PROPOINT 1/4 IN. MINI User manual

V1.0 8844169
Please read and understand all instructions before use. Retain this manual for future reference.
AIR DIE GRINDER

1/4 AND 1/8 IN. MINI

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
2 For technical questions call 1-800-665-8685
SPECIFICATIONS
Max. Pressure 90 PSI
Pressure Range 75 to 90 PSI
Air Consumption @ 90 PSI 2.8 CFM
CFM @ Full Load 20 CFM
No Load Speed 25,000 RPM
Collet Size 1/4 and 1/8 in.
Air Inlet 1/4 in.
Min. Hose Size 3/8 in.
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this manual.
A notice is an alert that there is a possibility of property damage, injury
or death if certain instructions are not followed.
DANGER! This notice indicates an immediate and specific hazard
that will result in severe personal injury or death if the
proper precautions are not taken.
WARNING! This notice indicates a specific hazard or unsafe
practice that could result in severe personal injury or
death if the proper precautions are not taken.
CAUTION! This notice indicates a potentially hazardous situation
that may result in minor or moderate injury if proper
practices are not taken.
NOTICE! This notice indicates that a specific hazard or unsafe
practice will result in equipment or property damage,
but not personal injury.

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 3
INTRODUCTION
The 1/4 and 1/8 in. Mini Air Die Grinder is ideal for a wide variety
of cutting, cylinder porting, weld breaking, deburring, polishing and
grinding tasks.
SAFETY
WARNING! Read and understand all instructions before using this
tool. The operator must follow basic precautions to reduce the
risk of personal injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or
inspection and maintenance instructions.
WORK AREA
1. Operate in a safe work environment. Keep your work area clean,
well-lit and free of distractions. Place lights so you are not working
in a shadow.
2. Keep anyone not wearing the appropriate safety equipment away
from the work area.
3. Store unused tools properly in a safe and dry location to prevent rust
or damage. Lock tools away and keep out of the reach of children.
4. Do not install or use in the presence of flammable gases, dust or
liquids.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by the
Canadian Standards Association (CSA) or American National
Standards Institute (ANSI).
PERSONAL PROTECTIVE EQUIPMENT
1. Always wear impact safety goggles that provide front and side
protection for the eyes. Eye protection equipment should comply
with CSA Z94.3-07 or ANSI Z87.1 standards based on the type of
work performed.
2. Wear the appropriate type of full-face shield in addition to safety
googles, as the work can create chips, abrasive or particulate matter.
3. Wear gloves that provide protection based on the work materials or
to reduce the effects of tool vibration.

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
4 For technical questions call 1-800-665-8685
3.1 Do not wear gloves when operating a tool that can snag the
material and pull the hand into the tool.
4. Wear protective clothing designed for the work environment and tool.
5. Non-skid footwear is recommended to maintain footing and
balance in the work environment.
6. Wear steel toe footwear or steel toe caps to prevent a foot injury
from falling objects.
7. Wear the appropriate rated dust mask or respirator.
8. This tool can cause hearing damage. Wear hearing protection gear
with an appropriate Noise Reduction Rating to withstand the
decibel levels.
9. The tool may contain high pressure. Use safety glasses and gloves
for protection during operation. Keep hands clear of the exposed
rubber portions of the hose.
PERSONAL PRECAUTIONS
Control the tool, personal movement and the work environment to avoid
personal injury or damage to tool.
1. Do not operate any tool when tired or under the influence of drugs,
alcohol or medications.
2. Avoid wearing clothes or jewelry that can become entangled with
the moving parts of a tool. Keep long hair covered or bound.
3. Do not overreach when operating a tool. Proper footing and
balance enables better control in unexpected situations.
4. Support the workpiece or clamp it to a stable platform. Holding the
workpiece by hand or against your body may lead to personal injury.
5. Keep your fingers away from the trigger/switch while carrying the
tool, attaching an air hose or an accessory. Lock the trigger/switch
safety if available.
6. Avoid unintentional starts. Be sure that the regulator/throttle switch
is in the neutral or OFF position when not in use and before
connecting it to any air source.
7. Serious injury or death may occur from inhaling compressed air. The air
stream may contain carbon monoxide, toxic vapors or solid particles.
Never inhale compressed air directly from the pump or air tool.

