Exerpeutic ExerWorK Series User manual

IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference. The specifications of this product may vary
from this photo, subject to change without notice.
Desk Recumbent Bike
OWNER’S MANUAL
7170.2-032519

PLEASE DO NOT RETURN THIS PRODUCT
TO THE STORE.
STOP. Contact customer service if you have any questions
regarding assembly or proper operation of the machine.
Email us at:
[email protected]
Or call us at:
1-844-641-7921
Hours:
8:00 am to 5:00 pm (PST)
Monday thru Friday

1
TABLE OF CONTENTS
SERVICE------------------------------------------------------------------------------- 2
LABEL PLACEMENT---------------------------------------------------------------- 3
IMPORTANT SAFETY GUIDELINES------------------------------------------- 4
OVERVIEW DRAWING------------------------------------------------------------- 6
PARTS LIST--------------------------------------------------------------------------- 8
HARDWARE & TOOLS PACK--------------------------------------------------- 10
ASSEMBLY---------------------------------------------------------------------------- 11
CONSOLE ---------------------------------------------------------------------------- 18
OPERATIONS & ADJUSTMENTS---------------------------------------------- 19
BATTERY INSTALLATION-------------------------------------------------------- 23
TRANSPORTION-------------------------------------------------------------------- 24
MAINTENANCE & TROUBLESHOOTING---------------------------------- 25
WARRANTY--------------------------------------------------------------------------- 26
PART REQUEST FORM----------------------------------------------------------- 27

2
SERVICE
SERVICE
IMPORTANT: FOR NORTH AMERICA ONLY
For damaged or defective product, questions, replacement parts or any other service
support, please contact our customer service department by the below methods:
For The Best Service, please Email:
[email protected]
Response Time: 1-2 Business Days
Emailing us with the information above will be the best method to receive a response
during peak business hours
Website:
www.paradigmhw.com
Toll-Free:
1-844-641-7921
(8:00 AM - 5:00 PM Pacific Standard Time, Monday thru Friday)
Response time may vary via calling
Please have the following information ready when requesting for service:
Your name
Phone number
Model number
Serial number
Part number
Proof of Purchase
For damaged or defective product please contact our customer service before returning to
the store.
Paradigm Health & Wellness, Inc.
1189 Jellick Ave.
City of Industry, CA 91748, USA

3
LABEL PLACEMENT

4
IMPORTANT SAFETY GUIDELINES
Basic precautions should always be followed, including the following safety guidelines
when using this desk bike. Read all of the guidelines before using this desk bike.
1. Before exercising and to avoid injuring your muscles, it is highly recommended that you
perform warm-up exercises for each muscle group.
2. Make sure all the components are not damaged and are in working order before using. This
equipment should be placed on a stable, flat surface. Using a mat or similar, covering material
on the ground is recommended.
3. Wear proper fitness apparel when using this equipment. Do not wear loose clothing or
accessories that may get caught by any part of the equipment.
4. Make sure all the components are not damaged and are in working order before using this
equipment.
5. Remember to tighten the pedaling straps. Keep dry. Do not operate the equipment in wet or
6. moist condition.
7. Do not use the equipment outdoors. This equipment is for household use only.
8. Only perform maintenance or adjustments that are instructed in this manual. Should any
problems arise, discontinue usage of the equipment and consult with our customer service.
9. Only one person should be on the equipment at a time. Keep children and pets away from the
product at all times. This machine is designed for adults only.
10. Be careful to always hold onto the handlebars when you’re mounting and dismounting. Be
careful to have the pedals at their lowest point when stepping off.
11. Hold onto the handlebars and use both the pedals in tandem to ensure a smooth, effective
workout.
12. This product requires a minimum of 7 square feet around for safe operation.
13. If you feel any chest pains, nausea, dizziness, or shortness of breath, you should stop
exercising immediately, and consult your physician before continuing.
14. DO NOT pedal in reverse.
15. ASSEMBLE ALL HARDWARE IN THE ORDER THAT IS SHOWN IN THE ILLUSTRATIONS
16. WARNING: CANCER AND REPRODUCTIVE HARM--WWW.P65WARNINGS.CA.GOV.
WARNING: Before beginning any exercise program consult your physician. This is
especially important for the people who are over 35 years old or who have pre-existing health
problems.
WARNING: Risk of Personal Injury - Do not attempt to service the unit yourself.
Discontinue use and contact customer service.
CAUTION: Read all guidelines carefully before operating this product. Retain this
Owner’s Manual for future reference.
!
!
!

