Procentec ComBricks User manual

User Manual

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 2/219
User Manual ComBricks
Monitoring, Networking and Control
PROFIBUS data hub for repeaters and fiber optic modules
Transparent for all PROFIBUS DP protocols
ProfiTrace for monitoring 4 networks
Drives 32 modules (10 communication modules)
Hot swap
Powerful web server
100 Mbps Ethernet
12 Mbps PROFIBUS
DIN-rail
IP 20

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 3/219
Safety Guidelines
This manual contains notices which you should observe to ensure your own personal safety, as well as to
protect the product and connected equipment. These notices are highlighted in the manual by a warning sign
and are marked as follows according to the level of danger:
Draws your attention to important information on handling the product, a particular part of the
documentation or the correct functioning of the product.
Warning
This device and its components may only be used for the applications described in this manual and only in
connection with devices or components that comply with PROFIBUS and RS-485 interface.
This product can only function correctly and safely if it is transported, stored, set up, installed, operated and
maintained as recommended. ComBricks is a CE class A product. In a domestic environment it may cause radio
interference in which case the user may be required to take adequate measures.
Warranty
Warranty is void if you open ComBricks.
Qualified Technicians
Only qualified technicians should be allowed to install and work with this equipment. Qualified technicians are
defined as persons who are authorized to commission, to ground, to tag circuits and systems in accordance
with established safety practices and standards. It is recommended that the technicians carry a Certified
PROFIBUS Installer or Certified PROFIBUS Engineer certificate.
Disclaimer of Liability
We have checked the contents of this manual as much as possible. Since deviations cannot be precluded
entirely, we cannot guarantee full agreement. However, the content in this manual is reviewed regularly and
necessary corrections will be included in subsequent editions. Suggestions for improvements are welcome.
Copyright © 2017 PROCENTEC
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted,
in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior
written permission of the publisher.
ComBricks is a registered trademark of PROCENTEC. Other products or company names are or may be
registered trademarks and are the property of their respective companies.


ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 4/219
Important information
Purpose of the Manual
This user manual provides information how to work with ComBricks.
Recycling and Disposal
The parts of the ComBricks can be recycled. For further information about environment-friendly recycling and
the procedure for disposing of your old equipment, please contact:
Document Updates
You can obtain constantly updated information on PROCENTEC products on the Internet at
www.procentec.com
You can also contact PROCENTEC Customer Support:
•by phone at [phone]
•by fax at [phone]
•by email at [e-mail]
PROCENTEC
Klopperman 16
2292 JD WATERINGEN
The Netherlands
Tel.: [phone]
Fax: [phone]
Email: [e-mail]

