ProFitter RMC-FA300PF Instructions for use

Operating Instructions & Parts Manual RMC-FA300PF
ProFitterTM
Propane Construction Heater
Description
ProFitterTM Model RMC-FA300PF heaters are 300,000 BTU/Hr construction heaters.
This heater uses propane gas for combustion, and electricity to run the fan. It
is primarily intended for temporary heating of well-ventilated buildings under
construction, alteration or repair. This heater should be utilized in sheltered, well-
ventilated areas, but never in occupied dwellings.
C US
C US
Output Rating Maximum Fuel Regulator
Model BTU/Hr Fuel Consumption Ignition Outlet Pressure
RMC-FA300PF 300,000 Propane Vapor Only 13.9 lb/h Direct Spark, Interrupted 7-10 PSIG
Hot Air Output Minimum Supply Maximum Supply Size
Model Approx. (CFM) Motor Pressure to Regulator Pressure to Regulator L x W x H (Inches) 3VE59C
RMC-FA300PF 0.085 HP 25 PSIG (For purposes Max Bottle Pressure 33.7 x 12.6 x 20.5
1,720 RPM of input adjustment)
Table of Contents Page
Description .......................1
Specifications......................1
Unpacking ....................... 1
General Safety Information ........1-3
Theory of Operation................3
Installation......................3-5
Ventilation........................5
Operation ........................6
Maintenance ....................5-6
Storage ..........................6
Wiring Diagram....................6
Repair Parts Illustration
and Parts List ....................8-9
Troubleshooting Chart .............10
Warranty ........................10
Unpacking
1. Unpack all materials used to protect
the heater inside of carton. Retain
plastic caps attached to exposed
fittings for use during storage.
2. Remove heater, accessories and all
hardware from carton.
3. Inspect all items for damage that may
have occurred during shipment.
GENERAL HAZARD
WARNING
FAILURE TO
COMPLY WITH THE PRECAUTIONS AND
INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS
BODILY INJURY AND PROPERTY LOSS,
OR DAMAGE FROM THE HZARARDS OF
FIRE, EXPLOSION, BURN. ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/
OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND
AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER
INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABELS, ETCETERA, CONTACT
THE MANUFACTURER.
General Safety Information
IMPORTANT: Be sure to read and
understand all cautions and warnings,
before operating this heater. Keep
this instruction manual for future
reference, and use it as a guide to safe
and proper operation of the heater.
Various precautions appear throughout
this manual. Please review and pay
close attention to them. Below is an
explanation of the various levels of
caution required while operating this
heater.
DANGER
Indicates an imminently
hazardous situation
which, if not avoided, WILL result in death
or serious injury.
WARNING
Indicates a potentially
hazardous situation
which, if not avoided, COULD result in
death or serious injury.
CAUTION
Indicates a potentially
hazardous situation
which, if not avoided, MAY result in minor
or moderate injury.
FIRE, BURN,
INHALATION, AND
EXPLOSION HAZARD, KEEP SOLID
COMBUSTIBLES, SUCH AS BUILDING
Model Electrical Input Amperage
RMC-FA300PF 120 V, 60 Hz 0.65
Electrical Specifications
General Specifications
(6.3 kg/h)
(85.6 x 32 x 52.1 cm)
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Specifications
Printed in China
Figure 1 – Model RMC-FA300PF
E
N
G
L
I
S
H
E
S
P
A
Ñ
O
L
F
R
A
N
Ç
A
I
S
ANS Z83.7-2017 CSA 2.14-2017
CONSTRUCTION HEATER
IMLPF300PF - LCU

2
ProFitterTM Operating Instructions and Parts Manual RMC-FA300PF
ProFitterTM
Propane Construction Heater
CSA 2.14b-2009, ANS Z83.7b-2009.
MATERIALS, PAPER OR CARDBOARD, A SAFE
DISTANCE AWAY FROM THE HEATER AS
RECOMMENDED BY THE INSTRUCTIONS.
NEVER USE THE HEATER IN SPACES WHICH
DO OR MAY CONTAIN VOLATILE OR
AIRBORNE COMBUSTIBLES, OR PRODUCTS
SUCH AS GASOLINE, SOLVENTS, PAINT
THINNERS, DUST PARTICLES OR UNKNOWN
CHEMICALS.
