Procusini 3.0 User manual

As at Jul 18; EN
User‘s Manual for
Procusini 3.0
3D Food Printer for
Commercial Use

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 2 of 33
Content
1 Basic Information ............................................................................................................................ 4
1.1 General description................................................................................................................. 4
1.2 Technical data Procusini (in/°F)............................................................................................... 5
1.3 Main components ................................................................................................................... 6
1.4 Schematic overview................................................................................................................. 6
2 Qualification of personnel............................................................................................................... 7
3 Safety Procedures / Precautions ..................................................................................................... 7
3.1 General introduction and definition of the safety instructions .............................................. 7
3.2 General safety instructions for machine operation ................................................................ 8
3.3 Special safety instruction for the machine.............................................................................. 8
General directions ........................................................................................................... 8
Setup, location of operation............................................................................................ 9
3.4 Use in accordance with regulations ...................................................................................... 10
3.5 Liability and guarantee.......................................................................................................... 11
Liability .......................................................................................................................... 11
Guarantee...................................................................................................................... 11
4 Description ofthe Functions and Operation of the Machine ........................................................ 12
4.1 Procusini and accessories...................................................................................................... 12
4.2 Preparation............................................................................................................................ 12
Preparation of the production plate ............................................................................. 12
Preparation of the flexible production mat, silicone .................................................... 12
Preparation of the cartridges ........................................................................................ 13
4.3 Commissioning ...................................................................................................................... 13
Connect Procusini to a WLAN enabled device (AP mode, recommended)................... 13
Prepare the first production with the Procusini............................................................ 14
4.4 Produce with the Procusini ................................................................................................... 17
4.5 Turn off the Procusini............................................................................................................ 19
5 Create your own objects ............................................................................................................... 19
5.1 The Procusini-Club................................................................................................................. 19

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 3 of 33
5.2 Upload the specially created objects from the Procusini Club into the user interface. ....... 22
5.3 Other uses of the Procusini Club........................................................................................... 23
Logos.............................................................................................................................. 23
5.4 Freehand drawing.................................................................................................................. 23
5.5 Text messages ....................................................................................................................... 24
5.6 Trace contours....................................................................................................................... 24
5.7 3D objects with own foods.................................................................................................... 25
6 Other functions of the user interface............................................................................................ 26
6.1 Changing the cartridge .......................................................................................................... 26
Manual change of the cartridge.................................................................................... 26
6.2 Alignment of the production plate........................................................................................ 27
6.3 Cleaning................................................................................................................................. 27
Cleaning the cartridge ................................................................................................... 27
Cleaning the dosing tip.................................................................................................. 27
Cleaning the stainless steel plunger.............................................................................. 27
Cleaning the heatable stainless steel tip....................................................................... 28
Cleaning of the production plate................................................................................... 28
Cleaning of the flexible production mat, silicone.......................................................... 28
6.4 Standby mode ....................................................................................................................... 28
6.5 Parking................................................................................................................................... 29
6.6 Optional: Connect (integrate into the home network)......................................................... 29
Windows 7 / Windows 8 / Windows 10........................................................................ 30
Apple MacBook / MacBook Air / MacBook Pro / iMac / iMac Pro / Mac Pro/Mac mini
30
Tablet (Android) ............................................................................................................ 30
Apple Ipad...................................................................................................................... 30
7 Troubleshooting ............................................................................................................................ 31
8 Returning Old Devices ................................................................................................................... 33
9 Servicing and Maintenance ........................................................................................................... 33
9.1 Safety instructions for servicing............................................................................................ 33