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 5/219
Contents
Important information........................................................................................... 4
1Product description........................................................................................ 10
1.1 Introduction.................................................................................................................................... 10
1.2 Application areas ............................................................................................................................ 10
1.3 Product features............................................................................................................................. 10
1.4 Modular PROFIBUS repeaters......................................................................................................... 11
1.4.1 Cable Redundancy .......................................................................................................................... 12
1.4.2 Comparison between ProfiHub and ComBricks ............................................................................. 13
1.4.3 Typical applications ........................................................................................................................ 13
1.5 ProfiTrace OE - Remote monitoring in a web browser................................................................... 14
1.5.1 Web server ..................................................................................................................................... 14
1.5.2 Email ............................................................................................................................................... 15
1.5.3 Channel List .................................................................................................................................... 15
1.5.4 Comparison between ComBricks and ProfiTrace 2 ........................................................................ 15
1.5.5 Offshore applications ..................................................................................................................... 16
1.5.6 Mining applications ........................................................................................................................ 16
1.5.7 Robot cells ...................................................................................................................................... 17
1.5.8 Logistics .......................................................................................................................................... 17
1.5.9 Traffic control ................................................................................................................................. 18
1.5.10 Cranes............................................................................................................................................. 18
1.5.11 Other applications .......................................................................................................................... 19
1.6 Output control................................................................................................................................ 19
1.7 CommDTM...................................................................................................................................... 20
2Quick start ......................................................................................................21
2.1 Quick start checklist........................................................................................................................ 21
2.2Prepare the backplane.................................................................................................................... 22
2.3 Insert modules................................................................................................................................ 22
2.4 Configure the repeater modules .................................................................................................... 22
2.5 Wire the repeater modules ............................................................................................................ 22
2.6 Power the Head Station.................................................................................................................. 22
2.7 Customizing the IP number through the web server ..................................................................... 22
2.8 Customizing the IP number through the Discovery Tool................................................................ 24
2.9 Checking the modules and the administrative info in the web server........................................... 25
2.10 Testing ProfiTrace OE on the PROFIBUS installation ...................................................................... 26
2.11 Resetting the Head Station............................................................................................................. 27
3Installation instructions..................................................................................28
3.1 Location .......................................................................................................................................... 28
3.2 Position........................................................................................................................................... 28
3.3 Mounting and un-mounting backplane units................................................................................. 28
3.4 Adding backplane units .................................................................................................................. 29
3.5 Detaching backplane units ............................................................................................................. 30
3.6 Inserting modules ........................................................................................................................... 31
3.7 Removing modules ......................................................................................................................... 31
3.8 Wiring Ethernet .............................................................................................................................. 32
3.9 Power Supply.................................................................................................................................. 34
3.9.1 Procedure ....................................................................................................................................... 34
3.9.2 Testing and commissioning ............................................................................................................ 34
3.10 Configuring repeater modules........................................................................................................ 36
3.10.1 Customizing the PROFIBUS network (NW0/NW1) ......................................................................... 36
3.10.2 Redundancy (RED) .......................................................................................................................... 36
3.10.3 Hardware or software settings (H/S).............................................................................................. 37
3.11 Wiring repeater modules................................................................................................................ 38

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 6/219
3.11.1 Screw terminals .............................................................................................................................. 39
3.11.2 DB9 connector ................................................................................................................................ 40
3.11.3 Testing and commissioning ............................................................................................................ 40
4Web server ..................................................................................................... 41
4.1 Status.............................................................................................................................................. 42
4.2 Channel list ..................................................................................................................................... 44
4.3 System log ...................................................................................................................................... 45
4.4 General configuration..................................................................................................................... 46
4.5 Network configuration ................................................................................................................... 47
4.6 IP Configuration.............................................................................................................................. 48
4.6.1 Server port configuration ............................................................................................................... 48
4.7 Output Control ............................................................................................................................... 49
4.8 Password setup and login............................................................................................................... 50
4.8.1 Access rights ................................................................................................................................... 50
4.8.2 Password best practice................................................................................................................... 51
4.8.3 External protocols........................................................................................................................... 52
4.8.4 Clearing password(s) ...................................................................................................................... 52
4.9 License update................................................................................................................................ 53
4.10 Document download page ............................................................................................................. 54
4.11 Email account config....................................................................................................................... 55
4.11.1 Alive email ...................................................................................................................................... 56
4.11.2 Email Troubleshooting.................................................................................................................... 57
4.12 Device Management....................................................................................................................... 57
4.12.1 Backup settings to SD-Card............................................................................................................. 58
4.12.2 Restore settings from SD-Card ....................................................................................................... 58
4.12.3 Restore settings to factory defaults ............................................................................................... 58
4.12.4 Clear all data................................................................................................................................... 58
4.12.5 Restart the device........................................................................................................................... 58
5ProfiTrace OE..................................................................................................59
5.1 Live List ........................................................................................................................................... 59
5.1.1 Updating the GSD file library .......................................................................................................... 60
5.2 Statistics.......................................................................................................................................... 61
5.3 Message recording ......................................................................................................................... 62
5.4 Event configuration ........................................................................................................................ 63
5.5 Tag name configuration.................................................................................................................. 64
5.6 Oscilloscope images........................................................................................................................ 66
5.6.1 Oscilloscope Configuration............................................................................................................. 67
5.6.2 Oscilloscope Images ....................................................................................................................... 68
5.6.3 Oscilloscope errors ......................................................................................................................... 68
5.7 Bar graph ........................................................................................................................................ 70
5.8 Streaming with ProfiTrace 2 ........................................................................................................... 70
5.9 Summary of Statistics and Events................................................................................................... 73
6Head Station 1A/1B/1C .................................................................................. 75
6.1 Overview......................................................................................................................................... 75
6.2 Relay contact .................................................................................................................................. 76
6.3 SD card............................................................................................................................................ 76
6.3.1 Inserting/replacing the SD card ...................................................................................................... 76
6.3.2 Life cycle of the SD card.................................................................................................................. 77
6.3.3 Directories and files........................................................................................................................ 77
6.4 Audio jack ....................................................................................................................................... 78
6.5 Switch navigation of the Head Station 1A/1B/1C........................................................................... 79
6.6 LEDs on the Head Station ............................................................................................................... 80
7Repeater modules (RS-485) ...........................................................................82
7.1 Multiple channels per module........................................................................................................ 83

