Screw (52)–4
3/8" Star
Washer (83)–4
Console Screw (67)–4
Pulse Bar Star
Washer (65)–4
Silver Pulse Bar
Screw (64)–4
Endcap Screw
(79)–2
2 3/4" Upright Bolt (85)–2
1 1/4” Tek Screw (108)–2
1” Tek Screw (77)–4
1" Upright Bolt (84)–2 11/4" Bolt (63)–4
1
Wire
Post
76

7
2. Slide a Front Endcap (80) onto the Base (81).
Partially tighten a Endcap Screw (79) into the
Front Endcap and the base.
Slide a Wheel Housing (86) onto the Base (81).
Attach the Wheel Housing with a 1" Tek Screw
(77) and a Base Pad (89) with a 1 1/4” Tek
Screw (108) as shown.
Attach an additional Base Pad (89) to the Base
(81) with a 1" Tek Screw (77). 89
89
86
79
77
81 80
2
3. With the help of a second person, carefully tip
the treadmill onto its right side as shown.
Partially fold the Frame (26) so the treadmill is
more stable. Do not fully fold the Frame until
the treadmill is completely assembled.
Hold the Left Upright (70) against the Base (81).
Then, thread a 2 3/4" Upright Bolt (85) and a 1"
Upright Bolt (84) with 3/8" Star Washers (83) into
the Base (81) and the bottom of the Left Upright
(70). Do not tighten the Upright Bolts yet.
26
85
70
81
83
3
4. Slide a Front Endcap (80) onto the Base (81).
Partially tighten a Endcap Screw (79) into the
Front Endcap and the base.
Slide a Wheel Housing (86) onto the Base (81).
Attach the Wheel Housing with a 1" Tek Screw
(77) and a Base Pad (89) with a 1 1/4” Tek
Screw (108) as shown.
Attach an additional Base Pad (89) to the Base
(81) with a 1" Tek Screws (77).
86
77
80 79
89
89
4
77
84
108 77
81
108

8
5. With the help of a second person, carefully raise
the Left Upright (70) and the Right Upright (not
shown) to a vertical position.
Remove the knob from the pin. Make sure that
the collar and the spring are on the pin. (Note: If
there are two collars, place one on each side of
the spring.) Then, insert the pin into the Latch
Housing (71), and tighten the knob onto the pin.
See steps 2 and 4. Fully tighten the two
Endcap Screws (79).
70
Pin
Collar
Spring
Knob
5
71
6. Slide a Handrail (62) onto the post on the Left
Upright (70). Finger tighten two 1 1/4" Bolts (63)
into the Handrail and the post; do not fully
tighten the Bolts yet.
Attach the other Handrail (62) to the Right
Upright (76) in the same way.
70
Post
62
62
63
63
76
6
7. Make sure that the Upright Wire (75) is posi-
tioned at the side of the post on the Right
Upright (76) as shown.
Set the Pulse Bar (66) on the Left and Right
Uprights (70, 76). Attach the Pulse Bar with four
Silver Pulse Bar Screws (64) and four Pulse Bar
Star Washers (65). Start all four Silver Pulse
Bar Screws before firmly tightening them.
Firmly tighten the four 1 1/4" Bolts (63).
70
64
65
64
65
63
76
66
63
7
75