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 4 of 33
1Basic Information
1.1 General description
The Procusini is an easy-to-use Procusini for use in commercial kitchen, e.g. in catering, event
gastronomy or bakery/confectionery.
It consists of a heatable cartridge holder, which is mounted to a positioning unit and operated via
WLAN. The x and y axis are controlled by a tooth belt, while the z axis and the extruder are set into
motion by threaded rods. The cartridge holder is located at the end of the y axis and during the
production process is moved upwards layer by layer by means of the z-motor. The production plate
represents the x axis and serves as a bearing surface for the pads to be printed (flexible production
mat; plates; breads etc.). The food is filled into food-safe cartridges or are available as food-safe
refills. These cartridges are inserted into the cartridge holder and if necessary heated to a
temperature specifically defined for the food item. There is no direct contact between the food item
located in the cartridge and the device itself.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 5 of 33
1.2 Technical data Procusini (in/°F)
Production
Usability Food with appropriate consistency
Technology Layer-by-layer deposition of consumables
Tip Heatable
Volume of capsule 2 oz
Building space 9,8 in
5,9 in
3,9 in
Precision 0,004 in
Nozzle diameter 0,02 - 0,05 in
Rate of printing 0,2 - 2 in/s
Movement velocity 0,2 - 7,9 in/s
Physical Dimensions
Measurements:
Maximum space: 23,6 in (Platform moves right and left)
23,6 in
25,6 in
Packaging volume 19,7 x 23,6 x 25,6 in (L x W x H)
Weight 9 kg
Shipping weight 15 kg
Temperature
Ambient temperature 50 - 82,4 °F
Storage temperature 32 - 89,6 °F
Process temperature of
heated cartridge 68 - 140 °F
Power Supply
Power supply (AC) 85 –264 VAC; 47 –63 Hz
Power (DC) 12 V; 8,5 A; 102W
Protection Short circuit / Overload / Over voltage / Over temperature
Power Plug 3 Pin; IEC connector
Software/ Connectivity
Interface Browser-based
Compatibility Google Chrome
Wireless LAN 802.11.b/g/n
Connectivity Independent printing via WiFi

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 6 of 33
1.3 Main components
(1)Printing Plate
(2)Cartridge holder
(3)Fill level display
(4)Power Switch
(5)Power Supply Socket
1.4 Schematic overview
1
2
3
4
5