WARNING
This product and the fuels used to
operate this product (liquid propane),
and the products of combustion of
such fuels, can expose you to chemicals
including benzene, which is known to
the State of California to cause cancer
and reproductive harm.
For more information go to
www.p65Warnings.ca.gov
Using this heater in a
residential garage
requires that the heater is positioned
so that it is protected against any possible
damage by a moving vehicle, etc. It must be
positioned so that the base of the heater is
no less than 18 in (450 mm) above the
garage floor or 8 ft (2450 mm) in repair
garages. The heater must be placed on a
stable surface. Do not place it on a chair,
ladder, etc. Raising the heater will reduce
BUT NOT eliminate the possibility of lighting
the vapor of any flammable liquids which
may be improperly stored or accidentally
spilled. If the smell of gasoline is present,
DO NOT operate this heater until the area
has been properly ventilated.
Not for home or rec-
reational vehicle use.
The heater is designed and approved
for use as a construction heater
under ANS Z83.7 CSA 2.14. It is hard
to anticipate every use which may
be made of this heater. CHECK WITH
YOUR LOCAL FIRE SAFETY AUTHORITY
IF YOU HAVE QUESTIONS ABOUT
APPLICATIONS.
Other standards govern the use of fuel
gases and heat producing products in
specific applications.
Your local authority can advise you
about these.
IMPORTANT: READ THIS USER’S
MANUAL CAREFULLY AND
COMPLETELY BEFORE TRYING TO
OPERATE OR SERVICE THIS HEATER.
IMPROPER USE OF THIS HEATER CAN
CAUSE SERIOUS INJURY OR DEATH
FROM FIRE, EXPLOSION AND CARBON
MONOXIDE POISONING.
This is a direct-fired forced air
construction heater for either indoor
construction or outdoor use. Its
intended use is primarily the temporary
heating of buildings or structures under
construction, alteration or repair. All
the products of combustion generated
by the heater are forced through the
heater and released into the area
being heated. This heater operates
at approximately 98%+ combustion
efficiency but still produces a small
amount of carbon monoxide. Humans
can tolerate small amounts of carbon
monoxide for short periods. Carbon
monoxide can build up in a heated
space and failure to provide adequate
ventilation could result in poisoning or
death.
For either indoor or outdoor use.
Adequate ventilation shall be provided
in accordance with OSHA 29 CFR
1926.154, Safety Requirements for
Temporary and Portable Space Heating
Devices and Equipment ANSI A10.10,
ANSI 223.1 / NFPA 54, Liquified
Petroleum Gas Code, NFPA 58 or the
National Gas and Propane Installation
Code, CAN B149.1 as appropriate.
IMPORTANT SAFETY INFORMATION
• Children should be carefully
supervised, when they are in the area.
• Always maintain proper clearance
from combustible materials. Minimum
clearance from combustibles:
Side - 24” (61cm); Top - 72” (1.8 m);
Front - 96” (2.4 m). Floor - combustible.
Not for use on finished floors.
• Heater must be placed on level and
stable surface.
• Never place anything including clothes
or other flammable items on the heater.
• The appliance area shall be kept clear
and free from combustible materials,
gasoline and other flammable
vapours and liquids.
• Do not modify or operate a heater
which has been modified.
• Adequate clearance for accessibility
and for combustion & ventilation air
supply must be maintained at all
times when the heater is operating.
• Service and repair should be done by
a qualified service person. The heater
should be inspected before each use
and at least annually by a qualified
person. More frequent cleaning may
be required as necessary. Do not service
while hot or operating.
• Never connect heater to an
unregulated gas supply.
• The heater is shipped from the
factory for LP(Propane) gas. This heater
is for use with propane gas only, do
not convert heater to any other gas.
Installation must conform to local
codes or, in the absence of local codes,
with the standard for the Storage and
Handling of Liquefied Petroleum Gases
ANSI/NFPA 58 and the Natural Gas and
Propane Installation Code CSA B149.1
• The minimum and maximum inlet
pressures to the regulator from the
gas tank are 5 psi and bottle pressure,
respectively. Use only the regulator
& hose assembly provided with the
heater. Inspect the regulator/hose
assembly prior to each use of the
heater. If there is excessive abrasion
or wear, or hose is cut, replace with
regulator/hose assembly listed on the
parts list prior to using this heater.
