Promax CG10 User manual

®
®
®
®
®
TWO-SIDED
GRILLS
MODEL
CG10, GR10
CG14 & GR14
Installation and
Operation
Instructions
2M-Z2906 Rev. O 10/03/2014
14 x 14 Grooved Grill

2
2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it ready when
you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
[email protected]
W[email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

3
SPECIFICATIONS
Model
No.
Grid
Surface “A” Width “B” Depth
Height
Voltage Wattage Amps NEMA
Approx. Weight
“C” Closed “D” Open Shipping Installed
GR10 Alum. 16-1/8” 21-1/8” 14-1/4” 28-3/4” 120 1800 15 5-15P 52 lbs. 36 lbs. 5-20P*
40.9 cm 53.7 cm 36.2 cm 73 cm 208/240 1350/1800 6.5/7.5 6-15P 23.6 kg 16.3 kg
GR10I Iron 16-1/8” 21-1/8” 14-1/4” 28-3/4” 120 1800 15 5-15P 67 lbs. 57 lbs. 5-20P*
40.9 cm 53.7 cm 36.2 cm 73 cm 208/240 1350/1800 6.5/7.5 6-15P 30.4 kg 28.1 kg
GR14 Alum.
19-5/8” 24-5/8” 14-1/4” 33” 120 1800 15 5-15P 67 lbs. 55 lbs
5-20P*
49.8 cm 62.5 cm 36.2 cm 83.2 cm 208/ 240 1350/1800 6.5/7.5 6-15P 30.4 kg 24.9 kg
230 1650 7.17 BS 1363A
GR14I Iron 19-5/8” 24-5/8” 17-1/4” 36” 208/240 2700/3600 13/15 6-20P 101 lbs. 87 lbs.
49.8 cm 62.5 cm 43.8 cm 91.4 cm 45.9 kg 39.4 kg

4
Specications
Model Platen Timer Country
CG10I-120V
CastIron
Grooved Top and Bottom Platens
without TimerCG10I-120VC Canadian
CG10I-240V
CG10IT-120V
with TimerCG10IT-120VC Canadian
CG10IT-240V
CG14-120V
Aluminum
without TimerCG14-120VC Canadian
CG14-240V
CG14-2T-120V with 2 Timers
CG14-2T-120VC Canadian
CG14GTB-120V Smooth Bottom and Grooved Top Platens with Timer
CG14I-240V
CastIron
Grooved Top and Bottom Platens
without TimerCG14IB-120V Grooved Top and Bottom Platens w/New Hinge
CG14IGT-240V Grooved Top andSmooth Bottom Platens
CG14IT-120V Grooved Top and Bottom
with Timer
CG14IT-120VC Canadian
CG14IT-240V Grooved Top and Bottom Platens
CG14ITGT-240V Grooved Top andSmooth Bottom Platens
CG14T-120V
Aluminum
Grooved Top and Bottom Platens
CG14T-120VC Canadian
CG14T-240V
GR10-120V
without Timer
GR10-120VC Canadian
GR10-240V
GR10I-120V
CastIron
GR10I-120VC Canadian
GR10I-240V
GR10IT-120V
with Timer
GR10IT-120VC Canadian
GR10IT-240
GR10T-120V
Aluminum
GR10T-120VC Canadian
GR10T-240
GR14-120V
without TimerGR14-120VC Canadian
GR14-240V
GR14-2T-120VC with 2 Timers Canadian
GR14B-UK
without Timer
United Kingdom
GR14C-240V Chrome
GR14I-240V
CastIron
GR14IT-120V
with TimerGR14IT-240V
GR14ITB-120V
GR14SN-120V
Aluminum
Snub NoseSmooth Top and Bottom without Timer
GR14SN-120VC Canadian
GR14T-120V
Smooth Top and Bottom Platens with Timer
GR14T-120VC Canadian
GR14T-240V

5
GENERAL INSTALLATION DATA
This equipment is designed and sold for commercial use only by personnel trained and experienced
in its operation and is not sold for consumer use in and around the home nor for use directly by the
general public in food service locations.
Before using your new equipment, read and understand all the instructions & labels associated with
the unit prior to putting it into operation. Make sure all people associated with its use understand the
units operation & safety before they use the unit.
All shipping containers should be checked for freight damage both visible and concealed.
This unit has been tested and carefully packaged to insure delivery of your unit in perfect
condition. If equipment is received in damaged condition, either apparent or concealed, a
claim must be made with the delivering carrier.
Concealed damage or loss - if damage or loss is not apparent until after equipment is
unpacked, a request for inspection of concealed damage must be made with carrier within
15 days. Be certain to retain all contents plus external and internal packaging materials for
inspection. The carrier will make an inspection and will supply necessary claim forms.
VENTILATION AND CLEARANCES
The installation of any components such as a vent hood, grease extractors, and/or re
extinguishing systems, must conform to their applicable nationally recognized installation
standards and/or local building codes.
ELECTRICAL CONNECTION
Before making any electrical connection be sure to read data plate which is located at the bottom of
the unit.
ELECTRICAL GROUNDING INSTRUCTIONS
This unit is equipped with a 3-prong (grounding) plug for your protection against shock hazard and
must be plugged directly into a properly grounded 3-prong receptacle.
DO NOT CUT OR REMOVE THIS PLUG OR GROUNDING PRONG FROM THE PLUG.
CONNECT/PLUG UNIT INTO DEDICATED A.C LINE ONLY SPECIFIED ON THE DATA PLATE
OF THE UNIT.
CAUTION
WARNING
WARNING

