PUSR AP310i Series User manual

AP(NR)310i User Manual
pusr.com
1
1
Wi-Fi6 AX3000
Be Honest & Do Best
Your Trustworthy Smart Industrial IoT Partner
User Manual
AP310i Series
V2.0

AP(NR)310i User Manual
pusr.com
1
- 2 -
Content
1. Introduction ...............................................................................................................................................- 4 -
1.1. Overview...........................................................................................................................................- 4 -
1.2. Features............................................................................................................................................- 4 -
1.3. Specification .....................................................................................................................................- 5 -
1.4. Button & Indicator .............................................................................................................................- 7 -
1.5. Dimension ........................................................................................................................................- 7 -
2. Get Started.................................................................................................................................................- 8 -
2.1. Hardware interface introduction........................................................................................................- 8 -
2.2. Quick test..........................................................................................................................................- 8 -
2.2.1. Login setting page ...................................................................................................................- 8 -
2.2.2. Brief introduce of the webpage ................................................................................................- 9 -
3. Configuration and parameter details ........................................................................................................ - 10 -
3.1. System status.................................................................................................................................. - 10 -
3.2. Mobile network ...............................................................................................................................- 12 -
3.3. Internet accessing settings ..............................................................................................................- 12 -
3.3.1. Mode selecting.......................................................................................................................- 12 -
3.3.2. Ethernet port setting ..............................................................................................................- 13 -
3.3.3. WAN settings .........................................................................................................................- 13 -
3.3.4. Wireless repeater ...................................................................................................................- 13 -
3.3.5. 5G AT.....................................................................................................................................- 14 -
3.3.6. 5G NR ....................................................................................................................................- 14 -
3.4. WLAN settings.................................................................................................................................- 15 -
3.4.1. 2.4G settings..........................................................................................................................- 16 -
3.4.2. 5G settings............................................................................................................................. - 17 -
3.4.3. Signal selecting .....................................................................................................................- 17 -
3.5. LAN network settings.......................................................................................................................- 18 -
3.6. Login settings .................................................................................................................................- 18 -
3.7. Client list.........................................................................................................................................- 19 -
3.8. Software upgrading ........................................................................................................................- 20 -
3.8.1. Firmware upgrading ..............................................................................................................- 20 -
3.8.2. Backup ..................................................................................................................................- 21 -

AP(NR)310i User Manual
pusr.com
1
- 3 -
3.8.3. Time & Date ...........................................................................................................................- 21 -
3.8.4. Reboot...................................................................................................................................- 22 -
3.8.5. Reset to factory setting...........................................................................................................- 22 -
3.9. System log......................................................................................................................................- 22 -
4. Warranty..................................................................................................................................................- 23 -
5. Contact Us................................................................................................................................................- 23 -
6. Disclaimer................................................................................................................................................ - 24 -
7. Revision History........................................................................................................................................- 24 -

AP(NR)310i User Manual
pusr.com
1
- 4 -
1. Introduction
1.1. Overview
AP/NR310i is a ceiling-mounted AX3000 Wi-Fi 6 dual-band AP, with the option for 5G NR. The product is
based on a powerful Qualcomm wireless core, with a strong power of 25dBm and external antennas to achieve
greater coverage. It supports IEEE 802.11a/b/g/n/ac/ax protocols, with a maximum Wi-Fi access rate of up to
3000Mbps. It comes with 512MB of RAM (supporting customizable options from 256MB to 1GB).
NR310i is equipped with a full-band 5G Sub-6GHz M.2 module designed for IoT/eMBB applications. It adopts
3GPP Release 16 technology and automatically adapts to 5G NR NSA and SA networking. It is backward
compatible with 4G/3G and can provide backup for wired broadband and cellular broadband networks. It can
also provide network access for Wi-Fi users in scenarios without wired broadband access through 5G broadband.
The excellent performance and stability of the product come not only from the high-end Qualcomm core
platform but also from the expertise of our professional R&D team in hardware and software design. The product
can be widely used in industries and scenarios such as enterprise offices, education and training, smart
healthcare, apartment dormitories, exhibition halls, and conference rooms.
1.2. Features
⚫AX3000 Wi-Fi 6, M.2 5G SA/NSA Sub 6GHz Router(NR310i).
⚫5G NR Router employs 3GPP Rel. 16 technology, it supports both 5G NSA and SA modes, covers all
the main stream carriers worldwide.
⚫Supports the Wi-Fi 6(802.11ax) standard,2.4GHz and 5GHz dual-frequency UL/DL MU-MIMO,
enabling AP to send data to multiple terminals at the same time.
⚫Fat and Fit AP in one, Fit AP mode managed uniformly by the wireless controller (AC)，Fat AP mode
independent web page management.
⚫2.5G Ethernet port. Using 2.5Gbps Ethernet port, compared with Gigabit port, the speed is greatly
improved.
⚫Set WAN/LAN port as WAN to enable NR310i use the landline internet from WAN, and 4G/5G
connection works as a backup to provide a sustained and reliable internet connection for you.
⚫Automated failover/failback back up among Ethernet, Cellular and Wi-Fi.
⚫Multiple SSID.