• Gas supply connections should be
checked using a 50/50 solution of liquid
dish soap and never use a flame to
check for gas leaks.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

3
Model RMC-FA300PF
ProFitterTM Operating Instructions and Parts Manual
• The electrical connection & grounding
must comply with National Electrical
Code. ANSI/NFPA 70 or in Canada CSA
C22.1, Canadian Electrical Code, Part 1.
Use only a properly grounded three (3)
prong receptacle.
• Do not restrict inlet or outlet by any
means. The flow of combustion and
ventilation air is not to be obstructed.
• This heater should not be directed
toward any propane-gas container
within 20 ft (6 m). The heater must be
located at least 6 ft. (1.83 m) in the U.S.;
or (ii) 10 ft. (3 m) in Canada, from any
propane gas container.
• The propane cylinder supply system
must be arranged to provide for vapour
withdrawal from the operating cylinder.
• This heater is not to be used with
external thermostats, timers or other
devices that control or alter electrical
supply to the heater.
• Installation of this Appliance at
altitudes above 2000 ft. (610 m) shall be
in accordance with local codes, or
in the absence of local codes the,
National Fuel Gas Code, ANSI Z223.1 /
NFPA 54, or National Standard of
Canada, Natural Gas and Propane
Installation Code, CSA B149.1.
Motor and fan must be
running before lighting,
during operation and at shutdown, in order
to prevent a flame-out condition which could
result in personal injury or property
damage.
• Do not adjust regulator below 7 PSIG
or above 10 PSIG
Theory of Operation
FUEL SYSTEM
The hose/regulator assembly runs from
the propane supply to the heater itself.
After the gas runs through the hose
and regulator, it passes through the
solenoid valve and out the nozzle into
the combustion chamber.
AIR SYSTEM
The internal motor turns the fan, which
pushes air around and through the
combustion chamber. Here the air is
heated and provides a constant stream
of warmth.
IGNITION SYSTEM
The spark module sends voltage to the
ignitor. The ignitor ignites the fuel and
air mixture.
SAFETY CONTROL SYSTEM
This system shuts the heater down
if the flame is extinguished. The fan
and motor will continue to operate,
butthere will not be any heat.
PROPANE SUPPLY
All propane gas and tanks are to be
provided by the user.
This heater should only be used with
a tank that has a vapor withdrawal
system. Refer to the Standard of
Storage and Handling of Liquefied
Petroleum Gas, ANSI/NFPA 58, Chapter
5. Your local fire department or library
will have this information.
Two factors will dictate how much
propane is used from each tank:
1. The amount of gas in each tank.
2. The surrounding air temperature at
each tank.
The chart below shows how many tanks
should be used at a given temperature.
This heater should not be operated with
a tank smaller than 100 pounds.
Average
Temperature
at Tank Location
40
32
20
10
0
-10
-20
Number
of Tanks
3
Use larger tank
Use larger tank
Use larger tank
Use larger tank
Use larger tank
Use larger tank
Use larger tank
°F
40
32
20
10
0
-10
-20
°C
4.44
0
-6.67
-12.22
-17.78
-23.33
-28.89
As the temperature drops, less gas is
vaporized, so a larger tank may be
necessary in very cold weather. Never
operate this heater with a tank smaller
than 100 pounds. Your local propane
dealer can help you select the proper
tank size and configuration.
VENTILATION
For either indoor or outdoor use.
Adequate ventilation shall be provided
in accordance with OSHA 29 CFR
1926.154, Safety Requirements for
Temporary and Portable Space Heating
Devices and Equipment ANSI A10.10,
ANSI 223.1 / NFPA 54, Liquified
Petroleum Gas Code, NFPA 58 or the
National Gas and Propane Installation
Code, CAN B149.1 as appropriate.
