Pyle PowerSport PLUTV471AR User manual

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
4’’WaterproofRatedOff-RoadSpeakers
800 Watt Compact PowerSport Vehicle Speaker System
forATV, UTV, 4x4, Jeep with RGB Lights
and Remote Control (2 Pair)
PLUTV471AR

www.PyleUSA.com
2www.PyleUSA.com 3
PRECAUTIONS
• This unit is designed for negative ground 12-14.50 Volts (DC) operation only.
• Use speakers with an impedance of 4 Ohms
• Avoid installing the unit where:
• It would be subject to high temperatures, such as from direct sunlight or hot air
from the heater.
• It would be exposed to rain or moisture.
• It would be subject to dust or dirt.
• If your vehicle or boat is parked in direct sunlight and there is a considerable rise
in temperature inside the car, allow the unit to cool off before operation.
• When installing the unit horizontally, be sure not to cover the heatsink ns with
the oor carpet.
• If this unit is placed too close to the resources radio, an interference may occur.
In this case, separate the amplier from the car radio.
• This power amplier employs a protection circuit to protect the transistors and
speakers if the amplier malfunctions. Do not attempt to test the protection
circuits by covering the heatsink or connecting improper loads.
• Do not use the unit with a weak auto battery as its optimum performance depends
on a normal battery supply voltage.
• For safety reasons, keep the volume of your audio system moderate so that you
can still hear normal traffic sounds in a reasonable distance.
WIRING INSTRUCTIONS
POWER CONNECTION
The battery terminal (BATT ) must be connected directly to the positive terminal
of the vehicle battery to provide an adequate voltage source and minimize noise.
Connecting the battery terminal lead to any other point (such as the fuse block)
will reduce the power output and may cause noise and distortion. Use only #12
gauge or thicker (smaller gauge #) wire for this lead and connect it to the terminal
of the battery after all other wiring is completed.
GROUND CONNECTION
The ground terminal (GND) connection is also critical to the correct operation of
the amplier. Use a wire of the same gauge as the power connection (#8 or thicker)
and connect it between the ground terminal (GND) of the amplier and a metal
part of the vehicle close to the mounting location. This wire should be as short as
possible and any paint or rust at the grounding point should be scraped away to
provide a clean metal surface to which the end of the ground wire can be screwed
or bolted.
REMOTE TURN-ON CONNECTION
The amplier is turned on by applying +12V to the remote turn-on terminal (REM).
The wire lead to this terminal should be connected to the "Auto-Antenna" lead from
the vehicle/or boat stereo resources which will provide the +12V only when the
stereo resources is turned on. If the car stereo does not provide an "Auto-Antenna"
lead, the remote turn-on lead may be wired to an "Accessory" or "Radio" terminal
in the vehicle’s/or boat’s fuse block. This will turn the amplier on and off with the
ignition key, regardless of whether the stereo resources is on or off.
The remote turn-on lead does not carry large currents. So #16 gauge wire may be
used for this application.
SPEAKER CONNECTIONS
Depending on the type and number of speakers used with the amplier wire them
to the speaker terminals as per the appropriate wiring diagram. For most applications
#18 gauge wire should be used for the speaker leads but in no case thinner than
#16 gauge. For leads is excess of 10 feet #12 gauge is recommended. When wiring
the speakers, pay careful attention to the polarity of the terminals on the speakers
and make certain they correspond to the polarity of the corresponding terminals
on the amplier. Do not ground any speaker leads to the chassis of the vehicle/or
boat.
OPERATION
After the amplier has been installed and all connectios have been made carefully
and securely, turn the radio on so that the amplier is switched on automatically.
After a short power-on period, the amplier reaches its full performance.
Now turn up the volume slowly using the volume control of the radio. If there is
no sound or only a distorted replay, switch off the radio immediately - the amplier
will also switch off automatically - and check if all connections have been made
correctly.
GND (-) = GROUND CONNECTION
Connect the GND terminal to the chassis ground of your vehicle/or boat and take
care of best electric and mechanic contact. In doing so, drill a hole into the vehicle/
or boat chassis near the amplier then remove color, dirt or any other substance
from the ground point. Thereafter fasten the cable end with added ring terminal
by using a screw. Ensure that the ground connection is as short as possible and
that the cable diameter is sufficient (min 4mm). Route the ground cables from the
radio and all other equipment parts, like equalizer, active crossover network or
other ampliers, to the same ground point.

