EUROM RAD 2000 Oilfree User manual

(page 36)
Instruction manual
Instruktionsbok (sida 48)
RAD 2000 Oilfree Wifi
Art.nr. 363913 & Art.nr. 363920 (Swiss plug)
This product is only suitable for well insulated spaces or occasional use.
Olievrije radiator / Ölfreie Radiator / Oil-free radiator / Radiateur sans huile / Oljefri radiator /
Radiátor bez oleje / Radiátor bez oleja / Rulant fără ulei
17-07-2019

2
Table VI:
Model identifier for electric local space heaters
Model
number:
RAD 2000 Oilfree Wifi
Item
Symbol
Value
Unit
Heat output
Nominal heat out-put
Pnom
kW
Minimum heat output
(indicative)
Pmin
kW
Maximum continuous heat
output
Pmax,c
kW
Auxiliary electricity consumption
At nominal heat output
elmax
kW
At minimum heat output
elmin
kW
In standby mode
elSB
kW
Type of heat input, for electric storage local space heaters only (single select)
manual heat charge control, with integrated thermostat
Yes No
manual heat charge control with room and/or outdoor temperature feedback
Yes No
electronic heat charge control with room and/or outdoor temperature feedback
Yes No
fan assisted heat output
Yes No
Type of heat output/room temperature control (single select)
single stage heat output and no room temperature control
Yes No
Two or more manual stages, no room temperature control
Yes No
with mechanic thermostat room temperature control
Yes No
with electronic room temperature control
Yes No
electronic room temperature control plus day timer
Yes No
electronic room temperature control plus week timer
Yes No
Other control options (multiple selections possible)
room temperature control, with presence detection
Yes No
room temperature control, with open window detection
Yes No
with distance control option
Yes No
with adaptive start control
Yes No
with working time limitation
Yes No
with black bulb sensor
Yes No
Contact details
EUROM-KOKOSSTRAAT 20-8281JC-GENEMUIDEN-NETHERLANDS

26
Thank you
Thank you very much for choosing for a EUROM device. You have made a good
choice! We hope you will be satisfied about its functioning. To get maximum profit
from your product, it is important to read this manual attentive and totally before
use, and to understand what is written. Read especially the safety instructions:
they are there to protect you and your environment. Keep the manual in a safe
place for future reference. Store also the package: that is the best protection for
your product in times of no-use. And if you at any time pass the appliance on, pass
on the manual and package too.
We wish you a lot of fun with the Rad 2000 Oilfree Wifi!
Eurom
Kokosstraat 20
8281 JC Genemuiden (NL)
[email protected] / www.eurom.nl
This manual has been complied with the utmost care. Nevertheless, we reserve the
right to optimize this manual at any time and to adjust it technically. The image
used may differ.
___________________________________________________________
Symbol Explanation
Do not cover the device
Technical data
Supply voltage
220-240V~50Hz
Maximum capacity
2000 W
Settings
1000-2000 W
Timer
+
Thermostat
+
Dimensions
42,8 x 25,1 x 63,6 cm
Weight
5,7 kg

27
Warning electric cables
Safety warning - general
1. Read the user instructions carefully and completely before using
(and installing) this device. Keep the instruction leaflet somewhere
safe so that you can consult it and pass it on in future.
2. Before use, check your new device (including cable and plug) for
any visible damage. Never use a damaged device but take it back
to the supplier for a replacement.
3. In the event of incorrect usage or installation, there is a risk of
electric shocks and/or a fire hazard.
Warnings device position
1. Only use the device when the wheels have been installed. Using the
device without wheels creates a significant risk of fire. Always
remove the plug from the socket if you are installing/removing.
2. This device is not suitable for wall or ceiling installation.
3. Do not use this device in the immediate vicinity of a bath, shower
or swimming pool.
4. This device is not suitable for use in damp spaces such as
bathrooms, wash rooms etc. Never locate the device near water-
points and reservoirs (tap, bath, shower, toilet, sink, swimming
pool, etc.). Make sure that the device cannot fall into water and
that it cannot be penetrated by water. If the device falls into water
make sure you remove the plug from the socket! Do not use a
device that is wet inside but take it to be repaired. Never immerse
the device, cable or plug in water or any other fluid and never touch
device with wet hands.
5. The air around the device must be able to circulate freely. Never
install it too close to walls or large objects and never under a shelf,
cupboard, curtains or similar. When locating the device, make sure
you have the following minimum free space:
Front, minimum free space 50 cm
Back, minimum free space 50 cm
Sides, minimum free space 50 cm
Top, minimum free space 100 cm
6. Always place the unit on a sturdy, flat horizontal surface
7. The base on which the device is placed must not be made of
flammable materials. It must be resistant to temperatures of at
least 125°C without burning, melting, deforming or bursting into

