Pyle nutrichef PKSTIND52 User manual

PKSTIND52
Portable Ceramic Double Burner
Induction Cooktop with Digital Display

Lock Button
Timer Button
Lock Button
Timer Button
Heating Area
Black Crystal Plate
Control Board
www.NutriChefKitchen.com 2
www.NutriChefKitchen.com
3
PRODUCT CONFIGURATION
CONTROL PANEL:
1. SAFETY CAUTIONS
WARNING: SWITCH OFF THE INDUCTION COOKER IN CASE OF ANY
CRACK ON THE COOK-TOP PANEL
1. Do not place the unit in any place that is near gas or hot
environment in order to avoid damages or malfunction.
2. To reduce the risk and damage, this plug should be t into and
individual outlet. The rated electrical current is not less than 15A.
3. Place the unit on a level surface, the distance between the unit and
background surrounding must be not less than 10cm.
4. Do not immerse the appliance and electric cord in water liquid, or
allow liquid to go into the cabinet and get short/contact inner
electrical parts, the power cord must be plugged out before cleaning.
5. Do not cover gas vent with anything during cooking, otherwise it
will cause danger.
6. To avoid danger, please uncap the cover before heating tinned food.
7. If it is still not working after inspection,please immediately contact
our service center and do not open the unit to avoid any danger.
8. Do not operate any appliance with a damaged cord or plug, or after
appliance malfunctions or has been damaged in any manner
9. It would get dangerous when the metal gets heated directly or
indirectly.
10. Do not place any metal on the plate and also to the nonmetal pad
within 10cm.
11. Do not cook with an empty pot to avoid malfunction or danger.
12. Always clean the unit and avoid any dirt that may go into the fan to
eect normal working.
13. Do not touch the plate while the unit is working to avoid getting
burned.
14. To avoid injuries such as scalding, do not let children operate the
appliance alone.

www.NutriChefKitchen.com 4
www.NutriChefKitchen.com
5
15. If you have a pacemaker, you should consult with your doctor
before you take advantage of any induction cooking device.
16. Do not place on or near a hot gas , electric burner, or in a heated
oven
17. To avoid danger, do not place paper, aluminium foil, cloth or other
unsuitable articles onto the induction cooker heating plate for
indirect heating.
18. Do not place the unit on the cloth or carpet to avoid blocking the
rear exhaust vent.
19. Please kindly avoid hitting the plate of the unit, in case of getting
cracked, should turn o the unit and plug out immediately and
then contact with service points of our company.
20. Do not touch the control panel with any sharp objects.
21. Do not place any metal on the unit while operating.
2. PRODUCT OPERATING INSTRUCTIONS
1. Place suitable cooking utensils in the center of the top plate.
2. Insert the plug in to AC 120V, 60Hz Socket. Press ON/OFF to switch
ON, after pressing Function. The default ”Power” P4 will auto select.
Dierent cooking functions, setting and adjustments.
3. To switch o, Press ON/OFF again, then plug out to shut o power.
2.1 COOKING MODE
1. Front Side: The Right Control Panel
Rear Side: The Left Control Panel
•Press the [ON/OFF] key display will show [P4], It can be adjusted by
pressing the [+] or [] key to set the desired power level.
•There are 9 power levels in total
(P1-P2-P3-P4-P5-P6-P7-P8-P9)
•To Cancel this mode, press [ON/OFF] key to stop the operation.
2.2 Timer Function: (99 Minutes Timer)
1. User can set the cooking time when the cooking modes is selected.
2. Press the [Timer] key ,display will show the default time [00], user
can press [+] or [] key to set for the desired time.
3. Press [+] or [] key once can increase or decrease1minute.
4. Press and hold to access quick adjustment, the time can be adjusted
from 0minute to 99 minutes.
5. After setting, user can press Cooking key once to confirm or wait
until the display stop.
6. To Cancel this mode, press [ON/OFF] key to stop the operation.
2.3 Lock Function:
•Press the [+/-] key together ,the Lock indicator will light up
representing that the appliance is locked.
•To Cancel this mode, press to [+/-] key and hold for 3 second or
[ON/OFF] to stop the operation.
3. SELECTION OF COOKWARE:
1. Material Required:
•Steel, cast iron, enameled iron, stainless steel, flat-bottom pans/pots
with diameter from 12 to 26cm.
•It is suggested to use the required pot. Do not attempt to use other
pot instead (especially pressure sensors vessels).
2. Please kindly check according to the below requirements if its
necessary to use the vessel.
•Pan/Pot must be suitable for induction cooker.
•Pan/pot should be tried out if it's bought by self to see if compatible
with the induction cooker
•Pan/Pot should be flat and comes with cover and gas vent.