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 7 of 33
2Qualification of personnel
This machine requires proper training. It is ONLY recommended for use by individuals with sufficient
training and/or those that are monitored by a person who has been properly trained on the safety
and intended use of the machine.
This machine is not meant for use by children.
This machine is to be operated by a single person!
Troubleshooting, service, and maintenance are to be performed only by qualified individuals who are
familiar with the technology and dangers of the machine and have been authorized by Print2Taste.
Work on electrical components is to be performed only by trained electricians.
The address for service is found in Chapter 6 of this user’s manual.
3Safety Procedures / Precautions
The following information pertaining to safety- and possible hazards is important not only for
protection of the machine, but also to protect the user. Please read through the following points
carefully:
3.1 General introduction and definition of the safety instructions
Important safety- and device-relevant instructions are represented as symbols in this handbook. The
directions are to be followed at all times in order to prevent accidents or damage to people or things.
WARNING! Danger from electrical current! This symbol indicates a situation in which
dangerous situations may exist due to electrical currents. If this safety information is
ignored, injury or a life-threatening situation may result.
WARNING! This symbol indicates dangers which may lead to injuries. Uphold all of the
given safety instructions exactly as indicated and pay special attention in such cases.
WARNING! Hot surface! This symbol indicates that a hot surface is present on the machine
during operation. If this is ignored, the user may get burned or a fire hazard may result!
WARNING! Danger from moving parts –keep fingers and other body parts away. This
symbol indicates the risk of injuries which may occur if the user reaches into the machine
during operation. Body parts may be smashed, drawn in, or injured in other ways.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 8 of 33
3.2 General safety instructions for machine operation
This device is built according to the current technical rules and regulations. However, dangers may
arise if the device is used in an inappropriate manner or out of accordance with regulations.
The information contained in the user’s manual designed to protect the user from injury. It
additionally serves to avoid mistakes, thus assuring that the device runs safely and disturbance-free
In order to avoid dangers and to ensure optimal performance, neither alterations nor reconstructions
are to be performed on the machine unless explicitly approved by the manufacturer.
The device may only be used in technical and operationally safe conditions in accordance with the
instructions contained within this user’s manual.
In the case of damage occurring due to a lack of observance of this operation manual, the guarantee
is voided. We take no responsibility for subsequent damages.
The manufacturer assumes no liability for damages to persons, objects or property that occur due to
inappropriate handling or a lack of adherence to the safety instructions. In these cases, the
guarantee is voided.
3.3 Special safety instruction for the machine
The information pertaining to work safety corresponds to the regulations of the European Union at
the time at which the device was manufactured.
General directions
Warning: Never leave the Procusini unattended when in use!
Warning: High temperatures may develop in the printing head of the Procusini. For this
reason, never grasp the printer while in operation. Change the food cartridge only after the
printer has cooled down sufficiently
Warning: The power supply plug must always be in the vicinity of the printer and be easily
reachable.
Warning: In the case of emergency, immediately disconnect the power source and power
plug!
Warning: In order to prevent fire or electrocution, never set this device onto damp or wet
surfaces.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 9 of 33
For commercial use as defined by the use in compliance with regulations, the user is required to
comply with the given work safety provisions and the current rules and standards as well as
observing any new specifications for the entire service life of the machine. For use outside of the
European Union, the occupational safety legislation and regional stipulations are to be followed
according to all local, state and federal regulations.
In addition to the occupational safety notes in this manual, the valid safety- and accident prevention
regulations as well as the valid environmental protection stipulations for the location at which the
machine operates are to be observed and maintained:
Setup, location of operation
Place the Procusini onto a stable, horizontal, large enough area only. Please note that the production
plate moves from right to left when operating and thus requires enough space. Additionally, some
movement also occurs vertically. When selecting the operating location, please make sure that the
device is able to move in these directions.
Choose the operating location in a way that children cannot reach the product.
When setting up the device, please make sure that the power adapter is easily accessible in order to
quickly and easily shut off the device in the event of an error.
Do not place the machine in areas where extreme temperatures, strong vibrations, high humidity
(i.e. rain or steam), dust, or heavy mechanical stresses may occur.
Do not place any liquid-filled vessels (i.e. glasses, vases, etc.) on top of or in the vicinity of the
machine and never pour water over the machine. Fluids may enter the machine casing and impair
the electronic stability of the machine. Additionally, there is a high risk of fire or life-threatening
electrical shocks!
If such an event occurs, shut down the respective power supply plug completely (i.e. turn off the
circuit breaker and earth leakage circuit breaker) and then pull the power cord from the socket.
Disconnect all wires from the device. The entire product is not to be used again. Please contact a
specialized dealer or the manufacturer.
Do not place any sources of ignition such as stoves, fryers or burning candles next to or on top of the
device.
While setting up the machine, be sure that the power line is not squeezed or damaged by sharp
corners.
Take note of the additional safety instructions found in the individual chapters of this manual.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 10 of 33
3.4 Use in accordance with regulations
Procusini is an easy-to-use Procusini for use in commercial applications, for instance in gastronomy,
catering, or pastry kitchens.
Only the intended food-proof cartridges may be used. Moreover, the intended food-proof
production plate has to be applied during the production process.
Care must be taken that only piece-free, paste-like food items can be processed, such as marzipan,
pasta dough, Choco, fondant, etc.
The machine may only be used under continuous monitoring of the operating personnel.
The machine is only intended for indoor use.
The permissible surrounding temperature for the system lies between 68 - 140 °F. The maximum
allowable operating temperature for the printer head is 140 °F.
The surrounding area should be dry and largely dust-free.
The reliability of device operation is only assured under operation in accordance with the regulations
found in this operator’s manual.
All technical work, including assembly and servicing, is to be performed only by qualified individuals
and those who have been authorized by Print2Taste.
The Procusini is only intended for printing edibles from the designed cartridges. The Procusini is
designed for food printing in the provided cartridges with the appropriate templates and objects
from the Procusini Club only.
Any use deviating from the intended purpose and/or other type of use of the equipment is forbidden
and is considered to be out-of-accordance with regulations and will negate the product warranty.
Claims of any type against the manufacturer and/or its agent due to damages resulting from use
other than the intended use are barred.
The user is held solely accountable for any damages occurring during use of the device that deviates
from the intended use.
Please retain all original packaging as well as all shipping and handling material. This is the only way
to assure a successful and safe transport of the Procusini, for instance in the case of a return under
warranty!
Print2Taste takes no liability for devices that are not returned in their original packaging or have
been packaged improperly!