9
8. While a second person holds the console as-
sembly near the Pulse Bar (66), connect the
Ground Wire (107) on the Pulse Bar to the
ground wire from the console assembly.
Connect the wire from the console assembly to
the Upright Wire (75). Make sure to connect
the connectors properly (see the inset draw-
ing). The connectors should slide together
easily and snap into place. If the connectors
do not slide together easily and snap into place,
turn one connector and then try again. IF THE
CONNECTORS ARE NOT CONNECTED
PROPERLY, THE CONSOLE MAY BE DAM-
AGED WHEN THE POWER IS TURNED ON.
Lay the wires inside the bottom of the Pulse Bar
(66).
75
Console
Assembly
Wire
76
107
8
75
9. Set the console assembly on the Left and Right
Uprights (70, 76). Be careful not to pinch any
wires.
Attach the console assembly to the Pulse Bar
(66) with six 3/4" Screws (23). Start all six
Screws, before tighten them yet.
23
Console Assembly
23 23
76 70
9
Ground
Wire
66
66
10.Identify the Left Handrail Cover (68), which has
aLEFT sticker on it. Slide the Left Handrail
Cover onto the left Handrail (62) and up against
the console assembly. Tighten two Cover
Screws (52) into the Left Handrail Cover and the
Left Upright (70); be careful not to overtighten
the Cover Screws.
Attach the Right Handrail Cover (74) in the same
way.
Console
Assembly
52
68
70
76
74
52
10
62
62

10
12. See the inset drawing. Push the Uprights (70,
76) sideways so that the treadmill Frame (26) is
centered between the Uprights.
Firmly tighten the Upright Bolts (84, 85) on each
side of the treadmill.
With the help of a second person, carefully raise
the Left Upright (70) and the Right Upright (76)
to a vertical position
76
70, 76
26
26
70
View From Above
Side View
12
85
84
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex key in a secure place; the large hex key is
used to adjust the walking belt (see page 23).
11.Lower the Uprights (70, 76) as shown.
Start the two indicated Console Screws (67) into
the Left and Right Uprights (70, 76) and the con-
sole assembly. If necessary, pull back on the
console assembly slightly to align the holes in
the Uprights with those on the console assem-
bly. Start the other two Console Screws be-
fore tightening all four; do not overtighten
the Console Screws.
Console Assembly
67
70
76
11
67
Start First
Start
First

11
1. Remove the key from the console and unplug
the power cord.
Remove the 3/4" Screw (23) and the Access Door
(100) from the back of the Console Base (98).
2. Connect the wire on the receiver (A) to the indi-
cated wire extending from the Console Base (98).
Hold the receiver so the small cylinder is ori-
ented as shown and is facing the Console
Base. Attach the receiver to the plastic posts on
the Access Door (100) with the two included
small screws.
3. Make sure that no wires are pinched. Reattach
the Access Door (100) with the 3/4" Screw (23).
Discard the other wires included with the re-
ceiver.
If you purchase the optional chest pulse sensor (see page 19), follow the steps below to install the receiver
included with the chest pulse sensor.
A
98
Small
Cylinder
23
100
Wire
Small
Screws

OPERATION AND ADJUSTMENT
THE PRE-LUBRICATED WALKING BELT
Your treadmill features a walking belt coated with high-
performance lubricant. IMPORTANT: Never apply sil-
icone spray or other substances to the walking
belt or the walking platform. Such substances will
deteriorate the walking belt and cause excessive
wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge
suppressor with your treadmill (see drawing 1 at
the right). To purchase a surge suppressor, see
your local PROFORM dealer or call the toll-free
telephone number on the front cover of this man-
ual and order part number 146148, or see your local
electronics store.
Use only a single-outlet surge suppressor that is
UL 1449 listed as a transient voltage surge sup-
pressor (TVSS). The surge suppressor must have a
UL suppressed voltage rating of 400 volts or less
and a minimum surge dissipation of 450 joules.
The surge suppressor must be electrically rated for
120 volts AC and 15 amps. There must be a moni-
toring light on the surge suppressor to indicate
whether it is functioning properly. Failure to use a
properly functioning surge suppressor could result
in damage to the control system of the treadmill. If
the control system is damaged, the walking belt
may change speed, accelerate or stop unexpect-
edly, which may result in a fall and serious injury.
This product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current, reducing the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord into a surge suppressor,
and plug the surge suppressor into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Important: The treadmill is not compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
DANGER: Improper connection
of the equipment-grounding conductor can
result in an increased risk of electric shock.
Check with a qualified electrician or service-
man if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product—if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin
12