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 5
SPECIFIC SAFETY PRECAUTIONS
WARNING! DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to the tool safety
rules. If you use this tool unsafely or incorrectly, you can suffer
serious personal injury.
1. Use the correct tool for the job. This tool was designed for a
specific function. Do not modify or alter this tool or use it for an
unintended purpose.
2. Do not use the tool if any parts are damage broken or misplaced.
Repair or replace the parts.
3. This tool will not stop moving immediately. Do not lay the tool down
or leave it unattended until it has come to a complete stop. A part
that is moving could make the tool jump or grab a surface and pull
the tool out of your control.
4. Always make sure the work surface is free from nails and other
foreign objects.
5. After changing the accessories or making adjustments, make sure
the collet nut and any other adjustment devices are securely
tightened. Loose adjustment devices will be violently thrown.
6. Always check accessories for damage before each use. Damaged
accessories can break during use and cause serious injury.
7. If you are interrupted when operating the die grinder, complete the
process and switch off the tool before looking up.
8. Use metal and voltage detectors to locate hidden electric, water or
gas lines. Avoid touching live components or conductors.
9. Only use die grinder attachments with this tool. Do not use drill bits.
AIR TOOL PRECAUTIONS
1. Use only clean and dry compressed air as a power source.
Contaminated or moist air will gradually damage the tool.
2. Install an in-line shutoff valve or regulator to allow immediate control
over the air supply in an emergency, even if a hose is ruptured.
3. Discontinue tool use if it does not work properly or air is leaking.
Tag or mark the tool as ‘defective’ or ‘out of service’ until repaired.
4. Check the manufacturer’s maximum pressure rating for air tools
and accessories. Compressor outlet pressure must be regulated to

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
6 For technical questions call 1-800-665-8685
never exceed the maximum pressure rating of the tool (see
Specifications). Exceeding the maximum PSI rating can create a
bursting hazard, causing injury and property damage.
5. Attach all accessories properly to the tool before connecting the air
supply. A loose accessory may detach or break during operation.
6. Never use oxygen, combustible gas or any other bottled gas as a
power source. Any power source other than an air compressor
could cause an explosion and serious personal injury.
7. Turn OFF the valve and discharge any remaining air pressure after
each use or before adjusting the tool.
8. Do not leave the air tool unattended with its compressed air supply
on. Turn off the compressed air supply and bleed the air tool of any
remaining compressed air before leaving the air tool unattended.
9. Serious injury may occur from loose debris being propelled at high
speeds from the compressed air stream. Always wear OSHA
approved safety glasses to protect the eyes during operation of the
air compressor.
10. Never point the air stream or tools at any point of your body, other
people or animals. Debris and dust may be ejected without
warning. Always turn off the air compressor and drain tank
pressure completely before attempting maintenance or attaching air
tools. Release pressure slowly from the system.
AIR HOSE PRECAUTIONS
1. Inspect the tool's air hose for cracks, fraying or other faults before
each use. Discontinue use if the air hose is damaged or hissing is
heard from the air hose or couplers. Replace the defective air hose.
2. Do not allow people, mobile equipment or vehicles to pass over the
unprotected air hose. Position the air hose away from high traffic
areas, in a reinforced conduit or place planks on both sides of the
air hose to create a protective trench.
3. Prevent damage to the air hose by observing the following:
3.1 Never carry the tool by the air hose.
3.2 Keep the air hose behind the tool and out of the tool's work path.
3.3 Keep the air hose away from heat, oil, sharp edges or moving parts.