5
The product weighs more than 44 lbs. It is heavily
recommended that at least 2 persons assemble.
IMPORTANT SAFETY GUIDELINES
Do not use this equipment if you have any of the following conditions or ailments:
Pregnancy
Extreme obesity
Middle ear infection
Hiatus hernia or Ventral hernia
Glaucoma, retinal detachment or conjunctivitis
Use of anticoagulants including Aspirin in high doses.
Spinal injury, Cerebral Sclerosis, or acutely swollen joints
Heart or circulatory disorders for which you are being treated
High blood pressure, Hypertension, Recent stroke or Transient Ischemic attack
Bone weaknesses including Osteoporosis, Unhealed fractures, Modular pins, or surgically implanted
orthopedic supports.
Do not exceed the maximum rated weight (load):
The Maximum Weight Capacity for this product is 250lbs/113kgs.
Retain this owner’s manual and keep the original purchase receipt
for future reference.
SAVE THESE GUIDELINES

6
OVERVIEW DRAWING

7
OVERVIEW DRAWING

8
PARTS LIST
No.
Description
Qty
No.
Description
Qty
1
Main Frame
1
32
Sensor Wire W=650mm
1
2
Front Stabilizer
1
33
Left Pedal
1
3
Rear Stabilizer
1
34
Left Pedal Strap
1
4
Left Handlebar
1
35
Right Pedal
1
5
Right Handlebar
1
36
Right Pedal Strap
1
6
Seat Bracket
1
37
Carraige Bolt M10*65
4
7
Backrest Frame
1
38
Curved WasherФ10
4
8
Front Post
1
39
Spring Washer Ф10
4
9
Desk Post
1
40
Cap Nut M10
4
10
Left Adjustable Post
1
41
Front Stabilizer End CAP
2
11
Right Adjustable Post
1
42
Self-Tapping Screw ST4.2*20
7
12
Desk Sliding Tube
2
43
Rear Stabilizer End Cap
2
13
Desk
1
44
Hex NutM8
1
14
Console
1
45
Adjustable Levler
1
14A
Console Wire A
1
46
Plastic Pad
1
15
Console Wire BW=750mm
1
47
Seat Bracket
1
16
Hex Bolt M6*10
1
48
Wave Washer Ф10
1
17
Hex Bolt M8*55
5
49
Flat Washer Ф10
1
18
Flat Washer Ф8
11
50
Round Knob M10
1
19
Nylon Nut M8
5
51
Foam Grip
2
20
Hex Bolt M8*20
1
52
Handlebar End Cap
2
21
Desk Post End Cap
2
53
Seat
1
22
Self-Tapping Phillips Screw
ST5*20
4
54
Backrest
1
23
Bushing
8
55
Sqaure End Cap
2
24
Adjustable Post Knob M8*20
2
56
Pin
1
25
Adjustable Post Cover
2
57
Flat Washer Ф6
8
26
Plastic Bracket
2
58
Spring Washer Ф6
10
27
Screw M5*10
4
59
Screw M6*20
8
28
Spring Ф10
2
60
Self-Tapping Screw ST2.9*12
2
29
Round Knob M8*36.5
2
61
Tension Knob
1
30
Spring Knob M16*1.5
1
62
Big Flat Washer Ф5
1
31
Bushing
1
63
Screw M5*15
1

9
PARTS LIST
No.
Description
Qty
No.
Description
Qty
64
Hex Nut 7/8”
2
78
Hex Bolt M8*50
1
65
Flat Washer Ф23
1
79
Sqaure End Cap
2
66
Bearing Nut
1
80
Fly Wheel
1
67
Ball Bearing
2
81
Flange Nut M10*1.0*6
2
68
Bearing Cup
2
82
Eye Bolt M6*36
2
69
Bearing Nut
1
83
U-Bracket
2
70
Flat Washer Ф24
1
84
Hex Nut M6
2
71
Crank
1
85
Left Cover
1
72
Belt 300 PJ6
1
86
Right Cover
1
73
Hex Bolt M8*10
1
87
Crank Cover
2
74
Idle Arm
1
88
Plastic Bolt Ø8*32
3
75
Pulley
1
89
Self-Tapping Screw ST4.2*20
6
76
Flat Washer Φ6
1
90
Hex Nut M8
1
77
Screw M6*10
1

