ProGear LCD-M5 User manual
DISPLAY MANUAL
LCD-M5 HAND CONTROL PANEL
OPERATION INSTRUCTIONS
ONLY TO BE ASSEMBLED BY A SKILLED BICYCLE MECHANIC.
Read all instructions carefully before using this product. Retain this owner’s manual for future reference.
TABLE OF CONTENTS
I. OUTER SHELL SIZE AND MATERIAL
II. FUNCTION DESCRIPTION
III. KEY INTRODUCTION
4
5
6
4
OUTER SHELL SIZE AND MATERIAL
I. OUTER SHELL SIZE AND MATERIAL
Outer shell material is ABS, Liquid crystal transparent window material is high hardness acrylic.
Transfer Ring Selection.
FRONT VIEW
SWITCH FRONT
VIEW
SWITCH SIDE
VIEW
56.4mm
86mm
18.15mm
48mm
48mm
43.85mm
22.2mm
93.4mm
6.4mm
31.8mm
22.2mm
SIDE VIEW
+
31.8mm stent is available
22.2mm, Ø25.4mm,
28.6mm
5
FUNCTION DESCRIPTION
II. FUNCTION DESCRIPTION
Speed display, power level display, power indicator, failure warning, total mileage,
single mileage, single driving time display.
Power switch control, 6Km/h point control, wheel diameter setting, maximum
speed setting, idle automatic hibernation time setting, backlight brightness
setting, voltage level setting.
All the contents of the display screen (full display in boot 1S).
Total mileage ODO, single mileage TRIP A, single mileage TRIP B, battery current
voltage VOL, current operating current CUR, remaining mileage RM; Instrument
boot time TM.
Walk boost mode.
PAS: Power le position: 0 ~ 9 Adjustable.
Battery
Show Content Introduction.
1. DISPLAY FUNCTION.
2. CONTROL - SETTING UP FUNCTIONS.
3. COMMUNICATION PROTOCOL: UART.
3.2 MULTIFUNCTIONAL DISPLAY AREA.
3.3 VEHICLE MODES.
3.1 BATTERY POWER DISPLAY.
6
KEY INTRODUCTION
III. KEY INTRODUCTION.
The specic combination of keys is as follows:
Press the button to use the brief.
Key operation is divided into short press and long press, and combination key
length press. Short press is used for rapid/frequent operations, such as the
specic key combination position as follows.
Short press , Help + 1.
Long press + Toggle speed display.
Short press , Help - 1.
1. When riding, you need to modify the power/speed
le, short press.
3. Toggle speed display
2. Toggle display data for multi-function areas during cycling,
short click. Single key length is mainly used to switch the mode / switch
state. Composite keys (long presses) are used to set parameters because the
operation is complex, which can reduce errors. (Short press does not make the
composite key, because it is easy to trigger mistakenly, so it is too dicult to do).
Specic operational explanations modify the power ratio / power le. For example:
7
III. KEY INTRODUCTION.
Static state of vehicles, long press
let go of cruise mode.
P16: Menu Interface, long press ve seconds, ODO clear zero.
Will enter 6KM/h cruise mode,
4. Set / Disable 6Km/h Cruise, Switch Headlight, ODO Clear Zero.
5. Switching liquid crystal display.
6. Toggle multi-function display area content.
7. Set Parameters.
If the current display is working, long press Will turn off the screen,
instead turn on the screen.
Short press , Can switch the value of the multifunction display area.
Long press + Will enter the parameter setting interface.
Parameters that can be set include, wheel diameter (in: inches), number of
magnetic steel, liquid crystal brightness, low pressure points, etc.
see settings: P01-P20.
Under Settings Interface:
can be short press or Set the value to perform a minimum -
precision unit value operation, you can also long press
or .
Continuous Fast Modify Parameters:
Short press , switch to next parameter, exit settings and save
parameters. If not operating, the modied parameters will automatically exit and
be saved after 8 seconds.
NOTE
Due to the upgrade of company products, the content of the
product will be different from the specications, but it will not
affect your normal use.
KEY INTRODUCTION
www.progearbikes.com.au