6
Note: For Canada, 120 volt units listed above have NEMA 5-20P plug.
Model No. Volts Rated Wattage Amps NEMA Plug
GR 14 120 1800 15 5-15P
GR 14 240 1800 7.5 6-15P
CG 14 120 1800 15 5-15P
CG 14 240 1800 7.5 6-15P
GR 14I 240 3600 15 6-20P
CG14I 120 1800 15 5-15P
CG 14I 240 3600 15 6-20P
CG 14IGT 240 3600 15 6-20P
GR 14C 240 3600 15 6-20P
ELECTRICAL SPECIFICATIONS
Model No. Volts Rated Wattage Amps NEMA Plug
GR 10 120 1800 15 5-15P
GR 10 240 1800 7.5 6-15P
GR 10I 120 1800 15 5-15P
GR 10I 240 1800 7.5 6-15P
CG 10I 120 1800 15 5-15P
CG 10I 240 1800 7.5 6-15P
Note: For Canada, 120 volt units listed above have NEMA 5-20P plug and 12/3 gage cord.
INITIAL START UP
Level unit using the adjustable feet under the unit (approximately 1/2" adjustment).
Before using the unit for the rst time, clean and heat for approximately 30 minutes. The grill may emit a small
amount of smoke as the cooking surfaces reach 300-350°F. Do not be alarmed, as the smoke is caused by oils
associated with the manufacturing process and will stop when the grill reaches 400°F.
SEASONING THE COOKING SURFACES (NON CHROME SURFACES)
FIRST TIME SEASONING
Follow your company/corporate guidelines for seasoning cooking surfaces. or
1. Bring the grill to 300°F and leave it on while doing the next three steps.
2. Brush the cooking surfaces with a salt free liquid vegitable oil. If using an aerosol agent, rst apply into a cup
and then brush onto cooking surface.
3. Let sit for 20 minutes, and then wipe clean using a warm damp cloth.
DAILY SEASONING
The grill should not require much seasoning while in use. In most cases, brush a light coating of a salt free liquid
vegitable oil in the morning and occasionally throughout the day will be enough to prevent any sticking. It is not
necessary to apply before grilling each item.
SETTING THE TEMPERATURE
The thermostat control knob is used to set the temperature to your requirements.
The maximum set point is 550°F (288°C), the minimum set point is 175°F (79°C).
See Knob Settings.
SETTING THE TIMER (TIMER MODELS ONLY)
(9 MIN. 59 SEC. MAX)
The timer may be factory pre-set. If changes are required follow these simple steps:
1. To increase time, press and hold the (UP) button.
The Start/Stop button can now be used to increase the cooking time.
2. To decrease time, press and hold the (DOWN) button.
The Start/Stop button can now be used to decrease cooking time.
When the timer reaches "00:00" the alarm will sound three times.

7
KNOB SETTING
Knob Position Approx. Temp
1-2 175°F / 79°C
3 200°F / 93°C
4 250°F / 121°C
5 300°F / 148°C
6 350°F / 176°C
7 400°F / 204°C
8 450°F / 232°C
9 500°F / 260°C
10 550°F / 287°C
ON/OFF ROCKER SWITCH
(TIMER MODELS ONLY)
The switch turns the unit on and off. The switch has three positions:
With the switch in this position, both top and bottom platens will heat.
With the switch in this position, neither platen will heat.
With the switch in this position only bottom platen will heat.
DAILY OPERATION
Always allow 10-20 minutes of preheat time before loading the unit with product.
Failure to allow sufcient preheat time will result in unsatisfactory cooking of the rst load.
Check the power cord to insure that it is plugged into a proper outlet.
Check that the switch and thermostat control are turned on.
Set the unit's ON/OFF rocker switch to desired position.
Set the thermostat control knob to desired temperature.
OPERATING HINTS AND SAFETY
Disconnect power to the unit with the switch at the end of each day of operation.
Do not leave the unit in operation without an attendant.
Turn thermostat down to 200°F (93°C) during idle periods. It will take only a few minutes to regain
operating temperature.
Use spatula to push excess grease into grease drawer after each load of food is cooked. This will
reduce smoking of hot grease and carbonizing.
Do not leave the unit at high temperature when not in use or during idle periods. This will cause food
particles and grease lm to carbonize.
"Season" cooking surfaces with non-salted vegetable oil to reduce product sticking.
MONTHLY LUBRICATION/INSPECTION
Apply two (2) drops of non-toxic mineral or vegetable oil to counter balance shoulder rivets and plastic
spacers.
Check and clean brass rollers to make sure they are rolling and not sliding on the cam
surfaces of the counterbalance.
Check the bolts, screws and nuts, tighten if necessary.