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 7/219
7.2 Channel structure ........................................................................................................................... 84
7.3 EMC barrier..................................................................................................................................... 85
7.4 Grounding system........................................................................................................................... 85
7.5 Baudrate detection......................................................................................................................... 85
7.6 PROFIBUS DP cable lengths ............................................................................................................ 85
7.7 PROFIBUS DP cable specifications .................................................................................................. 86
7.8 PROFIBUS DP cable types ............................................................................................................... 87
7.9 Redundancy .................................................................................................................................... 88
7.10 Mixing with other repeaters........................................................................................................... 89
7.11 LEDs of the repeater module.......................................................................................................... 90
8RS-485-IS Barrier module ............................................................................... 91
8.1 Compliancy and certificates ........................................................................................................... 92
8.2 Channel structure ........................................................................................................................... 93
8.3 Connecting the cable...................................................................................................................... 93
8.4 Grounding system........................................................................................................................... 93
8.5 Baudrate detection......................................................................................................................... 93
8.6 PROFIBUS DP cable lengths ............................................................................................................ 94
8.7 PROFIBUS DP cable specifications .................................................................................................. 94
8.8 LEDs and DIP switches of the repeater module.............................................................................. 95
8.9 Redundancy .................................................................................................................................... 95
9Fiber optic module (2FO-001)........................................................................ 96
9.1 Topologies ...................................................................................................................................... 96
9.1.1 Bus topology with ComBricks ......................................................................................................... 97
9.1.2 Star/Hub topology with ComBricks ................................................................................................ 97
9.2 Delay time....................................................................................................................................... 97
9.3 Baudrate detection......................................................................................................................... 98
9.4 Fiber optic modules in redundancy mode...................................................................................... 98
9.5 Use of FO modules in combination with other brands................................................................... 98
10 Fiber Optic Ring module (FOR-MM1 / SM1 / XM1) .......................................99
10.1 Topologies ...................................................................................................................................... 99
10.2 Delay time..................................................................................................................................... 100
10.3 Dipswitches................................................................................................................................... 102
10.4 LEDs .............................................................................................................................................. 103
10.5 Setting up Fiber Optic alarms ....................................................................................................... 103
11 PROFIBUS Slave Module PBS-001 ................................................................106
11.1 Status LEDs ................................................................................................................................... 106
11.1.1 RDY LED ........................................................................................................................................ 107
11.1.2 PROFIBUS LEDs ............................................................................................................................. 107
11.1.3 Dipswitches................................................................................................................................... 107
11.2 Quick Start checklist ..................................................................................................................... 109
11.3 Setting up the slave module ......................................................................................................... 109
11.3.1 Hardware addressing.................................................................................................................... 110
11.3.2 Software addressing ..................................................................................................................... 111
11.4 Remote I/O mode ......................................................................................................................... 112
11.4.1 Strict Check Configuration ............................................................................................................ 114
11.4.2 Failsafe behaviour of outputs....................................................................................................... 114
11.4.3 Input test patterns........................................................................................................................ 115
11.5 DP/DP coupling or Gateway mode ............................................................................................... 117
11.6 PROFIBUS / PROFINET gateway.................................................................................................... 118
11.7 Data consistency........................................................................................................................... 119
11.7.1 Consistency over 2 bytes .............................................................................................................. 120
11.7.2 Consistency over 4 bytes .............................................................................................................. 120
11.7.3 Consistency over 8 bytes .............................................................................................................. 121

