Proteus PEC-3320 User manual

-1-
STEP 1: ATTACH BOTH STABILIZERS ( 02 + 2a ) TO MAIN FRAME ( 01 ). FIX WITH BOLTS
( 27 ) AND WASHERS ( 31 ).
STEP 2:
a.ASSEMBLE PEDAL STRAPS TO PEDALS. ( STRAP MARKED "L" TO THE LEFT
PEDAL, STRAP MARKED "R" TO THE RIGHT PEDAL ).
b.ATTACH PEDALS ( 17 & 18 ) TO PEDAL CRANKS, ( PEDALS MARKED "L" AND
"R" INDICATES LEFT AND RIGHT SIDE OF BIKE. MAKE SURE NOT TO MIX IT UP ).
c. LEFT PEDAL HAS LEFTHAND THREAD AND MUST BE TURNED
COUNTERCLOCKWISE ( CCW ) TO ATTACH, RIGHT PEDAL HAS RIGHTHAND
THREAD, MUST BE TURNED CLOCKWISE ( CW ) TO ATTACH.
STEP 3: ATTACH SADDLE ( 12 ) TO SADDLE PLATE OF SEAT POST ( 03 ). FASTEN IT
WITH SPRING WASHERS ( 33 ) AND NYLON NUTS ( 34 ).
STEP 4: SLIDE SEAT POST INTO THE SEAT POST BOOT ( 13 ) THEN ATTACH SEAT POST
( 03 ) TO MAIN FRAME, ADJUST SADDLE TO DESIRED HEIGHT AND TIGHTEN
WITH KNOB ( 26 ).
STEP 5: INSERT TENSION CABLE ( 09 ) INSIDE OF HANDLEBAR POST ( 04 ), PULL THE
( 04 ) TENSION CABLE OUT OF MIDDLE HOLE OF HANDLEBAR POST.
CONNECT WIRE ( A ) ( 10 ) AND WIRE ( B ) ( 11 ), THEN ATTACH HANDLEBAR
POST TO MAIN FRAME ( 01 ), FIX WITH WASHERS ( 31 ) AND BOLTS ( 28 ).
ASSEMBLE TENSION CONTROL ( 08 ) AND TENSION CABLE ( 09 ), ( REFER TO
DIAGRAM ), PULL THE UPPER CABLE OF TENSION CONTROL ( 08 ) FROM
MIDDLE HOLE TO TOP HOLE OF THE HANDLBAR POST ( 04 )
.INSERT THE TENSION CONTROL ( 08 ) ONTO HANDLEBAR POST ( 04 ), TIGHTEN
WITH SCREW ( 29 ).
STEP 6: ASSEMBLE HANDLEBAR ( 05 ) ONTO HANDLEBAR POST ( 04 ), FIX WITH
WASHER ( 32 ) AND T-KNOB ( 25 ), THEN ASSEMBLE FOAM GRIPS ( 16 ) AND
CAPS ( 15 ) ONTO HANDLEBAR.
STEP 7: CONNECT WIRE ( A ) ( 10 ) ONTO MONITOR ( 07 ), THEN ATTACH MONITOR ON
THE PLATE OF HANDLEBAR POST WITH SCREW ( 35 ).
NOW YOUR PEC-3320 HAS BEEN WELL ASSEMBLED.
NOTE : WHILE ASSEMBLE FOAM GRIP ( 16 ) ONTO HANDLEBAR ( 05 ), USE SOME
SOAP WATER FOR LUBRICANT .
PEC-3320 MAGNETIC CYCLE ASSEMBLY INSTRUCTION
IMPORTANT : READALL STEPS BEFORE ATTACHING PEDALS.
" THE BATTERIES MUST BE REMOVED FROM THE APPLIANCE BEFORE IT IS
SCRAPPED AND THAT THEY ARE DISPOSED OF SAFELY ".

-2-
PEC332020030225GB
8
9
9
8
16
15
35
8
9
4 29 32 25
5
1
3
6
10
11
12
13
14
17
18
19
20
21
22
23
24
26
27
28
30
31
33
34
2
31 31
2a
27
7
EXPLODED VIEW

PARTS LIST
-3-
KEY. Q'TY DESCRIPTION
01. 1 MAIN FRAME
02. 1 STABILIZER
2a. 1 FRONT REAR STABILIZER
03. 1 SEAT POST
04. 1 HANDLEBAR POST
05. 1 HANDLEBAR
06. 1 CRANK ASSEMBLY
07. 1 CYCLEMONITOR
08. 1 TENSION CONTROL
09. 1 TENSION CABLE
10. 1 WIRE (A)
11. 1 WIRE (B)
12. 1 SADDLE
13. 1 SEAT POST BOOT
14. 1 30*60 SLEEVE
15. 2 HANDLEBAR END CAP
16. 2 FOAM GRIP
17. 1 PEDAL (R)
18. 1 PEDAL (L)
19. 1 CHAIN COVER (R)
20. 1 CHAIN COVER (L)
21. 1 CHAIN COVER (F)
22. 2 CRANK HOLE COVER
23. 2 WHEEL
24. 2 FOOT CAP
25. 1 T-KNOB
26. 1 KNOB
27. 4 M8 SOCKET BOLT x 70mm
28. 4 M8 SOCKET BOLT x 15mm
29. 1 M5 SCREW x 25mm
30. 2 M5 SCREW x 15mm
31. 8 M8 WASHER
32. 1 M8 SMALL WASHER
33. 3 M8 SPRING WASHER
34. 3 M8 NYLON NUT
35. 4 M5 SCREW x 10mm
GB