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 7
3.4 Do not wrap the air hose around the tool as sharp edges may pierce
or crack the air hose. Gently coil the hose and either hang on a
hook or fasten with a device to keep hose together when storing.
4. A damaged or disconnected air hose under pressure may whip
around and inflict personal injury or damage the work area. Secure
the compressor's air hose to a fixed or permanent structure with
clamps or cable ties.
COMPRESSOR/TANK PRECAUTIONS
DANGER! Do not use an air tank beyond its expiration date. A tank
rupture or explosion may kill or cause a serious injury to yourself
or a bystander. Disable and discard the air tank according to the
your municipality by-laws.
1. Never drill into, weld, patch or modify the air tank. Immediately
replace the tank or compressor if an air leak develops. The leak
may lead to a rupture.
2. Never make adjustments to the components that control tank
pressure. Serious injury or death may occur if modifications are
made to the pressure switch, safety relief valve or other
components that control the tank pressure.
3. Check operation of the pressure relief valve on a regular basis and
never operate without a factory approved pressure relief valve. Do
not make alterations to the factory operating pressure settings.
POWER TOOL PRECAUTIONS
Tool accessory is a general term that refers to drill bit, saw or cutting
blades, grinding wheel, etc. as appropriate for the tool.
1. Do not use any power tool with a malfunctioning power switch or
control. A power tool that fails to respond to the controls is dangerous
and can cause an injury. A qualified technician must repair and verify
the power tool is operating correctly, before it can be used.
2. Do not cover the air vents.
3. Disconnect the power source before installing or servicing the tool.
4. Never force the tool. Excessive pressure could break the tool,
resulting in damage to your workpiece or serious personal injury.
Excessive pressure is the cause if your tool runs smoothly under no
load, but roughly under load.

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
8 For technical questions call 1-800-665-8685
5. Keep hands and fingers away from the work area. Any part of body
contacting the tool’s working parts could cause an injury.
6. Only use accessories that are specifically designed for use with the
tool. Ensure the accessory is tightly installed.
7. Never touch the tool accessory or workpiece during or immediately
after use. They may be hot and could inflict a burn injury.
8. Never use a tool with a cracked or worn tool accessory. Change
the tool accessory before using it.
GRINDING TOOL PRECAUTIONS
WARNING! Some surfaces contain materials which can be toxic.
When working on materials that may contain lead, asbestos,
copper chromium arsenate or other toxic materials, extra care
should be taken to avoid inhalation and minimize skin contact.
1. Only use a grinding die that exceeds the maximum RPM of the tool
(see Specifications).
2. Only use a grinding die with the correct shaft size and shape.
3. Ensure the grinding attachment does not have wear or chipping.
Replace if necessary.
4. Before using the tool on the workpiece, run the tool at the highest
speed, without a load, for at least 30 seconds in a safe position.
Stop immediately if there is any vibration or wobbling that could
indicate poor installation or a poorly balanced grinding attachment.
Check the tool to determine the cause.
5. Sparks may be created when working with the die grinder. Hold the
tool so that sparks fly away from you and other persons or flammable
materials. Keep up-to-date fire-prevention safety instructions in the
event of a fire.
6. Do not use a coolant or water with this die grinder.
7. Do not use as a fixed grinder.
KICKBACK PRECAUTIONS
Kickback is a sudden reaction to a pinched or snagged grinding
accessory. The tool kicks out and away from the workpiece while the
grinding accessory is still active. This can inflict a serious injury on the
user or a bystander. Kickback can also damage the tool or workpiece.

