GETTING STARTED
Checking The Package Contents
PURDIO MMCX Bluetooth Cable MX840 Overview
 PoweringON / OFF
CHARGING THE BATTERY
Charging
 CheckingBaeryLevel
CONNECTING WITH YOUR IN-EAR MONITORS
To Connect The PURDIO MX840
To Disconnect The PURDIO MX840FromYourIn-earMonitors
CABLE MANAGEMENT CLIP
LED INDICATIONS
CONNECTING DEVICES
 PairingYourBluetooth®Device
PURDIO MX840 CONTROL
 MediaPlaybackAndVolumeFuncons
 CallFuncons
CARE AND MAINTENANCE
Storing
 ReplacementPartsAndAccessories
 CustomerService
SPECIFICATION
IMPORTANT SAFETY INSTRUCTIONS
 RegulatoryInformaon
TROUBLESHOOTING
LIMITED WARRANTY
FCC STATEMENT

32
ForotherlanguageversionsofQuickUserGuide,pleasevisitourwebsitewww.odoyo.com/purdio
Другие языковые версии Краткого руководства пользователя можно найти на нашем веб-сайте
www.odoyo.com/purdio.
ParaversionesdelaGuíarápidadelusuarioenotrosidiomas,visitenuestrosiowebenwww.odoyo.com/purdio
VerschiedeneSprachversionenderKurzanleitungndenSieaufunsererWebsitewww.odoyo.com/purdio
其它語言版本的快速使用指南，請上網站下載www.odoyo.com/purdio
其它语言版本的快速使用指南，请上网站下载www.odoyo.com/purdio
GETTING STARTED
CHECKING THE PACKAGE CONTENTS
Aeropeningthepackage,checkallitemsinthelistareincludedinthepackage.
Ifitemsaremissing,pleasecontactyourdealer.
1. PURDIO MMCX Bluetooth Cable MX840 (“PURDIO MX840”) × 1
2. Micro-USBChargingCable×1
3. CableManagementClip×1
4. CarryingPouch×1
5. UserGuide×1
USER GUIDE
1
2
3
5
4

54
GETTING STARTED
PURDIO MMCX BLUETOOTH CABLE MX840 OVERVIEW
1. (R) Right Unit
2. (L)LeUnit
3. Microphone
 Picksupthesoundofyourvoicewhentalkingonthephone.
4. Mul-funconBuons
 Buon–Power / Play / Pairing
 Buon–VolumeUp / NextSong
 Buon–VolumeDown / PreviousSong
5. IndicaonLED
 •Flashingredorbluelighttoindicatethepowercommunicaonstatusof
the PURDIO MX840.
 •Lightsupinredduringcharging.
*See secon “LED Indicaons” for more informaon.
6. Micro-USBChargingPort
2
4
1
3
6
5
POWERING ON / OFF
Turning On
WhenturningonPURDIO MX840bypressingandholdingthe
buonforabout2secondswhenthePURDIO MX840isturnedo.
(BlueLEDwillbelightuptwosecondsandavoiceprompt“PowerON”willbefollowed.)
Turning O
WhenturningothePURDIO MX840bypressingandholdingthebuonforabout2seconds.
(Red LEDwillbelightuptwosecondsandavoiceprompt“PowerOFF”willbefollowed.)
GETTING STARTED
R
L

76
CHARGING THE BATTERY
CHARGING
PURDIO MX840containsalithium-ionrechargeablebaery.Chargeit
usingthesuppliedMicro-USBcable.
ConnectthesmallendoftheUSBcableintotheMicro-USBChargingPort,
andthenconnecttheotherendtoUSBwallchargerorabootedcomputer.
MakesurethattheLEDindicatorlightsupinRedwhilecharging.
Chargingiscompletedinabout2hours(*)andtheLEDindicatorwillbe
changedtoBluelightautomacallywhenchargeiscompleted.
*Time required for charging the empty baery to its full capacity.
CHARGING THE BATTERY
CHECKING BATTERY LEVEL
1. IfPURDIO MX840baerylevelislowerthan5%whenyouarelisteningmusic,therewillbeavoicepromptannounces
“BaeryLow”andtheRedLEDindicatorwillbeashingtwiceineachminutetonofyyoutochargeit.
Formoreinformaon,pleasesee“LEDINDICATIONS”secon
2. PURDIO MX840willbeturnedoautomacallywhenthebaerylevelis0%.
3. TheremainingbaerylevelisshownonlyonthescreenofaniPhone,iPad,oriPodtouch(iOS5.0orlater)that
supportsHFP(Hands-freeProle).
4. MakesurethattheiPhone,iPadoriPodtouchisconnectedwiththePURDIO MX840cable.Otherwise,theremaining
baerylevelwillnotbedisplayedcorrectly.

