ProLite LD1 User manual

LD1 & LD2 BOILING TOPS
Important Installation Information
The installer must ensure that installation of the unit(s) is in conformity with
regulations in force at the time. For the UK, particular attention requires to be paid
to:-
BS7671 IEE Wiring Reg lations
Electricity at Work Reg lations
Health and Safety at Work Act
Fire Preca tions Act
The unit has been E-marked on the basis of compliance with the Low Voltage and
EM Directives for the voltage stated on the data plate.
WARNING: THIS APPLIANCE MUST BE EARTHED!
Preventive Maintenance Contract
In order to obtain maximum performance from the equipment, we would recommend
that a maintenance contract be arranged with AFE Service Line . Visits may then be
made at agreed intervals to carry out adjustments and repairs. A quotation for this
service will be provided upon request. ontact AFE Service Line as detailed below:-
Tel: [phone] Fax: [phone]
Falcon Foodservice Eq ipment
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
e-mail: [e-mail]
T100317 Ref. 3

Fig re 1 - Front View
SECTION 1 - SITING
Dimensions
LD1 - 300mm (W) x 645mm (D) x 240mm (H) Power
Rating - 3kW
Weight - 10kg F se Rating - 13A
LD2 - 600mm (W) x 645mm (D) x 240mm (H) Power
Rating - 7kW
Both Models - Side/Rear Clearance - 20mm Vertical
Clearance - 900mm
The LD1 and LD2 have been designed in modular form
to allow countertop use or base unit mounting.
Free-standing and base models should be installed
upon a firm, level surface and adjustable feet are
provided for levelling purposes.
ounter units must be positioned upon a table, counter
or similar surface.
Vertical and horizontal clearances required from the top
and sides of a particular unit to any overlying
combustible surface (ie wall, partition, etc) are listed
above. Relevant fire regulations must be complied with.
Mo nting Co nter Units on the Oven
When mounting a counter unit upon a light duty oven, it
is recommended that units which carry liquids, i.e. fryers
and bain marie, are secured as follows:
Remove oven outer back panel and crown plate.
Position unit(s) which require to be secured upon the
oven.
Secure hob unit(s) to oven through side flange centre
holes into the threaded inserts in the base(s) of the hob
unit(s). Use fixings provided (packed separately) and
replace oven back panel.
The unit is now ready for electrical connection.
Mo nting Co nter Units pon a Hotc pboard
Light duty hotcupboards are designed to be used in
conjunction with counter models. Assembly is achieved
by means of two shouldered fixings being applied to the
underside of a top unit from inside a base appliance as
detailed in Figure 1.
SECTION 2 -
ELECTRICAL SUPPLY AND CONNECTION
Electrical ratings are as stated on the unit data plate.
This is based on standard UK specification at 230V -
240V
~
as appropriate. Wiring must be executed in accor-
dance with the regulations listed in this booklet.
WARNING! -
Each individ al appliance m st be earthed!
After completion of installation, the method of operation
should be demonstrated to the kitchen staff. The
isolating switch location, for use in an emergency or
during cleaning should also be pointed out.
LD1 Boiling Top
This model is designed to be connected to a single
phase A supply using the 2 metre mains lead fitted as
standard.
Wires are coloured in accordance with the following
code and should be connected to the plug as follows:
EARTH to terminal marked E or coloured GREEN or
GREEN/YELLOW.
NEUTRAL to terminal marked N or coloured BLA K.
LIVE to terminal marked L or coloured RED.
Units which receive power from a plug, adaptor or
distribution board must be individually protected by a
fuse with an appropriate rating.
For models with two mains leads, each lead requires to
be protected by a fuse with an appropriate rating.
Any replacement supply cable must be 1.5mm
2
, cord
code designation 245 IE 57 ( ENELE H05 RN-F).
For internal connection, outer sheathing must be
stripped 140mm from the cable end. The live and
neutral conductors must be trimmed so that the Earth
conductor is longer by 50mm. Pass inlet cable through
the rear panel cord grip and ensure that the cable is
routed without leaving excessive free length inside the
appliance.
LD2 Boiling Top
This model is designed to be connected to a single
phase A supply. Electrical supply must be installed
using a suitable isolating switch with a minimum contact
separation of 3mm in all poles.

Rear Front
LH Front LH Rear RH Rear RH Front
SECTION 3 - USE and CLEANING
IMPORTANT: GENERAL NOTES ON CLEANING
Disconnect nit from electricity s pply prior to
cleaning.
Never se a coarse abrasive to clean exterior
panels. A soft cloth with a warm water and
detergent sol tion is s fficient.
Never attempt to steam clean or hose down with a
jet of water.
Plate Control Switch
Each hotplate is controlled by a switch which offers six
individual heat settings. The LD2 front plates have a
built-in cut-out device to automatically reduce heat if the
plates are left uncovered at a high setting. Always
switch plate settings to OFF position when not in use.
Fig re 2 - LD1 Model
Fig re 3 - LD2 Model
For efficient operation, it is important that good contact
be established between the plate and utensil. Ground
based pots should be used and the plate surface must
be clean. For maximum efficiency, the pot diameter
should be the same as that of the plate. This is not
always possible but, in the interest of fuel economy,
using very small or large pots should be avoided.
Spillage should never be allowed to accumulate around
the edge of a plate as this will burn on and become
difficult to remove.
Cleaning a Boiling Top
Allow the unit to cool before cleaning.
Use a detergent/water solution, take care to rinse and
dry all surfaces thoroughly. Stubborn stains may be
removed with a soap-filled pad. Be careful, NEVER use
a harsh abrasive on stainless steel.
SECTION 4 - SERVICING
SERVICE ACCESS
Base Plate
Upturn unit and rest it at the edge of a worksurface with
rear upstand overhanging the edge.
Undo base plate fixings to remove base plate.
FUNCTIONAL COMPONENTS
Control Switch
Remove base.
Remove control knob.
Remove electrical connections, noting their positions.
Undo fixings which secure control to panel and remove.
Replace in reverse order.
Elements
Remove base plate.
Undo electrical connections, noting their positions.
Undo element fixings and remove.
Replace in reverse order.
Terminal Block
Remove base plate.
Remove electrical connections at terminal block, noting
their positions.
Undo fixings which secure the block to the unit and
remove.
Replace in reverse order.
Neons
Remove base plate.
Remove electrical connections at terminal block, noting
their positions.
Remove and replace neon.
Replace in reverse order.
Cable
Remove base plate.
Undo mains cable cord grip at unit rear.
Undo electrical connections at terminal block and
remove cable.
Replace in reverse order. Ensure cable is fed through
the securing clamp and pulled taut before tightening the
clamp.
Short Spares List
735010100 Round Hotplate (1.5kW)
735010110 Round Hotplate (2kW)
735110050 ontrol Knob
735010130 ontrol Switch
735120014 Neon (Amber)
735110060 Neon (Red)

LD1 WIRING DIAGRAM
LD2 WIRING DIAGRAM