Ignitor Fan
Motor
Cool Air In (Back)
Clean Heated
Air Out (Front)
Combustion Chamber
Air For Heating Air For Combustion
PCB Control
Nozzle Solenoid Valve
Spark Module (Spark Ignitor)
Hose / Regulator
Assembly
On/Off Switch
Power Cord
Figure 2 – Cross Section Operational View
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
RMC-FA300PF
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

4
ProFitterTM Operating Instructions and Parts Manual 3VE59C
Figure 4 – Hose and Inlet Connector
Hose
Inlet Connector
Installation
Review and under-
stand all of the
warnings in the Safety Information
Section on pages 1–3. They are required to
operate this heater safely. Follow all local
and state codes when operating this
heater.
After installing
all gas piping, and
making the proper connections, be sure
to check for leaks. Apply a 50/50
mixture of dish soap and water to
all connections. Bubbles forming are
evidence of a leak. Be sure to correct
all leaks at once!
1. Provide propane supply system as
outlined above.
2. Connect POL fitting on hose/regulator
assembly to propane tank(s) by turning
the fitting COUNTERCLOCKWISE
into the threads on the valve on top of
the tank. Finish by tightening firmly,
using 7/8” (22.2 mm) wrench.
IMPORTANT: To protect the regulator
from weather damage, tighten the
fitting with the black adjustment knob
pointing down.
3. Connect female end of hose to the
inlet connector of the heater, and
tighten firmly with a wrench.
IMPORTANT: Use extra piping or hose
if necessary to connect the heater to the
gas supply, but always use the regulator
supplied with the heater.
4. Open supply valve on propane tank(s)
SLOWLY.
NOTE: If this valve is not opened slowly,
the excess flow check valve on the
tank will interrupt the gas flow. If this
happens, close the supply valve and
reopen slowly.
5. Adjust the regulator to between 7
and 10 PSIG.
Do not adjust the
regulator above 10
PSIG or below 7 PSIG, or the heater may
not operate properly.
6. Check all connections for leaks.
Never use an open
flame to check for
leaks. Apply a 50/50 solution of liquid
dish soap and water to check all
connections. Correct all leaks
immediately.
7. Close propane supply valve.
Ventilation
Always follow the
minimum fresh air
ventilation requirements. If these
guidelines are not followed, carbon
monoxide poisoning can occur. Always
provide proper amounts of fresh air
before operating this heater.
Provide at least three square feet (0.28 m²)
of fresh, outside air for each 100,000 BTU/
Hr of rating. This heater requires
a fresh air opening of at least 11.25 square
feet (1.05 m²). Provide extra fresh air if
more heaters are being used.
WARNING
Air Quality Hazard
• Do not use this heater for heating
human living quarters.
• Use of direct-fired heaters in the
construction environment can result in
exposure to levels of CO, CO2, and
NO2 considered to be hazardous to
health and potentially life threatening.
• Do not use in unventilated areas
• Know the signs of CO and CO2
poisoning
- Headaches, stinging eyes
- Dizziness, disorientation
- Difficulty breathing, feels of being
suffocated
• Proper ventilation air exchange (OSHA
29 CFR 1926.57) to support combustion
and maintain acceptable air quality
shall be provided in accordance with
OSHA 29 CFR Part 1926.154, ANSI
A10.10 Safety
Requirements for Temporary and
Portable Space Heating Devices and
Equipment used in the Construction
Industry or the Natural Gas and Propane
Installation Codes CSA B149.1
• Periodically monitor levels of CO, CO2
and NO2 existing at the construction
site – at the minimum at the
start of the shift and after 4 hours.
• Provide ventilation air exchange,
either natural or mechanical, as
required to maintain acceptable indoor
air quality
Figure 3 – Regulator with Vent Pointing
Down
POL Fitting
Supply
Valve Hose
Regulator
Propane/LP
Tank
Adjustment Knob
(Pointing Down)
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
ProFitterTM
Propane Construction Heater
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

5
E
N
G
L
I
S
H
®
Models XXXXX, XXXXX and XXXXX
Dayton Operating Instructions and Parts Manual
For Repair and service call 1-866-632-9866
USA 8-Hr Time weighted average
(OSHA 29 CFR 1926.55 App A)
CO 50 ppm
CO25000 ppm
NO2
USA – Ceiling Limit
(Short Term Exposure Limit = 15 minutes)
CO
CO2
NO25 ppm
Canada 8-hr time weighted average
WorkSafe BC OHS Guidelines Part 5.1
and Ontario Workplaces Reg 833
25 ppm
5000 ppm
3 ppm (Reg 833)
Canada STEL (15 minutes Reg 833/1 hour
WSBC) WorkSafe BC OHS Guidelines Part
5.1 and Ontario Workplaces Reg 833
100 ppm
15000 ppm (WSBC)
30000 ppm (Reg 833)
1.0 ppm (WorkSafeBC)
5.0 ppm (Reg 833)
• Ensure that the ow of combustion and ventilation air exchange cannot become obstructed.