13
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features designed to make your workouts more effec-
tive.
When the manual mode of the console is selected, the
speed and incline of the treadmill can be changed with
the touch of a button. As you exercise, the console will
display continuous exercise feedback. You can even
measure your heart rate using the built-in handgrip
pulse sensor or the optional chest pulse sensor (see
page 19).
In addition, the console features four preset programs.
Each program automatically controls the speed and in-
cline of the treadmill as it guides you through an effec-
tive workout. The console also features four calorie pro-
grams that automatically control the speed and incline
of the treadmill to help you burn unwanted pounds dur-
ing your workouts.
To use the manual mode of the console, follow the
steps beginning on page 14. To use a preset
program,see page 16. To use a calorie program,
see page 17.
Clip
CONSOLE DIAGRAM
Key
Note: If there is a sheet of clear plastic
on the face of the console, remove it.

HOW TO TURN ON THE POWER
Plug in the power cord (see page 12).
Locate the reset/off
circuit breaker near
the power cord. Make
sure that the circuit
breaker is in the reset
position.
Stand on the foot rails of the treadmill. Find the clip
attached to the key (see the drawing on page 13)
and slide the clip onto the waistband of your
clothes. Next, insert the key into the console. After
amoment, the display will light. Important: In an
emergency situation, the key can be pulled
from the console, causing the walking belt to
slow to a stop. Test the clip by carefully taking
afew steps backward; if the key is not pulled
from the console, adjust the position of the
clip.
HOW TO USE THE MANUAL MODE
Insert the key into the console.
See HOW TO TURN ON THE POWER above.
Enter your weight if desired.
If you enter your weight
into the console, the
console will display a
more accurate estimate
of the number of calo-
ries that you burn. To
enter your weight, press the weight increase and
decrease buttons repeatedly. Note: Once you have
entered your weight, it will be saved in memory.
Select the manual mode.
When the
key is in-
serted, the
manual
mode will
be selected.
If you have selected a program, reselect the man-
ual mode by pressing any of the buttons num-
bered P1 to P8 once or twice until a track appears
in the lower part of the display.
Start the walking belt.
Tostart the walking belt, press the Start button,
the Quick Speed increase button, or one of the
speed buttons numbered 1 to 10.
If the Start button or the Quick Speed increase
button is pressed, the walking belt will begin to
move at 1 mph. As you exercise, change the
speed of the walking belt as desired by pressing
the Quick Speed in-
crease and decrease
buttons. Each time a
button is pressed, the
speed setting will
change by 0.1 mph; if a
button is held down, the
speed setting will change in increments of 0.5
mph. Note: After the buttons are pressed, it may
take a moment for the walking belt to reach the se-
lected speed setting.
If one of the numbered speed buttons is pressed,
the walking belt will gradually increase in speed
until it reaches the selected speed setting.
To stop the walking belt, press the Stop button.
The time will begin to flash in the display. To
restart the walking belt, press the Start button, the
Quick Speed increase button, or one of the num-
bered buttons.
Note: The first time the treadmill is used, observe
the alignment of the walking belt, and align the
walking belt if necessary (see page 23).
Change the incline of the treadmill as desired.
To change the incline of
the treadmill, press the
Power Incline increase
and decrease buttons.
Each time a button is
pressed, the incline will
change by 0.5%. Note: After the buttons are
pressed, it may take a moment for the treadmill to
reach the selected incline setting.
5
4
3
2
1
3
2
1
14
Reset
Position
Track

