PROAIRA BP2-9A User manual

Features:
•Three Fan Functions:
COOL - Brings fresh air in
EXHAUST - Removes stale air from room
CIRCULATE - Operates fans opposing directions creating
air circulation and room ventilation
•Push Button «ON» Switch with Speed Settings: LOW, MEDIUM, HIGH
•Long Distance Full Function Remote Control
(requires 2 AAA batteries - batteries not included)
•Adjustable Accordion Extensions Expand from 23-1/2" to 37"
•Rust Resistant Construction
•Poly Fan Blades Designed for Maximum Air Movement
•Safety Grilles
•120V A.C. / 60Hz
9” Twin Window Fan
with Full Function Remote Control
Item: WNF9RW
Model: BP2-9A

2
2
INTENDED USE:
not for industrial or other commercial applications. Use only with
electrical wiring that is in good working order and that meets
applicable codes and ordinances. If you have any questions
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word "WARNING" to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
IMPORTANT INSTRUCTIONS:
As with all electrical appliances, basic safety precautions should
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non-combustible, level surface.
• Always unplug fan when not in use, when moving from place
to place, when assembling or disassembling parts, and before
cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non-window models).
• Do not operate the fan with blade guards or any safety device
removed.
extension cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with
area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
READ & SAVE THESE
INSTRUCTIONS!
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
or exhaust in any manner. Do not insert or allow foreign objects
to enter any ventilation or exhaust opening as this may cause an
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code.
CAUTION: TO PREVENT ELECTRIC SHOCK,
this product has a polarized two prong plug (one blade is wider
than the other) that must be fully inserted in to a matching
electrician. Do not attempt to defeat this safety feature.
CAUTION: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, do not use this product with any
solid-state speed control device.
DO NOT operate any fan with a damaged cord or plug or after
fan malfunctions, has been dropped or damaged in any manner.
Do not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact Comfort Zone®Customer Service by telephone or
mail for information and assistance.
DO NOT run power cord under carpeting. Do not cover cord
with throw rugs, runners or the like. Arrange cord away from
be used, the cord must be minimum 14 AWG and rated not
less then 1875 watts. Do not use an extension cord unless the
plug can be completely inserted into its receptacle. Unplug
the fan when not in use. Do not operate fan with its ventilation
obstructed.
Item: WNF9RW
Model: BP2-9A

3
3
ASSEMBLY INSTRUCTIONS
Simple assembly is required to use this fan on a
Locate slot on the base of fan. Align screw holes of base leg
and fan and attach base leg, be sure base leg is snapped in and
secured in slot (See Fig. 1). Use supplied screw to secure the
base leg to the fan (See Fig. 2). Repeat for the opposite side.
Note: Base legs should not be installed when secured inside a
window as described below.
Installation for Double Hung Window:
It is recommended that window screens be left in place. Legs
should not be installed when mounting in window.
1. Locate Slot behind Control Panel, remember it for future use.
2. With fan centered in window unlock Clips to Accordion Panels
Panels in place by closing the Clips on the top and bottom of
Accordion Panels (See Fig. 3).
3. Lower window into Slot behind Control Panel mentioned.
Fig 3
Pull Clip Up to Unlock
Pull Accordion Panel Out
Pull Clip Down to Unlock
Fig 1 Fig 2
Slot
Screw
Hole
Screw
Hole
CAUTION: TO REDUCE THE RISK OF FIRE AND TO
PROPERLY EXHAUST AIR, be sure to duct air outside.
Do not vent exhaust air into spaces within walls or ceilings
or into attics, crawl spaces, or garages.
FAN OPERATIONCONTROLS
This fan comes with the commands of the control/functions
panels and remote control expressed in two ways: WORDS
(Fig. 6) or SYMBOLS (Fig. 7).
USAGE
Fan Operation: Always operate the fan in the upright position
following all instructions and recommendations listed in this
manual.
Fan Location: Place the fan in the area of the room that will
provide proper fan cooling. This fan can be placed in a window
to provide additional FRESH air from outside. In this location, the
fan can also be used to push inside air to the outside using the
EXHAUST position.
Fan Connection: Plug fan directly into 120 volt A.C., 60 Hz wall
cause overheating and damage to the plug or fan.
Note: To prevent overloading a circuit, do not plug the fan into a
circuit that is servicing other electrical needs.
FAN SPEED CONTROL PANEL
AIR DIRECTION CONTROL PANEL
Fig. 6
Fig. 7
FAN SPEED CONTROL PANEL
AIR DIRECTION CONTROL PANEL

