Pulsar RS4288 User manual

INSTALLATION GUIDE
ENGLISH v1.0
code: RS4288
Name: 42U RACK server cabinet, floor standing, ready-to-assemble 800x800
IM RS4288
Edition: 1 from 20.02.2020
Supersedes: -------------
EN
1. Intended use:
The RACK 19” cabinet enables integrating CCTV, AC, I&HAS, RTV, LAN, or other systems in medium and big companies. It is
intended for devices manufactured in enclosures of the 19'' standard. Due to the RACK cabinets, the devices are aesthetically mounted
and protected against mechanical damage.
2. Specifications:
SPECIFICATIONS
Mounting dimensions:
W=19", H=42U, D=582mm
External dimensions:
W=800, H=2055, D=800 [mm, +/-2]
Net/gross weight:
123 / 129 [kg]
Materials:
- RACK mounting rails: cold-rolled steel SPCC 2mm RAL 9004 - bolted
- horizontal mounting rails: cold-rolled steel SPCC 1,5mm - bolted
- frame: cold-rolled steel SPCC 1,2mm RAL 9004 - welded
- front door: 5mm toughened glass / SPCC 1,2mm RAL 9004 - hinged
- side panel: cold-rolled steel SPCC 1,2mm RAL 9004 - removable
- rear door: cold-rolled steel SPCC 1,2mm RAL 9004 - hinged
Static load:
1000 kg (with leveling feet)
Use:
inside, IP20
Notes:
- adjustable distance between front and rear RACK rails
- ventilation holes in the top and bottom panel
- possible mounting of a fan unit in the top panels - RAWP (max. 3 pcs.)
- cable ducts in the top and bottom panel
- two cable management panels, vertical, mounted in front of cabinet
- 4 casters without locks and 4 leveling feet included
- possible assembly of a 100mm high plinth - RAC188M
- lockable front door (2 keys in set)
- lockable rear door (2 keys in set)
- side panel - lock assembly possible - RAZB16
- ready-to-assemble
Declarations, warranty:
RoHS, 12 months from the date of purchase
3. Structure of the RACK cabinet.

4. Components
Nu
mb
er
Component
Amou
nt
Foto
1
Top panel
1 pcs.
2
Bottom panel
1 pcs.
3
Front doors
1 pcs.
4
Rear door
1 pcs.
5
Side panel
2 pcs.
6
Cabinet
frame
2 pcs.
7
Horizontal
rail
6 pcs.
8
Distance
12
pcs.
9
RACK 19”
42U rail
4 pcs.
10
Cable
management
panel,
vertical
2 pcs.
11
Cable gland
end cup
(upper)
2 pcs.
12
Cable gland
end cup
(lower)
2 pcs.
Nu
mb
er
Component
Amou
nt
Foto
13
Lock- rear
door RAZ25
1 pcs.
14
Side door
distance
4 pcs.
15
"2” wheel
without lock"
4 pcs.
16
Leveling foot
4 pcs.
17
M8x12 Head
Cap Screw
16
pcs.
18
M8 nut
16
pcs.
19
10mm
Phillips
screw
92
pcs.
20
M5 nut,
spring
washer
2 pcs.
21
Spacer for
front/rear
doors
2 pcs.
22
M6x12
Phillips
screw
40
pcs.
23
M6 nut
(„cage nut”)
40
pcs.
24
Cross /
hexagon
wrench
1 pcs.

5. Assembling instructions of RACK:
The free standing, ready-to-assemble RACK cabinet is delivered in 5 separate packages.
5.1) Place horizontally two RACK cabinet frames with both top and bottom plates.
Pay attention to the grounding in the frame - as shown in the drawing
5.2) Mount the top plate and bottom plate to the left and right frames of the RACK cabinet, respectively.
Use M8x12 Head Cap Screws with M8 nuts (16pcs). Screw the cabinet wheels and legs to the bottom plate of the cabinet.
5.3) Place the RACK cabinet vertically and mount:
- Cable gland end cups (up and down) –screw 10mm (black) - 12pcs
- side door distance –screw 10mm –4pcs

5.4) Mount to frames (in front and back) cross profiles, distances and RACK profiles as shown below.

5.5) Screw vertical cable management panels to mounted distances
5.6) Installation of front, rear, and side doors