• As the building ‘tightens up’ during the construction phases ventilation may need to be increased.
Model RMC-FA300PF
ProFitterTM Operating Instructions and Parts Manual
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
RMC-FA300PF

6
E
N
G
L
I
S
H
Dayton Operating Instructions and Parts Manual
Dayton®(Product Name)
XXXXX, XXXXX and XXXXX
For Repair and service call 1-866-632-9866
Operation
Review and under-
stand all of the
warnings in the Safety Information
Section, on pages 1–3. They are required
to operate this heater safely. Follow all
local and state codes when operating this
heater.
TO START HEATER
1. Follow all safety, installation and
ventilation instructions in this
manual.
2. Position the heater on a stable and
level surface, and be sure that no
drafts blow into the inlet or outlet
of the heater.
3. Plug the power cord of the heater
into a three hole grounded extension
cord. Be sure that the extension cord
is at least 6 feet long, and is UL listed.
EXTENSION CORD SIZE
REQUIREMENT
• Up to 50 feet (15.2 m) long, use 18
AWG rated cord.
• 51 to 100 feet (15.5 - 30.5 m) long,
use 16 AWG rated cord.
• 101 to 200 feet (130.8 - 61 m) long,
use 14 AWG rated cord.
4. Plug extension cord into a 120 volt/60
hertz, three hole grounded outlet.
5. Open supply valve on propane tank(s)
SLOWLY.
NOTE: If this valve is not opened slowly,
the excess flow check valve on the
tank will interrupt the gas flow. If this
happens, close the supply valve and
reopen slowly.
6. Adjust the regulator to between 7
and 10 PSIG.
NOTE: The higher regulator setting
will enable the heater to produce
more heat.
Do not adjust the
regulator above 10
PSIG or below 7 PSIG, or the heater
may not operate properly.
7. Turn on/off switch to the ON (I)
position. Heater will start within
twenty seconds.
NOTE: If the heater does not start
following this procedure, turn on/off
switch to OFF ( ) position and wait
five (5) minutes. This will allow the
safety control to reset, and you can try
to light the heater once again.
TO SHUT DOWN HEATER
1. Tightly close control valve on propane
tank(s).
2. Give the heater a few seconds to burn
the gas still left in the hose.
3. Turn on/off switch to the OFF
position.
4. Unplug extension cord from power
source.
TO RESTART HEATER
NOTE: If the safety control stops the
flow of gas to the heater, the motor will
continue to run. To restart the heater:
1. Turn on/off switch to the OFF ( )
position.
2. Wait five minutes, then turn switch to
the ON (I) position.
If heater does not restart:
• Check all control valves to assure that
they are open.
• Check the fuel level in the propane
tanks. If the level is too low, replace
the tank with a full one.
If heater still does not restart, contact
your nearest Service Center.
Maintenance
Do not attempt to
service the heater
while it is hot, operating or plugged
in. Severe burns or electrical shock
can occur.
1. Be sure to inspect the heater before
each use. Check for leaks using the
method described on Page 4. Repair
any leaks immediately.
2. Always keep heater clean. Clean
the heater annually, or as often as
needed to remove any dust or debris.
When the heater becomes dirty, wipe
it down with a damp cloth.
3. Keep the inside of the heater
free from foreign objects and
combustibles.
Maintenance (Continued)
4. Have the heater inspected annually
by a qualified service person.
5. Keep inside of heater free of foreign
objects and combustible materials.
SERVICE PROCEDURES
Never service heater
while hot, operating
or connected to the gas supply. Severe
burns or electrical shock may occur.
