Lynx Ionic Series User manual

USER MANUAL
Lynx Pro Audio S.L.
Valencia, Spain - www.lynxproaudio.com - [email protected]
QB series
QB-5
SUB-08
V.21.04

Manufacturer
CE CERTIFICACTION, EUROPEAN PRODUCT
SUB-08
LYNX Pro Audio S.L.
Calle 1 - Pol. Ind. Picassent
E-46220 Picassent (Valencia)
This user guide is property of Lynx Pro Audio S.L. Any reproduction of this manual, by any means is strictly
prohibited. Copyright 2020. All rights reserved.
QB-5

Ionic Series User Manual
Lynx Pro Audio S.L 3www.lynxproaudio.com
INTRODUCTION
To facilitate, correct and reliable use of the QB series we have designed this instruction manual. Please read
the manual carefully before proceeding to install the cabinets.
The QB series comprises one two-way, passive full range cabinet and one subwoofer and is the smallest
series that Lynx Pro Audio offers, designed and intended for background sound reinforcement where the
power of the HR or BS series is not required.
All QB Series components have been carefully selected to offer a lightweight, versatile series delivering
dynamic sound whilst remaining as competitively priced as possible and guaranteeing utmost reliability. All
cabinets deliver a linear phase response and have been engineered to reduce distortion.
The components have been carefully selected to offer a lightweight, versatile series, delivering a linear phase
response with excellent sound distribution and delity for background installations in bars, restaurants,
conferences, etc.
CONTENTS
• SAFETY PRECAUTIONS 4
• SYSTEM OVERVIEW
QB-5 5
SUB-08 6
• CONNECTORS AND CONNECTIONS 7
• RAINBOW 3D ACOUSTIC SIMULATION SOFTWARE 9
• HARDWARE AND ACCESSORIES 10
• CERTIFICATIONS AND GUARANTEE 11

Ionic Series User Manual
Lynx Pro Audio S.L 4www.lynxproaudio.com
Before starting to use this device, please read this instruction manual carefully.
Keep these instructions in the place where the equipment will be used and with easy access to them.
• Electrical appliance
The exclamation mark within a triangle identies the presence of electricity. Use the system carefully without wet
hands or feet. Avoid installing the speaker in wet or excesivelly humid places. Do not place material that contains
liquid on or near the unit. Avoid dripping or splashing water or any liquid over the unit. Regularly check the condition
of the cables and make sure these are not being walked on or pinched. Connect the speaker to bipolar, earthed
mains. The mains plug must be connected to the appropriate protection (fuse or breaker). Connection to any other
type of mains could result in an electrical shock and violate local electrical codes.
CAUTION: DO NOT CONNECT OR DISCONNECT THE AC POWER CONNECTORS UNDER LOAD.
•Heavy equipment
Apply back protection when using the system. Avoid loading and unloading at heights.
•Electrical shock risk
The diagonal mark within a triangle identies the presence of dangerous voltage.
Do not open or handle the interior of the box. These parts are not to be adjusted by the user. For maintenance and/
or repair please go to an authorized service centre.In order to reduce the risk of electric shock, disconnect from
AC before plug in or unplugging Audio signal cables. Reconnect to AC only if all signal connections are made and
secured. Never manipulate the ground type plug provided.
The AC mains plugs should always remain accessible for operation.
Unplug the loudspeaker during storms or when it’s being used for a long time.
•Hearing damage risk
These systems can reproduce large quantities of sound pressure which can damage hearing. Take precautions if
you are going to be near them for extended amounts of time and do not get too close.
•Hanging / Flying
Do not hang the cabinets from the handles or from any other part other than the designated hanging point. When
ying this system please observe the technical and “Rainbow” software data carefully. Never exceed the maximum
safe working loads or ignore the instructions included within this manual. Use Only ying accessories provided by
Lynx Pro Audio S.L. Rigging must be always carried out by professionals.
•Delicate Material
Please ensure no foreign object or water enters the speaker. Only clean the unit with dry cloths. Do not use solvents.
•Overheating / Fire risk
To reduce the risk of the speaker over heating, avoid direct contact with sunlight. Avoid placing the unit close to heat
inducing objects such as radiators. Do not cover the equipment in use and do not block any ventilation openings.
Do not put naked ame, such as lighted candles, close or on top of the unit.
•Electromagnetic and interferente emissions
Avoid placing objects which through electromagnetic waves can damage the unit, such as mobile phones, lap tops,
magnetic strip cards etc.
This system complies with normatives EN 55103-1 (1)
EN 55103-2 (2)
(1) This device may not cause harmful interferences.
(2) This device may receive interference including interferences that may cause undesired working.
•IMPORTANT NOTE
This Equipment must be used in accordance with these instructions and by trained professional personnel only.
This equipment should not be used in places with extreme tropical climates. Don’t expose this apparatus to extreme
humidity and or temperature values.

