PROAIRA PFHV18B User manual

Features:
• Wide Area Oscillation
• ON/OFF Switch with 3 Speed Settings
• High Performance Blade
• Adjustable Height
• Large Stable Base
• Safety Grilles
• 120V A.C. / 60Hz
18" High Velocity
Oscillating Pedestal Fan
Item: PFHV18B

2
2
INTENDED USE:
or other commercial applications. Use only with electrical wiring
that is in good working order and that meets applicable codes
and ordinances. If you have any questions whether your wiring is
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word "WARNING" to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
IMPORTANT INSTRUCTIONS
As with all electrical appliances, basic safety precautions should
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non-combustible, level surface.
• Always unplug fan when not in use, when moving from place
to place, when assembling or disassembling parts, and before
cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non-window models).
• Do not operate the fan with blade guards or any safety device
removed.
extension cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with
area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
READ & SAVE THESE
INSTRUCTIONS !
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
block air intakes or exhaust in any manner. Do not insert or allow
foreign objects to enter any ventilation or exhaust opening as this
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, do not use this product with any
solid-state speed control device.
WARNING: PREVENT ELECTRIC SHOCK
This product has a cord with 3-prong grounding-type plug
-slot grounded receptacle (A2). DO NOT
remove the grounding prong (A1) if only a 2-slot receptacle (B)
is available.
For connecting 3-prong grounding-type plug to 2-slot
receptacle, use an ADAPTER (C). The grounding lug (C1)
extending from the adapter must be connected to a permanent
ground with the Metal Screw (D) such as a properly grounded
outlet box (E).
The adapter should not be used if a 3-slot grounded receptacle
is available.
DO NOT DEFEAT THE SAFETY PURPOSE OF EITHER
A GROUNDED PRONG OR A GROUNDING LUG.
Adapter is not included
(A)
(A1)
(A)2 (B)
(D)
(C1)
(C) (E)
Item: PFHV18B

3
3
USAGE:
Fan Operation: Always operate the fan in the upright position
following all instructions and recommendations listed in this
manual.
Fan Location: Place the fan in the area of the room that will
provide proper fan cooling.
Fan Connection: Plug fan directly into 120 volt A.C., 60 Hz
may cause overheating and damage to the plug or fan.
Note: To prevent overloading a circuit, do not plug the fan into a
circuit that is servicing other electrical needs.
Turning Fan On/Off: Place fan on stable level surface. Plug
fan into proper grounded outlet. To start the fan, rotate Control
Dial from “0” (OFF) to desired fan speed (1, 2 or 3). Rotate top
Control Dial again to “0” (OFF) position to discontinue use.
Unplug fan when not in use.
Oscillation: To start fan oscillation, press Oscillation Control
Knob (located above motor housing) down. To stop oscillation
function pull Oscillation Control Knob up while the fan is in any
oscillation position.
Fan Assembly: Simple assembly is required to use this fan.
Step 3
Step 5
Step 7
Step 9
Step 4
Step 6
Step 8
Step 10
Step 1 Step 2
Assemble Extension Pole onto
Base by inserting 4 ea. 2-1/2"
bolts through openings.
Place decorative Chrome
Flange over Extension Pole to
cover the base screws.
Attach Front Grille to Rear
Grille with Hook Clip centered
on the top above Wire Handle.
Assemble Rear Grille onto
Motor Housing using screws
removed in Step 6. Tighten the
4 screws securely.
Take Fan Motor Housing and
insert it into Extension Pole
and tighten set screw securely.
Using washers and nuts
supplied, tighten Extension
Pole to Base as shown.
Thread Extension Pole Nut
onto threads of Extension Pole.
Press remaining Grille Clips
onto Rear Grille to securely
attach Front Grille. Do not
operate fan without Grille
in place.
Place Fan Blade onto Motor
on Motor Shaft. Tighten
surface on Motor Shaft.
Remove four mounting screws
from Motor Housing where
indicated to use for Rear Grille
in Step 7.
Set
Screw
Set
Screw
Flat
Surface
Wire
Handle
on Top
Hook Clip
DO NOT operate any fan with a damaged cord or plug or after
fan malfunctions, has been dropped or damaged in any manner.
Do not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact Comfort Zone®Customer Service by telephone or
mail for information and assistance.
DO NOT run power cord under carpeting. Do not cover cord with
area where it will not be tripped over. Avoid the use of extension
the cord must be minimum 14 AWG and rated not less than
1875 watts. Do not use an extension cord unless the plug can be
completely inserted into its receptacle. Unplug the fan when not
in use. Do not operate fan with its ventilation obstructed.

4
4
4
4
Care and Maintenance:
Cleaning: CAUTION-Before cleaning the fan, be sure to unplug
the power cord from the outlet. Clean the grille surface
with a clean damp cloth. Do not use harsh chemical or abrasive
cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES IN
WATER. Replace front grille before fan use. Allow fan to dry
completely before use. Periodic grille cleaning with a vacuum will
prevent dust build up. The motor is sealed and does not require
any interior maintenance, cleaning or lubrication.
Maintenance: The Internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN
PLACE. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR
BECOME DAMAGED IN ANY WAY.
Storage: Keep original carton for storage of the fan. Coil and tie
the power cord to avoid damage during storage.
Note:Some models come with a plug where you can replace
a fuse. If your model has this, please read and follow the below
instructions to replace the fuse.
This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the
user servicing instructions (follow product marking for proper
fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for
examination and/or repair.
Fuse Replacement:
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on top of
attachment plug towards blades. See Fig. 2.
3. Remove fuse carefully. Use a small tool to pry the end of the
fuse from holder cavity. Be careful not to break glass window.
4.
identical 2.5 or 5.0 Amp, 125 Volt fuse (3.6mm x 10mm).
Be sure fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
Fig 1 Fig 2 Fig 3
Slide Cover to Open