98
TO CONNECT THE PURDIO MX840
1. IdenfytheleandrightofPURDIO MX840bythe(L)and(R)onthepsofthecable.
2. Matchthecabletotheappropriatein-earmonitors
3. Plugthecableintothein-earmonitorsbyshovingthepofthecableintotheMMCXsocket.
TO DISCONNECT THE PURDIO MX840 FROM YOUR IN-EAR MONITORS
Graspingthein-earmonitorsandthepsofthecablermlywitheachhandandpullingoutatastraightdireconfrom
thesocket.
NOTE: DO NOT HOLD ON THE BODY OF CABLE OR HAVE AN ANGLE WHEN UNPLUGGING THE PURDIO MX840
FROM YOUR IN-EAR MONITORS.
TO ADJUST THE LENGHT OF CABLE
Usetheprovidedcliptoanchorthecabletoacomfortablelengthwithnotoppingaroundasmuch.
CONNECTING WITH YOUR IN-EAR MONITORS
Le Right
L
R
CABLE MANAGEMENT CLIP

1110
LED INDICATIONS
TheLEDindicatorwillbeillustrangtheBluetooth®statusandbaerystatusonthecontrolpanel.
BLUETOOTH® INDICATOR ( )
INDICATOR ACTIVITY SYSTEM STATUS
AlternateFlashingRedLED and Blue LED ReadytoPair
QuickFlashingBlueLightTwoTimes SuccessfulPaired
Blue LEDFlashOneTimesInEachFiveSeconds Not Connected
Blue LEDFlashTwoTimesInEachFiveSeconds Connected
Red LEDFlashTwoTimesInEachFiveSeconds Connected with Two Devices
BATTERY INDICATOR ( )
INDICATOR ACTIVITY SYSTEM STATUS
LightsUpInBlueLEDForTwoSecond Power On
LightsUpInRedLEDForTwoSecond PowerO
FlashingRedLEDTwiceInEveryMinute LowBaeryLevel
LightsUpInRed Charging
LightsUpInBlue FullCharge
CONNECTING DEVICES
PAIRING YOUR BLUETOOTH®DEVICE
First Time Pairing
1. IfPURDIO MX840isturnedo,pressingandholdingbuonforabout5secondsunlhearavoiceprompt
“Poweron”rstandavoicepromptof“Lookingfordevice”.TheLED Indicator will light up in Blue and switching
BluelightandRedlightconsecuvely.
2. OnyourBluetooth®device,turnontheBluetooth®feature.
Tip: The Bluetooth®featureisusuallyfoundintheSengsmenu.
 Select“PURDIOMX840”fromyourdevicelist.
3. Oncepaired,youwillhearavoicepromptof“Connected”andtheBlueindicatorlightwillbeashingtenmesquickly.
Pairing Mode Overme
Inthepairingmode,ifdonothaveanyacviesintwominutes,PURDIO MX840willbeturnedoautomacally.
Disconnecng a Bluetooth®Device
• TurnotheBluetooth®featureonyourdevice.
• YourdeviceisplacedawayfromthereceivablerangeofthePURDIO MX840.
WhenyoudisconnectPURDIO MX840toyourBluetooth® device,youwillhearavoicepromptof“Disconnected”.
ThestatusofPURDIO MX840willbechangedtonon-connecngdeviceandtheLEDindicatorwillashingthebluelight
every5seconds.

