Proteco S-Park Series User manual

1
S-PARK - rev.1.1_06_2020
S-PARK
AUTOMATIC ROAD BARRIER
User manual

2S-PARK - rev. 1.1_06_2020
INDEX
1. WARNING 4
2. TECHNICAL FEATURES 4
2.1 Main features 4
2.2 Life line 4
2.3 Electronics 5
3. INSTALLATION 6
3.1 Introduction 6
3.2 Preliminary checks 6
3.3 General layout 6
3.4 Basement preparation 6
3.5 Fixing the barrier on ground 7
3.6 Balancing of the boom 7
3.6.1 Right hand and Left hand mounting 7
3.6.2 Mounting of the boom 7
3.6.3 Manual operation 8
3.6.4 Limit switches 9
3.6.5 Mounting and adjusting of the spring 9
3.6.6 Balancing (boom in unlocked mode) 10
3.6.7 Photocells RF40 10
3.6.8 Led strip 10
3.6.9 Boom accessories 11
3.6.10 Mirror barriers (TWINNING) 11
3.7 Wirings 11
3.7.1 Main power 230V 11
3.7.2 Back-up batteries 11
3.7.3 Stand-alone antenna (optional) 12
3.7.4 Wiring diagram 12
3.8 Legenda of terminals 13
3.8.1 START – wired command contacts (key switch, key pad, timer) 13
3.8.2 STOP – emergency push button or similar devices 13
3.8.3 STRT2 (optional additional START contact) 13
3.8.4 PH – Closing photocell (N.C. dry contact) 13
3.8.5 +24 (SAFETY) Closing photocell (power) 13
3.8.6 +TX - Closing photocell (photocell test) 13
3.8.7 LD (Loop Detector) 13
3.8.8 +24, R, G and B (BOOM) LED signalling strip 13
3.8.9 DAT and GND (TWINNING) 13
3.8.10 AUX – Relay output 13
3.9 Quickstart guide 14
3.10 Locking the upper top cover 14
4. OPERATION 14
4.1 Working cycle 14
4.1.1 LED strip signalling mode - legenda 14
4.1.2 Automatic closing after power cut 14
4.1.3 Programming keys 15

3
S-PARK - rev.1.1_06_2020
5. PROGRAMMING 15
5.1 Settings’conguration 15
5.2 Settings’ list 16
5.3 Setting’s description 16
5.3.1 A. RADIO 16
A.1 Store a remote control as START command 16
A.2 Store a remote control as START2 command 17
5.3.2 C. PROGRAMMING 17
C.1 Boom automatic learning 17
C.3 Reset (factory default) 17
C.4 LHandRHboomconguration 18
C.5  Workinglogicconguration 18
5.3.3 F. TORQUE 18
F. 1 Obstacle detection 18
5.3.4 H. SPECIAL FUNCTIONS 18
H.1 Pre-blinking in closing 18
H.2 Fixed-light blinker 18
H.3 “Follow me” closing 18
H.4 Automatic closing after power cut 18
H.6 Master/slavebarrierconguration 18
5.3.5 L. WORKING TIMES 18
L.1 Automatic closing 18
L.2 Automatic closing (pedestrian opening) 18
5.3.6 P. SAFETY 18
P. 1 STOP 18
P.2 PH (closing photocell) 18
P. 3 LD loop detector 19
P. 4 LED signalling strip (optional) 19
P.5 Light sensor 19
P. 6 Cabinet’s safety switch 19
5.3.7 U. MAINTENANCE 19
U.1 Overall cycles performed 19
U.3 Maintenance countdown 19
U.4 Maintenance recall 19
U.5 Installation date 20
6. DISPLAY 20
6.1 Messages 20
6.2 Faults 20
7. MAINTENANCE 21
7.1 Manual operation double check 21
8. END USER’S TIPS 21
8.1 Warnings 21
8.2 Boom manual release 21
8.3 Maintenance 22
8.4 Disposal 23

4S-PARK - rev. 1.1_06_2020
1. WARNING
This manual for S-Park series contains important information concerning personal safety.
An incorrect installation or an improper use may lead to severe injuries.
Read carefully and pay particular attention to the safety sections marked by the yellow triangle.
S-PARK series is projected to control transit areas; if necessary, provide a special and separate entry way for pedestrians.
The installation of automatic doors, gates and barriers must comply with the Machinery Directive 2006/42/CE and EN 12453
regulation,andperformedbyqualiedpersonnel.
Make sure the main power line is equipped with state of the art safety grounding system; as well be sure the whole installation is
protected by a power cut switch and against overcurrent.
Make sure the area is clear from flammable gases and/or electromagnetic interferences: it could lead to very dangerous injuries.
Switch the power and batteries OFF before any operation.
After installation, packaging and waste materials (cardboard, plastic, metal parts etc.) must be kept away from children as they could be
potentially harmfull.
Use only original spare parts. Any alteration to the system is prohibited. Proteco Srl will not respond in case of using additional and/or
fake spares.
Before commissioning the system, deliver the last pages of this manual to the user (section 8. END USER’S TIPS starting from
page 21).
Proteco S.r.l. reserves the right to make changes to the product without notice.
Main power
Max. absorption
Motor power
Accessories
Torque
Opening time
Operating temperature
Duty cycle
IP rating
2. TECHNICAL FEATURES
2.1 Main features
230V 50/60 Hz 230V 50/60 Hz
1,2A @ 230V 1,2A @ 230V
24V dc 24V dc
24V dc 24V dc
120 Nm 180 Nm
2.5 ÷ 4 sec. 4.5 ÷ 6 sec.
-25°C ÷ +55°C -25°C ÷ +55°C
80% 80%
(max 200 cycles/hour) (max 130 cycles/hour)
54 54
S-PARK 4 S-PARK 6
Boom up to 4 m Boom from 4 to 6 m
Fig. 1: Dimensions
2.2 Life line
The life of the barrier may be affected by multiple waste factors.
The life expectation can be calculated using the following
criteria.
In order to get the barrier waste rate refer to the information
included in Table 1, add together all values that comply with
the installation scenario along with the accessories installed.
The result achieved will be a value between 0 and 10, and it
represents the waste rate to be applied on the below graph
to calculate the estimated life rate.
ATTENTION: If the waste rate obtained is beyond
10, move to a superior barrier version in order to
fulll the expected performances .
S-Park 4 S-Park 6
Boom from 3 to 4 m length 1 -
Boom from 5 to 6 m length - 2
Photocell operation frequently cut 1 1
Normal operation frequently cut due to obstacle 0,5 1
Seaside areas 0,5 0,5
Sandy and dusty areas 1 1
Signicantly windy areas 1 2
Articulated boom 2 2
Boom tted with moving support 1 2
Boom tted with hanging rack 1 1,5
Boom tted with led strip 0,5 1
Outside temperatures often beyond 40° or below 0° 0,5 0,5
Table 1: Waste rate