REMOVING PROTECTIVE COVER
1. Remove base lower at the bottom of
the heater.
2. Remove fan guard.
Fan Guard
Base
Base Lower
Figure 5 – Protective Cover Removal
FAN
ProFitterTM Operating Instructions and Parts Manual 3VE59C
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
ProFitterTM
Propane Construction Heater

7
Model RMC-FA300PF
ProFitterTM Operating Instructions and Parts Manual
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
RMC-FA300PF
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com
IMPORTANT: Always remove the fan
from the motor shaft before removing
the motor assembly from the heater.
This will help prevent damage to
the fan.
1. Remove base lower.
2. Remove fan guard.
3. Remove base.
4. Disconnect lead wires attached to
the motor.
5. Remove motor assembly.
6. Remove fan setscrew using a 1/8”
(3.2 mm) Allen wrench (see Figure 6).
Figure 6 – Fan Motor Shaft and Setscrew
Location
Setscrew
Fan
Motor Shaft
7. Using a soft cloth moistened with
kerosene or a cleaning solvent,
carefully clean the fan blades making
sure not to bend them.
8. Dry fan with clean cloth.
9. Making sure that the setscrew lines
up with the flat spot on the motor
shaft, replace fan as shown in Figure
7. Tighten setscrew firmly (be careful
not to overtighten).
10.Reconnect lead wires as shown in the
Wiring Diagram (Figure 8).
11. Reassemble base, fan guard and
base lower.
IGNITOR
The only maintenance necessary for the
ignitor is to be sure that the gap between
the electrodes is kept between .10” and
.15” (2.5. - 3.8 mm). The ignitor is accessible
through the combustion chamber.
Storage
Always disconnect the
heater from the
propane tanks when not in use.
1. Always store propane tanks in accor-
dance with Chapter 5 of the Standard
for storage and handling of Liquefied
Petroleum Gasses, ANSI/NFPA 58.
Follow all local codes.
2. Replace the plastic caps over the
fittings that were installed when you
originally unpacked your heater.
3. Store the heater in a safe, clean
and dry location. Do not store the
hose/regulator assembly inside the
combustion chamber of the heater.
4. When removing the heater from
storage, always check inside of the
heater for any foreign objects left
by spiders or small animals. Keep
the inside of the heater clean from
foreign objects and combustibles.

Gas
Valve
Yellow
White
Blue
White
Motor
Black
White
Red
White
Yellow
Green
Black
White
Line
Neut
Valve
Ground
Line Cord Ground
PCB Assembly
High Limit
Switch
on / off
Thermostat
Spark Plug
Black
Back
Pressure
Switch
Green
Black
Orange
White
8
ProFitterTM Operating Instructions and Parts Manual RMC-FA300PF
If any original wiring as supplied with the heater must be
replaced, it must be replaced with type AWG105°C wire or its
equivalent except as indicated (∗Type SF2-200, ∗∗SGI-250°C)
Figure 8 – Wiring Diagram
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
ProFitterTM
Propane Construction Heater
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com
Wiring Diagram

E
N
G
L
I
S
H
9
Notes
ProFitterTM Operating Instructions and Parts Manual RMC-FA300PF
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

8
RMC-FA300PF/DG/DGD
For Repair Parts, call 1-877-447-4768
24 hours a day – 365 days a year
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
Figure 9 – Repair Parts Illustration for Propane Construction Heater
6
1
3
42
5
25
27
28
32
29
31
30
33
34
35
36
38
39
42
37
40
41
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58 24
23
22
12
20
14
13 15
16
17 18 19
21
7
910
11
8
26
For Technical Support or Troubleshooting, Call: 1-877-447-4768
ProFitterTM & Dyna-GloTM Operating Instructions and Parts Manual
10
ProFitterTM Operating Instructions and Parts Manual RMC-FA300PF
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
For Repair Parts, call 1-877-447-4768
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
E
N
G
L
I
S
H
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

Model RMC-FA300PF
11
RMC-FA300PF
ProFitterTM Operating Instructions and Parts Manual
Repair Parts List for Propane Construction Heater
1 Inner Shell Assembly 2315586 1
