CPM-DS3
1643, Issue 2, June 2014
2
Procedure 1. Installing the CPM-DS3 in a 3O3D3-CPL2C REVB, BP-19, or BP-23
STEP ACTION
1 When using the 3O3D3-CPL2C REVB, remove one network interface (NI) module blanking
plate from the chassis; save this screw for use in Step 3. If using the BP-19 or BP-23
2
, remove the
screws next to the desired CPM-DS3 mounting position; save these screws for use in Step 3.
Ensure that a pair of BNC feed-through couplers is snapped into place in the CPM-DS3 demarc
panel plate (provided with the kit).
3 Mount the demarc panel plate in place with the screw(s) saved from Step 1.
4 Connect one end of one coax cable (provided with the kit) to the TX coax feed-through coupler
on the demarc panel plate. Connect the opposite end of this coax cable to a TX DS3 connector on
the O3D3-MO or O3-3D3DN front panel.
5 Connect the second coax cable (provided with the kit) between the RX feed-through coupler on
the demarc panel plate and the RX DS3 connector on the O3D3-MO or O3-3D3DN front panel.
3 CUSTOMER SERVICE
Direct any questions concerning the CPM-DS3 to Pulsecom Technical Support.