15
Follow your progress with the display.
When the
manual
mode is se-
lected, the
lower part of
the display
will show a
1/4-mile track. As you walk or run, the indicators
around the track will appear in succession until the
entire track appears. The track will then disappear
and the indicators will again begin to appear in
succession.
The left side of the dis-
play will show the incline
level of the treadmill, the
elapsed time, and the
distance you have
walked or run. Note:
When a program is selected, the display will show
the time remaining in the program instead of the
elapsed time.
The right side of the
display will show the
speed of the walking
belt, the approximate
number of calories you
have burned, and your
pace (in minutes per mile). The display will also
show your heart rate when you use the handgrip
pulse sensor or the optional chest pulse sensor.
To reset the display, press the Stop button, re-
move the key, and then reinsert the key.
Note: The console can
display speed and dis-
tance in either miles or
kilometers. To determine
which unit of measure-
ment is selected, hold
down the Stop button while inserting the key into
the console. An “E” for English miles or an “M” for
metric kilometers will appear in the right side of the
display. Press the Quick Speed increase button to
change the unit of measurement. When the de-
sired unit of measurement is selected, remove the
key. Note: For simplicity, all instructions in this
section refer to miles.
Measure your heart rate if desired.
Note: If you
use the
handgrip
pulse sensor
and the op-
tional chest
pulse sensor
at the same
time, the
console will not display your heart rate accurately.
Before using the handgrip pulse sensor, remove
the clear plastic film from the metal contacts. In
addition, make sure that your hands are clean.
To measure your heart rate, stand on the foot
rails and hold the metal contacts on the
handrail—avoid moving your hands.When your
pulse is detected, the heart symbol in the right side
of the display will appear, one or two dashes will
appear, and then your heart rate will be shown.
For the most accurate heart rate reading, con-
tinue to hold the contacts for about 15 sec-
onds.
Turn on the fan if desired.
To turn on the fan at low speed, press the Cool
Breeze Fan button. To turn on the fan at high
speed, press the button a second time. To turn off
the fan, press the button a third time. Note: If the
fan is left on when the walking belt is stopped, the
fan will automatically turn off after a few minutes.
When you are finished exercising, remove the
key.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
setting. The incline must be at the lowest setting
when the treadmill is folded to the storage posi-
tion or the treadmill will be damaged. Next, re-
move the key from the console and put it in a se-
cure place. Note: If the display remains lit after
the key is removed, the console is in the
“demo” mode. See page 19 and turn off the
demo mode.
When you are finished using the treadmill,
switch the reset/off circuit breaker to the off
position and unplug the power cord.
9
8
76
Contacts
Track

16
HOW TO USE A PRESET PROGRAM
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
14.
Enter your weight if desired.
See step 2 on page 14.
Select one of the preset programs.
To select
one of the
preset pro-
grams, press
the P5, P6,
P7, or P8
button. After
each preset
program is
selected, the maximum speed setting of the pro-
gram and the maximum incline setting of the pro-
gram will flash in the display for a few seconds.
The display will also show how long the program
will last. The matrix in the lower part of the display
will show the first seven speed settings of the pro-
gram.
Press the Start button or the Quick Speed in-
crease button to start the program.
Amoment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings for the program. Hold the handrails
and begin walking.
Each program is divided into 30 one-minute seg-
ments. One speed setting and one incline setting
are programmed for each segment. Note: The
same speed setting and/or incline setting may be
programmed for two or more consecutive seg-
ments.
The speed
setting for
the first seg-
ment will be
shown in the
flashing
Current
Segment column of the matrix in the lower part of
the display. (The incline settings are not shown in
the matrix.) The speed settings for the next four
segments will be shown in the columns to the
right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. If the speed and/or in-
cline of the treadmill is about to change, the speed
setting and/or the incline setting will flash in the
display to alert you.
When the first segment is completed,
all speed
settings will move one column to the left .The
speed setting for the second segment will then be
shown in the flashing Current Segment column
and the treadmill will automatically adjust to the
speed and incline settings for the second seg-
ment. Note: If all five of the indicators in the
Current Segment column are lit,
the speed settings
may move downward
so that only the highest indi-
cators appear in the matrix.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column and the last segment
ends. The walking belt will then slow to a stop.
If the speed or incline setting for the current
segment is too high or too low, you can manually
override the setting by pressing the Quick Speed
or Power Incline buttons. Every few times a Quick
Speed button is pressed, an additional indicator
will appear or disappear in the Current Segment
column; if any of the columns to the right of the
Current Segment column have the same number
of lit indicators as the Current Segment column,
an additional indicator may appear or disappear in
those columns as well. Important: When the cur-
rent segment of the program ends, the tread-
mill will automatically adjust to the speed and
incline settings for the next segment.
To stop the program at any time, press the Stop
button. The time will begin to flash in the display.
To restart the program, press the Start button or
the Quick Speed increase button. The walking belt
will begin to move at 1 mph. When the next seg-
ment of the program begins, the treadmill will auto-
matically adjust to the speed and incline settings
for the next segment.
4
3
2
1
Current Segment