www.PyleUSA.com
4www.PyleUSA.com 5
+ 12V = POWER SUPPLY
Connect the BATT terminal to the positive pole of the battery with a lead cable and
add a fuse into the power cable in a distance of not more than 30 cm from the
battery. The lead cable’s diameter should be at least 4 mm’ for a length of 3m and
6mm” for a length of 6m.
REM (ON/OFF) REMOTE CONTROL
Connect the REM terminal to the automatic antenna connector of your vehicle/or
boat radio. Now when turning on and off your vehicle/or boat radio, the amplier
automatically switches ON and OFF. A cable diameter of 0.5mm2 is sufficient.
SPEAKERS CONNECTIONS
NOTES ON THE POWER SUPPLY
• Connect the +12V power input lead only after all other leads have been connected.
• Be sure to connect the ground wire of the unit securely to a metal part of the
vehicle/or boat.
• Loose or faulty connection may cause amplier malfunction
• REM: The unit is turned on by applying +12 Volts to this terminal. This terminal
does not draw heavy current like the tow Power Terminals so a thinner connecting
wire is acceptable. Standard 18 GAUGE is ne and the standard color is red. If the
radio is equipped with a Power Antenna control wire, it can drive this terminal.
If the Power Antenna wire is already in use, you can still splice into it. With this
method, the unit will turn ON automatically with the radio.
• Use the power supply lead with a fuse attached whose value is the same as
original fuse.
• Place the fuse in the power supply lead as close as possible to the car battery.
• During a full power operation, Maximum current will run through the system.
Therefore, make sure that the leads to be connected to the +12V and GND
terminals of the unit respectively must be larger than 18-Gauge (AWG.18) proper
Bridged operation. If only mono signal is available, a "Y" adapter is required.
FUSE REPLACEMENT
If the fuse blows, check the power connection and replace the fuse. If the fuse blows
again after replacement, there may be an internal malfunction. In this case, consult
your dealer.
WARNING
Use the specied amperage fuse. Use of a higher amperage fuse may cause
serious damage.
PROTECTION CIRCUIT
This amplier is provided with a protection circuit which operates in the
following cases when:
• the unit is overheated.
• the speaker terminals are short circuited.
HOW TO PROCEED IN CASE OF FAULTS
No Function:
• The connection cable is not connected correctly (=terminal +12V/GND/REM).
Ensure that all connections and mechanic contact and that the jacket has been
removed. The fuse is defective-pay attention to the correct value of a new fuse!

www.PyleUSA.com
6www.PyleUSA.com 7
No Sound:
• Speaker cable or speaker plug are not connected correctly.
• The plus and minus wires of the speaker cable have contact, thus eliminate the
short circuit. If you use Pay attention only 4 ohm load speaker is allowed. No 2
ohm or less impedance speaker connection is allowed.
Poor Sound Quality (Distortions):
• The speakers are overloaded, therefore turn down the volume level and check
the volume control positions.
No Stereo Sound And A Weak Bass:
• Speaker cables (+) and (-) are mixed up, unit wired out of phase.
INTERFERENCE
All cables can source and create interference. The power cable and Cinch/RCA
audio cable are very prone to interference; the remote cables are less prone.
There is often interference caused by the generator (piping), ignition (cracking)
or other vehicle/or boat electronic parts. Most of these problems can be
eliminated by correct and careful cabling. In doing so, here are the following
guidelines:
• Use only a screened audio cable for the wiring between “low level in” of the
amplier and RCA or DIN output of the radio.
• Lay the signal, speaker and power cables separately with enough distance from
one another and also from each other car cable. If not possible, you can lay the
circuit and ground cable together with the serial cables. Audio and speaker cable
should be as far away from these as possible. The REM cable to the automatic
antenna output of the radio can be laid together with the signal cables.
• Avoid ground loops by laying the ground wiring of all components to a center
point in a star-like way. you can nd the best central point in measuring the
voltage directly at the battery. Now compare this voltage value with the chosen
ground point and the (+) terminal of the amplier. If measured voltage is only
slightly different, you’ve found the correct central. Otherwise you have to look
for another point. You should measure with the ignition point for earth being
switched on and additionally switched on consumers (rear window heating and
light).
• If there are pickups from external electrical sources into the speaker cables, divide
the core leads and twist them together.
• If there are noises from the car electrics, add an interference suppression choke
into the power wiring.
• If there are humming noises, use thicker ground cables or add further ground
cables to the chassis.
• To reduce contact resistance and bad and loose contacts, please solder the cable
ends or use multi core cable ends, spade terminals or others. Gold Plated spade
terminal are free of corrosion and have the lowest contact resistance.
• Should all these meaures be without any success, the use of a ground loop
isolator may solve the problem.
PLUTV471AR Speaker Installation
Speaker Mounting suggestion as below:
Auto Reconnection:
Step 1: Unbolting the mounting bracket.
Step 2: Slide in the buckle with rubber pad attached to the bracket stand of the
speaker. Attach the set to the handle bar of vehicle/ship.
Step 3/4: Attach screw to lock the buckle.

