BG500 Series Barrier Gate User Manual
P a g e |1Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
For further details, please visit our Company’s website
www.zkteco.com.

BG500 Series Barrier Gate User Manual
P a g e |1Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Copyright © 2022 ZKTECO CO., LTD. All rights reserved.
Without the prior written consent of ZKTeco, no portion of this manual can be copied or
forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries
(hereinafter the "Company" or "ZKTeco").
Trademark
is a registered trademark of ZKTeco. Other trademarks involved in this manual are
owned by their respective owners.
Disclaimer
This manual contains information on the operation and maintenance of the ZKTeco equipment.
The copyright in all the documents, drawings, etc. in relation to the ZKTeco supplied
equipment vests in and is the property of ZKTeco. The contents hereof should not be used or
shared by the receiver with any third party without the express written permission of ZKTeco.
The contents of this manual must be read as a whole before starting the operation and
maintenance of the supplied equipment. If any of the content(s) of the manual seems unclear
or incomplete, please contact ZKTeco before starting the operation and maintenance of the
said equipment.
It is an essential pre-requisite for the satisfactory operation and maintenance that the operating
and maintenance personnel are fully familiar with the design and that the said personnel have
received thorough training in operating and maintaining the machine/unit/equipment. It is
further essential for the safe operation of the machine/unit/equipment that personnel has read,
understood and followed the safety instructions contained in the manual.
In case of any conflict between terms and conditions of this manual and the contract
specifications, drawings, instruction sheets or any other contract-related documents, the
contract conditions/documents shall prevail. The contract specific conditions/documents shall
apply in priority.
ZKTeco offers no warranty, guarantee or representation regarding the completeness of any
information contained in this manual or any of the amendments made thereto. ZKTeco does
not extend the warranty of any kind, including, without limitation, any warranty of design,
merchantability or fitness for a particular purpose.
ZKTeco does not assume responsibility for any errors or omissions in the information or
documents which are referenced by or linked to this manual. The entire risk as to the results
and performance obtained from using the information is assumed by the user.

BG500 Series Barrier Gate User Manual
P a g e |2Copyright©2022 ZKTECO CO., LTD. All rights reserved.
ZKTeco in no event shall be liable to the user or any third party for any incidental,
consequential, indirect, special, or exemplary damages, including, without limitation, loss of
business, loss of profits, business interruption, loss of business information or any pecuniary
loss, arising out of, in connection with, or relating to the use of the information contained in or
referenced by this manual, even if ZKTeco has been advised of the possibility of such damages.
This manual and the information contained therein may include technical, other inaccuracies or
typographical errors. ZKTeco periodically changes the information herein which will be
incorporated into new additions/amendments to the manual. ZKTeco reserves the right to add,
delete, amend or modify the information contained in the manual from time to time in the
form of circulars, letters, notes, etc. for better operation and safety of the
machine/unit/equipment. The said additions or amendments are meant for improvement
/better operations of the machine/unit/equipment and such amendments shall not give any
right to claim any compensation or damages under any circumstances.
ZKTeco shall in no way be responsible (i) in case the machine/unit/equipment malfunctions
due to any non-compliance of the instructions contained in this manual (ii) in case of operation
of the machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine
and equipment in conditions different from the prescribed conditions of the manual.
The product will be updated from time to time without prior notice. The latest operation
procedures and relevant documents are available on http://www.zkteco.com.
If there is any issue related to the product, please contact us.
ZKTeco Headquarters
Address ZKTeco Industrial Park, No. 32, Industrial Road,
Tangxia Town, Dongguan, China.
Phone +86 769 - 82109991
Fax +86 755 - 89602394
For business-related queries, please write to us at [email protected].
To know more about our global branches, visit www.zkteco.com.