8
CLEANING (NON CHROME SURFACES)
Begin cleaning procedure by using the operating procedures within your organization, or follow the
steps below:
1. If particles adhere to the cooking surface during the day, scrape them off with a spatula.
NOTE: It is best not to let food cook onto the grill, as food build-up on the grill will increase
sticking and smoking. In addition, carbon may build up on the grill surface and reduce the cooking
efciency.
CARBON BUILDUP: A black matter that forms on or near the cooking surface. Generally this is
a combination of: releasing agents, oils, food particles etc. that has cooked itself to the surface.
After a period of time without cleaning, this will reduce performance and material may start aking
off. When that happens, follow the "Carbon Cleaning" procedures.
2. At the end of the day, wipe down all surfaces with a warm, damp cloth and mild detergent, then
dry.
CARBON CLEANING
When carbon build up occurs, use a carbon removal agent according to the instructions provided with
the cleaner. When this process is complete, you must re-season the grill according to your company/
corporate guidelines, or the seasoning instructions in this manual.
DO NOT IMMERSE OR LET THE UNIT STAND IN WATER.
DO NOT HOSE DOWN THE UNIT OR THE TABLE/COUNTER IF THE UNIT IS ON THE
TABLE/COUNTER.
KEEP AWAY FROM RUNNING WATER.
DO NOT USE SHARP OBJECTS TO REMOVE CARBON BUILD-UP.
BEFORE CLEANING MAKE SURE POWER IS TURNED OFF, UNIT IS UNPLUGGED AND IS
NOT TOO HOT.
While holding top lid with one hand, apply only cleaners which are safe for aluminum and
iron surfaces. Wipe with clean sponge or towel until unit is clean.
DO NOT SPLASH FRONT CONTROL PANEL!
DO NOT SPLASH FLEX CONDUIT CONNECTING TOP AND BOTTOM OF THE UNIT.
Remove and empty to clean grease catcher drawer as required using mild detergent and water.
WARNING
Do not use ice or cold water to clean the cooking surfaces when the unit is hot.
The surfaces are cast aluminum or cast iron and may crack or deform under the shock of rapid
temperature change.
CLEANING (CHROME SURFACES)
It takes very little time and effort to keep this Industrial Chromium griddle surface sparkling clean and
performing at top efciency. DO NOT allow grease to accumulate as it will carbonize and become
difcult to remove. To prevent this condition the following cleaning suggestions should be followed:
1. Remove excess grease and food regularly with a 4” (100mm) wide Razor Sharp type scraper with
rounded corners and wipe surface with a damp cloth if desired.
2. Following the scraping, for end of the day cleaning, a damp cloth and a non-silicated, non-abrasive,
non-chlorinated cleaner such as Bon-Ami may be used to wipe surface clean, followed by wiping
with a clean wet cloth.
3. Use a clean cloth and good non-abrasive cleaner to clean the (NON COOKING SURFACES)
stainless steel body of the griddle. Wipe the control panel front with a soft cloth.
4. At least once a day, remove the waste drawer and wash in the same way as an ordinary cooking
utensil. The drawer is removed by pulling forward and out.
CAUTION

9
CAUTION
1. Never use pumice, griddle stones, or abrasives on a chromium surface.
2. Never strike a chromium griddle surface with a sharp instrument or spatula edge.
3. Never use steel wool.
4. Never use commercial liquid grill cleaner on the griddle surface.
5. Abusing surface voids the warranty.
CHROME SURFACE LIMITED WARRANTY EXCLUSIONS
Your Chrome Two Sided Grill has been designed to give you many years of cooking reliability and
requires minimum maintenance to keep the chrome surface in its original condition. All Chrome
surfaces are warranted for a period of 1 years against manufacturing defects to the original owner
from the date of installation. This limited warranty is void if it is determined by Star Manufacturing
International Incorporated or one of its authorized representatives that the chrome surface has been
misused or abused or subjected to the following situations:
1. Improperly installed.
2. Incorrect voltage applied to electric Pro-Max units allowing the surface to overheat and discolor.
3. The misuse of any instrument or tool which scratches or makes indentations in the surface which
could cause the surface to peel, ake, or chip off.
4. The use of any chemical or abrasive cleaning solution, griddle brick, stone, screen or other
cleaning products which could damage and affect the performance of the chrome surface.
5. The neglect of daily routine maintenance to the chromium surface.
OPERATION TROUBLESHOOTING
1. Unit not heating.
A. Check if unit is plugged in correct receptacle.
B. Check incoming power line.
C. Check that the switch is in correct position.
D. Check that thermostat is set to proper temperature.
2. Top platen not heating.
A. Check that the rocker switch is in correct position.
3. Counter balance roller not rolling.
A. Clean rollers.
If unit still does not operate contact the factory or one of its representatives or a local service
company for service or required maintenance.