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 11 of 33
3.5 Liability and guarantee
Liability
All entries and information supplied in this user’s manual have been compiled in accordance with the
effective regulations, the current technical development status as well as our personal long-time
knowledge and experience.
The translation of the user’s manual has also been conducted to the best of our knowledge.
However, we cannot accept liability for translations errors. The authoritative version of this user‘s
manual is the accompanying German version.
The actual scope of delivery may deviate from the explanations and graphic presentations given here
due to special designs, the utilization of additional order options or because of the most recent
technical changes. Please contact the manufacturer if you have any questions.
This user’s manual is to be read through carefully and completely before beginning any
work on or with the device, and especially before device operation! The manufacturer
assumes no liability for damages and disturbances resulting from a lack of observation of
this manual.
The user’s manual is to be stored in the vicinity of the device and within reach of all people working
on or with the device. We reserve the right to make technical changes to the product in order to
improve the operating characteristics and develop the device.
Guarantee
The guarantee for the Procusini is valid for 6 months starting on the date of purchase.
Please preserve all original packaging and transportation packaging in case the device should need to
be returned! This is the only way of assuring a safe transport of the Procusini!
The manufacturer assumes no liability for devices that are damaged during shipping if they are not
shipped in their original packaging and/or are improperly packaged!

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 12 of 33
4Description ofthe Functions and Operation of the Machine
4.1 Procusini and accessories
(1) Procusini 3.0; (2) 3 cartridges; (3) 5 dosing tips; (4) 1 cleaning hook; (5) 1 cleaning syringe; (6) 1
scalpel; (7) 1 production plate –standard with magnetic lock; (8) 1 flexible production mat, silicone;
(9) 3D Marzipan Natural - 4 refills (4 x 85 g); (10); (11) 3D Choco - 4 refills (4 x 75 g); (12) 3D Fondant
White - 4 refills (4 x 75 g); (13) 3D Pasta Natural - 4 refills (4 x 45 g); (14) Power supply; (15) Plug; (16)
cap
4.2 Preparation
Preparation of the production plate
Wash with warm soapy water and dry thoroughly prior to first use. Place the production plate onto
the work table so that the 3 magnets at the bottom rest on the 3 adjusting screws. Make sure that
the production plate is placed properly and cannot be moved.
Preparation of the flexible production mat, silicone
Wash with warm soapy water and dry thoroughly prior to first use. Place the flexible production mat
onto the production plate, so that you obtain a flat surface.
Do not cut on the flexible production mat. Do not use any sharp objects which can perforate
or cut up the production mat. Never use a flexible production mat which has tears or cuts.
3
5
2
1
8
16
7
6
4
12
11
13
15
14
9

