PROFILO BM6224 - annexe 2 User manual

Operating instructions
reliable appliances
9000 533 738 (9004)

Start
1246
9
53 7
Reset 3 sec.
8
10
20
21
23
24
25
26
27
28
29
30
32
22
31

en Table of contents
Safety instructions . . . . . . . . . . . . . . . . . 4
Delivery . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . 4
In daily use . . . . . . . . . . . . . . . . . . . . . 4
Children in the household . . . . . . . . . . 4
Door lock . . . . . . . . . . . . . . . . . . . . . . 4
Damage . . . . . . . . . . . . . . . . . . . . . . . 4
Disposal . . . . . . . . . . . . . . . . . . . . . . . 4
Getting to know your appliance . . . . . . 5
Control panel . . . . . . . . . . . . . . . . . . . 5
Appliance interior . . . . . . . . . . . . . . . . 5
Water softening system . . . . . . . . . . . . . 6
Setting . . . . . . . . . . . . . . . . . . . . . . . . . 6
Water hardness table . . . . . . . . . . . . . 6
Special salt $. . . . . . . . . . . . . . . . . . . . . 7
Using special salt . . . . . . . . . . . . . . . . 7
Detergents with salt component . . . . . 7
Switching off water softening system . 7
Rinse aid %. . . . . . . . . . . . . . . . . . . . . . . 8
Setting amount of rinse aid . . . . . . . . . 8
Switching off rinse aid refill indicator . . 8
Utensils . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Not suitable . . . . . . . . . . . . . . . . . . . . . 9
Glass and utensil damage . . . . . . . . . 9
Loading the dishwasher . . . . . . . . . . . 9
Unloading the dishwasher . . . . . . . . . 9
Cups and glasses . . . . . . . . . . . . . . . . 9
Pans . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cutlery basket . . . . . . . . . . . . . . . . . . 10
Folding spikes . . . . . . . . . . . . . . . . . 10
Small accessories holder . . . . . . . . . 10
Knife shelf . . . . . . . . . . . . . . . . . . . . . 10
Adjusting the height of the basket . . 11
Detergent . . . . . . . . . . . . . . . . . . . . . . . . 12
Adding detergent . . . . . . . . . . . . . . . 12
Combination detergent . . . . . . . . . . . 13
Overview of programmes . . . . . . . . . . 14
Programme selection . . . . . . . . . . . . 14
Information for test institutes . . . . . . . 14
Additional options . . . . . . . . . . . . . . . . 15
Express Wash . . . . . . . . . . . . . . . . . . 15
Half load . . . . . . . . . . . . . . . . . . . . . . 15
Hygiene . . . . . . . . . . . . . . . . . . . . . . . 15
Intensive zone . . . . . . . . . . . . . . . . . . 15
Extra drying . . . . . . . . . . . . . . . . . . . . 15
Washing the dishes . . . . . . . . . . . . . . . 15
Programme data . . . . . . . . . . . . . . . . 15
Aqua sensor . . . . . . . . . . . . . . . . . . . 15
Switching on the appliance . . . . . . . . 15
Remaining running time display . . . . 15
Timer programming . . . . . . . . . . . . . . 16
End of programme . . . . . . . . . . . . . . 16
Switching off the appliance . . . . . . . . 16
Interrupting the programme . . . . . . . . 16
Terminating the programme . . . . . . . 16
Changing the programme . . . . . . . . . 16
Intensive drying . . . . . . . . . . . . . . . . . 17
Maintenance and care . . . . . . . . . . . . . 17
Overall condition of the machine . . . . 17
Special salt and rinse aid . . . . . . . . . 17
Filters . . . . . . . . . . . . . . . . . . . . . . . . . 18
Spray arms . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . 19
Waste water pump . . . . . . . . . . . . . . . 19
... when the appliance is switched on 19
... on the appliance . . . . . . . . . . . . . . 20
... during the wash cycle . . . . . . . . . . 20
... on the utensils . . . . . . . . . . . . . . . . 21
Customer service . . . . . . . . . . . . . . . . 22
Installation . . . . . . . . . . . . . . . . . . . . . . 22
Safety instructions . . . . . . . . . . . . . . . 22
Delivery . . . . . . . . . . . . . . . . . . . . . . . 23
Technical specifications . . . . . . . . . . . 23
Installation . . . . . . . . . . . . . . . . . . . . . 23
Waste-water connection . . . . . . . . . . . 23
Fresh water connection . . . . . . . . . . . 23
Electrical connection . . . . . . . . . . . . . 24
Removing the appliance . . . . . . . . . . 24
Transportation . . . . . . . . . . . . . . . . . . 24
Protection against frost
(Emptying the appliance) . . . . . . . . . . 24
Waste disposal . . . . . . . . . . . . . . . . . . . 25
Packaging . . . . . . . . . . . . . . . . . . . . . 25
Old appliances . . . . . . . . . . . . . . . . . 25