10
2M-4497-2 6/1312
The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.
FOR ASSISTANCE
Should you need any assistance regarding the Operation or Maintenance of any Star equipment; write, phone, fax or email our Service Department.
In all correspondence mention the Model number and the Serial number of your unit, and the voltage or type of gas you are using.
ALL:
*Pop-Up Toasters
*Butter Dispensers
*Pretzel Merchandisers
(Model 16PD-A Only)
*Pastry Display Cabinets
*Nacho Chip Merchandisers
*Accessories of any kind
*Sneeze Guards
*Pizza Ovens
(Model PO12 Only)
*Heat Lamps
*Pumps-Manual
Visit our Website at: www.star-mfg.com Email: [email protected]
THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL
This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which
the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation
company who delivered the item to you and initiate your claim with same. If this procedure is not followed, it may affect the warranty status of the unit.
LIMITED EQUIPMENT WARRANTY
All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited
to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair
of defects without charge, by the factory authorized service agency or one of its sub-agencies. Models that are considered portable (see below) should be taken
to the closest Star service agency, transportation prepaid.
>Star will not assume any responsibility for loss of revenue.
>On all shipments outside the United States and Canada, see International Warranty.
* The warranty period for the Ultra-Max, Hot Plates, Griddles, Charbroilers is (3) years parts & labor.
* The warranty period for the Star-Max, Charbroilers, Griddles, Hot Plates, Fryers & Finishing Oven is (2) years parts & labor.
*The warranty period for the JetStar six (6) ounce & Super JetStar eight (8) ounce series popcorn machines is two (2) years.
*The warranty period for the Chrome-Max Griddles is ve (5) years on the griddle surface. See detailed warranty provided with unit.
*The warranty period for Teon/Dura-Tec coatings is one year under normal use and reasonable care. This warranty does not apply if damage occurs to
Teon/Dura-Tec coatings from improper cleaning, maintenance, use of metallic utensils, or abrasive cleaners, abrasive pads, product identiers and
point-of-sale attachments, or any other non-food object tha comes in continuous contact with the roller coating. This warranty does not apply to the
“non-stick” properties of such materials.
>This warranty does not apply to "Special Products" but to regular catalog items only. Star's warranty on "Special Products" is six (6) months on parts
and ninety (90) days on labor.
>This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by a Star Authorized Service Center or
the Service Center's sub-agency.
>This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage, wrong gas or operated contrary to the Installation and
Operating instructions.
>This warranty is not valid on Conveyor Ovens unless a "start-up/check-out" has been performed by a Factory Authorized Technician.
PARTS WARRANTY
Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The part only is warranted, the labor to replace the part is NOT warranted.
SERVICES NOT COVERED BY WARRANTY
PORTABLE EQUIPMENT
Star will not honor service bills that include travel time and mileage charges for servicing any products considered "Portable" including items listed below.
These products should be taken to the Service Agency for repair:
1. Travel time and mileage rendered beyond the 50 mile radius limit
2. Mileage and travel time on portable equipment (see below)
3. Labor to replace such items that can be replaced easily during a daily cleaning
routine, ie; removable kettles on fryers, knobs, grease drawers on griddles, etc.
4. Installation of equipment
5. Damages due to improper installation
6. Damages from abuse or misuse
7. Operated contrary to the Operating and Installation Instructions
8. Cleaning of equipment
9. Seasoning of griddle plates
10. Voltage conversions
11. Gas conversions
12. Pilot light adjustment
13. Miscellaneous adjustments
14. Thermostat calibration and by-pass adjustment
15. Resetting of circuit breakers or safety controls or reset buttons
16. Replacement of bulbs
17. Replacement of fuses
18. Repair of damage created during transit, delivery, &
installation OR created by acts of God
* The Model 510FD, 510FF Fryer.
* The Model 526TOA Toaster Oven.
* The Model J4R, 4 oz. Popcorn Machine.
*The Model 518CMA & 526CMA Cheese Melter.
* The Model 12MC & 15MC & 18MCP Hot Food Merchandisers.
* The Model 12NCPW & 15NCPW Nacho Chip/Popcorn Warmer.
* All Hot Dog Equipment except Roller Grills & Drawer Bun Warmers.
* All Nacho Cheese Warmers except Model 11WLA Series Nacho Cheese Warmer.
* All Condiment Dispensers except the Model HPD & SPD Series Dispenser.
* All Specialty Food Warmers except Model 130R, 11RW Series, and 11WSA Series.
* All QCS/RCS Series Toasters except Model QCS3 & RCS3 Series.
* All Fast Steamer Models except Direct Connect Series.

11
(ELEMENTO MAS BAJO)
BOTTOM ELEMENT
(ELEMENTO MAS ALTO)
TOP ELEMENT
5-15P PLUG STD
(NEGRO)
BLACK
(VERDE)
GREEN
(BLANCO)
WHITE
T-STAT
FRONT CONTROL PANEL
WIRE NO PART NO.
(HILO NO.) (PARTE NO.)
QTY.
(CANTIDAD)
1 D9-GR0103 1 2 D9-GR0104 1 3 D9-GR0105 1
PILOT LIGHT
(BLOQUE TERMINAL)
TERM BLOCK
REAR PANEL
1 3
2
5-20P PLUG FOR CANADA
MODEL:
GR/CG10I-120V, GR/CG14I-120V
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR MANUFACTURING INTERNATIONAL INC.
SK1706 Rev A 6/13/2005

12
(ELEMENTO MAS BAJO)
BOTTOM ELEMENT
(ELEMENTO MAS ALTO)
TOP ELEMENT
6-15P PLUG
(NEGRO)
BLACK
(VERDE)
GREEN
(BLANCO)
WHITE
T-STAT
FRONT CONTROL PANEL
PILOT LIGHT
(BLOQUE TERMINAL)
TERM BLOCK
REAR PANEL
1 3
2
INLET IEC 320 16A
230V UNIT
19
18
20
L N
G
WIRE NO PART NO.
(HILO NO.) (PARTE NO.)
QTY.
(CANTIDAD)
1 D9-GR0103 1
2 D9-GR0104 1 3 D9-GR0105 1
18 D9-GR0250 1 19 D9-GR0251 1
20 D9-GR0252 1
MODEL:
GR/CG10I-230/240V, GR/CG14I-230/240V
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR MANUFACTURING INTERNATIONAL INC.
SK1707 Rev A 8/10/2004

13
(ELEMENTO MAS BAJO)
BOTTOM ELEMENT
(ELEMENTO MAS ALTO)
TOP ELEMENT
NEMA 6-20P PLUG
(NEGRO)
BLACK
(VERDE)
GREEN
(BLANCO)
WHITE
T-STAT
FRONT CONTROL PANEL
PILOT LIGHT
(BLOQUE TERMINAL)
TERM BLOCK
REAR PANEL
13
2
INLET IEC 320 16A
230V UNITS
(CANTIDAD)
QTY.
1 D9-GR0103 1
2 D9-GR0104 1 3 D9-GR0105 1
18 D9-GR0250 1 19 D9-GR0251 1
20 D9-GR0252 1
(HILO NO.) (PARTE NO.)
WIRE NO PART NO.
19
18
20
N
L
G
MODEL:
GR/CG10-230/240V, GR/CG14-230/240V
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR MANUFACTURING INTERNATIONAL INC.
SK1708 Rev A 8/10/2004