5
S-PARK - rev.1.1_06_2020
Follow the waste rate line on the bottom of the graph to get the estimated
duty cycles.
The duty cycles obtained may be compromised if the maintenance plan is
not carefully respected.
Duty cycles are determined on the base of design analysis, project
calculations and tests carried out at factory.
Therefore the duty cycles achieved are a mere estimation.
2.3 Electronics
TERMINALS
FUSE
APP connector SCREEN
ANTENNA
KEY
KEY
KEY
KEY
START commands START, START2 (pedestrian opening), STOP
Radio 433 MHz embedded radio receiver, storage up to 96 random o rolling codes
Safety devices Closing photocell, loop detector (congurable)
Additional appliances TWINNING (mirror barriers), timer, light sensor
Outputs RGB led signalling strip
AUX output
Optional interfaces Expansion connector for optional modules
Connector for home automation usb key / APP
Main functions Operation mode, Obstacle detection, Follow me closing, Startup automatic closing,
Pre-blinking, Maintenance countdown, Maintenance alert, Installation date
ESTIMATED DUTY CYCLES
WASTE RATE

6S-PARK - rev. 1.1_06_2020
500 mm 500 mm
600 mm
500 mm
400 mm
3. INSTALLATION
3.1 Introduction
For a proper installation, strictly follow the following procedure, re-
specting the below chronological order:
• Prepare a strong basement using ferro concrete.
• Fix the cabinet to ground.
• Fit the boom and accessories.
• Adjust and balance the spring.
• Proceed to self-learning programming and adjust settings.
Additional information:
• TWINNING function, it allows to manage two mirror barriers.
• RGB led singnalling strip available to complete the boom.
•Photocellsandsimilarsafetyobstacledetectiondevicescanbetted.
3.2 Preliminary checks
Before proceeding to installation, it is necessary to double check
the good condition of every component of the barrier and make
sure the site is suitable for installation purposes.
• All components must be integral and suitable to use.
• Make sure the installation site complies with system’s dimensions.
• Make sure the concrete basement grants stability and solidity.
• Make sure the area around the barrier is clear enough to allow
eazy and safe manual operation.
3.3 General layout
As shown in the below plan view, a safety clearance of 500 mm all
around the barrier area has been left.
While the boom length can be adjusted, the concrete basement
remainsxedasitisbuilt(Picture 2).
Boom from 4000 to 6000 mm
Picture 2: Overall layout
3.4 Basement preparation
It is absolutely key to build a solid concrete basement (at least
EN206 C25/30 proof).
Basement dimensions must be no less than 400x500mm and no
less than 600mm deep.
We recommend to consider an extra concrete surface of 200 mm
all around the basement. (Picture 3)
Pay attention while arising the basement, since the concrete work
cannot impedetostudthexingscrews.
Do not forget wirings!
While preparing the concrete basement keep a duct of the proper
dimension to connect the main power and any possible additional
devices.
Picture 3: dimensions
Fit anchor screws M10 with nut and washer.
Nut and washer must be positioned in the same way for each single
bolt,inordertocreateabalancedsupportforgroundplatexing.
InsertanchorscrewsM10throughthegroundplateholes,twashers
and nuts M10 to protruding part of anchor screws, as shown below.
(Picture 5)
Pourtheconcrete,flushthesurfaceandxthegroundplate.
Be careful not to soil the upper face of the plate and the threads
of the anchor screws. Wait a few days before proceeding with
the installation of the S-Park.
Picture 4: Cabinet foundation
CONCRETE
BASEMENT
GROUND
PLATE
ANCHOR SCREW M10
WIRING

7
S-PARK - rev.1.1_06_2020
3.5 Fixing the barrier on ground
Remove washers and bolts M10 screwed on ground plate, lay the
cabinet on the concrete basement and match protruding anchor
screws to slots of cabinet floor. (Picture 6)
UseflatwashersM10,groverwashersandboltsM10providedtox
the cabinet to the ground plate.
Keep the barrier’s door facing inside the property.
Picture 5: Ground plate
Picture6:Cabinetxing
Picture 7: Cabinet to the ground plate
-
BASE PLATE
GROUND
PLATE
3.6 Balancing of the boom
3.6.1 Right hand and Left hand mounting
The barrier is available in one single version and can switch from
right to left hand and viceversa.
Once the barrier hand is determined, proceed to t the spring
accordingly as shown in the above picture.
If you need to change the opening orientation, complete the installation
rstandthenfollowtheinstructionsrotatingto90°theequalizer
lever before repositioning the boom and spring.
ATTENTION: FOR SAFETY REASONS REMOVE THE BOOM JUST
WHEN IN VERTICAL POSITION
3.6.2 Mounting of the boom
After determing the closing orientation, if necessary cut the boom
according to the length needed.
Werecommendtotthecutsideoftheboomtothexingplate.
Fix the bracket to the barrier plate: leave screws a bit loose, in order
to make the boom insertion as easy as possible.
Fit the boom inside the bracket and screw the 4 sets of washers and
screws M10. (Picture 9)
Picture 9: bracket mounting
Right version Left version
Picture 8: RIGHT (RH) and LEFT (LH) barrier version

