PRS Guitars Mark Tremonti MT15 User manual

Service Notes
Tubes
Tubes are consumables, as they have a given usable lifespan. They are part of the
heart of the tone, so keeping correctly operating tubes is essential. Tubes can fail
catastrophically or gradually, and it’s good to know what to look for if they start
to go bad. Periodically inspect them and look to see if anything inside the tube is
glowing cherry red other than the normal orange glow of the filament. This would
indicate a situation where the tube is conducting more current than it is capable
of handling and most likely about to fail. Two other conditions to observe are:
1) filaments not glowing or 2) a miniature fireworks display inside the tube. Any
of the above conditions indicate serious problems with the tube and should be
taken care of immediately. Tubes quite often are the cause of spurious noise in the
amp. Microphonic tubes will squeal or rale with the vibrations of the cabinet.
If suspected, tap each tube lightly with a pencil with the amp powered up—the
suspect tube will let you know. Note that there is a normal metallic clinking when
doing this, but a microphonic tube will be quite loud.
Replacing preamp tubes will not require any adjustment, but the power tubes will
need rebiasing to assure proper operation. After power tube replacement, initially
inspect the tubes often to assure there are no “cherry red” components within
the tube. Tubes today can have a wide variety of tolerances and a re-bias is highly
recommended with new ones.
Power tube bias should be adjusted to 30 mV, +/- 5 mV. If power tubes are
mismatched by less than 5 mV, average the two around 30. Mis-matched tubes
beyond 5 mV will induce noise and may cause a degradation of tone.
NOTE! Capacitors may retain an electric charge and can be dangerous even when
the unit is o, unplugged, and has not been played for an extended period of
time. USE CAUTION!!!!
© 2018 PRS Guitars - All rights reserved.
“Paul Reed Smith,” “PRS,” the PRS logo, the PRS Paul Reed Smith logo, the Paul Reed Smith signature, the bird
inlays, the headstock bird, the PRS headstock shape, the PRS body shape, the PRS “scoop” design, “Singlecut”,
“Mira” and the “SE” are all registered trademarks of Paul Reed Smith Guitars “Custom 24,” “Modern Eagle,”
“SE Custom,” “SC 245,” “SC 250,” “Starla”, “Tonare”, “Sewell”, “ Blue Sierra”, and “Angelus” are all trademarks
of Paul Reed Smith Guitars. The Birds, New Birds, are copyrighted by PRS Guitars.
LIT-AMP-MAN-MT15 REV B
Mark Tremonti MT15
User’s Manual
MT15
POWER
ON
STANDBY
ON
PRESENCE MASTER BASS MIDDLE TREBLE VOLUME BASS MIDDLE TREBLE GAIN
PULL BOOST
CLEAN CHANNEL LEAD CHANNEL
LEAD CHANNEL
CLEAN
LEAD
INPUT

Using your PRS Amplifier
IMPORTANT: Before using your amplifier, refer to the IMPORTANT SAFETY
INSTRUCTIONS insert supplied with the product.
Powering Up:
1. Make sure your speaker or speaker cabinet is connected to the correct speaker output
impedance jack with a high quality speaker cable. Do not use guitar cords.
2. Make sure the power cord is connected to the correct grounded outlet.
3. Make sure there is at least 6 inches (150mm) of clearance around the amplifier to allow
for proper cooling. Never place the amplifier against a wall or other equipment, and
keep it clear of other heat sources, such as other amplifiers or stoves. Make sure there
are no flammable items, such as curtains, behind the amp. Do not drape items over
the amps that can prevent proper cooling. Do not set drinks or other liquids on top of
the amp that can spill into the amp.
4. The amplifier is designed to be able to power up without the use of a Standby Switch.
It is OK to turn both switches on at the same time, or to leave the Standby Switch on
at all times. Use the Standby Switch to mute the amplifier when necessary.
5. Turn the master volume down (lead channel), volume control down (clean channel) or
flip the Standby Switch o to mute the amp, plug in the guitar cable and any eects,
switch on the Standby, bring the volumes up and play some tunes. This amplifier
can produce very loud volumes so take care with this procedure to avoid volume
surprises.
This equipment is capable of very high sound pressure levels. Prolonged
exposure may cause hearing damage.
This equipment contains no user-serviceable parts. Refer all repairs to qualified service
personnel.