14
GREEN
BLACK WHITE
15 AMP PLUG
NEMA 5-15P ON ALL 120V UNITS.
NEMA 6-15P ON 240V, 1,800 WATT UNITS.
20 AMP PLUG
NEMA 6-20P ON 240V, 3,600 WATT UNITS.
TOP ELEMENT
TRANSFORMER TERMINAL BLOCK
FOR REFERENCE
WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED
WITH THE BOTTOM PLATE REMOVED. ITEMS ARE IN
GENERAL LOCATION BUT MAY BE RELOCATED OR SCALED
FOR CLARITY.
3
E2 E1
8
8
1
1
11
12
12
11
5
2
52
4
4
10
10
9
9
13
3
3 7
6
7
INDICATOR LIGHT
(POWER ON)
TIMER BOARD SWITCH
THERMOSTAT
BOTTOM ELEMENT
230V UNITS
INLET IEC 320 16A
20
19
18
L N
G
6
13
MODEL: CG/GR, 10/14, 120V/230/240V,
WITH TIMER
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR MANUFACTURING INTERNATIONAL INC.
SK2001 Rev A 8/10/2004

15
WIRE DIAGRAM, CG/GR, 10/14, 120V/230/240V,
WITH 2 TIMERS, T-STAT, AND SPST SWITCH
STAR MANUFACTURING INTERNATIONAL, INC.
MODEL: SEE ABOVE SK2387 REV. A 2-26-09
B
A
CD
GREEN
BLACK WHITE
NORTH AMERICA:
15 AMP PLUG
NEMA 5-15P ON 120V, 1,800 WATT UNITS FOR U.S. ONLY.
NEMA 5-15P ON 120V, 1,400 WATT UNITS FOR U.S. AND CANADA.
NEMA 6-15P ON ALL 240V, 1,800 WATT UNITS.
20 AMP PLUG
NEMA 6-20P ON ALL 240V, 3,600 WATT UNITS.
NEMA 5-20P ON 120V, 1,800 WATT UNITS FOR U.S. AND CANADA.
TOP ELEMENT
TRANSFORMER
TERMINAL BLOCK
FOR REFERENCE WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED WITH THE
BOTTOM PLATE REMOVED. ITEMS ARE IN GENERAL LOCATION BUT MAY BE
RELOCATED OR SCALED FOR CLARITY.
E2 E1
2
1
3
6
6
5
5
4
11
TIMER BOARD
THERMOSTAT
BOTTOM ELEMENT
20
19
18
G
UNITS WITH IEC CONNECTOR:
POWER INLET CONNECTOR:
IEC 320 C-20 POWER INLET, ON ALL 208 - 240V UNITS.
FOR USE WITH DETACHABLE CORDSETS SUPPLIED
WITH A STRAIGHT, FEMALE, IEC 60320 C-19 CONNECTOR.
L N
E
REAR OF CONNECTOR SHOWN.
SWITCH
(INTERRUPTOR)
3
1
211
4
E2 E1
6
5
6
5
10
9
INDICATOR LIGHT
10
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLY AND IN
SOME ITEMS ARE INCLUDED FOR

STAR INTERNATIONAL HOLDINGS, INC. COMPANY
SK2455 Rev. E 10/03/2014
GR14,GR14I, GR14ITTC,CG14,CG14I,CG14IGT
This drawing contains information confidential
to Star Manufacturing International, Inc.
No reproduction or disclosure of its
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLY AND IN
SOME ITEMS ARE INCLUDED FOR
contents is permitted.
MODEL GR10I,CG10I,
TOP&
ON
POWER
TIME
START
STOP
2
3
FAVOR NO TOCAR
PELIGRO
SUPERIFICIE
CALIENTE
CAUTION
running water.
Keep away from
Do not hose down.
base stand in water.
Do not immerse or let
corriente de agua.
No rocia con
manguera.
Maintengase lejos de
DO NOT TOUCH
DANGER
HOT SURFACE.
PRECAUCION
Favorde no sumergir
estancada sobre agua
o dejar que la base este
BOTTOM
OFF
BOTTOM
ON ( I )
POWER ON
PRO-MAX
57
4
5
HOUSING ARM
CONNECTION
B
Version
Earlier
Version
1
B Style Hinge
Counterbalance
35
22
23
38
31
50
27
26 25
30
30a
21
20
49
33
32
29
18
19
17
17
17
17
46
56
19
28
39
40
41
42
45
47
55
37
60
34
48
52
53
15
16
13
54 9
54
51
16
44
58
59
24
6
14
710
12
11
69
70
71
72
73
69
7
9
68
67
66
68
67
66
61
= B Style Hinge Units Only
62
63
64
65
2M-Z2906 Two-Sided Grills 2M-Z2906 Two-Sided Grills