17
Follow your progress with the display.
See step 6 on page 15.
Measure your heart rate if desired.
See step 7 on page 15.
Turn on the fan if desired.
See step 8 on page 15.
When you are finished exercising, remove the
key from the console.
When the program has ended, make sure that
the incline of the treadmill is at the lowest set-
ting. Next, remove the key from the console and
put it in a safe place. Note: If the display remains
lit after the key is removed, the console is in
the “demo” mode. See page 19 and turn off the
demo mode.
When you are finished using the treadmill,
switch the reset/off circuit breaker to the “off”
position and unplug the power cord.
HOW TO USE A CALORIE PROGRAM
Insert the key into the console.
See HOW TO TURN ON THE POWER on page
14.
Enter your weight.
See step 2 on page 14. Note: Always enter your
weight before using a calorie program; the
speed and incline settings of the program will
depend on the weight setting that you enter.
Select a calorie program.
To select a
calorie pro-
gram, press
the P1, P2,
P3, or P4
button. After
each calorie
program is
selected, the
maximum speed setting of the program and the
maximum incline setting of the program will flash
in the display for a few seconds. The display will
also show how long the program will last. The ma-
trix in the lower part of the display will show the
first seven speed settings of the program.
Press the Start button to start the program.
Amoment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each program is divided into 30, 35, 40, or 45
one-minute segments. One speed setting and one
incline setting are programmed for each segment.
Note: The same speed setting and/or incline setting
may be programmed for two or more consecutive
segments.
The speed
setting for
the first seg-
ment will be
shown in the
flashing
Current
Segment column of the matrix. (The incline set-
tings are not shown in the matrix.) The speed set-
tings for the next four segmentswill be shown in
the columns to the right.
4
3
2
1
8
7
6
5
Current Segment

18
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. If the speed and/or in-
cline of the treadmill is about to change, the speed
setting and/or the incline setting will flash in the
display to alert you.
When the first segment is completed, all speed
settings will move one column to the left .The
speed setting for the second segment will then be
shown in the flashing Current Segment column
and the treadmill will automatically adjust to the
speed and incline settings for the second seg-
ment. Note: If all five of the indicators in the
Current Segment column are lit, the speed settings
may move downward so that only the highest indi-
cators appear in the matrix.
If the speed or incline setting for the current seg-
ment is too high or too low, you can manually
override the setting by pressing the Speed and
Incline buttons. Every few times a Speed button is
pressed, an additional indicator will appear or dis-
appear in the Current Segment column.
Important: When the current segment of the
program ends, the treadmill will automatically
adjust to the speed and incline settings for the
next segment.
To stop the program at any time, press the Stop
button. To restart the program, press the Start but-
ton or the Quick Speed increase button. The walk-
ing belt will begin to move at 1 mph. When the next
segment of the program begins, the treadmill will
automatically adjust to the speed and incline set-
tings for that segment.
The program will continue in this way until the last
segment of the program ends. The walking belt
will then slow to a stop. Important: The calorie
goal is an estimate of the number of calories
that you will burn during the program. The ac-
tual number of calories that you burn will de-
pend on your weight. In addition, if you manu-
ally change the speed or incline of treadmill
during the program, the number of calories
you burn will be affected.
Follow your progress with the display.
See step 6 on page 15.
Measure your heart rate if desired.
See step 7 on page 15.
Turn on the fan if desired.
See step 8 on page 15.
When you are finished exercising, remove the
key from the console.
See step 8 on page 17.
8
7
6
5