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 9
Kickback can be avoided by taking proper precautions:
1. Maintain a firm grip on the tool and position your body and arms to
allow you to resist a kickback. Kickback will propel the tool in the
direction opposite to the grinding accessory’s direction of rotation. A
snagged grinding die may pull the tool out of the grasp of the user.
2. If kickback occurs, the accessory may:
2.1 pass over a body part, causing a seriously injury;
2.2 wrench the user’s arm causing muscle or joint injuries; and
2.3 strike bystanders.
3. Use clamps or a vice to hold down smaller workpieces.
4. Use special care when working on corners, sharp edges or flexible
material. These workpieces have a tendency to snag the grinding
accessory.
5. Only use grinding accessories designed for the tool.
6. Support large panels to minimize the risk of pinching the grinding
accessory. Large panels may sag under their own weight.
VIBRATION PRECAUTIONS
1. This tool vibrates during use. Repeated or long-term exposure to
vibration may cause temporary or permanent physical injury. Take
frequent breaks when using the tool.
2. If you feel any medical symptoms related to vibrations (such as
tingling, numbness, and white or blue fingers), seek medical
attention as soon as possible.
3. Wear suitable gloves to reduce the effects of vibration.
4. DO NOT use this tool before consulting a physician if one of the
following applies:
a. Pregnant
b. Impaired blood circulation
to the hands
c. Past hand injuries
d. Nervous system disorders
e. Diabetes
f. Raynaud's Disease

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
10 For technical questions call 1-800-665-8685
UNPACKING
WARNING! Do not operate the tool if any part is missing. Replace
the missing part before operating. Failure to do so could result in
a malfunction and personal injury.
Remove the parts and accessories from the packaging and inspect for
damage. Make sure that all items in the contents are included.
Contents: • Air Die Grinder • Wrench
IDENTIFICATION KEY
A Collet
B Wrench Clamp
C Wrench
D Air Inlet
E Collet Nut
F Trigger Lever Safety
G Trigger Lever
H Air Exhaust/Muffler
ASSEMBLY & INSTALLATION
Letter references in parenthesis (A) refer to the included Identification Key
INSTALL AIR COUPLER
Prepare a standard 1/4 in. NPT male air coupler (sold separately) for
use with your tool.
1. Wrap the external threads of the male coupler with sealant tape.
1.1 Wrap tape in a clockwise direction so it will not unravel.
1.2 Do not tape all the threads. Leave several leading threads
unwrapped for easier alignment.
2. Screw the coupler into the tool's air inlet and tighten with a wrench
until snug.
3. Run the compressor at a low volume and check the connection for
air leaks. Do not use the tool until all air leaks are repaired or the
faulty component is replaced.
Fig. 1

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 11
IMPORTANT! Vibration may cause failure if a quick coupler is
connected directly to the air tool. To overcome this, connect a
leader hose to the tool. A quick coupler may then be used to
connect the leader hose to the air line hose.
INSTALL THE GRINDING DIE
Position the grinder with the collet nut (E) to your left and the air inlet
(D) to your right.
1. Swing the wrench clamp (B) to the side and remove the wrench (C)
from the tool’s back.
2. Insert the wrench over the collet nut’s (E)
flats.
3. Press the collet nut (E) into the grinder
body, and rotate the wrench upward to
unlock the grinder collet.
3.1 The die grinder’s underside has arrows
engraved to indicate the direction to
lock the collet (see Fig. 2).
4. Release the collet nut and confirm it is
retracted (Fig. 3-1) .
5. Insert the grinder die shaft into the collet.
Make sure it is fully seated.
6. Rotate the collet nut downward to lock
the die in the collet. The collet unit is
extended when locked (Fig. 3.1).
OPERATION
1. Clean the die grinder of packing grease before first use. Also grease
the spindle gears. See the Air Tool Lubrication section for instructions.
2. Install the grinding die (See Assembly & Installation). The type of
grinding die installed will depend on the material and task.
3. Connect the tool to the air source.
4. Set the compressor to the correct air pressure and flow (see
Specifications). Start the compressor.
5. Push the trigger lever safety (F) forward to free the trigger lever (G).
Fig. 2
Fig. 3
3-1