AP(NR)310i User Manual
pusr.com
1
- 5 -
1.3. Specification
Table 1. Parameters table
Mobile(Optional)
5G NR Module
Qualcomm Snapdragon X62
Frequency Bands
5G NR SA:
n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40
/n41/n48/n66/n70/n71/n75/n76/n77/n78/n79
5G NR NSA:
n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40
/n41/n48/n66/n70/n71/n75/n76/n77/n78/n79
LTE FDD:
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/
B30/B32/B66/B71
LTE TDD:
B34/B38/B39/B40/B41/B42/B43//B48
LAA:B46
WCDMA:B1/B2/B4/B5/B8/B19
Data Transmission
Rates
5G SA Sub-6: Max. 2.4 Gbps (DL)/Max. 900 Mbps (UL)
5G NSA Sub-6: Max. 3.4 Gbps (DL)/Max. 550 Mbps (UL)
5G NSA mmWave: Max. 4.0 Gbps (DL)/Max. 1.4 Gbps (UL)
LTE-FDD: Max. 1.6 Gbps (DL)/Max. 200 Mbps (UL)
HSPA+ : Max. 42Mbps (DL)/Max. 5.76Mbps (UL)
Antennas
Internal high gain antenna*4
SIM Card
1 x Mini SIM(2FF), Push-push type
Wi-Fi Interface
Wi-Fi Chipsets
2.4GHz: Qualcomm IPQ5018 (Dual-core ARM Cortex-A53@1GHz)
5GHz: Qualcomm QCN6102
Memory
Flash:SPI NAND 128MB + SPI NOR 8MB
RAM:512MB DDR3L SDRAM
Wi-Fi Standards
2.4 GHz: IEEE802.11b/g/n/ax

AP(NR)310i User Manual
pusr.com
1
- 6 -
5.8 GHz: IEEE 802.11a/n/ac/ax
Frequency
2.4 GHz(2.412GHz - 2.484GHz)
5 GHz(5.15GHz～5.85GHz)
Antennas
Internal high gain antenna*4
Wi-Fi Security
Open, WPA, WPA2PSK TKIPAES,WAP2 EAP.WPA3
Operating Modes
Wireless router mode
Access point mode
Repeater mode
End Users
256
Wi-Fi Data Rates
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 1733 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps+4804Mbps
TX Power
24dBm
Ethernet Interface
WAN
1 x 2.5Gigabit WAN RJ45, 10/100/1000 Mbps, auto MDI/MDIX
LAN
1 x 1Gigabit LAN RJ45, 10/100/1000 Mbps, auto MDI/MDIX
Mode
Full or Half Duplex (Auto-Sensing)
Power Supply
Power Input
48V PoE input over WAN
Power Consumption
15W
Standard
IEEE 802.3at standard
Physical Characteristics
Housing
Plastic
Dimension
190*190*42mm(L*W*H)
Installation
Ceiling mounting
Operating
Temperature
0℃~ +40℃