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 8/219
12 PA Link/Coupler module...............................................................................122
12.1 Quick Start checklist ..................................................................................................................... 123
12.2 Monitoring mode.......................................................................................................................... 124
12.2.1 Module status............................................................................................................................... 124
12.2.2 PA oscilloscope images................................................................................................................. 125
12.2.3 PA Bar Graph ................................................................................................................................ 125
12.2.4 PA measurements......................................................................................................................... 126
12.2.5 Oscilloscope configuration ........................................................................................................... 127
12.3 Link mode (module firmware v2.10.1 and higher only) ............................................................... 128
12.3.1 Converting PA GSD files ................................................................................................................ 128
12.3.2 Link configuration –bus parameters............................................................................................ 128
12.4 Coupler mode ............................................................................................................................... 129
12.4.1 Bus Parameters............................................................................................................................. 129
12.5 Physical layer ................................................................................................................................ 130
12.5.1 Connecting a PA segment............................................................................................................. 130
12.5.2 Cable specifications ...................................................................................................................... 131
12.5.3 Spur lines ...................................................................................................................................... 133
12.5.4 Current consumption calculations................................................................................................ 133
12.5.5 Voltage at the end of the segment............................................................................................... 134
13 PROFINET Device PND-001...........................................................................135
13.1 Topologies .................................................................................................................................... 135
13.2 Status LEDs ................................................................................................................................... 136
13.2.1 RDY LED ........................................................................................................................................ 136
13.2.2 PROFINET LEDs ............................................................................................................................. 137
13.3 Quick Start checklist ..................................................................................................................... 138
13.4 Identification and name assignment ............................................................................................ 139
13.4.1 MAC address................................................................................................................................. 139
13.4.2 Assigning a custom name ............................................................................................................. 139
13.4.3 Assigning a pre-defined name ...................................................................................................... 140
13.5 Remote I/O mode ......................................................................................................................... 140
13.6 PN/PN coupling or Proxy mode .................................................................................................... 141
13.7 PROFINET / PROFIBUS proxy ........................................................................................................ 142
14 CommDTM ...................................................................................................144
14.1 Installing drivers, CommDTM and server ..................................................................................... 144
14.2 Setting up the PCD server............................................................................................................. 144
14.3 Using the CommDTM ................................................................................................................... 145
15 OPC...............................................................................................................148
15.1 Installing the OPC drivers ............................................................................................................. 148
15.2 Setting up a stream....................................................................................................................... 149
15.3 Selecting OPC tags ........................................................................................................................ 149
15.4 Activating the OPC server............................................................................................................. 150
16 SNMP............................................................................................................153
16.1 List of data items .......................................................................................................................... 153
16.2 Viewing the MIB file ..................................................................................................................... 154
17 Firmware updates ........................................................................................156
17.1 Updating the Head Station ........................................................................................................... 156
17.2 Updating modules ........................................................................................................................ 158
18 Tips and Tricks..............................................................................................159
18.1 Ident Number lookup ................................................................................................................... 159
18.2 Solution for secured email connections ....................................................................................... 159
18.3 IP address adjustment tool........................................................................................................... 159
18.4 Free Wi-Fi channel detector ......................................................................................................... 159