PARTS LIST October 03, 2014, Rev. O
10' TWO SIDED GRILLS
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL
Star Manufacturing International, Inc.
Fig No Part No Qty Description Application
1 2C-Z2992 2 SCREW, HANDLE
2 2V-Z2990 1 HANDLE - 10”
3 2B-Z2988 2 ARM - 10”
42C-40637 4NUT 1/4-20 ACORN CAP MS
2C-08-07-0262 WASHER
5
2C-Z2992 4 SCREW, ARM TO BRACKET
2C-1523 4SCREW, .250-20UNC X .75 LG RHP B SERIES COUNTERBALANCE
2C-08-07-0262 LOCKWASHER, .250 INTERLOCK TOOTH
6 D9-Z2038 1 HOUSING-TOP-10”
7 2C-Z3200 2 PIN - TOP HOUSING
8 2C-Z2855 2 RETAINER RING
9 2C-08-07-0040 2 1/4” NUT, USE WITH TOP HOUSING PIN
10 24-Z3827 1 CONDUIT KEEPER PLATE
11 2C-Z3780 2 CONDUIT RETAINER
12 2E-Z2898 1 CONDUIT ASSY. - PTFE
13 2E-Z3768 1 CONDUIT LOCKNUT
14 D9-04-
GR-0166 1 WIRE MOUNT
15 D9-Z14985 2 BRACKET, INSLUATION HOLD DOWN
16 D9-Z2908 2 INSULATION - 10”
17 2C-Z2893 8 NUT 10-24 HEX STL ZP
18 D9-Z2772 1 TOP ELEMENT/INS. PLATE/10
3 TOP ELEMENT/INS PLATE/10 CG10ITSB
19 2C-08-07-0285 8 SCREW, ELEMENT RET. PLATE
20 PS-Z1978 1TOP ELEMENT, HEATING, 800W/120 GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
PS-Z2019 TOP ELEMENT, HEATING, 800W/240V GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
21
PS-GR0348
1
KIT, 2F-Z1928 CSTG, SM. TOP,ALUM.-10” GR10, GR10T
PS-GR0349 KIT, 2F-Z1932 CSTG, SM. TOP, IRON-10” GR10I, GR10IT
PS-GR0347 KIT, 2F-Z1934 CSTG, GR. TOP, IRON-10” CG10I, CG10IT
22 2K-Y3240 1BUSHING 90 SR 17-2 GR10, GR10T, GR10I, GR10IT, CG10I, CG10IT,
(120&240V MODELS)
2K-Y6764 BUSHING - STRAIN RELIER (120C MODELS)
23
2E-Z2770
1
CORD, POWER, 14-3, 6-15P GR10T, GR10, GR10I, GR10IT, CG10I, CG10IT,
(240V MODELS)
2E-Z2935 CORD SET 14/3 NEMA 5-15P GR10T, GR10, GR10I, GR10IT, CG10I, CG10IT,
(120V MODELS)
2E-Z4119 CORD, POWER, 12/3 5-20P 120C MODELS
24 2M-Z2620 1 LABEL CAUTION, BI-LINGUAL
25 2E-05-07-0350 1TRANSFORMER 230V/10V 6VA GR10T, GR10IT, CG10IT (240V)
2E-05-07-0351 TRANSFORMER 115/10V 6VA GR10T, CGR10IT, CG10IT, GR10IT4 (120V)
26 2E-Z2894 1 TERMINAL BLOCK
27 D9-GR0053 1 REAR LINER ASSY. - 10”/BOT
28 2C-1512 2 SCREW - PIN ASSY
29 2V-Z3252 1 PIN ASSY - TOP HOUSING STOP
30 2R-Z2907 1COUNTERBALANCE -10”-IRON
2R-Z3333 COUNTERBALANCE -10”-ALUM.
31 D9-GR0032 2 TORQUE BOX ASSY.
32 D9-Z3071 4 BRACKET-HANDLE
2M-Z2906 Two-Sided Grills 2M-Z2906 Two-Sided Grills