10
HARDWARE & TOOLS PACK
6

11
ASSEMBLY
Step 1
1A. Front Stabilizer Installation: Lift up the front of the Main Frame (1), and attach the
Front Stabilizer (2) onto the front curve of the Main Frame (1) with two Carriage Bolts (37),
two Curve Washers (38), two Spring Washers (39), and two Cap Nuts (40). Use the Open-
Ended Flat Wrench to tighten the Cap Nuts (40)until firm and secure.
1B. Rear Stabilizer Installation: Lift up the rear of the Main Frame (1), and attach the Rear
Stabilizer (3) onto the front curve of the Main Frame (1) with two Carriage Bolts (37), two
Curve Washers (38), two Spring Washers (39), and two Cap Nuts (40). Use the Open-
Ended Flat Wrench to tighten the Cap Nuts (40)until firm and secure.
Hardware Pack:
Open-Ended Flat Wrench
S10, S13, S17, S19 1PC
TOOLS
(37) Carriage Bolt
4 PCS
(38) Curved Washer
4PCS
(40) Cap Nut
4 PCS
(39) Spring Washer
4 PCS

12
ASSEMBLY
Step 2
2A. Pedal Strap installation: Install the Left Pedal Strap (34) onto the Left Pedal
(33). Install the Right Pedal Strap (36)onto the Right Pedal (35).
2B. Left Foot Pedal Installation: Insert the threaded shaft of the Left Pedal (33)into
the threaded hole on the left side of the Crank (37). Turn the pedal shaft by hand in the
counter-clockwise direction until snug. Tighten the pedal shaft of the Left Pedal (33)
with the Multi Hex Tool with Phillips Screwdriver provided.
Note: DO NOT turn the LEFT pedal shaft in a clockwise direction; doing so will
strip the threads.
2C. Right Foot Pedal Installation: Insert the threaded shaft of the Right Pedal (35) into
the threaded hole on the right side of the Crank (37). Turn the pedal shaft by hand in the
clockwise direction until snug. Tighten the pedal shaft of the Right Pedal (35) with the
Multi Hex Tool provided.
Note: DO NOT turn the RIGHT pedal shaft in a counter clockwise direction; doing
so will strip the threads.
Multi Hex Tool
With Phillips Screwdriver
1PC
TOOLS
The Cranks, Pedal
Straps, Pedal Shafts,
and Foot Pedals are
marked “R” for Right
and “L” for Left.

13
ASSEMBLY
Step 3
3A. Handlebar Installation: Attach the Left and Right Handlebars (4,5) onto the Seat Bracket
(6). Using two Hex Bolts (17), four Washers (18) and two Nylon Nuts (19). Then tighten with the
6mm Allen Wrench and the Multi Hex Tool with Phillips Screwdriver provided.
Multi Hex Tool
With Phillips Screwdriver
1PC
6mm Allen Wrench
1PC
TOOLS
Hardware Pack:
(17) Hex Bolt
2 PCS
(19) Nylon Nut
2 PCS
(18) Flat Washer
4 PCS

14
ASSEMBLY
STEP 4
4A. Seat Installation : Remove the four Screws (59), four Spring Washers (58) and the four Flat
Washers (57) from the Seat (53). Align the holes of the Seat (53) to the holes of the Seat Bracket
(6). Secure the Seat (53) with four Screws (59), four Spring Washers (58) and the four Flat
Washers (57), Then tighten by using the Multi Hex Tool with Phillips Screwdriver provided.
STEP 5
5A. Backrest Installation : Remove the four Screws (59), four Spring Washers (58) and the four
Flat Washers (57) from the Backrest (54). Align the holes of the Backrest (54) to the holes of the
Backreat Frame (7). Secure the Backrest (54) with four Screws (59), four Spring Washers (58)
and the four Flat Washers (57), Then tighten by using the Multi Hex Tool with Phillips
Screwdriver provided.
Multi Hex Tool
S10, S13, S14, S15 1PC
TOOLS
Multi Hex Tool
S10, S13, S14, S15 1PC
TOOLS