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
12 For technical questions call 1-800-665-8685
6. Wait until the grinding die has reach full speed before applying it to
the material
7. Test the tool under no load to confirm the grinding die is installed
correctly.
8. Apply the grinding die against the material so the debris is moved
away from the work area. Do not press down too hard, as this can
cause the die to slow or gouge the workpiece.
9. Lift the die grinder from the material and slowly release the trigger
lever. The trigger lever safety will automatically snap back into place.
10. Wait for the grinding die to stop before placing the tool down.
11. Shut the compressor off once the task is completed. Squeeze the
trigger to release residual compressed air from the hose and tool.
Disconnect the tool.
DIES AND ATTACHMENTS
Die grinder dies and attachments are designed to cut, polish and shape
surfaces. Some attachments can be used on any material while others are
designed specifically for wood, plastic or metal. Consult the manufacturer
information to determine the correct use of the die or attachment.
CARE & MAINTENANCE
1. Maintain the tool with care. A tool in good condition is efficient,
easier to control and will have fewer problems.
2. Inspect the tool fittings, alignment, hoses and power supply cord
periodically. Have damaged or worn components repaired or replaced
by an authorized technician. Only use identical replacement parts
when servicing.
3. Verify the die grinder’s speed with a tachometer to ensure it does
not exceed the maximum speed. Have the tool repaired if the max.
speed is higher than the no load speed in Specifications.
4. Follow instructions for lubricating and changing accessories.
5. Only use accessories intended for use with this tool.
6. Keep the tool handles clean, dry and free from oil/grease at all times.
7. Maintain the tool’s labels and name plates. These carry important
information. If unreadable or missing, contact Princess Auto Ltd. for
replacements.

V1.0 1/4 and 1/8 in. Mini Air Die Grinder 8844169
Visit www.princessauto.com for more information 13
8. Keep the vent passages clear of accumulated dirt, dust, and oil.
9. Clean the tool after each use.
WARNING! Only qualified service personnel should repair the
tool. An improperly repaired tool may present a hazard to the
user and/or others.
AIR TOOL LUBRICATION
NOTICE! Only use air tool oil to lubricate the tool. Other lubricants
are not suitable and will damage the tool or cause a malfunction
during use.
NOTICE! Never use a penetrating oil to lubricate an air tool.
Penetrating oil acts as a solvent that will dissolve the tool’s
grease packing and may damage the o-rings, causing the tool to
seize or malfunction.
1. All air tools have an internal coating of grease to prevent corrosion
during shipping and storage. Remove this grease by adding a
generous amount of air tool oil in the air inlet and then run the tool
under no load until the exhaust is clear.
2. Manually add a drop or two of air tool oil into the tool’s male
coupler before each use and after every hour of continuous use.
The tool will not work properly without lubrication and parts will
wear prematurely.
3. Avoid adding too much air tool oil as this can cause premature
power loss and eventual tool failure. A qualified technician will need
to take the tool apart and clean out the excess oil.
4. Apply a generous amount of air tool oil to the tool before storing it
for an extended period of time (overnight, weekend, etc.). Run the
tool for approximately 30 seconds to ensure the oil is evenly
distributed throughout the tool. Store it in a clean and dry location.
DISPOSAL
Recycle a tool damaged beyond repair at the appropriate facility.
Contact your local municipality for a list of disposal facilities or by-laws
for electronic devices, batteries, oil or other toxic liquids.
IMPORTANT! DO NOT pollute the environment by allowing
uncontrolled discharge of waste oil.