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 9/219
18.5 Some SNMP tools ......................................................................................................................... 159
19 Technical Data - ComBricks in general ......................................................... 160
20 Technical Data - Head Station 1A/1B/1C......................................................161
21 Technical Data - SCOPE Repeater (101-201210)..........................................163
22 Technical Data - 2 Channel Repeater (101-201102) ....................................165
23 Technical Data - 1 Channel Repeater (101-201101) ....................................167
24 Technical Data - Fiber Optic Module (101-201510).....................................169
25 Technical Data - Fiber Optic Ring MM1 (101-201530).................................171
26 Technical Data - Fiber Optic Ring SM1 (101-201531) ..................................173
27 Technical Data - Fiber Optic Ring XM1 (101-201532)..................................175
28 Technical Data - SALT Repeater (101-201710).............................................177
29 Technical Data - PA Module (101-201610) ..................................................179
30 Technical Data - 4 CH Relay Module (101-210210) .....................................181
31 Technical Data - 8 CH D-out Module (101-210110).....................................182
32 Technical Data - 8 CH D-in Module (101-210010) .......................................183
33 Technical Data –RS-485-IS Barrier (101-201410)........................................184
34 Technical Data - PROFIBUS Slave Module PBS-001......................................186
35 Technical Data - PROFINET Device PND001 .................................................188
36 Technical Data - 6A Power Module T1 (101-230010) ..................................190
37 Frequently asked questions / FAQ ...............................................................191
38 Products and spare parts .............................................................................194
39 Glossary........................................................................................................199
40 Revision history ............................................................................................204
41 Other PROCENTEC products.........................................................................205
42 Sales offices and distributors .......................................................................207
43 About PROCENTEC .......................................................................................212
44 Certificates ...................................................................................................213
45 Notes ............................................................................................................217

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 10/219
1Product description
1.1 Introduction
ComBricks™ - The first PROFIBUS and PROFINET-based
automation system that unites network components, permanent
monitoring with ProfiTrace and remote I/O.
ComBricks is a modular system that allows a mix of automation
components on a backplane. Repeater modules can be inserted
next to a PROFIBUS slave and at the same time, in a web browser
over Ethernet, the condition of the installation can be remotely
inspected with ProfiTrace OE.
1.2 Application areas
•Remote maintenance station with ProfiTrace OE
•Modular repeater backbone with hot swap
•Transparent data hub (repeaters, fiber optic, RS-485-IS, DP slave, PROFINET, etc.)
1.3 Product features
•Drives 32 modules (10 high-speed modules)
•Wide range of modules available
•Hot swap and extendible
•Powerful web server
•ProfiTrace OE for monitoring 4 networks
•Multi-language
•DIN-rail mounting
•IP 20

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 11/219
1.4 Modular PROFIBUS repeaters
The current trend in PROFIBUS projects is to use segmentation with repeaters, fiber optic and ProfiHubs to
bridge the common faults of the end-user concerning his cabling difficulties. ComBricks adds another important
element; the creation of modular and random repeater hubs which can be maintained remotely with a
permanent internal ProfiTrace (see Fig. 1).
ComBricks is based on a backplane which can hold up to 10 hot swap repeater modules. Each module has one
or two channels (so a total of max 20 galvanic isolated transparent segments). Every channel can handle 31
PROFIBUS stations and maximum 1200 m cable length (depends on the baudrate). Fig. 2 illustrates some
configurations.
Each channel has a fail-safe circuit which ensures that the remainder of the PROFIBUS network continues to
operate correctly and that the availability of the installation remains optimal.
The connection of the bus cable allows for a high degree of flexibility as the repeater modules contain both a 9-
pin and screw connector.
It is possible to dynamically exchange equipment during operation. ComBricks is ideal for flow meters, pH
analysers, actuators, drives and especially motor control centres that make use of drawer systems.
ProfiHubsStandard repeaters
- 1 Meter rule problems
- Termination problems
- Power supply overload
- Costs and installation time
- 5 fixed channels
- RS 485 only
- No asset management
- Single power supply
COMbricks
ProfiTraceOE
- Modular and hotswap
- ProfiTrace over Ethernet
- Bus redundancy
- DTM, OPC, SNMP, HTTP
Fig. 1 - Latest trend in segmentation