Ensure that the mains plug is easily accessible to allow the unit to be switched o.
Only connect this unit to an earthed supply socket.
THIS UNIT IS CLASS 1 CONSTRUCTION AND MUST BE EARTHED!
MT15 Amplifier Front Panel Controls
Input: ¼” Standard Mono Guitar Cable.
Channel Select: Selects between Lead and Clean channels.
Lead Channel
Gain Control: Adjust for preamp volume/distortion/saturation.
Treble Control: Adjusts the high frequencies within the overall tone. This adjustment
allows the tone to become warmer at low seings and brighter at higher seings.
Middle Control: Adjusts the midrange frequencies within the overall tone. This adjustment
allows the user to add fullness or body to the sound, or create a “scooped”, crisp sound.
Bass Control: Adjusts the low frequencies within the overall tone. Lower seings will
sound tighter, especially with more gain and higher seings will add deep fullness and
thump.
Lead Channel Master: Adjusts the overall loudness of the lead channel. Work this along
with the Gain Control to balance the volume between the Lead and Clean channels.
Clean Channel
Volume Control: Increases the volume and gain of the clean channel.
Treble Control with Pull Boost: Adjusts the high frequencies like the lead channel with an
added general gain boost of the clean channel frequencies when pulled.
Middle and Bass Controls: Similar function to the lead channel controls.
Presence Control: Adjusts power amp brightness on both channels globally.
Power On/O and Standby Switches: The MT15 was designed to not need a Standby Switch
as part of properly powering the amp on. However, as a convenience we have provided a
Standby Switch that eectively mutes the amp while it is still powered on. Use the switch
to mute the amp when changing guitars, eects, or between sets.
Rear Panel Controls
Mains Socket: Always use the mains lead supplied. Your sales outlet can provide a
lead suitable for your country. Always disconnect the equipment from the mains and
ancillary units before moving.
Fuses: This amplifier is equipped with multiple accessible and inaccessible fuses.
Replacement fuses must be of the same type and rating as indicated. Failure to comply
may result in permanent damage to the product, and/or create a safety hazard. Always
disconnect the equipment from the mains supply before replacing a fuse.
Mains Fuses: These are located in the mains socket. There is one active and one spare.
B+ Fuse and Filament fuses: These are located on the PCB board and should be
evaluated and replaced by a qualified technician.
Bias Jacks and Pot: These jacks measure the power tube current draw in milliVolts.
1mV=1mA. Review the information on the back of this manual for guidance on replacing
tubes. Biasing and tube replacement should be performed only by a qualified
technician. Bias adjustments can be made with a jewelers Phillips head screwdriver.
Speaker Jacks: These are the main outputs for your speaker cabinet(s). There are 3
total jacks to use. There are two 8 ohm jacks wired in parallel, and a single 16 ohm
jack. Determine beforehand what your total speaker loading will be and use the
appropriate jacks. Never use the 16 Ohm jack with the 8 Ohm jacks at the same time.
For two 16 ohm cabinets in parallel (creating and 8 Ohm load), plug each cabinet into
one of the two parallel 8 ohm jacks. Failure to correctly match the speaker load to the
appropriate output jacks can cause tube socket arcs, blown power tubes, or failure of
the amp.
Half Power Switch: Selecting the half power seing changes the operation of the
power tubes from full-power pentode configuration to 8 was in triode configuration.
Power down the amp when changing this switch or make the selection prior to turning
on the amp.
Eects Loop: This amplifier features a series eects loop that is integral to the overall
sound of the amp. Connect the Send jack with a 1/4” mono instrument cable to the
input of your pedal(s). Connect your pedal(s) output to the Return jack also using
a 1/4” mono instrument cable. To minimize your cables picking up hum, arrange the
cables together for the first few feet away from the amp, and move them away from
the power transformer and mains power cable.
Footswitch Jack: Connect the included PRS FSIM footswitch to control Channel
switching. Do not use other footswitches as they can possibly damage the amp. When
aached, the front panel Channel selector switch becomes inoperable.
Safety Symbols: The following symbols mean:
Warning: read instructions to understand possible hazard
Danger: electrical shock hazard
Warning: This equipment is capable of very high sound pressure levels.
Prolonged exposure may cause hearing damage.

