Frequency Range: 88.1MHz-107.9MHz (frequency interval is 0.1MHz)
Frequency Stability: +10PPM (-10 ~+50 )
Noise Limitation 60dB
Frequency deviation: 75KHz
Trasnmitting range: 8M
Audio input bandwidth: 100~15000Hz
Power Supply: DC12V
Ipod Car FM Transmitter
Instruction Manual
Thank you for choosing iPYLE PiFMPK9 Car FM Transmitter with Ipod
docking. This device is a full band Car FM Transmitter with frequency
range from 88.1MHz to 107.9MHz. Totally there are 199 selectable
frequencies. Up to 10 frequently used frequencies can be stored into
memory for future use. It has power off memory. The last used frequency
before power off can be kept in memory. When you use this unit next time,
the last used frequency will be displayed automatically.
To use this unit correctly, smoothly and comfortably, please read this
instruction manual carefully before operation.
To protect unit's excellent functions, avoid using it in the following
environment:
1. Too much moisture
2. Too high temperature
3. At direct sunlight
4. To be easy to fall off
Pay attention in the listening:
1. To avoid harm to your ear, please choose suitable volume level.
2. To adjust the volume, please don't turn up to very high level to avoid
damage to your car speaker system.
3. Please be more careful or stop using in any environment with potential
danger
1. No need to change any equipment of car. Just plug the cigar head into
cigarette lighter socket.
2. Special port for Ipod with charge function.
3. It is perfect for all kinds of Ipod such as Ipod mini, Ipod nano, Ipod Video.
4. Built-in FM stereo wireless transmitter transmits the music from Ipod to
car radio for playing. PLL circuit to ensure stability of frequency and
prevent the frequency from skipping fast.
5. Full band to avoid interference. Frequency range is from 88.1MHz to
107.9MHz. Frequency interval is 0.1MHz. Up to 10 channels can be stored
in memory.
6. Large size LCD digital display for frequency. Blue backlight design is
convenient for operation in the dark place.
7. Transmitting range is more than 8M.
8. 3.5mm audio input jack for connecting external audio device with
3.5mm plug such as MP3, MP4, portable CD, DVD, etc.
9. 3.5mm audio output jack can output audio signal to other audio devices
such as recording equipment.
10. Power off frequency memory function.
11. Auto ON when receive any audio signal.Auto OFF when no audio
signal received in 50 seconds.
1. Frequency up/down
2. Function keys:
adjust/store frequency
3. LCD digital display
4. Ipod connector
5. 3.5mm audio input jack
6. 3.5mm audio output jack
7. Cigar head
8. Polarity "-"
9. Polarity "+"
1. Plug cigar head into car cigarette lighter socket.
LCD display lights up and shows current
frequency.
2. Plug Ipod into special port for Ipod. Press "play"
to start playing.
3. Press frequency up/down to set a suitable one for
using. LCD display shows the frequency in using.
4. Turn on car radio. Adjust the frequency to the same
one as transmitter manually or use AUTO SCAN
function to set the frequency.
5. If any interference, please press CH+/CH- to
choose another suitable frequency. Slightly press
CH+/CH-, frequency will go up or down 0.1MHz.
Press CH+/CH- for few seconds to fast forward
or backward frequency.
6. Press "P" to select previous stored channel. The
frequency will cycle from CH01 to CH10. LCD
will display first the selected CH NO and then
frequency after one second.
7. To keep regular used frequency in memory, please set
it as current frequency. Press down P for seconds until
CH NO flashes to enter CH saving mode. Adjust
CH+, CH- to choose the location(CH NO.) for the
frequency you want to save. Press P to keep both CH
NO and frequency in memory.
8. If use MP3, MP4, portable CD, DVD or other 3.5mm
audio input, please connect the 3.5mm audio cable
to 3.5mm input jack.
1
2
3
4
PiFMPK9