Ionic Series User Manual
Lynx Pro Audio S.L 5www.lynxproaudio.com
SYSTEM OVERVIEW
• Technical Data:
Components:
•LF: 1 x 5” transducer
• HF: 1 x 1” tweeter
Frequency range: 65 Hz – 20 KHz (-10dB)
Frequency response: 75 Hz – 18 KHz (± 3dB)
Sensivity 88 dB (1W@1m)
Max SPL / Peak: 107 dB - 113 dB peak
Coverage: 90º H x 90º V conic
RMS power: 80 W
Program power: 160 W
Nominal impedance: 16 Ω
Input connectors: 4 x Terminal Block 7.62 mm between pins
Finish: Water based paint
Material: 9 mm premium birch plywood
Dimensions: 254 x 167 x 186 mm (H x W x D)
Weight: 3 Kg (6.6 lbs)
•QB-5
Ultra-compact, full range, two way passive cabinet for background sound reinforcement. It consists of a
5” transducer and a 1” high frequency neodymium tweeter. It offers 90ºconic dispersion and 110 dB SPL
(160W program).
• QB-5 measurements
2 x M6 for wall bracket
(ref.:WB-10)
1 x M6 for wall bracket
(ref.:UBR-QB5)

Ionic Series User Manual
Lynx Pro Audio S.L 6www.lynxproaudio.com
SYSTEM OVERVIEW
• Technical Data:
Components: 1 x 8” transducer (2 x 50mm voice coil)
Frequency range: 43 Hz – 160 Hz (-10dB)
Frequency response: 47 Hz – 154 Hz (± 3dB)
Sensivity 93 dB (1W@1m)
Max SPL / Peak: 116 dB - 122 dB peak
Coverage: 360º single unit
RMS power: 200 W
Program power: 400 W
Nominal impedance: 2 x 8 Ω
Input connectors: 2 x Neutrik Speakon NL4MP
Finish: Polyurea coating
Material: 15 mm Premium birch plywood
Dimensions: 268 x 641 x 304 mm (H x W x D)
Weight: 9 Kg (20 lbs)
•SUB-08
Ultra-compact double band pass, passive sub woofer with one 8” transducer with double independent
coil and rubber suspension. 117 dB SPL (400W).
• SUB-08 measurements

Ionic Series User Manual
Lynx Pro Audio S.L 7www.lynxproaudio.com
CONNECTORS AND CONNECTIONS
• Normative
QB Series cabinets meet the following standards:
EN 55103-1:1996: Electromagnetic compatibility. Product family standard for audio, video, audiovisual and
entertainment lighting control apparatus for professional use (-1 Emmision).
EN 55103-1:1996: Electromagnetic compatibility. Product family standard for audio, video, audio-visual and
entertainment lighting control apparatus for professional use. (-2 Immunity)
EN 60065:2002: Audio, video and similar electronic apparatus. Safety requirements.
• Cable connection
In the following table you can see the maximum power of the cabinets and their nominal impedance.
Connector Connections per box Impedance Power
NL4MP ±1 2 16 Ohms 80 W
NL4MP ±1/ ±2 1 2 x 8 Ohms
• Connectors
The QB Series has a connection panel at the rear of the cabinet. This consists
of 2 internally bridged Neutrik NL4-MP connectors which apply no process
to the signal.
Note: If pins +-2 are not used they will still be internally bridged.
To power the cabinet use NL4 speakon connectors as shown in the following
diagram. Consult the ‘’Conection cable table’’ on previous page, under the
column ‘Speakon Connections’ to see which pins are used for each cabinet.
To connect the speakon follow the instructions in g. 1
Insert the male speakon in its corresponding hole and turn right until it clicks. This xes it safely and strongly and
helps stop it being pulled out by mistake. At the other end of the cable connect in the same way to the amplier
channel.

Ionic Series User Manual
Lynx Pro Audio S.L 8www.lynxproaudio.com
• Recommendations
Always ensure cables are in good condition. Know the recommended cable length and thickness according to
the cabinet and quantity you are installing. An incorrect connection can affect the functioning of the system
or even damage it. Cable thickness will vary according to cabinet impedance, quantity and distance. This is
especially important when connecting Sub-bass cabinets.
As a guide, please see the following table which outlines the thickness depending on the power and length
of cable.
CONNECTORS AND CONNECTIONS
Bear in mind Ohm ratings on the ampliers used to power the cabinets. For example 2 ohm amplier
congurations are not recommended due to the excessive power from the amp output.
Never connect more cabinets than recommended in parallel. With parallel connections, the total impedance
can be calculated by dividing the impedance of 1 cabinet by the number connected. E.g: 2 QB-8 cabinets in
parallel have an impedance of 4Ohm (8Ohm impedance - for 1 cabinet - divided by 2 – numbers of cabinets
connected).
Maximum recommended cable length for low impedance systems
Wire section AWG number Cable resistance in 100 meters
Maximum recommended lenght (in meters)
2 Ω 4 Ω 8 Ω 16 Ω
13.3 mm² 6 0.25 Ω 24 57 122 253
6.63 mm² 8 0.49 Ω 12 28 61 126
5.26 mm² 10 0.62 Ω 10 23 48 100
3.31 mm² 12 0.99 Ω 6 14 30 63
2.08 mm² 14 1.57 Ω 4 9 19 40
1.31 mm² 16 2.49 Ω 26 12 25
0.82 mm² 18 3.98 Ω 24 8 16
0.52 mm² 20 6.28 Ω 1 2 5 10
0.33 mm² 22 9.89 Ω 1 1 36