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 12/219
1.4.1 Cable Redundancy
The bus redundancy technology of the repeater modules is very advanced. A redundant system can be built
using 10 parallel cables. This architecture provides extremely high availability. Most suppliers only allow 2
cables (see Fig. 3).
redundant channels
Maximum 10 redundant channels
1 channel repeaters
2 segments
3 segments
Mix of 1 channel and
2 channel repeaters
2 segments
Maximum10 modules (2 channel repeaters)
20 segments
Fig. 2 - Repeater configuration examples
Fig. 3 - Redundancy configuration example

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 13/219
1.4.2 Comparison between ProfiHub and ComBricks
ProfiHub A5 and B5
(simple)
ComBricks
(flexible and high-tech)
•One component
•PROFIBUS
•RS-485 only
•Easy installation
•IP 65 version
•Low cost
•Modular
•Multi interface
•Multi network
•ProfiTrace OE
•Asset management
•Light weight
1.4.3 Typical applications
•Repeaters with permanent ProfiTrace
•Removable drives and motors
•Star, tree and bus structured networks
•Motor control centers (drawers)
•Redundancy for high availability
•EMC vulnerable applications
•Spur lines
•Isolator for sensitive devices

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 14/219
1.5 ProfiTrace OE - Remote monitoring in a web browser
Permanent and simultaneous monitoring of 4 PROFIBUS networks is a powerful feature of ComBricks. Global
projects and a shortage of (qualified) technical staff members are causing significant capacity problems.
ComBricks offers a solution by remotely monitoring PROFIBUS installations over the Internet and alerting the
user by email.
The user can simply connect surrounding PROFIBUS networks and every network can be set to a unique
baudrate. The modular technology of ComBricks enables the network to be monitored when multiple repeater
modules are installed. All transparent messages from the backplane are constantly analysed.
Up to 10 Repeater modules with 2 channels each (20 galvanic isolated segments in total) can be inserted into
the backplane. Using DIP switches or the web server, repeater modules can be assigned to a network group.
This ensures isolated communication from the repeaters which are assigned to other network groups; the
networks are not combined or connected in any way. Only the Head Station can see all networks groups.
1.5.1 Web server
A web server with a ProfiTrace shell visualizes the information in an understandable format (ProfiTrace OE).
Because of the web browser, additional software is NOT required and a constant connection with a PC to the
ComBricks is NOT necessary.
The monitoring and logging is performed by the repeater modules which are inserted in the backplane.
ComBricks is the first system that has integrated a busmonitor in network components. Deploying ComBricks
repeaters for regular automation means automatic availability of ProfiTrace OE.
Monitoring 4 networks
Monitoring 4 networks
Monitoring 4 networks
Worldwide access
to any COMbricks

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 15/219
1.5.2 Email
Email messages provide real-time alerts in the event of detected faults in the PROFIBUS communication. These
email alerts are easy to set up in the web server.
1.5.3 Channel List
A brand new functionality within ProfiTrace OE is the Channel List. It gives a detailed overview of all repeater
channels (segments) and all connected stations.
1.5.4 Comparison between ComBricks and ProfiTrace 2
The application area for ComBricks (ProfiTrace OE) compared to ProfiTrace 2 is completely different. ProfiTrace
OE should be seen as a watchdog and ProfiTrace 2 as the mobile analyzer to do on-site work.
ProfiTrace 2
(troubleshooting on-site)
ComBricks
(watchdog)
•USB (power supply)
•Mobile
•Software
•C1 Master
•Triggers and filters
•Large file recording
•Reporting
•Fast
•Ethernet / Internet
•Permanent installation
•Web server
•Multi network monitor
•Multi access
•Email and Log