www.NutriChefKitchen.com 6
www.NutriChefKitchen.com
7
4. MAINTENANCE AND DAILY CARE
1. Remove the power plug prior to clean the unit. Do not clean it until
the surface cools down.
2. Glass Plate, Panel and Shell:
• Soft Cloth for slight stain.
• For greasy, dirt, blot by using a clean damp cloth with neutral
detergent.
3. While the radiator-fan is working,dust and dirt would remain on the
gas vent, please clean it by brush or cotton stick regularly.
4. Do not wash the unit by water directly to avoid damage.
5. To protect the induction cooker,be sure to have a good contact
between plug and socket before use.
6. Do not pull out the power cord directly during operation. To extend
the appliance's life, press then ON/OFF button rst to power o then
pull out the power cord.
7. In order to make operating time longer,the fan will still work for
cooling the plate, it is better to plug out after the fan stops working.
8. If the appliance is not be used for a long period of time, pull out the
power plug.
9. Some models have structural design against cockroaches, if needed,
you can put something like mothball to expel the cockroaches.
5. TROUBLESHOOTING AND TREATMENT
During operations, if any errors occurred, please check the following
table before calling for service.
Below are common errors and solutions.
PROBLEM CHECK POINTS SOLUTION
After connecting
the power and
pressing the Power
key, the appliance
has no response
Induction Cooker
send out
"Beep Sound"
No operation
during the heating
being in use
Power outage? Use when electricity
resumes
Is the plug connected
rmly?
Is the fuse broken down?
Check the root
causes carefully. If
the problem can't
be xed, please
contact service
center for checking
and repairing.
Incompatible cookware or
no cookware is used?
Is the cookware not
considerable placed from the
center of the heating zone?
Replace compatible
cookware for the
induction cooker
Replace the cook-
ware at the center of
the dened heating
zone
Is the cookware bigger
than 12cm?
Change the diameter
of cookware bigger
than 12
Is the cookware empty or
the temperature too high?
Please check whether
the appliance is being
misused
Is the air intake/exhaust
vent clogged or dirt has
accumulated
Is the cooker working
over 2 hours without any
external instruction?
Remove the stu
clogging the air intake
/exhaust vent. Operate
the appliance again
after cooling down.
Reset cooking modes
or use timer function

PHENOMENON CHEC K POINTS SOLUTION
Error Codes
Occur EO
Error Codes
Occur E1
Error Codes
Occur E2
Error Codes
Occur E3
Error Codes
Occur E4
Error Codes
Occur E5
Error Codes
Occur E6
Error Codes
Occur E7
No Cookware or
Incompatible cookware used
Low-Voltage
High-Voltage
Top Plate Overheat
Top Plate Sensor Open Circuit
IGBT Overheat
Top Plate Sensor Short Circuit
Internal Circuit Error
If error signal EOE, 3,
ES shows, please
check whether the
cookware is not
suitable or switch on
the appliance again
after it cooled down
naturally.
If error signal E1,E2,
E4, E6, E7, occurs
please contact
service center for
checking and
repairing
www.NutriChefKitchen.com 8
www.NutriChefKitchen.com
9
If the above solutions can't x the problem, unplug the appliance
immediately, contact service center for inspection and repairing, note
the error code and report it to service center ltd.
To avoid any danger and damage to the appliance, do not
disassemble or repair it by yourself.
PKSTIND52
Portable Ceramic Double Burner Induction Cooktop
with Digital Display
Features:
• Ceramic Tempered Glass Induction Cooktop
• Simple Electronic Plug-in Flameless Burner Design
• (2) Circular Top Panel Heating Zones
• Independent Congurable Temperature Zone Setting
• High-Powered Heating Elements
• Quickly Heats for Instant Food Prep
• Digital LCD Display Screens
• Sensor Touch Controls
• Countdown Timer Setting
• Stain-Resistant & Easy-to-Clean
• Compact & Space-Saving Style
• Energy Ecient: Low Power Consumption
• Safety Certied & Approved
• For Use with All of Your Steel Kitchen Cookware, Pots & Pans
Technical Specs:
• Dual Heating Element Power: 1800 Watt
• Circular Heat Zone Diameter: 5.9’’ -inches (-Each)
• Max. Timer Setting: Up to 99 minutes
• Construction Materials: Tempered Ceramic Glass, Metal Housing
• Power Cord Length: 4.9’ft
• Power: 120V
• Unit Size (L x W x H): 20.47’’ x 11.42’x 3.15’’ –inches
• Sold as: 1