MODEL
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE 2
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
Star Manufacturing International, Inc.
PARTS LIST October 03, 2014, Rev. O
10' TWO SIDED GRILLS
Fig No Part No Qty Description Application
33 2V-Z3072 2 HANDLE - SIDE
34 D9-GR0034 1 GREASE CABINET ASSY. All Models
35 D9-GR0517 1 GREASE DRAWER ASSY
37
D9-Z2711
1 BASE BOTTOM - 10”D9-Z12973 120VC MODELS
D9-GR0246 230V MODELS
38 2A-Z11501 4 FOOT, 1” SOLID RUBBER
39
D9-GR0413
1
BODY ASSY. - 10” w/TIMER GR10T, GR10IT, CG10IT
D9-GR0412 BODY ASSY. - 10” w/o TIMER GR10, GR10I, GR10I, CG10I, CG10I
D9-GR0460 BODY WELD ASSY CG10IT2-120V
40 2J-Z1836 1TIMER CONTROL CG10T, CG10IT, GR10T, GR10IT
2 CG10IT2
41 2K-Z1971 4 SPACER CG10T, CG10IT, GR10T, GR10IT
2K-Z1971 8 SPACER .25X.75X.25 NYLON CG10IT2-120V
42 2J-Y6689 1PILOT LIGHT, 120V GR10, GR10I, CG10I (120V MODELS)
2J-Z2329 PILOT LIGHT, 240V GR10, GR10I, CG10I (240V MODELS)
44
2E-Z6863
1
SWITCH 3 POS CG10T, CG10IT, GR10T, GR10IT
2E-Z3808 SWITCH (EATON)-30A@120V CG10IT2-120V
PS-GR0223 SWITCH
CG10IT-120V W/SERIAL NO BELOW CGA24279
CG10IT-240V W/SERIAL NO BELOW CGA20294
GR10IT-120V W/SERIAL NO BELOW GRA27109
CG10TJD-240V W/SERIAL NO BELOW CGA29997
GR10T-240V W/SERIAL NO BELOW GRA03390
45
2M-Z6881 1 OVERLAY - 10” w/TIMER GR10T, GR10IT, CG10IT
2M-Z11836 2 OVERLAY - 10” W/2 TIMERS CG10IT2-120V
2M-Z3051 1 OVERLAY - 10” NO TIMER GR10, GR10I, CG10I
46 2I-05-07-0013 1 RUBBER BOOT, SWITCH
47 2R-Z4621 1 KNOB-CONTROL
48 2T-6447 1 THERMOSTAT 118V-236V
49 2A-Z3026 1 HALF CLIP
50 D9-Z16492 2 INSULATION HOLD DOWN, BTM 10”
51 D9-Z2773 1 BTM ELEMENT RET. PLATE 10”
52 2N-Z1979 1 BTM ELEMENT, HEATING, 1000W/120 GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
2N-Z2020 1 BTM ELEMENT, HEATING, 1000W/240 GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
53
PS-GR0359 1 KIT, 2F-Z1929 CSTG, SM.BOT., ALUM.-10” GR10, GR10T
PS-GR0360 1 KIT, 2F-Z1933 CSTG, SM. BOT., IRON-10” GR10I, GR10IT
PS-GR0358 1 KIT, 2F-Z1935 CSTG, GR. BOT., IRON-10” CG10I, CG10IT
54 2C-Z5883 8 SCREW 10-24X1/2 FZA
55 PS-GR134 2 ROLLER BEARING KIT
56 D9-Z11283 1 COUNTER BALANCE STOP BASE ACCESSORIES
57 D9-Z11284 1 COUNTER BALANCE STOP, BRACKET ACCESSORIES
58 2M-Z18461 1 LABEL ON & OFF CG10IT2
60
D9-GR0550
1BASE ASSY/GREASE CABINET
120/240V MODELS
D9-GR0552 120C MODELS
D9-GR0553 230V MODELS
2M-Z2906 Two-Sided Grills 2M-Z2906 Two-Sided Grills

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 4
Some items are included for illustrative purposes only and in certain instances may not be available.
Star International Holding, Inc. Company
MODEL
PARTS LIST October 03, 2014, Rev. O
14' TWO SIDED GRILLS
Fig. No Part No Qty Description Application
1 2C-Z2992 2 SCREW, HANDLE
2
2V-Z11395
1
HANDLE, B-STYLE HINGE
CG142TB, CG14B, CG14E, CG14IB, CG14IGTB, CG14ITB,
CG14ITGTB240, CG14ITLB, CG14ITSC, CG14TB, GR14B,
GR14E, GR14IB, GR14ITB, GR14SNB, GR14TB
2V-Z2989 HANDLE - 14”, COUNTERBALANCE
2V-Z3413 HANDLE - 14” S.S. GR14, GR14T, SER. # GRC00112 - 00138, GRC00778 - 00858,
GRC00864 - 01256
3
2B-Z11391
2
ARM 14” SPT GR14SNB
2B-Z2987 ARM - 14” CG14EA, CG14IEA, GR14EA, GR14IEA, GR14C, CG14I,
CG14IGT, CG14IT, CG14ITGT, GR14, GR14I, GR14IT
2B-Z3336 ARM GR14SN
2B-Z14019 ARM, STANDARD 45 DEG. CG14DTB, CG14B, CG14E, CG14IB, CG14IT, GR14B, GR14E,
GR14IB, GR14ITB
42C-40637 4NUT 1/4-20 ACORN CAP MS ALL EXCEPT GR14SNB MODELS
2C-08-07-0262 WASHER
5
2C-Z2992 4 SCREW, ARM TO BRACKET
2C-1523 4SCREW, .250-20UNC X .75 LG RHP B SERIES COUNTERBALANCE
2C-08-07-0262 LCKWSHR, .250 INTERLOCK TOOTH
6
D9-Z2036 1 HOUSING-TOP-14”
D9-Z14020 1 TOP HOUSING, LEFT, 14”
CG142TB, CG14B, CG14E, CG14IB, CG14IGTB, CG14ITB,
CG14ITGTB240, CG14ITLB, CG14ITSC, CG14TB, GR14B,
GR14E, GR14IB, GR14ITB, GR14SNB, GR14TB
7 2C-Z3200 2 PIN - TOP HOUSING
8 2C-Z2855 2 RETAINER RING
9 2C-08-07-0040 2 1/4” NUT, USE PART NUMBER 2C-Z2820
10 2A-Z3827 1 PLATE, STAMPING - CONDUIT
11 2C-Z3780 2 CONDUIT RETAINER
12 2E-Z2898 1 CONDUIT ASSY. - PTFE
13 2E-Z3768 1 CONDUIT LOCKNUT
14 D9-04-GR-0166 1 WIRE MOUNT
15 D9-Z13099 2 BRACKET, INSLUATION
16 D9-Z2888 2 INSULATION - 14”
17 2C-Z2893 8 NUT 10-24 HEX STL ZP
18 D9-Z2075 1 TOP ELEMENT/INS. PLATE/14
19 2C-08-07-0285 8 SCREW, ELEMENT RET. PLATE
20
PS-Z1980
1
ELEMNT REPL. KIT, 800W/120V CG14, CG14T, GR14, GR14IB GR14T, CG14IT-120V
PS-Z2021 ELEMNT REPL. KIT, 800W/240V CG14, CG14T, GR14, GR14T
D9-GR0535 ELEM\NT ASSY 800W/240V CG/GR14E-230V, CG/GR14E-240V
PS-Z2391 ELEMNT REPL, KIT, 1800W/240 GR14I, GR14IT, CG14IGT, CG14ITGT, CG14I, CG14IT
D9-GR0514 ELEMENT, TOP CG14E-120V, GR14E-120V, GR14IE
21
PS-GR0351
1
KIT, 2F-Z1946 CASTING CG14, CG14T, CG14GTB
PS-GR0352 KIT, 2F-Z1948 CASTING GR14I, GR14IT
PS-GR0353 KIT, 2F-Z1950 CASTING CG14IGT, CG14ITGT
PS-GR0350 KIT, 2F-Z7786 CAST-TOP ALM GR14, GR14T
2M-Z2906 Two-Sided Grills 2M-Z2906 Two-Sided Grills