15
ASSEMBLY
STEP 6
6A. Backrest Frame Installation: Insert the Backrest Frame (7) onto the Seat Bracket (6), and
align the hole tighten with one Hex Bolt (17), two Flat Washers (18) and one Nylon Nut (19).
Tighten the hardware with 6mm Allen Wrench and the Multi Hex Tool with Phillips
Screwdriver provided.
6B. Insert the Pin (56) onto the Seat Bracket (6).
(17) Hex Bolt
1 PC
(19) Nylon Nut
1 PC
(18) Flat Washer
2 PCS
Multi Hex Tool
S10, S13, S14, S15 1PC
6mm Allen Wrench
1PC
TOOLS
Hardware Pack:

16
ASSEMBLY
STEP 7
7A. Desk Installation: Remove one Flat Washer (18) and one Hex Bolt (20) from the Front Post
(8). Insert the Front Post (8) onto the bracket of the Desk (13), align the hole and tighten with two
Hex Bolts (17), four Flat Washers (18), two Nylon Nuts (19), one Flat Washer (18) and one Hex
Bolt (20) that were previously removed. Tighten the hardware with 6mm Allen Wrench and the
Multi Hex Tool with Phillips Screwdriver provided.
7B. Connecting the Console Wires: Connecting the Console Wire 14A (FIG.A) from the Desk
(13) with the Console Wire (15) from the Front Post (8). See Fig. A.
Multi Hex Tool
S10, S13, S14, S15 1PC
6mm Allen Wrench
1PC
TOOLS
(17) Hex Bolt
2 PCS
(19) Nylon Nut
2 PCS
(18) Flat Washer
4 PCS
Hardware Pack:

17
ASSEMBLY
STEP 8
8A. Connecting the Console Wire (15) with the Sensor Wire (32): Connecting the Console
Wire (15) from the Front Post (8) with the Sensor Wire (32) from the Main Frame (1).
8B. Front Post Installation: Insert the Front Post (8) onto the Main Frame (1) and tighten with
one Spring Knob (30).
Fig. B

18
CONSOLE
SPECIFICATIONS:
TIME -----------------------------0:00-99:59 MIN:SEC
SPEED --------------------------0.0-99.9 ML/H
DISTANCE ---------------------0.0-999.9 ML
CALORIE -----------------------0.0-9999 KCAL
CONSOLE FUNTIONS:
MODE: Press the “MODE” button to select between, SCAN,SPEED,DISTANCE,TIME, and CALORIES.
AUTO ON/OFF: The console will automatically turn on when pedaling begins. The console will
automatically turn off after 4 minutes of inactivity.
SCAN: Press the “MODE”button until the arrow (◄) points to “SCAN”. The console will automatically scan
the workout statistics of TIME, SPEED, and DISTANCE, every 6 seconds.
TIME: Press the “MODE”button until the arrow (◄) points to “TIME”. The console will display the total time
exercised in minutes and seconds. The console automatically counts up from 0:00 to 99:59 in one second
intervals.
SPEED: Press the “MODE”button until the arrow (◄) points to “SPEED”. The console will display your
current workout speed in miles per hour.
DISTANCE: Press the “MODE”button until the arrow (◄) points to “DIST”. The console will display the
distance traveled during each workout up to a maximum of 999.9 miles.
CALORIE: Press the “MODE”button until the arrow (►) points to “CAL”. The console will estimate the
cumulative calories burned during a workout. The console will count up from 0.0 to 9999calories.
When the MyCloudFitness logo is blinking, it is scanning for bluetooth devices. Once its
paired to a device the MyCloudFitness logo will stop blinking.
RESET: Hold this button for 4 seconds to reset all values from the console, Except ODOMETER.
HOW TO INSTALL THE BATTERIES:
1. Remove the battery cover on the underside of the Desk (88).
2. Place two "SIZE-AAA" batteries into the battery housing.
3. Insure the batteries are correctly positioned and the battery springs are in proper contact
with the batteries.
4. Re-install the battery cover.
5. If the display is illegible or only partially legible, remove the batteries and wait 15 seconds
before reinstalling.