8S-PARK - rev. 1.1_06_2020
BRACKET
Picture 10
FRAME
RUBBER
PROFILE
RUBBER
PROFILE
CAP
CAP
Adjusttherubberproleabitshorterthantheboom’slength(about
19cm shorter). (Picture 10)
Fit the rubber prole into the according compartment inside the
boom’s frame, and lead it till the end, then adjust leaving a gap of
1 cm. (Picture 10/11)
Nowttherubberprolecapandxitwithsilicone.
Thenproceedtottheboom capand x it with the provided
self-threading 3,5x32mm screw, refer to Pitcure 12.
Picture 11 Picture 12
Finally,xtheanti-shearingcoverwiththetwoM5screwssupplied,
using the two inserts on the bracket. (Picture 13)
Picture 13
M5X16 screws
ATTENTION:
BEFORE FITTING THE BRACKET COVER, BREAK THE PLASTIC
COMPARTMENT AS SHOWN IN PICTURE 14.
Picture 14
3.6.3 Manual operation
In order to facilitate adjustments, balancing, spring and limit switch
regulation, put the barrier in manual operation mode.
Put the barrier to manual operation mode just after completing
the whole installation. Be carefull when releasing the boom,
it could accidentally lift up and be dangerous.
Use the lock located on the right side of the cabinet.
Turn the key anticlockwise to release the handle.
Rotate the handle clockwise all the stroke long to unlock the barrier:
now it is possible to manually move the boom.
Picture 15
Picture 16
In order to lock the barrier again, turn counterclockwise the handle
until the two symbols of locked padlock are in line.
Finally, turn the key of the lock clockwise to lock the handle, and
remove the key from the barrel.
The barrier is provided with one key set to manage both the lock
and cabinet's door.
PRE-BREAKING
COMPARTMENT
CUT SIDE

9
S-PARK - rev.1.1_06_2020
1 2 3 3 2 1
3.6.4 Limit switches
In order to adjust the stroke of the boom, open the cabinet door,
unlock the automation as explained above and use the two threaded
pins on the "V" reinforcement positioned above the gearbox.
Turn the two pins clockwise / counterclockwise to increase or
decrease the stroke of the boom and evaluate the most correct
position according to the inclination of the ground where the barrier
willbetted.
Picture 17
LIMIT SWITCHES
3.6.5 Mounting and adjusting of the spring
Before proceeding to balancing, make sure the spring is tted to
the proper hole, considering the boom weight and length and
possible accessories, as outlined in Table 2.
There are three different springs (A/B/C) that can be matched to
three different holes (1/2/3). Example: if matching all the data you
getasresultA3,itmeansspringA(MM010)ttedtohole3.
Lookingattheequalizerleveryouwillnd3holesontherightside
and 3 holes on the left side. If the boom closes to the right side, use
the holes on the left side of the equalizer lever and viceversa.
Picture 18
• Make sure the barrier is unlocked and put the boom to vertical
position.
• Lock it again.
• Drive the M12 hexagonal screw through the spring hole, and
put a washer as spacer. The screw’s head must be oriented as
shows Picture 18.
• Fit the spring to the equalizer lever, using the proper hole.
Put a washer in order to facilitate rotation.
• Tighten bolt and washer M12.
• Use the hook to secure the spring to barrier’s plate, as shows
Picture 19.
ATTENTION: The barrier’s plate is provided with two xing points,
on the left and right side. Make sure spring is hooked to the
proper xing point according to the barrier’s hand.
WASHER M12
JOINT M12
THREADED BAR M12
SCREW TE 12X45
SPRING
TRIGGER M8
Picture 20: Spring components
Legenda of springs
MMO10 A
MMO11 B
MMO12 C
BOOM FEATURES 2-3m 3-4m 4-5m 5-6m
BOOM (integrated with rubber prole) A 2 A 1 B 2 B 1
BOOM + LED STRIP A 2 A 1 B 2 B 1
BOOM + MOVING SUPPORT A 1 B 3 B 1 C 1
BOOM + HANGING RACK A 2 B 2 B 1 C 1
BOOM+HANGING RACK+MOVING SUPPORT A 1 B 2 B 1 -
ARTICULATED BOOM B 2 B 1 C 3 C 2
BOOM + LED STRIP + MOVING SUPPORT A 1 B 3 B 1 C 1
BOOM + LED STRIP + HANGING RACK A 2 B 2 B 1 C 1
BOOM + LED STRIP + HANGING RACK A 1 B 2 B 1 -
ARTICULATED BOOM + LED STRIP A 1 B 1 C 2 C 1
Table 2: Guideline to matching of spring and equalizer lever hole
Picture 19
LH holes RH holes
RH Barrier LH Barrier
BOLT M12
HOOK
EQUALIZER LEVER LAYOUT
BOLT M12
EQUALIZER LEVER

10 S-PARK - rev. 1.1_06_2020
3.6.6 Balancing (boom in unlocked mode)
Picture 22
30°
OK
3.6.7 Photocells RF40
The cabinet is provided with pre-drilled housings for RF40 photocell
mounting, protected by plastic covers.
Remove covers using a flathead screwdriver.
Use the big central hole to drive the power cable through.
Theremainingholesaresupposedtoxthephotocell’sbase(use
3,5x9,5 self-threading screws provided).
Oncethebaseisxedcompletewithcover(use3,5x9,5self-threading
screws provided) and screw.
Put photocells at the most suitable heigth according to your needs.
Refer to Chapter 3.7.4 Wiring diagram p. 12.
Picture 23
Picture 24
3.6.8 Led strip
The LED strip increases the visibility of the barrier during operation.
Drive the LED strip through the proper compartment inside the
rubberprole.
LED lights have to be downward oriented, refer to Picture 25
Picture 25
LED downward
Picture 21
For a proper balancing adjust the
tension of the spring:
• rotate the spring anticlockwise
to decrease the tension
• rotate the spring clockwise to
increase the tension.
Movetheboommanuallyto30°position,asshowsPicture 22.
Make sure the boom remains still keeping the position.
If the boom moves to opening position , decrease the spring tension.
If the boom moves to closing position, increase the spring tension.
ATTENTION: IT IS MANDATORY TO
PROCEED TO BALANCING BEFORE
ACTIVATING THE BARRIER, IN ORDER
TO AVOID INCORRECT OPERATION.
Balancing must be performed just after
completing the whole barrier installation.
Unlock the barrier as previously
outlined (Refer to chapter 3.6.3
Manual operation, p. 8 ).