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 16/219
1.5.5 Offshore applications
With satellite internet offshore PROFIBUS networks can be remotely monitored. Emails can inform the
mainland about the status of the installation.
These applications simplify maintenance and eliminate the hassle to fly an expert over to fix a possible
problem. On the LAN local technicians can also monitor the networks.
1.5.6 Mining applications
Because of the depth, gasses and inaccessible areas, ComBricks is required to keep the control room and the
experts on a distance to monitor the PROFIBUS installations.
Multiple WLAN routers can bring Ethernet up to the surface.
With DTM technology the devices can also be diagnosed and parameterized.
Fig. 4 - Offshore applications
Fig. 5 - Mining applications

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 17/219
1.5.7 Robot cells
Robot cells are hazardous environments with many safety zones. Crossing a safety border can cause a machine
shutdown and restarting can take a long time. Measuring PROFIBUS remotely decreases costs and improves
human safety.
Fig. 6 - Robot cells
1.5.8 Logistics
In demanding high-speed applications, ComBricks is ideal. The technician does not have to touch the
installation and can measure the network from a distance. This is also convenient if the installation is behind a
high-security zone such as baggage handling systems at airports, or parcel handling systems.
Fig. 7 - Baggage handling or parcel systems

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 18/219
1.5.9 Traffic control
When distance and downtime are critical factors, ComBricks can be very helpful. Difficult to reach speed
indicators above the highway can be monitored from the road-side control cabinet, or even from the control
room.
Fig. 8 - Traffic control applications
1.5.10 Cranes
Many harbour cranes use PROFIBUS. There cranes are huge and sometimes hard to reach. The whole crane can
be monitored remotely, which is especially useful if the crane is equipped with a WIFI connection.
Fig. 9 - Crane applications

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 19/219
1.5.11 Other applications
•Cross border installations
•Water treatment
•Long commissioning and test cycles
•24-7 service contracts
1.6 Output control
Relay- and digital output modules can be configured to respond directly to bus problems, such as bus voltage
too low, retries, syncs, master lost, diagnostics, etc.
This offers a multitude of applications to directly and independently act on the machinery when the bus
communication becomes unreliable. Especially when safety, human lives or the environment are at stake.
Power switches, hold switches, indicators, backup systems and LED towers are a few examples of machine
parts that can be hooked up to the relays. ComBricks is the only monitoring product that has the capability to
respond directly on the hardware with multiple relays.
•The Head Station already contains 1 relay.
•The relays can also be configured to be switched manually or on time.
24 55 834
2 3
Segment 2
Segment 1
Power switches, Hold switches,
Indicators, Backup systems,
Device I/O, Doors,
LED towers, etc.
Retries
Syncs
Bus voltage low
Lost
Diagnostics
Repeaters I/O
Fig. 10 - Output control

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 20/219
1.7 CommDTM
The FREE ComBricks CommDTM offers FDT 1.2 based asset management tools a powerful Ethernet pass-
through to access PROFIBUS devices which are connected on ComBricks repeater modules.
The internal DP-V1 class 2 masters are able to drive 2 out of 4 networks. When a CommDTM connection is
closed, the user can enter another network. The 2 active networks are managed by 1 or 2 PC Ethernet
connections.
The CommDTM provides the same auto baudrate detection facilities as the famous ProfiCaptain. It detects all
busparameters before it goes online. An available master address is required.
CommDTM
CommDTM
Device DTM
PROFIBUS DP
Device DTM
PROFIBUS PA
FDT Applications ProfiTraceOE
Fig. 11 - CommDTM structure
