PROAIM CT-VNGD-CS4 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Vanguard cart for C-stand CS4
(CT-VNGD-CS4)
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
4 x Rods
Cart Tray 2 x Spanner Size: (19 & 13)
4 x Bolts & 5mm Allen Key
Vanguard cart for C-stand CS4
2 x Pneumac Wheels

2
FUNCTION
For Comfortable Handling & Can
maintain a secure and comfortable grip.
Rubber Hand Grips
For Damage-Free Stand
Mounng & Scratches and
damages can be avoided.
So Carpet Lining
Eliminate the hassle of
transportaon with rear
wheels.
Pneumac Wheels
Designed to safely carry up to
10 stands at once.
Rods
For Stand Mounng
Tray
A unique holding plate with 10
holes for c-stand extensions.
Hole

3
Vanguard Cart for C-Stand Setup
• To attach the Vanguard cart to the tray, first
remove the bolt by loosening the nut.
• To properly attach the Vanguard cart to the
tray, match and insert the bolts from the
bottom, as shown in the image.
• After inserting the bolt, tighten it and secure it
using the spanner.
• To attach the pneumatic wheel, remove the
bolts and washers from the wheel using the
spanner.
• Now, insert the wheel in the rod and repeat
the same process for the second wheel.
• After attaching the wheels, insert back the
bolts and washers to completely secure the
wheels.

4
• After attaching the wheels, secure them using
the spanner.
NOTE: Enjoy hassle free transportation with
pneumatic rear wheels that provide incredibly
smooth movement.
• To remove the bolt from the rod, use an Allen
key.
• To insert the rod in the Vanguard Cart, tighten
it by twisting them around, as shown in the
image.
• Repeat the same process for the remaining
three rods.
• After inserting the bolts, tighten them using
the Allen key.
Feature: It features a unique holding plate with
ten holes for c-stand extensions.
• After inserting all four rods, insert bolts from
the backside of the cart, as shown in the
image.
Feature: With its non-slip rubber hand grips, you
can maintain a secure and comfortable grip.
• All rods are securely inserted on the Vanguard
cart for C-Stand.

5
• Loosen the knob of the 360° Rotatable Grip
Clamp (Not Included).
• Hang the C-Stand on the rod and insert the
clamp.
Feature: Effortlessly carry C-stands around the
set with Vanguard cart for C-stand, designed to
simultaneously maneuver up to 10 stands.
• The Vanguard Cart can hold up to 10 C-stands
with extra protection using the Grip Clamp
(Not Included).
NOTE: It has a 360-degree locking design with
12mm or 16mm holes that allow you to mount
your equipment in variable positions.
• The image shows 10 C-Stands securely hung
on the Vanguard Cart.
YOUR PROAIM VANGUARD CART FOR C-STAND CS4
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