BG500 Series Barrier Gate User Manual
P a g e |3Copyright©2022 ZKTECO CO., LTD. All rights reserved.
About the Company
ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial,
Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-
range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate
Recognition (LPR) gate controllers and Consumer products including battery-operated
fingerprint and face-reader Door Locks. Our security solutions are multi-lingual and localized in
over 18 different languages. At the ZKTeco state-of-the-art 700,000 square foot ISO9001-
certified manufacturing facility, we control manufacturing, product design, component
assembly, and logistics/shipping, all under one roof.
The founders of ZKTeco have been determined for independent research and development of
biometric verification procedures and the productization of biometric verification SDK, which
was initially widely applied in PC security and identity authentication fields. With the
continuous enhancement of the development and plenty of market applications, the team has
gradually constructed an identity authentication ecosystem and smart security ecosystem,
which are based on biometric verification techniques. With years of experience in the
industrialization of biometric verifications, ZKTeco was officially established in 2007 and now
has been one of the globally leading enterprises in the biometric verification industry owning
various patents and being selected as the National High-tech Enterprise for 6 consecutive years.
Its products are protected by intellectual property rights.
About the Manual
This manual introduces the operations of BG500 Series Barrier Gate.
All figures displayed are for illustration purposes only. Figures in this manual may not be exactly
consistent with the actual products.

BG500 Series Barrier Gate User Manual
P a g e |4Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Table of Contents
1 OVERVIEW............................................................................................................................ 5
2 FEATURES AND FUNCTIONALITIES .................................................................................... 5
3 APPEARANCE AND DIMENSIONS ........................................................................................6
4 SPECIFICATIONS .................................................................................................................. 6
5 INSTALLATION PROCEDURE ............................................................................................... 7
INSTALLATION PRECAUTIONS ....................................................................................................... 7
CABLE EMBEDDING ......................................................................................................................7
BOOM INSTALLATION ...................................................................................................................8
5.3.1 BOOM INSTALLATION PROCEDURE ...................................................................................................................................8
5.3.2 INSTALLATION OF THE FOLDING BOOM ..........................................................................................................................9
5.3.3 INSTALLATION OF THE FENCE BOOM ARM ................................................................................................................. 10
6 DEFINITION OF LEFT AND RIGHT DIRECTIONS ................................................................11
7 MAINBOARD WIRING INSTRUCTIONS ..............................................................................11
CONNECTION WITH LPR CAMERA .............................................................................................. 12
CONNECTION WITH UHF CONTROLLER ...................................................................................... 13
CONNECTION WITH LOOP DETECTOR ......................................................................................... 13
CONNECTION WITH VR10 RADAR SENSOR ................................................................................ 14
CONNECTION WITH INFRARED/PHOTOCELL DETECTOR ...............................................................15
8 FUNCTION PARAMETER ADJUSTMENT INSTRUCTIONS ................................................. 17
MAINBOARD PARAMETER SETTINGS ...........................................................................................17
8.1.1 OPERATING PROCEDURE ...................................................................................................................................................17
PARAMETER SETTINGS DESCRIPTION ..........................................................................................18
REMOTE CONTROL LEARNING INSTRUCTIONS .............................................................................19
SET DELAY FOR AUTOMATIC CLOSING AFTER OPENING THE BOOM ............................................20
9 BOOM BARRIER ADJUSTMENTS ....................................................................................... 21
HORIZONTAL AND VERTICAL ANGLE ADJUSTMENT OF BARRIER BOOM (MECHANICAL
ADJUSTMENT) .......................................................................................................................................21
DIRECTION INTERCHANGE OF THE BOOM ARM ........................................................................... 22
SPRING ADJUSTMENT ................................................................................................................ 22
10 PRODUCT PACKING LIST .............................................................................................. 23
11 TROUBLESHOOTING ..................................................................................................... 24

BG500 Series Barrier Gate User Manual
P a g e |5Copyright©2022 ZKTECO CO., LTD. All rights reserved.
1Overview
The BG500 barrier gate uses a high-performance and safe low voltage DC brushless motor
that provides stable and reliable operation, as well as digital coding control for quick and
accurate response.
The all-in-one worm-gear reducer-transmission mechanism is easy to install and maintain,
has a high load capacity and support install different types of barrier arm.
2Features and Functionalities
Highly energy-efficient because of the DC brushless motor.
The modular structure makes it simple to maintain.
Digital control mainboard with multiple configuration possibilities.
Accurate and safe operation with the digital encoder.
The barrier arm will rebound when an obstacle is being detected.
Simple and compact transmission mechanism.
Reversible boom direction.
Adjustable angle of up/down.
Manual move up and down in case of the absence of power.
Adjustable opening and closing speed from 1.5s to 6s.
Barrier arm’s length from 3m to 6m.
Various barrier arm.