Using your PRS Amplifier
IMPORTANT: Before using your amplifier, refer to the IMPORTANT SAFETY
INSTRUCTIONS insert supplied with the product.
Powering Up:
1. Make sure your speaker or speaker cabinet is connected to the correct speaker output
impedance jack with a high quality speaker cable. Do not use guitar cords.
2. Make sure the power cord is connected to the correct grounded outlet.
3. Make sure there is at least 6 inches (150mm) of clearance around the amplifier to allow
for proper cooling. Never place the amplifier against a wall or other equipment, and
keep it clear of other heat sources, such as other amplifiers or stoves. Make sure there
are no flammable items, such as curtains, behind the amp. Do not drape items over
the amps that can prevent proper cooling. Do not set drinks or other liquids on top of
the amp that can spill into the amp.
4. The amplifier is designed to be able to power up without the use of a Standby Switch.
It is OK to turn both switches on at the same time, or to leave the Standby Switch on
at all times. Use the Standby Switch to mute the amplifier when necessary.
5. Turn the master volume down (lead channel), volume control down (clean channel) or
flip the Standby Switch o to mute the amp, plug in the guitar cable and any eects,
switch on the Standby, bring the volumes up and play some tunes. This amplifier
can produce very loud volumes so take care with this procedure to avoid volume
surprises.
This equipment is capable of very high sound pressure levels. Prolonged
exposure may cause hearing damage.
This equipment contains no user-serviceable parts. Refer all repairs to qualified service
personnel.
Ensure that the mains plug is easily accessible to allow the unit to be switched o.
Only connect this unit to an earthed supply socket.
THIS UNIT IS CLASS 1 CONSTRUCTION AND MUST BE EARTHED!
MT15 Amplifier Front Panel Controls
Input: ¼” Standard Mono Guitar Cable.
Channel Select: Selects between Lead and Clean channels.
Lead Channel
Gain Control: Adjust for preamp volume/distortion/saturation.
Treble Control: Adjusts the high frequencies within the overall tone. This adjustment
allows the tone to become warmer at low seings and brighter at higher seings.
Middle Control: Adjusts the midrange frequencies within the overall tone. This adjustment
allows the user to add fullness or body to the sound, or create a “scooped”, crisp sound.
Bass Control: Adjusts the low frequencies within the overall tone. Lower seings will
sound tighter, especially with more gain and higher seings will add deep fullness and
thump.
Lead Channel Master: Adjusts the overall loudness of the lead channel. Work this along
with the Gain Control to balance the volume between the Lead and Clean channels.
Clean Channel
Volume Control: Increases the volume and gain of the clean channel.
Treble Control with Pull Boost: Adjusts the high frequencies like the lead channel with an
added general gain boost of the clean channel frequencies when pulled.
Middle and Bass Controls: Similar function to the lead channel controls.
Presence Control: Adjusts power amp brightness on both channels globally.
Power On/O and Standby Switches: The MT15 was designed to not need a Standby Switch
as part of properly powering the amp on. However, as a convenience we have provided a
Standby Switch that eectively mutes the amp while it is still powered on. Use the switch
to mute the amp when changing guitars, eects, or between sets.
Rear Panel Controls
Mains Socket: Always use the mains lead supplied. Your sales outlet can provide a
lead suitable for your country. Always disconnect the equipment from the mains and
ancillary units before moving.
Fuses: This amplifier is equipped with multiple accessible and inaccessible fuses.
Replacement fuses must be of the same type and rating as indicated. Failure to comply
may result in permanent damage to the product, and/or create a safety hazard. Always
disconnect the equipment from the mains supply before replacing a fuse.
Mains Fuses: These are located in the mains socket. There is one active and one spare.
B+ Fuse and Filament fuses: These are located on the PCB board and should be
evaluated and replaced by a qualified technician.
Bias Jacks and Pot: These jacks measure the power tube current draw in milliVolts.
1mV=1mA. Review the information on the back of this manual for guidance on replacing
tubes. Biasing and tube replacement should be performed only by a qualified
technician. Bias adjustments can be made with a jewelers Phillips head screwdriver.
Speaker Jacks: These are the main outputs for your speaker cabinet(s). There are 3
total jacks to use. There are two 8 ohm jacks wired in parallel, and a single 16 ohm
jack. Determine beforehand what your total speaker loading will be and use the
appropriate jacks. Never use the 16 Ohm jack with the 8 Ohm jacks at the same time.