Ionic Series User Manual
Lynx Pro Audio S.L 9www.lynxproaudio.com
RAINBOW 3D Acoustic Prediction Software
Lynx Pro Audio’s R&D department is working on Rainbow 3D, a new acoustic simulation software with dynamic
3D features. With a sophisticated design, Rainbow 3D stands out for its speed, being able to provide a simulation
in just a few seconds. It also provides algorithms for beam steering and optimizing the listening area.
• Designed from scratch by professionals
Rainbow 3D has been programmed from scratch by Lynx Pro Audio engineers, using new programming procedures
that achieve an effective simulation with really low calculation time.
• Multiple listening zones
The program can simulate all Lynx Pro Audio’s acoustic enclosures located in a 3D space, including the classic
side, top and front views. It can also dene multiple listening zones and allows offset positioning and symmetry.
Blueprint images, textures and PNG format pictures can be imported.
• Unlimited sound sources
Allows the acoustic simulation for an unlimited number of sound sources and audio systems. You can place as
many systems (subwoofers, line arrays, columns and individual boxes) as you desire. Also, the line arrays can be
placed in stack or own conguration.
• Beam steering
Rainbow 3D has the ability to add DSP processing to the simulation and uses algorithms to control the directivity
(beam steering) in columns, without the need to tilt them physically, being able to divide the column into several
beams that point to different zones.
• Accurate optimization thanks to FIR lters
Optimized algorithms are used in the listening area to improve the sound coverage and the frequency response. This
feature can be executed in a matter of seconds. Additionally, the export of FIR coefcients can be performed with
the optimization for later loading in the DSP via Ethernet or a USB device. In the near future direct communication
with Lynx Pro Audio and OCS will be available.
• Multiple measures and tools
Likewise, the R&D department is developing multiple measurement and analysis tools for the calculated data. For
example, the sound pressure curves (SPL) in the listening areas and the capture of virtual measurements that show
the frequency response in the points of location indicated and added. Among other tools you will nd autosplay
and a wizard to set up different subwoofer arragements.

Ionic Series User Manual
Lynx Pro Audio S.L 10www.lynxproaudio.com
HARDWARE AND ACCESSORIES
The QB Series is designed to be used in xed installations such as pubs, bars, restaurants, conference halls,
hotels, etc. A large selection of accessories are available to help ease the installation and achieve the necessary
angulation to direct the sound towards the required listening zones.
WB-10
Wall bracket for the QB-5.
Also available in white
with Ref.: WB-10W
UBR-QB5
Horizontal ying /mounting
bracket for QB-5

Ionic Series User Manual
Lynx Pro Audio S.L 11www.lynxproaudio.com
DECLARATION OF CONFORMITY
Lynx Pro Audio S.L.
Calle 1 - Pol. Ind. Picassent
46220 Picassent (Valencia)
SPAIN - EU
Tel.: [phone]
www.lynxproaudio.com
Lynx Pro Audio S.L. declares that ionic series are in conformity with the following EC directives:
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility EMC 2004/108/EC
RoHS Directive 2002/95/EC
In accordance with Harmonized European Norms:
EN 60065:2002 Audio, video and similar electronic apparatus. Safety requirements
EN 55103-1:1996 Electromagnetic compatibility. Product family standard for audio, video,
audiovisual and entertainment lighting control apparatus for professional use.
Part 1: Emission.
EN 55103-2:1996 Electromagnetic compatibility. Product family standard for audio, video,
audiovisual and entertainment lighting control apparatus for professional use.
Part 2: Immunity.
Ionic models: QB-5 / SUB-08

Ionic Series User Manual
Lynx Pro Audio S.L 12www.lynxproaudio.com
LYNX PRO AUDIO GUARANTEE
Lynx products are guaranteed against every kind of manufacturing fault 2 year after the date of sale. When
products are under guarantee, the repairing and the free supplying of the device parts in order to correct
any kind of defect are guaranteed by Lynx Pro Audio S.L. In the case that the product could not be returned
to the factory for checking and repairing, Lynx Pro Audio S.L. would supply all the necessary parts.
Lynx Pro Audio S.L. is not responsible for any damage or defect caused during the transport or caused by an
undue or improper handling y a non-authorized person during the life of this guarantee.
All our products undergo rigorous tests and quality controls. We guarantee the characteristics described
here within and their quality against any fabrication defect.
The user loses all warranty rights if he incorporates or carries out any modication to the product, if he uses
it outside of the stated safe working loads or does not secure the system properly using all the pins in their
corresponding holes.
WEEE Declaration: Electrical and electronic equipment must be disposed of separately from normal was-
te at the end of its operational lifetime. Please dispose of this product according to the respective national
regulations or contractual agreements. If there are any further questions concerning the disposal of this
product please contact Lynx Pro Audio S.L.