BG500 Series Barrier Gate User Manual
P a g e |6Copyright©2022 ZKTECO CO., LTD. All rights reserved.
3Appearance and Dimensions
4Specifications
Model
BG530
L/R
BG545
L/R
BG560
L/R
BG545
L/R-LED
BG545
L/R-90
BG545
L/R-F
Operating Speed
1.5s
2.5s
5s
2.5s
2.5s
2.5s
Boom Length
3m
4.5m
6m
4.5m
4.5m
4.5m
Boom Type
Straigh
t boom
Telescopic
boom
Straight boom
with LED
Folding
boom
Fence
boom
Motor Type
DC 24V brushless motor
Output Power
160W
Output Current
10A
Operating Voltages
DC 24V
Power Supply
AC 220V/110V, 50Hz to 60Hz
MCBF
2 million times
Remote Control Distance
≥30m
Operating Temperature
-30°C to 75°C
Protection Level
IP54
Chassis Dimension (W*L*H)
350*270*1020 (mm)
Net Weight (excluding the
barrier arm)
43 kg

BG500 Series Barrier Gate User Manual
P a g e |7Copyright©2022 ZKTECO CO., LTD. All rights reserved.
5Installation Procedure
Installation Precautions
1. Install the parking barrier on a level ground. If the ground is not firm and level, a cement
base is needed before the installation.
2. The length of the boom can be cut but cannot be increased. To establish new balance
after cutting the boom length, the spring balance must be reset. The bottom of the
spring has two plastic nuts for adjusting the new balance.
3. When the power is on, do not make any changes to the wire connections inside.
4. The GND should be connected to the cabinet for secure protection.
Cable Embedding
1. Prepare for a total of φ25 protective sleeve and cable in advance.
2. Connect the route cables through the protective sleeves.
3. Use a tool to open a cable tray on the ground.

BG500 Series Barrier Gate User Manual
P a g e |8Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Dimensions
Boom Installation
5.3.1 Boom Installation Procedure
1. Pull the vice boom out from the main boom and install them with the two screws, as
shown in Figure 1.
2. Install the boom to the chassis, as shown in Figure 2.
Figure 1 Connect the main boom with the vice together by 2 screws
Figure 2 Installing the Boom to the Chassis

BG500 Series Barrier Gate User Manual
P a g e |9Copyright©2022 ZKTECO CO., LTD. All rights reserved.
5.3.2 Installation of the Folding Boom
1. Install the folding boom assembly element after disconnecting the machine's power.
2. Fix the folding boom.
3. Adjust the vertical and horizontal position of the boom arm.
4. Start the power supply and observe the running state of the machine. If the boom arm
open shaking, it is then necessary to loosen the spring and slow down the speed
appropriately. It is also necessary to tighten the spring and slow down the speed
accordingly if the boom arm closes shaking.
Note:
Default total height: H≤2.8m, Default total length: L≤4.5m（Support customization, specify
total height and total length in the order remarks）

BG500 Series Barrier Gate User Manual
P a g e |10 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
5.3.3 Installation of the Fence Boom Arm
1. Install the fence boom install part after disconnecting the machine's power.
2. Fix the fence boom.
3. Adjust the vertical and horizontal position of the boom arm.
4. Start the power supply and observe the running state of the machine. If the boom arm
open shaking, it is then necessary to loosen the spring and slow down the speed
appropriately. It is also necessary to tighten the spring and slow down the speed
accordingly if the boom arm closes shaking.
Notes：
1) Before the machine is energized to run the test, please make sure to install the barrier
boom of the corresponding length for the test. If the barrier boom is not installed,
please adjust, and remove the spring under the guidance of a professional person.
2) If the length of the barrier boom is cut and adjusted, the tightness of the spring and
the position of the hanging hole must to adjusted accordingly in order to avoid the
abnormal condition of the machine that cannot drop the boom.

BG500 Series Barrier Gate User Manual
P a g e |11 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
6Definition of Left and Right Directions
7Mainboard Wiring Instructions
1. Please disconnect the power supply before wiring.
2. Please note that to switch the input voltage to 110V, you must set the DIP switch on the
power supply to the following:
3. Make sure the terminals are securely fastened and the wiring is secure.
4. The wiring diagram of the control panel is explained as follows:
L: The Chassis on the left,
the boom arm on the right.
R: The Chassis on the right,
the boom arm on the left.