11
S-PARK - rev.1.1_06_2020
+ - + -
If the LED strip struggles when passing through the compartment,
put a little oil to facilitate the insertion.
Thendrivethe powerwirethroughthebracket,beforettingthe
boom.
Fix the wire exactly as shown in Picture 27, then drive it through one
of the cabinet’s holes, the most suitable one according to installation
features and proceed to wiring (refer to Chapter 3.7).
Fixthecaptotherubberproleusingtheprovided3,5x19screw.
(Picture 26)
ATTENTION: If for any reason the LED strip has been cut, put
siliconeonthecutsidebeforettingthecaptotherubberprole.
3.6.9 Boom accessories
Ifyouplantottheboomwithanyaccessory,doitbeforeproceeding
to programming.
3.6.10 Mirror barriers (TWINNING)
Picture 27 Picture 26
SELF-THREADING
SCREW 3,5X19
Mirror barriers installed on the same drive way (as shows the above
picture) can work simultaneously if wired together on TWIN terminals.
The master barrier will command the slave barrier; slave barrier
may only stop if detecting an obstacle during operation.
Any safety and command devices shall be wired to the master
barrier only.
As well the master barrier is the only one that shall perform pede-
strian opening, terminal START2.
Master barrier settings Slave barrier settings
Set function H.6 to 1 Perform C.1 programming
Set function P.2 to 0
Set function H.6 to 2
Refer to Chapter 3.8.1.9 DAT + GND (TWIN), p. 25.
3.7 Wirings
3.7.1 Main power 230V
The main power terminal is located on the upper side of the cabinet,
close to control unit:
MAIN POWER
230 Vac
ATTENTION: factory pre-wiring,
do not make any alteration.
PHASE
GROUND
COMMON
3.7.2 Back-up batteries
BATTERY
CONNECTOR
Use two 12V / 1,2Ah batteries wired
in series;
Wire cable + (red) to red faston
Wire cable – (black) to black faston.
Grey faston remains free.
Battery 12V dc
1,2 Ah
Battery 12V dc
1,2 Ah

12 S-PARK - rev. 1.1_06_2020
3.7.3 Stand-alone antenna (optional)
ThecontrolunitisttedwithaWhipantenna.
If you wish to connect an external stand-alone atenna, remove the
Whip aerial and wire the core cable (RG58); wire the shield cable
on the other terminal as shown in the picture.
SHIELD
CORE
3.7.4 Wiring diagram
(The below diagram is a mere overall view
about all
possible wirings)
AUX
TWIN SLAVE
BARRIER
LED
STRIP
LOOP DETECTOR
(NO or NC contact)
TRANSMITTER
RECEIVER
INFRARED BEAM

13
S-PARK - rev.1.1_06_2020
3.8 Legenda of terminals
3.8.1 START – wired command contacts
(key switch, key pad, timer)
Any start command contact shall be wired on this terminal, refer to
Chapter C.5 Inputs set up p. 18.
Any pulse below 10 seconds is considered a regular START command,
including automatic closing mode (L.1 automatic closing); any pul-
se over 10 seconds activates the timer mode and the barrier will
remain in opening position according to the timer settings.
Wire N.O. contacts between START (or START2) and COM.
Any additional contact shall be wired in parallel.
3.8.2 STOP – emergency push button or similar devices
Any stop command contact shall be wired on this terminal.
Multiple stop contacts shall be wired in series.
Wire N.C. contacts between STOP and COM.
If N.C. contact opens the barrier stops. If no STOP contact is wired,
deactivate parameter P. 1 STOP contact set up p. 18, otherwise
no operation will start.
Any single STOP pulse immediately stops the operation.
3.8.3 STRT2 (START2: pedestrian opening)
The operation logic is the same of START.
Just set the pedestrian automatic closing, parameter L.2 Pedestrian
automatic closing p. 18.
In case of mirror barriers installation (TWINNING set up), STRT2 will
open just the master barrier.
3.8.4 PH – Closing photocell (N.C. dry contact)
Any closing photocell and similar devices shall be wired on this
terminal, N.C. contacts.
Wire the receiver’s N.C. contact between PH and GND.
Additional photocells shall be wired in series.
Power the receiver on +24 (and GND), while the transmitter on +TX
(and GND).
Refer to chapter 3.7.4 Wiring diagram p. 12 to get the complete
wiring view.
3.8.5 +24 (SAFETY)
Closing photocell (power)
This terminal permanently powers at 24Vdc, 0,5A all safety devices.
On the contrary, +TX terminal cuts power during photocell test.
3.8.6 +TX - Closing photocell
(cuts power during photocell test)
This terminal powers at 24Vdc, – 0,3A all safety devices, but unlike
+24 (SAFETY) cuts the power during photocell test.
3.8.7 LD (Loop Detector)
This terminal can manage both N.O. and N.C. contacts; loop detector
works as closing photocells do, but in addition can also command
an opening start pulse.
Wire the loop detector between LD and GND, and activate parameter
P.3 LD set up p. 19 choosing the desired function and contact.
3.8.8 +24, R, G and B (BOOM)
LED signalling strip
Wire the LED strip to BOOM terminal, according to colors: black
wire to +24, red wire to R, yellow wire to G and white wire to B.
The LED strip lights up showing the different operation modes;
parameter P.4 LED strip conguration p. 19, allows to set up the
signalling mode.
Thiscongurationhastobesetwhenboomisinclosingposition.
+24Vdc, 0,5A voltage is permanent on terminal +24.
Itispossibletokeeptheboomlitduringnight:talightsensor,N.O.
dry contact and wire it in series to +24 terminal (BOOM).
Then activate parameter P.5 light sensor mode p. 19.
It is possible as well to wire the light sensor’s contact between
START2 and COM, or between LD and GND; in this case LD and
START2 loose their initial function.
3.8.9 DAT and GND (TWINNING)
These terminals are used to activate the TWINNING function in
case of a mirror barrier installation.
Wire DAT to DAT and GND to GND of both barriers, then set up
parameter H.6 Master/Slave mode p. 18.
If the distance between the two barriers is more than 14m, use a
screened cable: shield to GND and core to DAT.
3.8.10 AUX – Relay output
This terminal AUX allows the connection of a relay (N.O. contact)
that can feature several functions.
Refer to Chapter A.6 AUX conguration p. 17.
Contacts can max. bear 250V ac/dc, 10 A.
It’s a dry contact, therefore it cannot power direct any device.
Use an external power supply, or in alternative+24V from +24
SAFETY terminal able to power up to 300 mA.