en
4
Delivery
– Check the packaging and dishwasher
immediately for damage caused in
transit. Do not switch on a damaged
appliance, but contact your supplier.
– Please dispose of the packaging
material in an environmentally friendly
manner.
– Do not let children play with packaging
and its parts. There is a risk of
suffocation from collapsible boxes and
film.
Installation
Read the “Installation” chapter to learn
how to install and connect the appliance
correctly.
In daily use
– Use the dishwasher only in the
household and only for its designed
purpose: for washing domestic dishes.
– Children or people whose physical,
sensory or mental abilities prevent
them from using the appliance safely
must not use this appliance without
supervision or instruction
by a responsible person.
– Do not lean or sit on the open door.
The appliance could tip.
– Please note that free-standing
appliances may tip over if the baskets
are overloaded.
– Do not add any solvents to the washing
chamber. Danger of explosion!
– Open the door carefully when the
programme is still running. There is a
risk of hot water spraying out of the
appliance.
– To prevent injuries, e. g. caused by
stumbling, open the dishwasher only
briefly in order to load and unload
the dishwasher.
– Read and observe the safety
information and instructions for use on
the packaging for cleaning and rinsing
agents.
ã=Warning
Knives and other utensils with sharp points
must be placed in the cutlery basket with
the points downwards or horizontally on
the knife shelf *.
* depending on model
Children in the household
– If fitted, use the childproof lock. An
exact description can be found in the
back of the envelope.
– Do not allow children to play with or
operate the appliance.
– Keep children away from detergents
and rinse aid. These may cause
chemical burns in the mouth, throat
and eyes or asphyxiation.
– Keep children away from open
dishwasher. The water in the rinsing
compartment is not drinking water and
could contain detergent residue.
Ensure that children do not place
fingers in the tablet collecting tray 12.
Small fingers could become caught in
the slots.
– If the appliance is installed at eye-level,
ensure when opening and closing the
door that children are not caught or
crushed between the appliance door
and the cupboard door situated below.
Childproof lock (door lock) *
The description of the childproof lock is at
the back in the envelope.
* depending on model
Damage
– The appliance may be repaired and
opened up by a technician only. To do
this, disconnect the appliance from the
power supply. Pull out the mains plug
or switch off the fuse. Turn off the tap.
Disposal
– Make redundant appliances unusable
to prevent subsequent accidents.
– Dispose of the appliance in an
environmentally friendly manner.
Safety instructions

en
5
ã=Warning
Children could become locked in the
appliance (risk of suffocation) or find
themselves in other dangerous situations.
Therefore: Pull out the mains plug, sever
and dispose of the power cord. Destroy
the door lock so that the door can no
longer be closed.
Diagrams of the control panel and the
interior of the appliance can be found in
the envelope at the front.
Individual positions are referred to in the
text.
Control panel
* depending on model
** Number depending on model
Appliance interior
* depending on model
Getting to know your
appliance
(ON/OFF switch
0Door opener
8Programme selector
@START button
HDigital display
PTimer programming *
XAdditional options **
`Rinse aid refill indicator
hSalt refill indicator
)" Display “Check water supply”
1" Top basket
1* Knife shelf *
12 Tablet collecting tray
1: Top spray arm
1B Bottom spray arm
1J Dispenser for special salt
1R Filters
1Z Cutlery basket
1b Bottom basket
1j Dispenser for rinse aid
9" Detergent dispenser
9* Lock for detergent dispenser
92 Rating plate