2 Screw 2001355 6
3 Frame Holder 2315587 1
4 Screw 2001355 3
5 Nut 2000112 2
6 Sleeve 2315511 2
7 Thermal Switch 2201153 1
8 Screw 2001059 2
9 Nut 2305686 1
10 Spark Plug Assembly 2315582 1
11 Bolt 2001447 3
12 Burner Top 2315603 1
13 Inner Ring 2315602 1
14 Burner 2315601 1
15 Nut 2000121 3
16 Burner Tube Assembly 2315600 1
17 Outer Shell 2315575 1
18 Handle Assembly 2101447 1
19 Screw 2000416 2
20 Nut 2000384 2
21 Motor Assembly 2315590 1
22 Fan Assembly 2315592 1
23 Motor Support 2315584 1
24 Motor Bracket 2315591 1
25 Fan Guard 2315500 1
26 Screw 2001355 3
27 Thermostat Assembly 2201186 1
28 Screw 2000375 2
29 Clip 2301973 1
30 Screw 2000375 1
31 Nut 2000231 1
32 Capacitor 2201586 1
33 Bushing Strain Relief 2101633 1
34 Power Cord Assembly 2201163 1
35 Switch 2201549 1
36 Solenoid Valve 2315449 1
37 Screw 2001206 2
38 Connector Inlet 2315595 1
39 Fitting 2315596 1
40 Solenoid Valve Bracket 2315594 1
41 Screw 2000416 2
42 Nut 2000384 2
43 Back Pressure Switch 2201594 1
44 Base Lower 2315589 1
45 Screw 2001355 6
46 PCB Assembly 2201181 1
47 Screw 2001445 2
48 Nut 2000231 2
49 Base 2315588 1
50 Plastic Tube 2101052 1
51 Aluminum Tube Bracket 2315700 2
52 Screw 2001355 4
53 Aluminum Tube 2315699 1
54 Tubing Assembly 2315599 1
55 Nozzle Base 2315598 1
56 Nozzle 2315597 1
57 Knob 2101207 1
Regulator & Hose Assembly KR-126-10-31
Ref. Part
No. Description No. Qty.
Ref. Part
No. Description No. Qty.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Use only original
replacement parts. This
Heater must use design-
specific parts. Do not substitute or use
generic parts. Improper replacement parts
could cause serious or fatal injuries.
58 1
10 ft (3m)
KR-126-15-31
Regulator & Hose Assembly
15 ft (4.6m)
E
N
G
L
I
S
H
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com

12
RMC-FA300PF
ProFitterTM Operating Instructions and Parts Manual
Symptom Possible Cause(s) Corrective Action
Fan does not turn when
electrical connection is
made
Heater will not fire
Heater quits while
running
1. No electric power to heater
2. Fan blade contacts inside of heater
housing
3. Fan blade(s) bent
4. Fan motor defective
1. No spark at igniter
2. Improper spark gap
3. Bad electrode
1. Internal temperature too high causing
limit switch to shut down operation
2. Damaged control valve
3. Dust or debris build-up inside of heater
1. Check current to electric outlet. If voltage is
correct, check power cord and extension cord for
cuts and breaks
2. Be sure that housing is not damaged. Make sure
there are no obstructions to the fan
3. Straighten blade(s) to match others
4. Replace motor
1. Check igniter wire. Reattach or tighten if loose.
Check spark module. Replace if necessary. Check
all electrical components
2. Set gap to 0.08” (2 mm)
3. Replace spark plug
1. If the heaters output is restricted, internal tem-
perature becomes too high. Move heater away
from any obstructions
2. Replace control valve
3. Clean inside of heater
Troubleshooting Chart
Always be sure to follow proper maintenance procedures, by cleaning the heater once per month during regular
usage, and check spark gap at least once per season.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
ProFitterTM
Propane Construction Heater
E
N
G
L
I
S
H

LIMITED WARRANTY:
This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any
defect in materials and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at it’s option, will either
provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers
as directed by GHP Group, Inc., within one (1) year of retail purchase. (Shipping costs, labour costs, etc. are the responsibility of the purchaser.)
DUTIES OF THE OWNER:
This heating appliance must be operated in accordance with the written instructions furnished with this heater. This warranty shall not excuse
the owner from properly maintaining this heater in accordance with the written instructions furnished with this heater. A bill of sale, canceled
check or payment record must be kept to verify purchase date and establish warranty period. Original carton should be kept in case of warranty
return of unit.