14 S-PARK - rev. 1.1_06_2020
3.9 Quickstart guide
Once the installation is mechanically and electrically completed,
close the cabinet door and proceed to the following steps:
• Boom programming: perform C.1 p. 17.
IMPORTANT: the programming procedure has to be repeated
every time anything on the boom changes: weight, length,
balancing, limit switch, run.
• Adjust settings.
• Store remote controls if expected.
Refer to parameter A.1 Remote control storage as START
fucntion or A.2 Remote control storage as START2 pedestrian
functionp. 16 - 17.
• Double chek the overall operational status – safety devices
particularly.
Refer to Chapter 4.1 Working cycle p. 14, to get a closer detailed
view of the boom operation logic.
Refer to Chapter 5. Programmingp.15forsettingsconguration.
3.10 Locking the upper top cover
After completing the whole barrier installation and regulation, close
the cabinet door without locking.
Proceed to wire the blinker integrated in the cover to the control unit.
Fit the upper cover and secure it with screws M3, refer to Picture 28.
Lock the cabinet door by key, in this way the embedded safety
microswitch will activate.
The microswitch allows to carry out maintenance in safety conditions,
since it stops any possible commands from remote (additional
information available at Chapter P.6 Door switch set up p. 19.
Picture 28
SCREWS M3X20
SCREWS M3X20
CABINET
BLINKER
CONNECTOR
COVER
4. OPERATION
4.1 Working cycle
During normal operation the barrier could be in one of the following
mode:
• STILL MODE: Just when the barrier is in STILL mode it is possible
to program it or adjust settings.
The blinker is OFF and the display is in stand-by “ _ _ “.
• OPENING MODE: The blinker flashes slowly and the display
shows “/ \” opening.
If during opening the barrier detects an obstacle, the boom
reverts to closing position, remains still for 10 seconds (the
display shows count-down) and then starts to open again.
• AUTOMATIC CLOSING COUNTDOWN:
When countdown begins the blinker starts flashing briefly for
afewsecondsswitichingthentoxedlight.
If a start command is sent during countdown, the automatic
closing is suspended.
Refer to Chapter C.5 Working logic, p. 18.
• CLOSING MODE: If during closing the barrier detects an
obstacle or photocell’s beam is cut, the boom reverts to OPENING
position.
4.1.1 LED strip signalling mode - legenda
Barrier’s status Signalling
Unidentiedposition(nofull
duty cycle has been performed
yet)
Red light ON, blinker may slowly
flash.
The boom might be in low position,
refer to chapter P.4, p. 19.
Still mode, not in opening
position
Red light ON, blinker may slowly
flash.
The boom might be in low position,
refer to chapter P.4, p. 19.
During opening Red light ON.
Opening position, NO automatic
closing or automatic closing
countdown over 5 seconds
Green ligh ON.
In opening position, automatic
closing countdown below 5
seconds
Red light ON.
During closing Red light flashing
4.1.2 Automatic closing after power cut
Once the power supply is restored, after 15 seconds the barrier
startsclosing,ifallthefollowingconditionshavebeenfullled:
• Parameter H.4 Automatic closing after power cut p. 18 is
activated.
• Parameter C.4 LH and RH boom conguration p. 18 is not
set to position 2 (factory setting).
• No wired/radio command is sent, no key is pressed.
During the 15 seconds the system doubles check that all the a.m.
tips have been respected.
Ifthisisthecase,theblinkerwillflashshortlytoconrmclosingwill
start soon.

15
S-PARK - rev.1.1_06_2020
Keys (OPERATION MODE) Functions
START pulse
START2 pedestrian pulse
together with
(press and while holding press )
Opening command
together with Closing command
(hold it pressed for short seconds) Programming menu: the
display shows A.1
4.1.3 Programming keys
Pressing any key during operation the barrier stops.
With an exception for key : if pressed during countdown the barrier
starts immediately working again, refer to Chapter 4.1 Working
cyclep. 14.
When barrier is in still mode, the display may show “- -” flashing, or
just “- “ if energy save is on and in this circumstance it is possible
to handle the following service keys and functions:
KEY
KEY
KEY
KEY
In programming mode the display alternately shows the outstanding
parameter and its value.
Ex.: parameter H.2/value1,thedisplayreadsrst“H.2” and after “01.”.
In this circumstance it is possible to handle the following programming
keys and functions:
Keys
(PROGRAMMING MODE)
Functions
This key increases the value of the
parameter.
This key decreases the value of
the parameter till 0
This key switches from menu to
menu (ex. H.3 - J.1).
From U.x menu the control unit
returns back to A.1.
This key switches from parameter
to parameter (ex. H.3 - H.4).
From last parameter the control
unitreturnsbacktotherstone
(ex. H.6 - H.1).
together with This key quits the programming
and returns to operation mode.
5. PROGRAMMING
5.1 Settings’ conguration
Proceed to programming only when the barrier
is in still mode (any key pressed during operation
stops the barrier).
Press key and hold shortly (a quick pulse is
insufcient):displayreads“A.1”.
Press asmanytimesasndingthedesired
parameter expressed by an alphabetical letter
(left side of the display).
Then press asmanytimesasndingthe
gurecorrespondingtothedesiredparameter
(right side of the display).
Ex.: if you wisht to set parameter H2, press
three times (scrolling through C.1, F.1 and
H.1), then press again to move to H.2.
Once the desired parameter is reached, use
and to increase or decrease the value.
Pay attention: when display reads the desired
parameter, wait a little while to read the
according value.
Thescreenrstreadstheparameterandafter
its value.
If you wish to move to another parameter,
follow the procedure previously mentioned.
To quit the programming press and
together.
The control unit, however, automatically quits
the programming after two minutes of inactivity.
Some parameters are merely functions and
therefore are not matched to any value.
These functions usually require a longer or
shorter pressure of key toconrmexecution.
Unlike other functions as A.1, A.2 and A.3
that do only require a radio signal.
PRESS P
FOR A LITTLE WHILE
PRESS P
PRESS P
PRESS P
PRESS S
TO SWITCH
TO NEXT SETTING
DEFAULT 0
PRESS +
TO INCREASE
PRESS -
TO DECREASE
PRESS S - P
TO QUIT
THE PROGRAMMING