For two 16 ohm cabinets in parallel (creating and 8 Ohm load), plug each cabinet into
one of the two parallel 8 ohm jacks. Failure to correctly match the speaker load to the
appropriate output jacks can cause tube socket arcs, blown power tubes, or failure of
the amp.
Half Power Switch: Selecting the half power seing changes the operation of the
power tubes from full-power pentode configuration to 8 was in triode configuration.
Power down the amp when changing this switch or make the selection prior to turning
on the amp.
Eects Loop: This amplifier features a series eects loop that is integral to the overall
sound of the amp. Connect the Send jack with a 1/4” mono instrument cable to the
input of your pedal(s). Connect your pedal(s) output to the Return jack also using
a 1/4” mono instrument cable. To minimize your cables picking up hum, arrange the
cables together for the first few feet away from the amp, and move them away from
the power transformer and mains power cable.
Footswitch Jack: Connect the included PRS FSIM footswitch to control Channel
switching. Do not use other footswitches as they can possibly damage the amp. When
aached, the front panel Channel selector switch becomes inoperable.
Safety Symbols: The following symbols mean:
Warning: read instructions to understand possible hazard
Danger: electrical shock hazard
Warning: This equipment is capable of very high sound pressure levels.
Prolonged exposure may cause hearing damage.

Service Notes
Tubes
Tubes are consumables, as they have a given usable lifespan. They are part of the
heart of the tone, so keeping correctly operating tubes is essential. Tubes can fail
catastrophically or gradually, and it’s good to know what to look for if they start
to go bad. Periodically inspect them and look to see if anything inside the tube is
glowing cherry red other than the normal orange glow of the filament. This would
indicate a situation where the tube is conducting more current than it is capable
of handling and most likely about to fail. Two other conditions to observe are:
1) filaments not glowing or 2) a miniature fireworks display inside the tube. Any
of the above conditions indicate serious problems with the tube and should be
taken care of immediately. Tubes quite often are the cause of spurious noise in the
amp. Microphonic tubes will squeal or rale with the vibrations of the cabinet.
If suspected, tap each tube lightly with a pencil with the amp powered up—the
suspect tube will let you know. Note that there is a normal metallic clinking when
doing this, but a microphonic tube will be quite loud.
Replacing preamp tubes will not require any adjustment, but the power tubes will
need rebiasing to assure proper operation. After power tube replacement, initially
inspect the tubes often to assure there are no “cherry red” components within
the tube. Tubes today can have a wide variety of tolerances and a re-bias is highly
recommended with new ones.
Power tube bias should be adjusted to 30 mV, +/- 5 mV. If power tubes are
mismatched by less than 5 mV, average the two around 30. Mis-matched tubes
beyond 5 mV will induce noise and may cause a degradation of tone.
NOTE! Capacitors may retain an electric charge and can be dangerous even when
the unit is o, unplugged, and has not been played for an extended period of
time. USE CAUTION!!!!
© 2018 PRS Guitars - All rights reserved.
“Paul Reed Smith,” “PRS,” the PRS logo, the PRS Paul Reed Smith logo, the Paul Reed Smith signature, the bird
inlays, the headstock bird, the PRS headstock shape, the PRS body shape, the PRS “scoop” design, “Singlecut”,
“Mira” and the “SE” are all registered trademarks of Paul Reed Smith Guitars “Custom 24,” “Modern Eagle,”
“SE Custom,” “SC 245,” “SC 250,” “Starla”, “Tonare”, “Sewell”, “ Blue Sierra”, and “Angelus” are all trademarks
of Paul Reed Smith Guitars. The Birds, New Birds, are copyrighted by PRS Guitars.
LIT-AMP-MAN-MT15 REV B
Mark Tremonti MT15
User’s Manual
MT15
POWER
ON
STANDBY
ON
PRESENCE MASTER BASS MIDDLE TREBLE VOLUME BASS MIDDLE TREBLE GAIN
PULL BOOST
CLEAN CHANNEL LEAD CHANNEL
LEAD CHANNEL
CLEAN
LEAD
INPUT
Other manuals for Mark Tremonti MT15
1
Table of contents
Other PRS Guitars Amplifier manuals