BG500 Series Barrier Gate User Manual
P a g e |12 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
BG500 Wiring Diagram of Mainboard
Connection with LPR Camera

BG500 Series Barrier Gate User Manual
P a g e |13 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Connection with UHF Controller
(Note: The reader 1 and 2 of the inbio260 controller are corresponding to LOCK1, Reader 3
and 4 are corresponding to LOCK2)
Connection with Loop Detector
Anti-smash and Auto-close function:

BG500 Series Barrier Gate User Manual
P a g e |14 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Coil Circumference
Coil Number
3m
Based on the requirements, ensure that the
inductance is between 100μH to 200μH
3m to 6m
5 to 6 turns
6m to 10m
4 to 5 turns
10m to 25m
3 turns
25m
2 turns
Connection with VR10 Radar Sensor
Anti-smash and Auto-close function

BG500 Series Barrier Gate User Manual
P a g e |15 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Connection with Infrared/Photocell Detector
Anti-smash function

BG500 Series Barrier Gate User Manual
P a g e |16 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Anti-smash and Auto-close function

BG500 Series Barrier Gate User Manual
P a g e |17 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
8Function Parameter Adjustment Instructions
After the initial installation and power-on, you must complete the self-check process and
learn the opening and closing strokes by pressing the "on" and "off" buttons on the
mainboard.
Mainboard Parameter Settings
Key Description
Menu: Menu options / Confirm and Enter
Enter: Confirm and Exit
Open/-: Decrease parameter/value
Close/+: Increase parameter/value
8.1.1 Operating Procedure
The display status is given below:

BG500 Series Barrier Gate User Manual
P a g e |18 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Parameter Settings Description
Parameter
List of
menu
items
3m boom
parameter
value
4.5m boom
parameter
value
6m boom
paramete
r value
Opening speed adjustment: the larger
the value, the faster the gate opening
speed
L-1
80
60
60
Closing speed adjustment: the large
the value, the faster the gate closing
speed
L-2
70
50
50
Barrier boom in the place balance
adjustment(default)
L-3
12
12
12
Anti-smashing car reaction time
sensitivity adjustment(default)
L-4
30
30
30
Motor strength value
Adjustment(default)
L-5
70
70
70
Horizontal adjustment of barrier
boom
L-6
5
5
10
Test mode selection: 0 is manual,1 is
automatic (default)
L-7
0
0
0
Turn on the memory function: 0
means no memory; 1 means memory
and 4 indicates peak mode (default)
L-8
0
0
0
Vertical position adjustment of barrier
boom
L-9
5
5
8
Adjusting the deceleration stroke of
the first stage of opening barrier
L-L
40
40
30
Adjusting the deceleration stroke of
the first stage closing barrier
L-B
40
40
30
Anti-smashing car force adjustment
(default)
L-C
50
50
50
The forward and reverse running
settings of the barrier type,1 is L and 2
is R (factory setting)
L-D
0 or 3
0 or 3
0 or 3
Start motor strength value of gate
(default)
L-E
30
30
30
Remote learning function: 000 is the
learning state; 253 is the automatic
deletion of the remote control
L-F
0
0
0

BG500 Series Barrier Gate User Manual
P a g e |19 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Adjustment of the deceleration stroke
for the second section of the barrier
opening (default)
L-H
0
0
0
Adjustment of the deceleration stroke
of the second barrier closing
L-P
21
21
21
Traffic light mode adjustment
L18
0
0
0
Ground sensing delay to drop the
boom: 0 means the function is
disabled,1 to 255 is the time
corresponding to the delay (need to
cooperate with the ground sensing
system)
L-19
0
0
0
Automatic boom-dropping
adjustment after starting delay:ss 0
means that function is disabled,1 to
255 is the time corresponding to
delay automatic boom falling
L-20
0
0
0
Remote Control Learning Instructions
1. Remote Control Pairing: Long press the Menu, then press +/- to select L-F [L15]. Press
the Menu again to set the parameter value. At this time, the LED display value is "000",
and then press any button on the remote control until you hear a beep sound from the
Mainboard. If the pairing is successful, it will automatically return to the menu option.
Press Enter to exit the menu.
2. Delete Remote Control Pairing: Long press the Menu, then press +/- to select L-F [L15].
Press the Menu again to set the parameter value, and then set the parameter value to
"253". At this time, it will automatically return to the menu, indicating that all the remote
controls have been deleted.