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 13 of 33
Preparation of the cartridges
The preparation of the cartridges as well as its filling with food are individual for each product and
are extensively described in the annex and the application instructions. More information as well as
the current application instructions for food items can be found at www.procusini.club.
4.3 Commissioning
a. Connect the power adapter of your Procusini to the
socket on the rear side of the device (see illustration).
b. Plug in the power cord of the Procusini to an electrical
outlet.
c. Turn on the power switch of the Procusini.
d. Procusini starts operating. As soon as it is ready for the
next steps, it moves for the first time and slides into the
“home position”.
e. Please wait for this first move (this may take several
minutes) before proceeding with the next step!
Connect Procusini to a WLAN enabled device (AP mode,
recommended)
Open your Wi-Fi connections.
Connect to Procusini Wi-Fi. The password is
"procusini"
Open Google Chrome.
Enter 10.250.250.1 in the address bar.
The Procusini user interface opens.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 14 of 33
Prepare the first production with the Procusini
The preparation of the cartridges and the filling with food are product-specific and are described in
detail in the application instructions for the various foods. For more information, as well as the
current application instructions for food, see also www.procusini.club.
Tip: For the first production of an object with the Procusini, we recommend starting with our 3D
marzipan to get a feel for the handling of the device.
Screw the enclosed metal tip into the printhead.
Important! Only hand-tighten the metal tip.
Warning! The metal tip heats up during operation. Let it cool sufficiently before you
remove it for cleaning.
Prepare your desired food according to instructions. If necessary, open it on one side with
the included scalpel.
Place the open refill in one of the supplied cartridges (with the cut side down).
Screw one of the plastic tips onto the cartridge.
Put the whole thing in the head of the device.
When opening the head, be sure to press the side handle to open the door.
When the head is filled and the door is closed again, click on "Produce object" in the user
interface.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 15 of 33
The "Select food" field appears.
Select the food you have previously used, tick the box and confirm with "OK".
The message "Calibrate Now?" Appears.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 16 of 33
Calibration is necessary the first time you use the Procusini and every time you exchange
your production documents.
Click on "ok" to start the process.
Calibration is done using the arrow keys.
Attention: Just click on an arrow once, the system remembers the steps and if it clicks too often the
device could move into the production file and cause damage to the Procusini
•If the tip is about 1mm above the production platform, confirm with "Done".
•The Procusini is now back in its starting position.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 17 of 33
4.4 Produce with the Procusini
•When the preparations are completed until the first production, you will be taken to the
page with the first objects.
•For foods that require heating, a red bar appears with the appropriate preheat time.
•When preheating is finished, you can click on one of the objects.
•It is framed in green and turns.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 18 of 33
•Now click on the button "Start" and the window "Predosing" appears.
•Pre-dosing until some of the food used comes out of the top.
•Confirm with OK". The device now moves to its starting position.
•Here you can, if necessary, readjust the height of the starting point with the arrow keys.
•If you are satisfied with the distance, click on "Start" and the Procusini will start production.
•Now a progress bar appears.
•When the device is finished producing, it returns to its starting position.

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 19 of 33
4.5 Turn off the Procusini
To avoid damage to the device, be sure to use the "Off"
button on the user interface to shut down the operating
system.
Then choose whether you want to remove the cartridge
or leave it in the device in order to continue working with
this food at a later date. Recommendations for handling
food can be found in the instructions for use and in the
Procusini Club.
Now press the on / off switch on the Procusini to switch
off your device.
5Create your own objects
5.1 The Procusini-Club
Creating an object with the Procusini Club requires an internet connection.
•Open your browser and type www.procusini.club in the search bar.
•You now get to the login for the club.
•Log in with your access data. If you do not have a login, please register.
•Now you get to the start page of the club.
•Here you can select existing objects from the template library or create your own templates
under "Applications".

User´s Manual for Procusini
For questions, please do not hesitate to email us at: [e-mail]
Page 20 of 33
•Under Applications you have the different options to create your own objects.
•The principle of creating your own template is largely similar for the various applications.
•As an example, the procedure with the application "3D objects" is illustrated here.
•Select the desired food.
•Select your desired file in STL format. (Maximum size 5 MB)
•The file must be an STL file (common 3D model file).
Tip: There are many websites that provide such templates (STLs) free of charge.
"Www.thingiverse.com".