AP(NR)310i User Manual
pusr.com
1
- 7 -
Storage Temperature
-40℃～+70℃
Ingress Protection
IP30
Weight
500g
Software
Network Protocols
IPv4/IPv6,HTTP,DHCP,NAT,PPPoE
Network Security
Access Control, DMZ, Port Forwarding, SPI firewall, Filtering (IP & MAC &
Domain),IP & MAC Binding
VPN Client
IPSec Client, PPTP VPN Client, L2TP VPN Client
Others
Button
Press and hold 5s to restore factory Settings
Indicators LED
WAN,LAN, Internet
1.4. Button & Indicator
Item
Description
WPS button
Holding for 5s to reset to factory settings.
Indicator
Blue: Can access Internet successfully.
Red: Can’t access Internet successfully.
1.5. Dimension
Unit：mm
Figure 1. Dimension of AP310i

AP(NR)310i User Manual
pusr.com
1
- 8 -
2. Get Started
2.1. Hardware interface introduction
2.2. Quick test
2.2.1. Login setting page
Connect PC to the LAN port of the AP controller, and set the IP to static IP, such as 192.168.1.101. The IP
should be on the same network segment as the AP device.
You can test whether the network is connected by ping 192.168.1.1.

AP(NR)310i User Manual
pusr.com
1
- 9 -
Figure 2. Ping command
Enter the default IP address of the AP 192.168.1.1 in the browser, and the browser will navigate to login page.
The username and password are both admin.
Figure 3. Login page
2.2.2. Brief introduce of the webpage
The left column is divided into 9 menu pages: System status, mobile network, Internet settings, WLAN
settings, LAN settings, Login settings, client list, upgrade and system log.
There are three auxiliary options in the upper right corner: PUSR cloud, Luci, language, as shown in the
following figure.

AP(NR)310i User Manual
pusr.com
1
- 10 -
Figure 4. Overview of function
3. Configuration and parameter details
3.1. System status
This interface displays the basic information of the router, including 4 major blocks: system information,
WAN port information, LAN port information, WLAN information. The specific information is shown in the figure
below.

AP(NR)310i User Manual
pusr.com
1
- 11 -
Figure 5. Router mode

AP(NR)310i User Manual
pusr.com
1
- 12 -
Figure 6. AP mode
3.2. Mobile network
This function block displays the basic information of mobile network, including SIM information, 5G model
information, 5G band, 4G LTE band, 3G WCDMA band.
Figure 7. Mobile network
3.3. Internet accessing settings
Users can set the router: Mode selecting, Ethernet settings, WAN settings, Wireless repeater.
3.3.1. Mode selecting
There are 2 modes that can be selected: Router mode and AP mode.
Router mode: In this mode, the WAN port supports DHCP client, static IP, PPPoE. For LAN port, it supports
DHCP service to assign IP addresses to terminal network devices.
AP mode: In this mode, WAN and LAN are bridged together, and DHCP service is turned off.
Figure 8. Mode selecting

AP(NR)310i User Manual
pusr.com
1
- 13 -
3.3.2. Ethernet port setting
In this function block, users can implement WAN/LAN switching, and can monitor whether the Ethernet port
is connected to a device.
Figure 9. Ethernet port settings
3.3.3. WAN settings
On this page, users can set parameters of WAN port to get access to Internet, including DHCP client, static IP,
and PPPoE.
MAC clone: Replace the AC's MAC address with this MAC.
Figure 10. WAN settings
3.3.4. Wireless repeater
Click <SCAN>, it will display the Wi-Fi SSID nearby, check the needed SSID, enter the password, select the
needed frequency, check “Turn on”， then click “Apply”.

AP(NR)310i User Manual
pusr.com
1
- 14 -
Figure 11. Wireless repeater
3.3.5. 5G AT
To get information or settings of 5G module via sending AT command.
Figure 12. 5G AT
3.3.6. 5G NR
Settings of 5G module.

AP(NR)310i User Manual
pusr.com
1
- 15 -
Figure 13. 5G NR
Table 2.
Items
Description
5G enable
Turn on/Turn off 5G NR.
Station selecting
Select the right base station.
APN
Enter the APN of the SIM card.
Pin code
If a PIN code has been set on the card, please enter the correct PIN code.
3.4. WLAN settings
It includes 3 parts in this function block: 2.4G settings, 5.8G settings, Signal selecting.