28
flames. Check regularly to ensure that the surface is not
overheating; this could be dangerous!
8. Never place the device on surfaces such as beds or deep-pile carpet
as openings could be blocked.
9. Do not place the device near an open window as rain could blow in;
do not place on wet surfaces and avoid any liquids being spilt
nearby. Do not place the device behind a door or along a walking
route to avoid accidental trips.
10. Do not place the device near, under or facing an electrical socket
and not in the vicinity of an open fire or heat source.
11. Do not use the device nearby or facing furniture, curtains, paper,
clothing, bedding or other flammable materials. Keep at least 1
metre from device!
12. Do not use the heater outdoors or in areas that are smaller than
15m³.
13. The device contains hot and/or glowing and sparking components.
Do not, therefore, use where fuels, paint, flammable fluids and/or
gases are stored. Do not use the device in an environment that
poses a fire risk, e.g. near gas tanks, gas pipes or aerosols. This is
an explosion and fire risk!
Warnings - use
1. Do not use additions/accessories on the device that have not been
supplied or approved by the manufacturer.
2. Only use the device for its intended purpose and in the manner set
out in this instruction leaflet.
3. Some parts of this device will get very hot and could cause
burns. You must pay particular attention to children,
vulnerable persons and pets that are present near the
device. Never leave them alone with a working device.
4. Never cover or block the device; it will overheat and this could lead
to a fire risk. Never hang or place objects such as clothing,
blankets, cushions, paper, etc. on the device.
The minimum distance of 1 metre between the device and
flammable materials must always be applied.
Ventilation openings should never be blocked as this may pose a
fire risk. Never use the device to dry clothing or place anything on
it. Do not let anything lean against the device!
5. Do not set the device to come on automatically using a timer, clock
or other facility. You must always check for safe conditions before

29
using the fireplace! Never use the device with an external voltage
regulator such as a dimmer or similar, as this could be dangerous!
6. The device is exclusively intended for normal, household usage.
Only use for providing heat in your home.
7. The connection voltage and frequency, as given on the device, must
correspond to that of the socket to be used. The electrical socket to
be used must be an earthed connection. The electrical installation
must be protected via a 30 mA earth leakage circuit breaker. The
electrical socket that you are using must be to hand at all times in
order to be able to remove the plug from the socket in the event of
an emergency.
8. To avoid overloading and/or fuses being blown, do not use any
other equipment on the same socket or electrical group as the one
used for the device.
9. Unroll the electric cable for the device fully before inserting the plug
into the socket and ensure that the electrical cable does not come
into contact with the fireplace or get hot. Do not run the electrical
cable under carpet, cover with mats, runners or similar and do not
place in areas that are walked on frequently. Ensure that it cannot
be stepped on and that no furniture is placed on top of it. Do not
bend the electrical cable around sharp corners and do not roll up
too tightly after use! Prevent the electrical cable coming into
contact with oil, solvents and sharp objects. Check the cable and
plug regularly for damage. Do not bend or pinch the electrical cable
and do not wind it around the device; this could damage the
insulation!
10. The use of an extension cable is not advised as this can lead to
overheating and fire. If the use of an extension cable is
unavoidable, make sure that it is not damaged and that it is an
approved extension cable with a minimum diameter of 3x2,5mm²
and a minimum permitted capacity of 2500 Watt. Always fully
extend the cable in order to prevent overheating.
11. Only connect the device to a fixed socket. Do not use multi-plug
adapters or similar.
12. During use, the plug may begin to feel warm; this is normal. If it’s
really warm, there may be something wrong with the socket. Please
contact your electrician.
13. Always turn off the device and remove the plug from the power
socket: Never turn the device off using the plug!

30
14. Prevent foreign objects entering the radiation/ventilation or outlet
openings on the device. This may cause electric shock, fire or
damage.
15. Never leave a working device unattended but switch off and then
remove the plug from the socket.
16. Apart from manual use, this device can also be operated via an app
or timer. However you operate it, make sure that the safety
guidelines are taken into account at all times!
17. Always remove the plug from the socket when the unit is not in
use! Always remove plug by pulling on the plug itself; never pull on
the electrical cable!
18. This device gets hot during use. Never touch the device when it is
on or shortly thereafter; it could burn you.
19. Never operate the device with wet hands.
Who can use the device?
1. Children younger than 3 must be kept out of the vicinity of the
device unless they are continuously supervised.
2. Children between the ages of 3 and 8 may only switch the device
on or off if it is set up or installed at its usual location and they are
supervised or have received instructions regarding the safe use of
the device and understand the corresponding hazards. Children
between the ages of 3 and 8 may not insert the plug into the
socket, adjust the device settings or clean or maintain it.
3. This device can only be used by children from the age of 8 and
elderly persons and persons with diminished physical or mental
capacities or a lack of experience and expertise if they are
supervised or have received instructions regarding the safe use of
the device and understand the corresponding hazards.
4. Children may not clean or maintain the device without supervision.
5. Children may not play with the device.
Warnings for maintenance
1. Keep the device clean. Dust, dirt and/or deposits in the device often
lead to overheating. Ensure that this type of build-up is regularly
removed.
2. Always switch the device off, remove plug from socket and let the
device cool down before you:
- clean the device
- users maintain the device.
- touch or move the device.