19
THE INFORMATION MODE/DEMO MODE
The console features an information mode that keeps
track of the total number of hours that the treadmill has
been operated and the total number of miles that the
walking belt has moved. The information mode also al-
lows you to select miles or kilometers as the unit of
measurement and to turn on and turn off the demo
mode.
To select the information mode, hold down the Stop
button while inserting the key into the console. When
the information mode is selected, the following informa-
tion will be shown in the display:
The left side of the display
will show the total number of
miles (or kilometers) that the
walking belt has moved and
the total number of hours
that the treadmill has been
used. An “E” for English miles or an “M” for metric kilo-
meters will appear in the right side of the display. Press
the Quick Speed increase button to change the unit of
measurement.
IMPORTANT: If a “d” appears in the right side of the
display, the console is in the “demo” mode. This mode
is intended to be used only when a treadmill is dis-
played in a store. When the console is in the demo
mode, the power cord can be plugged in, the key can
be removed from the console, and the indicators in the
display will automatically appear in a preset sequence,
although the buttons on the console will not operate. If a
“d” appears when the information mode is selected,
press the Quick Speed decrease button so the “d”
disappears.
To exit the information mode, remove the key from the
console.
THE OPTIONAL CHEST PULSE SENSOR
Anoptional chest pulse sensor adds even more fea-
tures to the console. The chest pulse sensor offers
hands-free operation, and enables you to use the con-
sole’s two heart rate programs. To purchase the op-
tional chest pulse sensor, call the toll-free tele-
phone number on the front cover of this manual.
Miles Hours

20
HOW TO FOLD AND MOVE THE TREADMILL
HOW TO FOLD THE TREADMILL FOR STORAGE
Before folding the treadmill, adjust the incline to the
lowest position. If this is not done, the treadmill may be per-
manently damaged. Next, unplug the power cord. CAUTION:
You must be able to safely lift 45 pounds (20 kg) to raise,
lower, or move the treadmill.
1. Hold the metal frame firmly in the location shown by the
arrow at the right. CAUTION: To decrease the possibility
of injury, do not lift the frame by the plastic foot rails.
Make sure to bend your legs and keep your back straight.
As you raise the frame, make sure to lift with your legs
rather than with your back. Raise the frame about halfway
to the vertical position.
2. Move your right hand to the position shown and hold the
treadmill firmly. Using your left hand, pull the latch knob to
the left and hold it. Raise the frame until the latch pin is
aligned with the hole in the center of the cushion. Slowly re-
lease the latch knob. Make sure that the latch pin is fully
inserted in the hole in the center of the cushion.
To protect the floor or carpet from damage, place a mat
under the treadmill. Keep the treadmill out of direct sun-
light. Do not leave the treadmill in the storage position in
temperatures above 85° Fahrenheit.
HOW TO MOVE THE TREADMILL
Before moving the treadmill, convert the treadmill to the storage
position as described above. Make sure that the latch pin is
fully inserted in the hole in the center of the cushion.
1. Hold the upper ends of the handrails. Place one foot against
one of the wheels.
2. Tilt the treadmill backward until it rolls freely on the front
wheels. Carefully move the treadmill to the desired location.
To reduce the risk of injury, use extreme caution while
moving the treadmill. Do not move the treadmill over an
uneven surface.
3. Place one foot against one of the wheels, and carefully lower
the treadmill until it is resting in the storage position.
Engaged
Cushion
Latch
Knob
Latch Pin
Wheel
Handrail
Frame