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
2
5
Star International Holding, Inc. Company
MODEL
PARTS LIST October 03, 2014, Rev. O
14' TWO SIDED GRILLS
Fig. No Part No Qty Description Application
22
2K-3485
1
BUSHING-HEYCO #SR-9P-2 GR14I, GR14IT, CG14IGT, CG14ITGT, CG14I, CG14IT
(240V MODELS)
2K-Y2968 BUSHING 7W-2 CG14IT-120V
2K-Y3240 BUSHING SR 17-2, 90°
2K-Y6764 BUSHING - STRAIN RELIEF (120VC MODELS)
23
2E-Z2905
1
CORD SJTO 12/3 NEMA 6-20P GR14I, GR14IT, CG14IGT, CG14ITGT, CG14I, CG14IT
(240V MODELS)
2E-Z2935 CORD SET 14/3 NEMA 5-15P (120V MODELS)
2E-Z2770 CORD, POWER, 14-3, 6-15P 240V, 72”
LONG
CG14, CG14T, GR14, GR14E, GR14T, GR14ITB, GR14IB,
(240V MODELS)
2E-Y9251 CORD SET CONT EUR 16 AMP 230V MODELS
2E-Z9192 CORDSET (DETACHABLE) UK GR14B-UK
2E-Z16940 CORDSET, 14/3, SJTO, 90°, 5-15 GR14TQ
24 2M-Z2620 1 LABEL CAUTION, BI-LINGUAL
25 2E-05-07-0350 1TRANSFORMER 230V/10V 6VA 230 & 240V MODELS
2E-05-07-0351 TRANSFORMER 115/10V 6VA 120V MODELS
26 2E-Z2894 1 TERMINAL BLOCK
27
D9-GR0054
1
REAR LINER ASSY. - 14”/BOT CG14, GR14, CG14T, GR14T
D9-GR0080 REAR LINER ASSY. - 14”/REAR CG14I, GR14I, CG14IGT, CG14IT, GR14IT, CG14ITGT
D9-GR0201 REAR LINER ASSY. CG14IT (120V)
28 2C-1512 2 SCREW - PIN ASSY
29 2V-Z3252 1 PIN ASSY - TOP HOUSING STOP
30 2R-Z2896 1COUNTERBALANCE -14”-IRON
2R-Z2897 COUNTERBALANCE -14”-ALUM.
30a PS-GR0537 1KIT, HINGE & SPRING, 14” ALUMINUM 14” ALUMINUM, CG14B, GR14B SERIES
PS-GR0538 KIT, HINGE & SPRING, 14” IRON 14” IRON, CG14B, GR14B SERIES
31 D9-GR0032 2 TORQUE BOX ASSY.
32 D9-Z3071 4 BRACKET-HANDLE
33 2V-Z3072 2 HANDLE - SIDE
34 D9-GR0034 1 GREASE CABINET ASSY. CG14-230V, CG14I-230V, CG14IT-230V, CG14ITGT-230, CG14T-
230V, GR14-230V, GR14I-230V, GR14IT-230V, GR14T-230V
35 D9-GR0517 1 GREASE DRAWER ASSY
37
D9-Z10086
1
PLATE, BOTTOM GR14-2T-120C
D9-GR0519 BASE ASSY/GREASE CAB. 14” 120V & 240V MODELS
D9-GR0523 BASE BTM/GRS CAB ASM-230V 230V MODELS
38
2A-Z1485
4
FOOT, 1” ADJUSTABLE, 1/4” STUD CERTAIN APPLICATIONS
2A-Z11501 FOOT, 1” SOLID RUBBER, 1/4” STUD ALLUMINUM PLATES
2A-Z0314-1 BASE, FOOT 4” CAST W/RUBBER FOOT CG14IB, CG14IGTB, CG14ITB, CG14ITLB, CG14ITSC, GR14IB,
GR14ITB
2A-Z12980 2.5” FOOT BASE, 3/8” STUD GR14I, GR14IT, CG14I, CG14IT, CG14IGT, CG14ITGT
2A-Z12946 BASE, FOOT, NON-SKID CG14I, CG14IB, CG14IE, CG14IEGT, CG14IGTB, GR14I GR14IB,
GR14IE, GR14ITB, (mfg after 4-2010)
39 D9-GR0061 1BODY ASSY. - 14”
D9-GR0184 BODY ASSY GR14SN
40 2J-Z1836 1 TIMER CONTROL CG14T, CG14IT, CG14IGT, GR14T, GR14IT
2M-Z2906 Two-Sided Grills 2M-Z2906 Two-Sided Grills