AP(NR)310i User Manual
pusr.com
1
- 16 -
3.4.1. 2.4G settings
Figure 14. 2.4G settings
Table 3.
Items
内容
SSID
Set the SSID of AP device, the maximum length is up to 22 characters.
Password
Length: 8~32, it can be characters and numbers.
Users can leave it blank, it will open to all users.
Default：www.pusr.com
Wi-Fi enable
Turn on / turn off the Wi-Fi function.
Hiding SSID
Turn on / turn off the SSID. After enabling this function, users will not be able to
detect the SSID.
AP Isolation
Turn on: STAs connected to this AP cannot access each other.
Turn off: STAs connected to this AP can access each other.
channel
Channel 1~ 13 can be selected, or user can leave it to auto.
IEEE 802.11
802.11ax/n/g/b.
Bandwidth
HT20/HT40.
WPA3 Encryption
Enable WPA3 enhanced encryption protocol.
80211r
Turn on / turn off 802.11r protocol.

AP(NR)310i User Manual
pusr.com
1
- 17 -
3.4.2. 5G settings
Figure 15. 5G settings
Table 4.
Items
Description
SSID
Set the SSID of AP device, the maximum length is up to 22 characters.
Password
Length: 8~32, it can be characters and numbers.
Users can leave it blank, it will open to all users.
Default：www.pusr.com
Wi-Fi enable
Turn on / turn off the Wi-Fi function.
Hiding SSID
Turn on / turn off the SSID. After enabling this function, users will not be able to
detect the SSID.
AP Isolation
Turn on: STAs connected to this AP cannot access each other.
Turn off: STAs connected to this AP can access each other.
channel
Channel 36、40、44、48、52、56、60、64、149、153、157、161、165 can be
selected, or user can leave it to auto.
IEEE 802.11
802.11ax/ac/ (n/a) /a
Bandwidth
HT20/HT40/HT80/HT160
WPA3 Encryption
Enable WPA3 enhanced encryption protocol.
80211r
Turn on / turn off 802.11r protocol.
3.4.3. Signal selecting
Users can choose (Energy Saving)/(Normal)/(Penetration) signal strength based on requirements.

AP(NR)310i User Manual
pusr.com
1
- 18 -
Figure 16. Signal level
3.5. LAN network settings
This function block is used to set the LAN IP address of the AC200/1000, with the setting options as shown in
the following diagram, and the configuration instructions as in Table 3.
Figure 17. LAN settings
Table 5.
Items
Description
IP address
The LAN IP of the AC200/1000. The default is 192.168.10.1
Subnet Mask
Subnet Mask of AC200/1000’s LAN port.
DHCP service
After enabling DHCP, the AC200/1000 can assign IP addresses to terminal
devices. The IP addresses start from the “initial value”and can be allocated up to
the “maximum number“set.
3.6. Login settings
This function is used to change the login password of a webpage.

AP(NR)310i User Manual
pusr.com
1
- 19 -
Figure 18. Login password
3.7. Client list
Client list has 3 submenus: DHCP List wireless clients and IP Binding.
DHCP List: Clicking on “refresh” button will display the information of computers that have obtained IP
addresses through the router's DHCP service, as shown in the following figure.
Figure 19. DHCP client
Wireless clients: It displays the clients connected to the AP device via wireless. Click “Refresh” to update the
latest client list.
Figure 20. Wi-Fi clients

AP(NR)310i User Manual
pusr.com
1
- 20 -
IP Binding: Enter the IP address and MAC address of the device that needs to be bound, then click on <Add>.
Click on <Refresh> to view the devices that have already been bound.
Figure 21. IP binding
3.8. Software upgrading
This functional block includes five submenus: [Firmware Upgrade], [Backup/Restore Configuration],
[Date/Time], [Restart], and [Restore Factory Settings].
3.8.1. Firmware upgrading
Select firmware file-> Click upgrade
Figure 22. Firmware upgrading