16 S-PARK - rev. 1.1_06_2020
5.2 Settings’ list
Herebelowyouwillndaresumeofallavailableparametersandfunctions.
More details are found in Chapter 5.3 Settings’ description p. 16.
ID DESCRIPTION Default LINK
A
A.1 Store a remote control as “START” command C.5
A.2 Store a remote control as START2 pedestrian command C.5
P. 5
A.3 Store a remote control as AUX / 2nd channel A.6
A.4 Delete a single remote control
A.5 Delete all remote controls
A.6 AUX/2ndchanneloutputconguration 1A.3
U.4
C
C.1 Automatic programming C.4
C.3 Reset (factory default)
C.4 LhandRHboomconguration 2C.1
C.5 Workinglogicconguration 0
FF. 1 Obstacle detection 5
H
H.1 Pre- blinking 0
H.2 Fixed-light blinker 0
H.3 “Follow me” closing 0
H.4 Automatic closing after power cut 1
H.6 TWINNING(master/slavebarriersconguration) 0
L
L.1 Automatic closing 8
L.2 Automatic closing pedestrian opening 12
P
P. 1 STOP 0
P. 2 PH (closing photocell) 1
P. 3 LD (loop detector) 0P. 5
P. 4 Boom light mode when in closing position (optional led strip) 1P. 5
P. 5 Light sensor 0P. 4
P. 6 Cabinet safety switch 1
U
U.1 Overall cycles performed
U.2 Cycles performed since last maintenance U.4
U.3 Maintenance countdown 1U.4
U.4 Maintenance recall 0
U.5 Installation date
U.6 Trouble shooting and “dead man” functions
5.3 Setting’s description
5.3.1 A. RADIO
This menu includes procedures about how to store radio devices,
remote controls mainly.
Everyremotecontrolstoredisautomaticallyidentiedbyaprogressive
number: if by accident a remote control is lost it can be deleted
from the control unit memory.
It is possible to store up to 96 different users; when a remote control
is deleted its radio position still remains available for a new remote
control storage.
Any key of the remote control can be set up as follows:
• START command, corresponding to a wired contact to START
terminal
• START2 pedestrian command, corresponding to a wired contact
to START2 (STRT2) terminal
• AUX feature, known as well as 2nd radio channel, matchable
to AUX output.
Choose the function you need before starting storing any key of the
remote control.
There are three different settings available (A.1, A.2 and A.3)
corresponding to different functions.
A.1 Store a remote control as START command
Set A.1. Press the remote control (the display reads“Y-”) together
with to store.
If successfull the display will show the radio position matched to the
remote control.
In case of an already existing remote control, the display will only
show its radio position (01, 02, …).
If storage capacity is full the display will reads “FF”.
It is important to press the remote control’s key and together,
otherwise the storage will not be successfull and the control unit
might save any incoming undesired radio signal.
If you have additional remote controls to store, repeat the same
procedure.

17
S-PARK - rev.1.1_06_2020
Set C.1 and press holding during 5 seconds.
If C.4 isnotconguratedyet,thedisplaywill
show the boom hand (boom has to be in horizontal
position).
Press to set a RH boom or to set a LH boom.
If C.4isconguratedthedisplayremainsclear.
Boom performs 6 steps; every step is shown
on the display (01, 02, 03...) with a short pause
in between.
In any moment it is possible to stop the boom
operation, just pressing any key.
A.2 Store a remote control as START2
pedestrian command
Set A.2 and repeat the same procedure here above.
For more details refer to Chapter 3.8.1.3 STRT2 (START2) p. 13.
A.3 Store a remote control as AUX/2nd radio channel
Set A.3 and repeat the same procedure as per A.1 here above.
At the same time set parameter A.6 according to the desired
congurationorinalternativeuseaMRX-01 optional interface card
module duly set up.
A.4 Delete a single remote control
Everyremotecontrolstoredismatchedtoaradiopositionidentied
by a number.
Set A.4, press or tondtheremotecontrolyouneedtodelete
then press both keys together and hold until the display flashes
“”.
If there is just remote control stored, the display will show just that
one.
A.6 AUX - Functions/Modes
0AUX output is OFF.
AUX output is ON if U.4 maintenance recall is activated
1
(default)
2nd channel / MONOSTABLE: the output is activated by a remote
control stored in A.3 AUX. The contact closes when giving
and holding a start pulse with the remote control. The contact
opens just when the remote control’s key is released.
22nd channel /BISTABLE: the output is activated by a remote
control stored in A.3 AUX. The contact closes or opens when
giving a start pulse with the remote control.
3SIGNALLING BOOM IN VERTICAL POSITION: the output is
activated when the boom is in vertical position. If the control unit
came about to be powered it may not detect the boom position,
therefore the signalling light may remain switched off.
4SIGNALLING BOOM IN HORIZONTAL POSITION: the output is
activated when the boom is in horizontal position.
If the control unit came about to be powered it may not detect
the boom position, therefore the signalling light may remain
switched off.
5COURTESY LIGHT (30”): the output is activated when the
contact closes and remains closed during the whole working
cycle. The contact opens after 30 seconds after working cycle
is completed.
6COURTESY LIGHT (60”): the output is activated when the
contact closes and remains closed during the whole working
cycle. The contact opens after 60 seconds after working cycle
is completed.
7COURTESY LIGHT (90”): the output is activated when the
contact closes and remains closed during the whole working
cycle. The contact opens after 90 seconds after working cycle
is completed.
5.3.2 C. Programming
C.1 Boom automatic learning
Boom automatic learning must be perfomed just when installation is
fully completed (balancing included).
The control unit learns about the mechanical features of the boom:
working cycle, speed, torque.
If for any reason mechanical features should change (new accessories
tted that may affect the boom weight) the automatic learning
procedure shall be repetead.
Learning logic: the procedure expects 3-opening steps and 3-closing
steps.
If for any reason one of the steps is cut, procedure shall be repeated
in full.
A.5 Delete all remote controls
Set A.5, the display will show “.-” , press toconrmyouwish
to delete all remote controls stored and hold during 5 seconds;
if all remote controls have been successfully deleted, the display
flashes “ ”.
A.6 AUX /2nd radio channel output conguration
The AUX is a multifunction output: it can be used as maintenance
recall, refer to chapter (U.4 maintenance recall p. 19).
Or it can set up the following modes/functions:
Step (01), boom slowly opens until detecting the mechanical limit
switch.
If the boom works to the opposite direction, stop the operation and
properly set up C.4. Then repeat C.1.
Step (02), boom slowly lows down until detecting the closing position;
the following steps are meant to set speed, torque and double
check all settings.
The automatic learning is successfully completed when display
shows “ ” flashing.
RH BOOM LH BOOM
C.3 Reset (factory default)
Set C.3, press ,holdduring5secondstoconrmreset(returnto
factory settings).
Parameters U.5, U1 and U.2 CANNOT be reset and no remote
control previously stored can be deleted.
Now repeat C.1 procedure.
Reset is successfully completed when display shows “ ” flashing.