8844169 1/4 and 1/8 in. Mini Air Die Grinder V1.0
14 For technical questions call 1-800-665-8685
TROUBLESHOOTING
Visit a Princess Auto Ltd. location for a solution if the tool does not
function properly or parts are missing. If unable to do so, have a
qualified technician service the tool.
PROBLEM(S) POSSIBLE CAUSE(S) SUGGESTED SOLUTION(S)
Tool runs at normal
speed, but loses
power under load.
Motor parts worn. 1. Have a qualified technician
service the tool.
2. Replace tool or parts.
Tool runs slowly. Air
flows slightly from
exhaust.
Motor parts jammed
with dirt particles.
OR
Airflow blocked by dirt.
1. Check air inlet filter for
blockage.
2. Pour air tool lubricating oil
into air inlet as per lubrication
instructions for clearing
shipping grease.
3. Operate tool in short bursts to
clear debris.
4. If tool still jammed, clean tool
and lubricate per lubrication
instructions.
Tool runs slowly. Air
flows slightly from
exhaust.
Air regulator in closed
position.
Open the air regulator to desired
airflow.
Tools will not run. Air
flows freely from
exhaust.
Damage or excessive
wearing of internal
parts.
1. Have a qualified technician
service the tool.
2. Replace tool or parts.
Tool will not shut off. 1. Throttle valve o-ring
dislodged from seat
inlet valve.
2. Trigger mechanism
jammed or dirty.
1. Replace throttle valve
o-rings.
2. Clean trigger mechanism and
lubricate.
Loss of power or
erratic performance.
1. Excessive drain on
the air hose.
Incorrect size or type
of hose couplers.
2. Moisture or
restriction in the air
hose/tank
3. Air compressor has
insufficient flow.
1. Check the air hose and
confirm the hose fitting is
correct for the inlet bushing.
2. Depressurize system and
drain tank and air hose of
water.
3. Ensure tool is connected to a
compressor with a rate flow
that matches the tool.

V1,0 8844169
Vous devez lire et comprendre toutes les instructions avant d'utiliser l'appareil. Conservez ce
manuel afin de pouvoir le consulter plus tard.

MINI DE 1/4 ET 1/8 PO

8844169 Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po V1,0
2 En cas de questions techniques, appelez le 1-800-665-8685
SPÉCIFICATIONS
Pression max 90 lb/po carré
Plage de pression en lb/po carré 75 à 90 lb/po carré
Consommation d'air à 90 lb/po carré 2,8 pi cubes/min
Débit à pleine charge
20 pi cubes/min
Vitesse à vide 25 000 tr/min
Taille de Pince de serrage
1/4 et 1/8 po
Vitesse nominale 1/4 po
Diamètre min. de tuyau 3/8 po
DÉFINITIONS DE DANGER
Veuillez-vous familiariser avec les avis de danger qui sont présentés
dans ce manuel. Un avis est une alerte indiquant qu'il existe un risque
de dommage à la propriété, de blessure ou de décès si on ne respecte
pas certaines instructions.
DANGER ! Cet avis indique un risque immédiat et particulier
qui entraînera des blessures corporelles
graves ou même la mort si on omet de prendre
les précautions nécessaires.
AVERTISSEMENT ! Cet avis indique un risque particulier ou une
pratique non sécuritaire qui pourraitentraîner
des blessures corporelles graves ou même la
mort si on omet de prendre les précautions
nécessaires.
ATTENTION ! Cet avis indique une situation possiblement
dangereuse qui peut entraîner des blessures
mineures ou modérées si on ne procède pas de
la façon recommandée.
AVIS ! Cet avis indique un risque particulier ou une
pratique non sécuritaire qui entraînera des
dommages au niveau de l'équipement ou des
biens, mais non des blessures corporelles.