1312
CONNECTING DEVICES
Reconnecng to Your Bluetooth®Device
Mark sure the Bluetooth®featureofpreviouslypairedBluetooth®devicehasbeenturnedon.
Power on the PURDIO MX840bypressingandholdingthebuonfor2seconds,itwillautomacallyreconnectwith
previouslypaireddeviceandyouwillhearavoicepromptof“Deviceconnected”aer.Ifnot,pleaseselect“MX840”from
yourdevicelist.
Note: The devices must be within range and powered on.
Connecng with Two Bluetooth®Devices
PURDIO MX840canbeacvelyconnectedtwodevicesatame.
1. PoweronthePURDIO MX840bypressingandholdingthebuonfor2seconds
2. TurnonBluetooth®featureoftwopreviouslypairedBluetooth®devices
3. Itwillautomacallyreconnectwithpreviouslypaireddevices.Ifnot,pleaseselect“MX840”fromyourdevicelist.
4. Ifoneofthedevicesisinrstmeparing,pleaseconnectthenewdevicerstbyfollowtheinstruconsofFirstTime
Pairingabove,thenturnonBluetooth®featureofthepreviouslypairedBluetooth®deviceandselect“MX840”from
thedevicelist.
Once PURDIO MX840isconnectedwithtwodevices,theLEDindicatorwillbeashingtheBluelighttwicequicklyfor
eachveseconds.
Note: You can only play audio from one device at a me.
CONNECTING DEVICES
Switching between Two Connected Bluetooth®Devices
1. Pauseaudioonyourrstdevice.
2. Playaudioonyourseconddevice.
Switching to a New Bluetooth®Device
TurnoPURDIOMX840andfollowtheinstruconsofFirstTimePairing.
Clearing the PURDIO MX840 Pairing List History
• Power on the PURDIO MX840.
• Inthepairingmode,pressandholdtheandbuonsfor10seconds.
• Deleteyour“MX840”fromtheBluetooth®listonyourdevice(s).AllBluetooth®device(s) are cleared and
theheadphonesarereadytopairanewdevice.

1514
PURDIO MX840 CONTROL
MEDIA PLAYBACK AND VOLUME FUNCTIONS
The PURDIO MX840controlsarelocatedontheinlineremotebelowtherightearbud.
FUNCTION WHAT TO DO
Play / Pause Pressbuon
SkipForward Pressandholdbuon2sec
SkipBackwardPressThreeTimesQuickly Pressandholdbuon2sec
VolumeUpPress Press
VolumeDownPress Press
PURDIO MX840 CONTROL
CALL FUNCTIONS
FUNCTION WHAT TO DO
Answeracall Pressbuon
Endacall Pressbuon
Re-diallastnumbercalled Pressbuontwicequickly
Declineanincomingcall Pressandholdbuon2sec
Answerasecondincomingcallandendthecurrentcall Whileonacall,pressbuon
Answerasecondincomingcallandputthecurrentcall
on hold
Pressbuontwicequickly
Switch between two calls Pressbuontwicequickly
VolumeUp Press
VolumeDown Press

1716
CARE AND MAINTENANCE
STORING
TurnoPURDIO MX840whennotinuse.
BeforestoringthePURDIO MX840formorethanafewmonths,fullychargethebaery.
Place the PURDIO MX840inthecarrypouchforstorage.
REPLACEMENT PARTS AND ACCESSORIES
ReplacementpartsandaccessoriescanbeenquiredthroughODOYOcustomerservice.
Findmoredetailson“CUSTOMERSERVICE”secon.
CUSTOMER SERVICE
ForaddionalhelponusingyourPURDIO MX840 cable:
Visit: www.odoyo.com/purdio/
Contact ODOYO customer service at [email protected]om or contact ODOYO’s ocial dealer in your region.
SPECIFICATION
BLUETOOTH VERSION Bluetooth4.1withaptX®
BLUETOOTH PROFILE A2DP / AVRCP / CVC6.0 / HFP / HSP / AAC / SBC
SWEAT & DUST PROOF IP64
TRANSMISSION 10m
CORD LENGTH 640mm
CORD TYPE: EPIC
BATTERY CAPACITY 100mAh
STAND-BY TIME 200 hrs
PLAY TIME 8 hrs
CHARGING TIME 2‒3hrs
WEIGHT 10g
* Volume was set to 50%. Tesng consisted of full PURDIO MX840 baery discharge while playing audio unl the rst
PURDIO MX840 stopped playback. Baery life depends on device sengs, usage, and many other factors.
“This product specicaons and data are subject to change without noce to improve reliability, funcon or otherwise.”