18 S-PARK - rev. 1.1_06_2020
C.5 Working logic conguration
It is possible to set 3 different working logics:
C.5 Working logic
0
(default)
SEQUENTIAL
Every START command stops or reverts the working
cycle according to the sequence: OPEN – STOP –
CLOSE – OPEN ...
1 PRIORITY TO OPENING
Every START command gives priority to opening; boom
automatically closes according to the time set (refer to
L.1 Automatic closing)
2 STEP BY STEP
START terminal commands the opening; START2 terminal
commands the closing.
Automatic closing activates if congurated, refer to L.1
Automatic closing and L.2 Automatic closing
pedestrian opening
5.3.3 F. Torque
F.1 Obstacle detection
Obstacle detection is a safety feature that complies with outstanding
regulations and makes the barrier area more protected and safer.
If during operation any speed alteration or sudden stress are
detected, the barrier stops in order to avoid or limit damages to
persons or objects.
This feature can be adjusted on different sensitivity levels:
0 = detection is OFF while 10 = maximum detection sensitivity;
factory value (default) is set to 5.
H.3 “Follow me” closing - Functions
0
(default)
The function is OFF.
The barrier closes according to the automatic closing time set up.
1The barrier closes 2 seconds after completing the opening.
2 ... 10 The barrier closes according to the delay time set, from 2 to 10
seconds when photocell beam is cut and before the opening
is completed.
H.4 Automatic closing after power cut
If you set H.4 to 1, in case of power cut the barrier will close 15
seconds after power is restored.
This function can be activated only if conditions included in chapter
4.1.2 Automatic closing after power cut, p. 14 are applied.
The factory setting is 1 (default).
H.6 Master/slave barrier conguration
This parameter allows to set up TWINNING feature in case of a
double barrier installation (mirror barriers).
H.6 Master/slave (TWINNING)
0
(default)
TWINNING OFF
1Set 1 to congurate the master barrier
2 Set 2 to congurate the slave barrier
5.3.5 L. Working times
L.1 Automatic closing
This parameter sets the automatic closing time, adjustable from 0 =
automatic closing OFF to 99 seconds.
L.2 Automatic closing (pedestrian opening)
This parameter sets the automatic closing time for pedestrian opening,
adjustable from 0 = automatic closing OFF to 99 seconds.
L.1 and L.2 are totally independent one to the other: they can be set
up in different ways with different times, as well L.1 can be ON while
L.2 can be switched OFF, and viceversa.
5.3.6 P. SAFETY
P.1 STOP
The factory setting is 0 = output OFF.
If you wish to connect a stop device, set P. 1 to 1position.
P.2 (closing photocell)
When P. 2 is set to 0 = output OFF
It is highly recommended to set P. 2 to:
1 = closing photocell ON (photocell test is OFF)
or
2 = closing photocell ON (photocell test is ON)
The photocell test is a safety provision that helps detecting a faulty
or unsafety photocell.
The test works as follows: before closing, the control unit switches
the power off from TX photocell terminal, in this way the photocell
has no other option but to open the contact.
If the contact doesn’t open in short time, it means the photocell is
faulty and the barrier remains still.
5.3.4 H. SPECIAL FUNCTIONS
H.1 Pre-blinking in closing
Pre-blinking feature warns the user that closing will start soon.
Receiving a start command the blinker starts flashing during a few
seconds before boom starts closing.
Pre-blinking time is adjustable, from 0 to 8 seconds.
H.2 Fixed-light blinker
Ifyouwishtoswitchtheblinkertoxed-lightmode,setH.2to1.
H.3 “Follow me” closing
This function allows the barrier to immediately close after cutting
the photocell beam.
C.4 Boom conguration
0 RH barrier
1 LH barrier
2 (default) No conguration is set
C.4 LH and RH boom conguration
This parameter shows the boom opening direction or the boom
position.
Looking from inside the property (cabinet’s door inside the property)
and boom in horizontal position, values are intended as follows:
MIN. 0 1 2 3 4 56 7 8 9 10 MAX.
DEFAULT