V 1,0 Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po 8844169
Visitez www.princessauto.com pour plus d'informations 3
INTRODUCTION
La Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po est
idéale pour une grande variété de travaux de découpage, de perçage de
cylindre, de rupture de joints de soudure, d’ébavurage et d’opérations de
polissage et de meulage.
SÉCURITÉ
AVERTISSEMENT ! Veuillez lire et comprendre toutes les
instructions avant d'utiliser cet outil. L'utilisateur doit respecter
les précautions de base lorsqu'il utilise cet outil afin de réduire
le risque de blessure ou de dommage à l'équipement.
Conservez ce manuel qui contient les avertissements de sécurité, les
précautions, les instructions de fonctionnement ou d'inspection et
d'entretien.
AIRE DE TRAVAIL
1. Travaillez dans un environnement de travail sécuritaire. Gardez votre
aire de travail propre, bien éclairée et exempte de toute distraction.
Placez les lampes de façon à ne pas travailler dans l’ombre.
2. Assurez-vous que les personnes qui ne portent pas l'équipement de
sécurité approprié ne se trouvent pas à proximité de l'aire de travail.
3. Rangez les outils correctement dans un lieu sécurisé et sec.
Gardez les outils hors de la portée des enfants.
4. N'installez pas et n'utilisez pas d'outils électriques en présence de
gaz, de poussière ou de liquides inflammables.
SÉCURITÉ PERSONNELLE
AVERTISSEMENT ! Portez de l'équipement de protection personnelle
homologué par l'Association canadienne de normalisation (CSA) ou
l'American National Standards Institute (ANSI).
ÉQUIPEMENT DE PROTECTION PERSONNELLE
1. Portez toujours des lunettes antiprojections qui offrent une
protection frontale et latérale pour les yeux. L'équipement de
protection des yeux devrait être conforme à la norme CSA Z94.3-
07 ou ANSI Z87.1 fonction du type de travail effectué.

8844169 Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po V1,0
4 En cas de questions techniques, appelez le 1-800-665-8685
2. Portez un écran facial panoramique de type approprié avec les
lunettes de sécurité puisque cette tâche peut créer des copeaux,
des matières abrasives ou des particules.
3. Portez des gants qui protègent en fonction des matériaux de travail
et pour réduire les effets des vibrations de l'outil.
3.1 Ne portez pas de gants lorsque vous utilisez un outil dans lequel
le tissu pourrait demeurer coincé, entraînant ainsi la main.
4. Portez des vêtements de protection conçus pour l'environnement
de travail et pour l'outil.
5. Les chaussures antidérapantes sont recommandées pour maintenir
la stabilité et l'équilibre au sein de l'environnement de travail.
6. Portez des chaussures à embout d'acier ou à coquilles d'acier pour
éviter les blessures aux pieds dues à la chute d'objets.
7. Portez un masque antipoussières ou un appareil respiratoire
nominal approprié.
8. Cet outil peut causer des dommages à l'ouïe. Portez un dispositif
de protection anti-bruit présentant une cote de réduction du bruit
adéquate en fonction du niveau de décibels.
9. L’outil peut être à haute pression. Portez des lunettes de sécurité et
des gants pour vous protéger au cours de l'opération. Gardez les
mains à l'écart des parties de caoutchouc exposées du tuyau.
PRÉCAUTIONS PERSONNELLES
Gardez le contrôle de l'outil, de vos mouvements et de l'environnement
de travail pour éviter les blessures ou le bris de l'outil.
1. N'utilisez pas l'outil si vous êtes fatigué ou sous l'effet de drogues,
d'alcool ou de médicaments.
2. Évitez de porter des vêtements ou des bijoux pouvant se prendre
dans les pièces mobiles d'un outil. Gardez les cheveux longs
recouverts ou attachés.
3. N'utilisez pas l'outil si vous devez étirer les bras pour vous en
servir. Une stabilité et un équilibre appropriés sont nécessaires afin
d'avoir un meilleur contrôle en cas de situations inattendues.
4. Soutenez la pièce à travailler ou fixez-la sur une plate-forme stable.
Une pièce à travailler tenue dans les mains ou appuyée contre

