U S E R M A N U A L
S o u n d S y s t e m S p e a k e r s
CAB100 –CAB200

Safety Information
Precautions
The lightning flash with the arrowhead symbol in an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” inside the appliance that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the product.
Important Instructions
1) Read these instructions.
2) Retain these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this appliance near water.
6) Clean only with a dry cloth.
7) Do not block any of the ventilation openings that were installed in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the plug provided does not fit into your outlet, consult an electrician to ensure
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point
where it exits from the appliance.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the appliance. If
using a cart, be careful when moving the cart/appliance combination to avoid injury from tip-over (Figure 1).
13) Unplug this appliance during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the appliance has been damaged in any
way, for example, the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen inside the
appliance, the appliance has been exposed to rain or moisture, does not operate normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION: The appliance should not be exposed to drips or splashes of water. Objects filled with liquids, such as vases, should
not be placed on the appliance.
Thank you for purchasing this digital appliance. To ensure perfect operation and security, please read the manual carefully
and retain it for future reference.
This logo indicates that the product can be recycled after it has been used. Please do not dispose of the product with
your normal household waste. Return the product to the shop where you purchased it or place it in the designated
recycling container.

Contents
1 –Introduction............................................................................................................................1
2 –Connections ............................................................................................................................1
3 –Settings ....................................................................................................................................3
4 –Audio Input/Output Sockets ............................................................................................3
5 –Speaker Orientation ............................................................................................................4
6 –Specifications .........................................................................................................................5

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
-1-
1 –Introduction
Thank you for choosing this PRODIPE product.
Safety Information
To ensure both your safety and the proper functioning of this product, please take
the time to read the safety instructions on the back cover.
WARNING. To avoid any possibility of electric shock, please do not remove the
back panel of this product. For any repair work please contact either the shop
where you purchased the product or a qualified technician.
Please note that when the volume is turned up high, this equipment can produce
sound levels which may irreparably damage your hearing.
2 –Connections
To ensure that your speaker is properly connected, please adhere to the following steps:
1. Check your audio lead.
2. Switch on the equipment you intend to use with the speaker (console, PC, audio
equipment, etc.).
3. Check the speaker settings and your audio equipment (volume turned down to its
lowest level).
4. Check the voltage , turn the speaker POWER switch to ON - the red LED should
light up.
Note that: when powering off, the Prodipe speaker should be switched off first (switch to
OFF and red LED goes out).
Important: the choice of voltage via the AC SELECT switch depends on your power
supply. Any change to the voltage should be carried out when the speaker is off (switch to
OFF and speaker unplugged from the power supply). When setting up your speaker, please
pay regard to the following procedure:
CAB 100
CAB 200
POWER SUPPLY
100V –120V
220V –240V
100V –120V
220V –240V
AC SELECT 
115V
230V
115V
230V
FUSE 
T2AL
T1AL
T3, 15AL
T1, 6AL
Figure 1

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
-2-
Figure 2
1
3
2

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
-3-
3 –Settings
Various settings are available on the front panel of the speakers:
Figure 3
VOLUME
STEREO: controls the volume of the STEREO L and R inputs
MIC: adjusts the volume of the MIC input
INST: adjusts the volume of the INST input
MASTER: adjusts the master volume
EQUALISER
BASS: corrects the bass tonality
TREBLE: corrects the treble tonality
When the controls are mid way, no correction is taking place; moving the control in an
anti-clockwise direction decreases the tonality, whereas in a clockwise direction it
increases the tonality.
4 –Audio Input/Output Sockets
Figure 4
The CAB 100 and the CAB 200 feature three different sockets for maximum flexibility:
STEREO: 1 stereo connector with L and R jacks for connection to any line-input
equipment such as a keyboard, PC or other audio player (MP3, SmartPhone, etc.) - a
strong stereo signal is maintained.
INST: 1 mono jack input to connect an instrument such as an acoustic electric guitar.
MIC: 1 XLR input to connect a mic.

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
-4-
The CAB 100 and the CAB 200 also feature a LINK male XLR output socket so that you can
supplement the power by adding another speaker such as another CAB 100 or CAB 200.
IMPORTANT: This output does not control the stereo of the combined L and R inputs.
5 –Speaker Orientation
The ‘foot bath’ shape of the speakers (45° angled cabinet) is deliberate. It makes them
perfect for a near-field speaker setup or a combined speaker/amp setup.
The CAB 100 and CAB 200 speakers are also fitted with a slot so that they can be attached
to a stand (sold separately).
Figure 5
45°
Speaker stand slot

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
-5-
6 –Specifications
CAB100
CAB200
Frequency Response
40Hz -20kHz (+/-3dB)
35Hz -20kHz (+/-3dB)
High Frequency Driver
3” (75 mm)
Magnetically shielded
Fibre cone
3” (25 mm)
Magnetically shielded
Fibre cone
Low Frequency Driver
10” (250 mm)
Magnetically shielded
Fibre cone
12” (300 mm)
Magnetically shielded
Fibre cone
AMPLIFICATION
Power Rating
100 watts RMS
200 watts RMS
Signal to Noise Ratio
>95dB
Typical (A)
>95dB
Typical (A)
Input Impedance
Balanced
Unbalanced
10K Ohm
20K Ohm
10K Ohm
20K Ohm
CROSSOVER FREQUENCY
Active filter
Active filter
POWER SUPPLY:
FUSE 5 x 20mm
100V - 120V~/60Hz
220V - 240V~/50Hz
1A
500mA
2A
1A
FEATURES
1 x Mic Input (XLR)
2 x Line Inputs (6.35mm stereo jacks)
1 x Instrument Input (6.35mm stereo jack)
1 x Link XLR Output
Bass Equaliser: adjustable from -6dB to +6dB
Treble Equaliser: adjustable from -6dB to +6dB
Stereo Volume Control
Mic Volume Control
Instrument Volume Control
Master Volume Control
LED Power Indicator (On/Off) at the front
Dimensions (H x L x P) en mm
440 x 310 x 315
528 x 370 x 365
Weight (individually)
11.6 Kg
15.2 Kg

Actual product(s) may differ from illustrations/photographs used
Copyright © 2012 IPE Music