31
3. Never switch the device on if you have noticed damage to the
device itself, the cable or plug or if it does not work properly,
makes strange noises, smells odd or you can see smoke, or if it has
fallen or shows any other signs of damage. Remove the plug from
the socket immediately. Take the entire device back to your
supplier or a recognised electrician to be checked and/or repaired.
Always ask for original parts to be used.
4. The device may only be opened and/or repaired by a competent
and qualified person. Do not carry our your own repairs as this
could be dangerous! Repairs carried out by unauthorised persons or
changes made to the device could damage the dust/waterproof
capacity of the device and will nullify the guarantee and the
manufacturer’s liability.
5. If the electrical cable is damaged, it must be replaced by the
manufacturer, their service department or somebody with similar
qualifications in order to prevent creating a hazard.
Failing to adhere to points 3, 4, 5, could lead to damage, fire and/or
personal injury. They will invalidate the guarantee and the supplier,
importer and/or manufacturer shall not be liable for the consequences.
Description
1. Grip
2. Display
3. Thermostat/Mode knob
4. Wifi/Standby knop
5. On/Off switch
6. Wheel support (x2) with swivel wheels
Installation, Location and Connection
Remove all packaging material and keep out of reach of children. After removing
packaging, check the appliance for damage or other signs that could indicate a
fault/defect/malfunction. In case of doubt, do not use the appliance, but contact
your vendor for inspection or replacement.
Turn the radiator upside-down (make sure you don’t scratch the paint or the
floor!)

32
Unscrew the 4 screws on the bottom of the stove, attach the two wheel supports
to the stove and screw these supports tightly, see illustration.
Return the heater to its upright position, wheels down.
Select a suitable location for the device taking into account all the
aforementioned warnings in this manual.
Warning: only use the heater when it is in an upright position, with the
wheels attached to the bottom (as pictured on the front of this booklet).
Any other position is dangerous!
Set-up and operation
Push the plug into an earthed socket.
Press the ON/OFF switch to start the heater; the heater will make a beep sound
once. The display shows .
Press the WiFi/Standby button to switch to the standard
heater setting:
-Ambient temperature 20°C
-Timer off
-Heating level: H3 (2000W)
To switch off, press the WiFi/Standby button and the heater will
stop operating. Now take out the plug from the socket.
Note: The heater always starts at the standard heater settings.
Note: A radiator cools down slowly. Therefore, give it sufficient
time before you touch it or move it (use the handle!).
Setting the temperature
Turn the MODE button to the desired temperature setting
between 5°C and 35°C. Clockwise increases the temperature, counter clockwise
decreases the temperature.
If you turn the MODE button completely counter clockwise, the temperature
drops to under 5°C. The heater now stands in the frost protection mode. The
display shows .
Setting the heating capacity
Press the MODE button once and subsequently turn it counter clockwise for
setting the heating capacity:

33
-H1=Use heating element 1=1000 W
-H2=Use heating element 2=1000 W
-H3=Use heating element 1+2=2000W
Press the MODE button once again and wait 5 seconds to confirm the desired
setting.
Setting the timer
Press the MODE button for at least 3 seconds to start the Timer mode. The
display shows .
Subsequently, turn the clock button clockwise to increase from 1 to 9 hours and
counter clockwise to reduce the timer.
Wait 5 seconds to confirm the desired setting.
When the Timer is set, the display shows the timer time and the temperature
set after several seconds.
WiFi and App operation
The heater can also be operated using an app. For that purpose, the heater must
be connected to a WiFi modem.
Download the Eurom Smart App via the QR-code below or search for ‘Eurom
Smart’ in the APP store or Google play.
Follow the downloaded instructions.
For more information about the App and how to connect to the App, see
http://www.eurom.nl/nl/manuals
Simultaneously, press the WiFi/Standby button and the MODE button for at
least 3 seconds in order to switch on the WiFi function.
The WiFi icon will start to flicker rapidly; the heater is now connected to the App
on your smart device.
To switch off the WiFi function, press the WiFi/Standby button and the MODE
button simultaneously once again for at least 3 seconds.
If the WiFi icon flickers slowly, press the WiFi/Standby button for at least 3
seconds and the icon will starts flickering rapidly.
Safety measures App
Safety and operating remotely
Your Eurom heater can be easily operated via the same WLAN, via another WLAN,
or via 3G or 4G mobile network. This enables you to operate the heater remotely
without directly supervising the heater. Be aware that also when you operate the
heater remotely, you have to observe all the safety measures included in the user
guide delivered with the appliance. Read and understand these safety measures
and make sure that you comply with all these measures when operating remotely.