19
S-PARK - rev.1.1_06_2020
5.3.7 U. Maintenance
U.1 Overall cycles performed
This feature allows to display the overall cycles performed.
No possibility of reset.
Cyclesaredisplayed2by2gures:
Ex.: if the barrier totally performed 823.605 cycles, the screen will
read:
00. 82 36 0.5.
Ifyouwishtoscrollguresjustpresskey .
U.2 Cycles performed since last maintenance service
This feature allows to display the overall cycles performed since last
maintenance service.
Cycles can be reset when a maintenance service has been carried
out (if U.3 is updated and set up).
If you wish to reset press and together holding for 3 seconds:
display will flash “ ”toconrmresetsuccessfullycompleted
P.4 LED signalling strip (optional)
BoomcanbettedwithaRGBledstripthatmakestheoperationmore
visible.
The LED strip can be adjusted in 4 different signalling modes when
boom is in closing position.
Refer to be below table:
P. 4 Signalling mode when boom in closing position
0 OFF
1Lit (red light); flashing if battery powered
2 (default) Lit (red light).
3Flashing (red light)
P.5 Light sensor
It is possible to wire a light sensor or daily/weekly timer to switch
the LED signalling strip OFF during day hours.
Therearetwopossiblecongurations:
• Wiring the N.O. contacts of the sensor/timer in series to COMMON
(terminal BOOM+24)
• Wiring the N.O. contacts of the sensor/timer between GND
and STRT2 or LD, setting P. 5 accordingly; in this case the wired
terminal looses its original function.
P. 5 Light sensor possible congurations
0 (default) No light sensor is wired to STRT2 or LD.
1 Light sensor is wired between STRT2 and COM.
START2 no longer works as pedestrian contact.
2 Light sensor is wired between LD and GND.
LD no longer works as Loop detector.
P.6 Cabinet’s safety switch
The barrier may develop extremely dangerous circumstances during
operation.
That’s why if cabinet is opened the barrier immediately stops working
(justgureoutifaccidentallyaradiostartcommandisgiven,how
dangerous it could be).
However barrier can be managed in “dead man” mode using on
board keys.
P. 6 safety function may be switched OFF setting P. 6 to 0 position; by
default P. 6 is ON (P.6=1).
U.3 Maintenance countdown
This feature allows to set the number of cycles till next maintenance
service (starting from a minimum of 1000 cycles and so on).
U.3 will accordingly and automatically update U.1 and U.2 if activated,
at every closing operation.
It is also possible to warn the end user that maintenance service is
needed.
To set this function, set parameter U.4.
U.4 Maintenance recall
As previously explained in parameter U.3, it is possible to set a
visible flashing “maintenance recall”.
Refertothebelowtabletosetthedesiredrecallconguration:
P. 3 LD output / features and contacts (N.O./N.C.)
0 (default) The contact is OFF.
1 N.O. (normally opened) START command.
The closed contact makes the barrier opening.
2 N.O. SAFETY mode
The closed contact makes the barrier reverting exactly
as a closing photocell.
3N.C. (normally closed) START command
See setting 1 above.
4 N.C. (normally closed) SAFETY mode
See setting 2 above
U.4 Maintenance recall – signalling conguration
0
(default)
OFF – factory setting
No maintenance recall has been activated.
1 SPECIAL FLASHING DURING AUTOMATIC CLOSING TIME
When boom in vertical position, the flashing light on the cabinet
permanently flashes.
To activate this mode the automatic closing time shall be set
no less than a couple of seconds, otherwise signalling will not
be sufciently visible.
2SPECIAL FLASHING DURING OPENING
When boom is opening, the flashing light on the cabinet
permanently flashes.
3 AUX OUTPUT
AUX output activates (the contact closes) when maintenance
service is neeed.
P.3 LD loop detector
P.3allowstottoLDterminalavehicledetector(loopdetector)that
works exactly as a safety device, like closing photocell.
In addition it can command a START pulse: when the vehicle
approaches the barrier, a START command is given and the barrier
opens.
Settings available:

20 S-PARK - rev. 1.1_06_2020
U.5 Installation date
This feature allows to load the installation date.
The display will show the installation date in 3 different steps: the
rstgureshownistheday(from1to31);pressing the month
shows up (from 1 to 12); pressing again the year shows up with
two dots.
Pressing the sequence START.
EX.: if your installation date is 14-03-2019 the sequence displayed
will be:
14. 03 1.9.
If you wish to set installation date, press together and holding
during 4 seconds; screen will read “d”, use or to load the day,
from 1 to 31; save pressing .
Screen will read “n”, use or to load the month, from 1 to 12;
save pressing .
Screen wil read “Y”, use or to load the year. Save pressing .
Installation date loading completed.
U.6 Trouble shooting and “dead man” functions
Set U.6 and press toconrm.
This feature allows to display the status of all inputs and at the same
time allows to command direct the boom in “dead man” mode (key
permanently pressed).
Press (and hold) to lift the boom and to lower it.
Release the key to stop the boom.
Attention: during all these operations, safety devices are not
working, be carefull.
The screen displayes the status of every single input, everyone iden-
tiedbyasymbol.
If the input is “active” the according symbol will be lit.
START, STRT2 (LH symbol), when lit the input is active; Radio dot
lights up when receiving a radio signal, saved or unknown.
PH, LD (RH symbol), when lit the input is not active (safety contact
impeeds the operation).
CABINET, when lit the cabinet’s door is not closed.
If one of the P. settings is OFF (Chapter 5.3.6 SAFETY p. 18), the
screen will not show any status (symbol permanently switched off).
The red dot on the right remains permanently lit to confirm
programming is ON.
To quit press and together.
6. DISPLAY
The display shows the barrier status.
If no key is pressed, after 8 hours the display switches off; shortly
press any key to light the display up.
As soon as control unit is powered, the display reads “8.8.” (all segments
are lit so as to detect a possible fault).
Afterthatthedisplayreadsrmwareversion(ex.“1.0”, or “2.3” and
similars).
If control unit is brand new and no programming has been carried
out yet, the display reads “EE” for a half second.
As last step, control unit goes to STAND-BY mode and display reads
“--” flashing.
The remaining messages are listed in the below table.
6.1 Messages
During normal operation messages may show up.
Refer to the below table indicating possible messages and according
meaning:
Messages Meaning
Vertical segments that move
from center outwards
The barrier is opening
Vertical segments that move
from center inwards
The barrier is closing
-S (start) Receiving a START command
-P (start2 / parziale) Receiving a START2 command (pedestrian)
-H (halt / stop) Receiving a STOP pulse
CO (case open) Cabinet’s door opened
PC (photo close) Closing photocell is working
Ld (loop detector) Loop detector LD (3.8.1.7 LD loop detector
p. 13) is detecting a vehicle
Pair of gures (ex. 02) Receiving a radio signal by a saved remote
control (remote control saved on radio
position 2).
Usually S or -P show up to conrm which
kind of remote control has been used.
-C A timer has been wired to START or START2,
automatic closing is stopped
-L Permanent LD signal (3.8.1.7 LD loop detector
p. 13) that stops automatic closing
6.2 Faults
The display shows faults and anomalies that may stop the barrier
operation: the fault message is coded with two “dots” matched to
guresorletters.
Refer to the below table:
DISPLAY message FAULT
oE (encoder) Obstacle detected due to a sudden slow run
of the barrier.
oA (amperometric) Obstacle detected due to a sudden motor
absortion increase
o5 (standstill) Obstacle detected due to motor standstill
oC (voltage overcharge) Obstacle detected due to motor voltage
overcharge (max. limit rate)
Ld (loop detector) Loop detector operating
PC (photo close) Closing photocell operating
AH (abort halt/stop) STOP pulse
AC (abort cabinet) Cabinet’s door is opened
AU (abort user) Operation interrupted using onboard keys
FC (photocell test failed) Photocell test detected a faulty photocell
EC (over current) Motor absorbs too much current
EY (overheating) Component overheating
EF (start fail) Barrier fails to start
EU (timeout) Time exceeded
EN (encoder wiring) Motor and/or encoder are not properly wired
START
START2 STOP
RADIO
DOT
PERMANENTLY
LIT
CABINET
PH
LD