V 1,0 Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po 8844169
Visitez www.princessauto.com pour plus d'informations 5
votre corps sera instable et peut entraîner des blessures
corporelles.
5. Gardez vos doigts à bonne distance de la gâchette/commutateur lors
du transport de l’outil ou du branchement d’un tuyau à air ou d’un
accessoire. Engagez le verrou de gâchette/interrupteur, le cas échéant.
6. Évitez les mises en marche involontaires. Assurez-vous que le
régulateur/commutateur est en position neutre ou OFF (arrêt) lorsque
l’outil n’est pas utilisé et avant de le brancher à une source d’air.
7. Des blessures graves ou même la mort peuvent survenir en cas
d’inhalation de l’air comprimé. Le jet d’air peut contenir du
monoxyde de carbone, des vapeurs toxiques ou des particules
solides. N’inhalez jamais l’air comprimé provenant directement de
la pompe ou d’un outil pneumatique.
CONSIGNES DE SÉCURITÉ SPÉCIFIQUES
AVERTISSEMENT! Ne permettez PAS au confort ou à votre
familiarisation avec l'outil (obtenus après un emploi répété) de
se substituer à une adhésion stricte aux règles de sécurité de
l'outil. Si vous utilisez cet outil de façon dangereuse ou
incorrecte, vous pouvez subir des blessures corporelles graves.
1. Utilisez le bon outil pour la tâche à effectuer. Cet outil a été conçu
pour une utilisation spécifique. Évitez de modifier ou d'altérer cet outil
ou de l'utiliser à une fin autre que celle pour laquelle il a été conçu.
2. N’utilisez pas l’outil si des pièces présentent des dommages ou
sont déplacées. Réparez ou remplacez les pièces.
3. L'outil ne s'arrêtera pas immédiatement. Ne posez pas l'outil sur
une surface ou ne le laissez pas sans surveillance avant qu'il ne
s'immobilise. Une pièce mobile pourrait faire sauter l'outil ou
s'agripper à une surface et vous pourriez perdre la maîtrise
de l'outil.
4. Assurez-vous toujours que la surface de travail est dépourvue de
clous ou autres objets étrangers.
5. Après avoir changé les accessoires ou effectué des réglages,
assurez-vous que l’écrou de pince de serrage et tout autre
dispositif réglé sont solidement serrés. Les dispositifs de réglage
desserrés seront projetés avec violence.

8844169 Meule à rectifier les matrices pneumatique mini de 1/4 et 1/8 po V1,0
6 En cas de questions techniques, appelez le 1-800-665-8685
6. Vérifiez toujours si les accessoires sont endommagées avant
chaque utilisation. Les accessoires endommagés peuvent se
casser pendant l'utilisation et causer des blessures graves.
7. Si l’on vous interrompt alors que vous utilisez la meule à rectifier
les matrices, complétez l’opération et placez celle-ci hors tension
avant de soulever le regard.
8. Utilisez des détecteurs de métal et des détecteurs de tension pour
repérer les conduites cachées d'électricité, d'eau ou de gaz. Évitez
de toucher les composants ou les conducteurs sous tension.
9. Utilisez seulement des accessoires de meule à rectifier les
matrices avec cet outil. N’utilisez pas de forets.
PRÉCAUTIONS RELATIVES AUX OUTILS
PNEUMATIQUES
1. Utilisez uniquement un air comprimé propre et sec comme source
d’énergie. L’air contaminé ou humide endommagera progressivement
l’outil.
2. Installez une soupape d'arrêt ou un régulateur sur la conduite afin
de permettre une commande immédiate de l'alimentation en air, en
cas d'urgence, même si un tuyau se fend.
3. Arrêtez d’utiliser l’outil s’il ne fonctionne pas correctement ou s’il
présente des fuites d’air. Attachez une étiquette sur l’outil indiquant
qu’il est « défectueux » ou qu’il est « hors service », jusqu’à ce qu’il
soit réparé.
4. Consultez la pression nominale maximale du fabricant en ce qui
concerne les outils pneumatiques et accessoires. La pression de
sortie du compresseur doit être réglée de façon à ne jamais
dépasser la pression nominale maximale de l'outil (consultez
Spécifications). Si on dépasse la pression nominale maximale, il
pourrait en résulter un risque d’explosion capable d’entraîner des
blessures et des dommages aux biens.
5. Arrêtez d’utiliser l’outil s’il ne fonctionne pas correctement ou s’il
présente des fuites d’air. Attachez une étiquette sur l’outil indiquant
qu’il est « défectueux » ou qu’il est « hors service », jusqu’à ce qu’il
soit réparé.
