USER'S MANUAL FOR
NXG-Pro
(Next Generation Desktop Power Supply/UPS)
Model Number: PS1236DT
WARNINGS
Review the following important safety warnings to avoid bodily injury or damage
to equipment during installation or operation of this device.
Read ALL instructions before attempting to install or operate this device.
This device is intended for indoor use only. To prevent the risk of fire or
eletrical shock, install in dry location free from damp or wet environment,
or potentially damp or wet environment.
Adhere to all acceptable operating environment limitations as listed to
prevent the risk of of fire or electrical shock (see user specifications within
User's Manual)
Risk of fire or explosion if improper battery is installed and attempted to
operate within this device. Device is rated and approved for use with
standard sealed lead acid battery rated at 12Vdc 7Ah-8Ah. Follow User
Manual instructions for proper installation of battery. Dispose of used
batteries in accordance to battery manufacturer specifications.
NO user-replaceable parts within this device except the battery. Do not
remove cover unless you are installing, replacing, or servicing the battery.
NOTE: The reference to "NXG-Pro" within this User Manual refers to PowerTec
Solutions Model PS1230DT (Next Generation Desktop Power Supply/UPS) and
all package accessories as listed below.
CONTENTS OF NXG-Pro PACKAGE
NOTE: Please verify all standard contents are accounted for upon receipt of
NXG-Pro.
STANDARD: (1) Desktop Power Supply/UPS; (1) Cable Guide; (1) AC Power
Cord; (3) Cable Ties; (1) 7-Pin Connector; (1) User's Manual; (1) Wall-mount
installation template
Optional: (1) 3M Telemetry Wire (associated with Model PS1230DT-3M), or (1)
10M Telemetry Wire (associated with Model PS1230DT-10M).
NXG-Pro INTRODUCTION
NXG-Pro is designed and intended for use as Desktop or Wall-mount DC power
supply and battery back up device for Indoor and Outdoor 12Vdc Optical
Network Terminals (ONT) as well as wireless local loop applications. The NXG-
Pro not only provides constant supply of DC power during normal operating
conditions, but offers battery backup power in case of electrical power outage
when paired with approved standby battery. NXG-Pro also provides customer
facing Network Interface Reset Intelligence to provide integrated ONT reset
technology designed to reduce Provider OPEX.
VISUAL AND AUDIBLE STATUS/ALARM SIGNALS
STATE VISUAL AUDIBLE DESCRIPTION
INDICATOR INDICATOR
Normal
ON
Battery
Replace
Battery
Battery
Missing
Low
Battery
System Status
Indicator On
DC Indicator On
Battery Indicator
On
Battery Indicator
On
DC Indicator
Flashes
1/2 second
audible
indicator every
15 min
1/2 second
audible
indicator 4
times per
minute
Operating under normal AC line
power load and conditions, charges
battery. Battery is connected and in
good condition.
AC line power failure or AC cord
disconnection. NXG-Pro is being
supplied with battery power.
Replace faulty or end of life battery
NXG-Pro is operating on AC line
power only without available stanby
power for outage scenario. When
battery is removed from unit,
battery indicator will illuminate after
15 sec.
Battery has reached equal to or
less than 45% remaining capacity
on battery discharge.
INSTALLATION
DESKTOP USE:
A. Slide battery door down and located on rear of NXG-Pro
and install battery. Intall red wire to red battery terminal and
black wire to black battery terminal. Note: 90 degree red
terminal connector prevents ability to miswire. Battery
installation is optional. NXG-Pro will operate without battery
as long as AC line power is present and connected.
B. Connect NXG-Pro power cord to NXG-Pro power cord connector point
C. Plug NXG-Pro power cord in to AC wall outlet
D. Connect 7-pin DC Power/Telemetry Wire in to DC Output/Telemetry Connector

INSTALLATION (CONT.)
WALL MOUNT USE:
A. Use provided wall mount template to install screws to the wall for keyhole
mounting of the NXG-Pro. NOTE: Ensure that AC Cord provided will
accomodate length needed from NXG-Pro AC cord power input connector to AC
wall outlet.
B. Follow steps A-D as instructed in Installation: Destop Use.
C. Use provided keyhole mounting option for NXG-Pro to hang on previously
installed screws.
BATTERY TYPE
Standard sealed lead acid battery rated at 12Vdc/7-8Ah.
BATTERY REPLACEMENT
As long as AC line power is available, NXG-Pro can resume operation while
battery is replaced.
PROCEDURE:
1. Remove the battery cover from back of NXG-Pro
2. Slide battery out of NXG-Pro and disconnect both red and black connection
wires from battery terminals and remove battery. NOTE: Follow battery
manufacturer specifications for proper disposal of battery.
3. Install new battery by connecting red wire to red (positive) battery terminal and
black wire to black (negative) terminal and slide battery into NXG-Pro battery
compartment.
4. Replace battery cover to resume normal operation.
TECHNICAL SPECIFICATION
INPUT
Voltage Range
Frequency Range
Input Power Cord
Output Ground Reference
OUTPUT #1
On Battery Output Voltage
Continuous Power Capacity
Efficiency (at 75% Max Load)
OUTPUT #2
Voltage Range
Frequency Range
Output Max Current
Input Ground Reference
BATTERY
Battery Type
Number of Battery
Typical Recharge Time
Replaceable
SURGE PROTECTION
AND FILTERING
Lightning/Surge Protection
MANAGEMENT
Battery Auto-Charge
PHYSICAL
Maximum Dimensions (LxWxD)
Weight (lb.)
ENVIRONMENT
Operating Temperature
Operating Humidity
Max Operating Elevaion
Max Storage Elevation
Storage Temperature
100Vac-240Vac
47-70Hz
NEMA 5-15/3-Prong Power Cord
Earth Grounded
12Vdc
36W
> 75%
100Vac-240Vac
50-60Hz
15A
Earth Grounded
SLA Battery
12Vdc/7-8Ah x 1
< 20 hrs
Yes
Yes (IEC 61000-4-5 2005 Level D)
Yes
6.8 x 3.2 x 7.3 (in)
7.16 (with battery)
-20C - 45C (-4F - 113F) at full power
0-95% noncondensing within enclosure
10,000ft (3,000m)
50,000ft (15,000m)
-20 - 45C (-4F - 113F)
FCC NOTICE
This equipment has been tested and found to comply with the limit for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with these instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
tuning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: (1) Reorient or relocate
the receiving antenna. (2) Increase the separation between the equipment and
receiver. (3) Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected. (4) Consult the dealer or an experienced
radio/TV technician for help.
CAUTION: Any changes or modifications could void the authority granted by the
FCC to operate this equipment.
NOTE: PowerTec Solutions International reserves the right to change or correct
the contents of this document and does not assume any responsiblity for
ommissions or errors.
PowerTec Solutions International
Corporate Headquarters
1290 Harbor Court
Hollywood, FL 33019
P: 615-879-3326
E: [email protected]
Website: www.powertecsolutions.net
