PYLE Audio PLBASS10 User manual

10
Mounting the subwoofer
1. Find a suitable location in the vehicle in which to mountthe amplifier.
A typical location is shown below:
2. Make sure there is sufficient air circulation around the intended mounting location.
3. Mark. the location for mounting hole screws by positioning the cabinet where you
wish to inst all it. Make a small mark to identify the position and remove the unit.
Thoroughly dean
the area you plan to attach the subwoofer, using avacuum cleaner.
Then attach the supplied double adhesive tape, and put the subwoofer in the place
and press down on it securely.
Troubl .... ootlng
If you experience operation or performance problems wtIh this product, compare your
installation with
the electrical wiring diagram on the previous pages. If problems
persist,
read the following troubleshooting tips which may help eliminate the problems.
PROBLEM POSSIBLE REASON
SOLUTION
_i'D+12.fb paM!!"..we
_ Check. lJsae and c:onnacllons 1D batIB
NatMIdIIIlII 00. PtMa -
No pcMIlI" b ft!I"I"de ..we
- C2"Iec:k remote on connections 1D head unit
lB) not 'on'
-FLBe belen
- Replace fuse with correct type and
amperage
-FIBJ liMn
- Replace fuse with correct type and
Netv.tlIki'Q but sBIus
amperage
lED '00'
_ fvtova unit to vanlBd area
- AnlfI'er tlo I"d.
_ Tum head unit dCMn
No .....
'_lH
-Check heed unit volume level
- GI!Ih ariel rD: II1II: ~
- Ensure you have set up the amplifier
gain level control
-Co. r IS
-Check all paovar, remote on and grcxn::l
"""""""""
PYLE'
www.pyleaudio.com
PLBASS10
" Super Slim
Active Subwoofer
OWNER'S MANUAL

PLBASS10
1000 Watts Max 10” Super Slim Active Subwoofer
10” Slim woofer
RCA low level input
High level input
Green & red LED power status indicator
Remote level control
Phase shift switch: 0 or 180°
Adjustable input sensitivity: 0.2V-3V
0 to +12dB variable Bass Boost (@45Hz)
Low pass filter (50-150 Hz)
Soft delay remote turn-on
Thermal, short and overload protection circuits
Fuse: 2x20A
Max power: 1000 Watts
RMS Power: Amplifier: 100 Watts
Slim woofer: 250 Watts
Dimension: 15” X11.8” X 3”
Weight: 14.1 Lbs.
10

Low Level Input Wiring
Low-level (RCA) input wiring is preferred for best audio performance. Most
trunk or hatchback installations will require a 15-20 foot RCA cable, while
pickup trucks and under-seat installations will require a 6-12 foot RCA cable.
Always use a high-quality cable.
NOTE: Do not connectBOTH the high level and low levelinputs
from
your receiver to your amplifier at the same timel
High Level Input Wiring
•
I~I
Iq :;:;:;:; ;:;..J
•
ToAudlo
I Outuput. of head
unit or signal
proc ••• or
The high level input(s) should only be used when your receiver lacks RCA
outputs. If the RCA outputs are not present, connect the speaker outputs from
the receiver to the high level input connector of the amplifier. Be sure to
observe polarity to avoid audio phase problems.
NOTE: Do not connectBOTH the high level and low levelinputs
from
your receiver to your amplifier at the same time!
•
•
~ ---
@@ .. ~ ..
•
WHITE 1+
BLUE 1-
'USES
......
•
C -C
I~I
2+GREEN
2-PURPLE
•
•
10
1 I I
TO Sp •• kef Terminal.
DDDDDO ofh •• d unit
5-PLBASS10 Owner's Manual
Introduction
With the PLBASS10, we are introducing a low-profile amplified
subwoofer. Low enough to easily fit below the seat
of yourcar, This
system offers you a quick and easy
way to add a high-powered
subwoofer system to youraudio system.
The integrated amplifier
in the PLBASS10 features both high pass
and low pass crossovers, and a control for adjusting the input
sensitivity from 0.2Vto 3V .
Both high level (speaker level) and low level (RCA
type) inputs are
present, making this a universal solution
for use with any head unit
or other input source.
Forfurther flexibility in the use
of a subwoofer, a variable bass boost
control has been included.
You can control the subwoofer level with
the remote level control module.
What is included?
When first unpacking your new amplified subwoofer, please
check first that the package contains all of the items below. If
something is missing, contact the store where you purchased
the prod uct.
• PLBASS10 amplified subwoofer
• Remote subwoofer level control
• Remote subwoofer control cable
• High level input wire
• Mounting hardware
PLBASS1Q Owner's Manual-2

Front panel controls and features
CD POWER ON LED INDICATOR
® PHASE SHIFT
Use this switch to help compensate for time alignment problems
in the
system. Such problems usually result from having the subwoofer at a
different distance from the listener than the other speakers
in the system.
@ INPUT GAIN CONTROL
After you have installed your system, turn this control to minimum.
Tum the head unit
on (and the subwooferwill tum on via the remote
connection). Turn the head unit volume to about
2/3 full level.
Slowly turn up the subwoofer input gain control until you hear a small
amount
of distortion. Then reduce the level until the distortion is
completely
gone. Leave the control at this setting.
@BASSBOOST
The bass boost feature will increase the sound level the bass frequencies.
® LOW PASS FILTTER
This control permits you define the frequency range you want the subwoofer
amplifierto receive. The subwooferwill reproduce all sound BELOW the
frequency you set.
Ifthe rest
of your system is weak on the mids , you may wish to set this
control relatively high. Ifthe midrange is well covered by the rest
of your
system, you will probably want the subwooferto only receive lower
frequency signal.
® REMOTE LEVEL CONTROL PORT
Attach the included remote level control to control the volume level
of the
subwoofer independently.
(j) PROTECT LED INDICATOR
3-PLBASS10 Owner's Manual
Rear panel controls and features
CD LOW LEVEL RCA INPUTS
Low level inputs are the recommended way to introduce the audio signal
to the subwoofer
if RCA outputs are present on your head unit or other
signal source (such as a sound processor).
® HIGH LEVEL (speaker level) INPUTS
If
your head unit does not have RCA outputs, you can use the speaker
outputs for the audio source forthe PLBASS10. Use the supplied cable
and connect the outputs properly
as shown in the connection diagram
in this
manual.
@FUSE
The fuse is rated at 20A. Do not use a fuse with a different value and
NEVER replace the fuse with a wire or coin.
@
POWER TERMINALS
PLBASS10 Owner's Manual-4