WHAT IS NOT COVERED:
1. Damage resulting from use of improper fuel.
2. Damage caused by misuse or use contrary to the owners manual and safety guidelines.
3. Damage caused by a lack of normal maintenance.
4. Fuses
5. Use of non-standard parts or accessories.
6. Damage caused in transit. Freight charges on warranty parts or heaters to and from the factory shall be the responsibility of the owner.
This warranty does not imply or assume any responsibility for consequential damages that may result from the use, misuse, or the lack of
routine maintenance of this heating appliance. A cleaning fee and the cost of parts may be charged for appliance failures resulting from lack of
maintenance. This warranty does not cover claims which do not involve defective workmanship or materials. FAILURE TO PERFORM
GENERAL MAINTENANCE (INCLUDING CLEANING) WILL VOID THIS WARRANTY.
THIS LIMITED WARRANTY IS GIVEN TO THE PURCHASER IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE. THE
REMEDY PROVIDED IN THIS WARRANTY IS EXCLUSIVE AND IS GRANTED IN LIEU OF ALL OTHER REMEDIES. IN NO EVENT WILL
GHP GROUP, INC. BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not
allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.
CLAIMS HANDLED AS FOLLOWS:
1. Contact your retailer and explain the problem.
2. If the retailer is unable to resolve the problem, contact our Customer Service Dept. detailing the heater model, the problem, and proof
of date of purchase.
3. A representative will contact you. DO NOT RETURN THE HEATER TO GHP GROUP,INC. unless instructed by our Representative.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TO REGISTER THE WARRANTY ON YOUR HEATER, PLEASE FILL OUT THIS CARD COMPLETELY
AND MAIL WITHIN 14 DAYS FROM DATE OF PURCHASE OR REGISTER ON-LINE AT www.ghpgroupinc.com
NAME: ______________________________________ PHONE: ( ) __________________ EMAIL: ____________________________
ADDRESS: _________________________________ CITY: ______________________________ STATE: __________ ZIP: ____________
MODEL: ____________________ SERIAL #: _______________________________________ DATE PURCHASED: __________________
DEALER PURCHASED FROM: ____________________________________________ TYPE OF STORE: __________________________
CITY & STATE WHERE PURCHASED: ______________________________________________ PRICE PAID: _______________________
Please Take a Minute To Give Us Your Answers To The Following Questions.
All Responses Are Used Solely For Market Research And Are Held In Strict Confidence.
Who primarily decided this purchase? Male Female 18-24 25-39 40-59 60 and over
Purpose of Purchase? _______________________________________________________________________________________________
Do you own any other portable heaters? Yes No If yes, type____________________________brand_____________________
How do you intend to use your new heater? Construction Site Farm Warehouse/Commercial Garage/Outbuilding Other
How did you become aware of this heater? In-Store Display Newspaper Ad Magazine Ad Friend/Relative
TV Commercial Store Salesperson Other ___________________________
What made you select this heater? Style Size/Portability Price Package Brand Other ___________________
Do you: own rent Would you recommend this heater to a friend? Yes No
Please give us your comments:________________________________________________________________________________________
THANK YOU FOR COMPLETING THIS FORM!
Information will be held confidential.
WARRANTY

WARRANTY REGISTRATION
IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14)
days of date of purchase. You can also register your warranty on the internet at
www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card
for your records.
SAVE THIS CARD!
Place
Postage
Stamp
Here
GHP Group, Inc.
8280 Austin Avenue
Morton Grove, IL 60053-3207
GHP Group, Inc.
8280 Austin Ave.
Morton Grove, IL 60053-3207
Tel: [phone]
www.ghpgroupinc.com
8280 Austin Avenue
Morton G rove , IL.
6 0 053-3207
Tel: ( 847 ) 324 - 5900
Fax: ( 847 ) 324 - 5901
Toll Free (877) GHP Group
( 8 7 7 ) 44 7 - 4 7 6 8
www.ghpgroupinc.com
GHP
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
Tel: [phone]
www.ghpgroupinc.com
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
