Pyle Pro PDMXi3 User manual

PDMXi3
Owner’s Manual
WWW.PYLEAUDIO.COM
PDMXi3
2 Channel USB/iPod DJ Mixer
2 Channel USB/ iPod DJ Mixer

INPUT SECTION FEATURES
1) THE POWER INDICATION
When the power is on, the red light will illuminate.
2) RCA Master Output
Use this knob to adjust the volume of master mix output
3) CROSSFADER
This fader is used to mix between the two channels.
4) iPod DOCKING STATION
Connect any iPod with a bottom connector here. Audio, Video, and the controls are
communicated through this port from the iPod to the mixer.
2 Channel USB/iPod DJ Mixer

5) THE USB PLAY INDICATION
When the USB is connected, the red light will illuminate
6) USB PROT
Connect any USB flash drive with mp3 or WMA file. Audio and the controls are communicated
through this port from the USB to the mixer.
7) PLAY/PAUSE BUTTON
This button plays and pauses music from the iPod or USB flash drive
8) PREVIOUS TRACK
Use this switch to re-start the track or to select the last track.
9) NEXT TRACK
Use this knob to select the next track.
10)GAIN ADJUSTMENT
Each channel has a gain adjustment which is used to level between sources. This is very
useful when working on MP3 files as they are often recorded at varying output levels.
11) HIGH FADER (CH1/CH2)
Adjust CH1&CH2 equalization for treble.
12) LOW FADER (CH1/CH2)
Adjust CH1&CH2 equalization for base.
13) MID FADER (CH1/CH2)
Adjust CH1&CH2 equalization for voice.
14) VOLUME (CH1/CH2)
Adjust the volume level for CH1&CH2.
15)MICROPHONE
Plug 1/4” microphone in here.
16) MIC GAIN
Adjust the level for microphone.
17) MIC TONE
Adjust the TONE for microphone.
18) CUE MIX
This knob selects what output is sent to the headphones.
19) CUE GAIN
Adjust the level of CUE. The CUE LEVEL adjust your headphone output's level.
20) HEADPHONE
Plug 1/4” microphone in here.

21) LINE SWITCH IPOD 2
This small switch allows you to choose between a iPod 2 input or a
AUX level (MP3,CD,Tape player etc...).
22) AUX INPUT
When the switch is in the AUX position you may connect any AUX level
device as described before(MP3,CD,Tape etc).
23) AUDIO OUTPUT
This is a master output, to connect your amplifier or powered speaker
by RCA cable included in the gift box.
24) POWER
Press the power switch to turn the unit on. To switch the power off.
press the power switch again.
25) AC IN
Connect the external AC adapter included in the gift box.
A

FEATURES
• 2 Channel: USB port and iPod socket
•Next/Previous/play/pause Control
• 3 band Equalizer
• Gain/Volume control per channel
• Master level control
• Stereo output 2RCA
•AUX input 2RCA
•Microphone input with gain, tone control
•Headphone jacket
•CUE, CUE level control
•LED Indicator power and USB play
• External power supply
•Size:8.26”*8.26”*2”
•AC adapter:input 110V-115V~60Hz Output:9V~60Hz
WARNING:CHANGES OR MODIFICATIONS TO THIS UNIT NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE WILL VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.ANY CHANGE TO
THE EQUIPMENT WILL VOID FCC GRANT.
CAUTION:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPARATUS TO RAIN OR CORDS. IF THIS HAPPENS,BE SURE
POWER TO THE ELECTRICAL OUTLET IS TURNED OFF BEFORE YOU TOUCH
OR UNPLUG THE APPLIANCE.