4
4
FAN SPEED CONTROL PANEL
with WORDS
with SYMBOLS
Speed Indicator Lights
ON/Speed
Button
OFF
Button
Fig. 8
ON/Speed
Button
OFF
Button
Speed Indicator Lights
Turning Fan On and Off: (See Fig. 8)
To start the fan, press
1
2
3
the «ON/SPEED» button repeatedly
for the speed settings: 1 – LOW, 2 – MEDIUM, 3 – HIGH .
To stop the fan,
press the «OFF» button.
Fan Functions: (See Fig. 9). This fan has three functions for
maximum comfort. To switch between functions, press function
control button repeatedly.
COOL - Brings fresh air in.
EXHAUST - Removes stale air from room.
CIRCULATE - Operates fans in opposing directions
creating air circulation and room ventilation.
AIR DIRECTION CONTROL PANEL
Function Control Button
Function Indicator Lights
Function Indicator Lights
Fig. 9
with WORDS with SYMBOLS
If you have the fan with comands in words, see the
column «Word» in the table below. If you have the fan
with comands in symbols, see the column «Symbol».
Symbol Word Description of
Function
ON/SPEED
button
ON switch with
speed settings:
1-Low, 2-Med,
3-High
OFF
button
Shuts fan off
LOW
indicator light
Fan speed is on
LOW
MEDIUM
indicator light
Fan speed is on
MEDIUM
HIGH
indicator light
Fan speed is on
HIGH
COOL
indicator light
Brings fresh air in
EXHAUST
indicator light
Removes stale air
from the room
CIRCULATE
indicator light
Operates fans in
opposing directions for
air circulation and room
ventilation
Fan Push Buttons and Indicator Lights

5
5
If you have the fan with comands in words, see the
column «Word» in the table below. If you have the fan
with comands in symbols, see the column «Symbol».
Place 2 « AAA » size batteries in the remote control (Batteries are
not included). Point the remote control towards the control panel
for the sensor to receive a signal. Use the buttons on the remote
as you would with the control panel.
WARNING: Do not mix old and new batteries.
Do not mix standard (Carbon-Zinc), alkaline, or rechargeable
(Ni-Cd, Ni-MH, etc.) batteries. Used batteries should be disposed
through local recycling centers.
FULL FUNCTION REMOTECONTROL
ON/OFF
Switch
Speed Button
1 – Low,
2 – Medium,
3 – HIGH
Air Direction Button
Cool
Exhaust
Circulate
with
WORDS
with
SYMBOLS
Symbol Word Description of
Function
POWER
button
Turns fan
ON/OFF
SPEED
button
Speed settings:
1-Low,
2-Med,
3-High
Works in the same way
as a push button on
the fan.
Pushing the button
repeatedly changes the
fan speed.
COOL
EXHAUST
CIRCULATE
Works in the same way
as a push button on
the fan.
Pushing the button
repeatedly changes the
air direction.
Remote Control Push Buttons
Fig 1
Slide Cover to Open
Fig 2 Fig 3
CARE AND MAINTENANCE:
Cleaning: CAUTION-Before cleaning the fan be sure to
disconnect power cord from the plug. Clean the grille surface
with a clean damp cloth. Do not use harsh chemical or abrasive
cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES IN
WATER. Allow fan to dry completely before use. Periodic grille
cleaning with a vacuum will prevent dust build up. The motor is
sealed and does not require any interior maintenance, cleaning
or lubrication.
Maintenance: The Internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN
PLACE. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR
BECOME DAMAGED IN ANY WAY.
Storage: Keep original carton for storage of the fan. Coil and tie
the power cord to avoid damage during storage.
Note:Some models come with a plug where you can replace
a fuse. If your model has this, please read and follow the below
instructions to replace the fuse.
This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the
user servicing instructions (follow product marking for proper
fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for
examination and/or repair.
Fuse Replacement:
1. Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on
top of attachment plug towards blades. See Fig. 2
3. Remove fuse carefully. Use a small tool to pry the end
of the fuse from holder cavity. Be careful not to break
glass window.
4. Replace fuse.
WARNING:
2.5 or 5.0 Amp, 125 Volt fuse (3.6mm x 10mm). Be sure
fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