www.PyleUSA.com
8www.PyleUSA.com 9
Remote Control Functions
• 16 static colors for choice with 8 kind of brightness which can adjust up and down.
• 3 colors ash, 4 colors strobe, 7 colors fade, 7 colors smooth, all modes can adjust
the brightness and speed.
• In static color mode, the brightness can adjust up and down.
Features:
• Pro Audio Power Sports Speakers with RGB Lights
• Pro Audio Power Sports Amplier System Kit
• 4-Channel Marine Audio Amplier
• Marine Grade Rugged Construction
• Waterproof Rated & Weather-Resistant Connectors
• Integrated Power Wiring Harness
• Perfect for Custom Installations & Applications
• Ability to Connect & Stream Audio from External Devices
• Wired AUX Audio Input
• Speaker Wiring Connectivity
• Anti-Thump Turn-On
• Soft Turn On / Off
• Pre-Amp RCA Out to Any OEM / Factory-Made Universal Mono Block/or Full
Range Amplier
• Overload & Power Protection Circuitry
• Used for Watercraft & Portable Mobile Vehicle Sound Systems
Marine Speakers Features:
• Pro Audio Power Sport Speakers
• Sound System: (4) x 4” Woofers + (4) x 0.5’’ Tweeters
• 2-Way Full Range Stereo Sound Reproduction
• Quick-Connect Spring-Loaded Speaker Terminals
• Impressive Bass Response
• Sleek Design, Machine Molded Speaker Cabinet Housing
• Rugged, Universal Mount Bracket Design for Roll-Bar / Roll-Cage
What’s in the Box:
• (4) 4'' -inch Off-Road Speakers
• Compact 4 Channel Marine Amp
• (4) 2 Meters Speaker Wire
• (4) 5.9’’ x 0.7’’ x 0.2’’ -inches Rubber Pads
• (4) 6.5’’ x 0.7’’ x 0.08’’ -inches Rubber Pads
• (16) Butt Connector
• (Red Color For A.W.G 16-22)
• (1) RGB Connection Wire, 6.6’ ft.
• (3) RGB Connection Wire, 13.2’ ft.
• (1) RGB Connection Wire, 1.15’ ft.
• Remote Control
Marine Technical Specs:
• Power Output: 800 Watt MAX
• Marine Grade Waterproof Rating: IP-X5
• Speaker Style: Passive Speakers
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x4)
• Tweeter Type: Neodymium Dome (x4)
• Frequency Response: 144Hz-20kHz
• Magnet Type: 20 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0'', Aluminum
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Universal Mounting Brackets Roll-Bar / Roll-Cage Diameter: 1.25’’ ~ 2.0’’ -inches
• Power Supply: DC 12V
• Speaker Dimensions: 5.6’’ x 8.4’’ x 7.3’’ -inches, with Bracket (-Each)

California Prop 65 Warning
WARNING:
This product contains Di (2-ethylhexyl) phthalate (DEHP) which
is known to the state of California to cause cancer birth
defects and other reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
www.PyleUSA.com
10 www.PyleUSA.com 11
Technical Specs:
• Amplier Type: 4-Ch. Audio Component
• Power Output: 1500 Watt MAX
• 4 x 45 Watts RMS @ 4 Ohm
• 4 x 150 Watts MAX @ 4 Ohm
• Marine Grade IP-65 Rating
• T.H.D: 0.1%
• S/N Ratio: > 93dB
• Channel Separation: > 50dB
• Frequency Response: 20Hz-20kHz
• Fuse: 20A
• Power: DC 12V
• Remote Control Battery Operated, Requires (1) x CR2025 Batteries (Included)
• Battery Type: 3.2V Lithium-ion 150mAh (Not Rechargeable)
• Amp Dimensions (L x W x H): 5.9’’ x 3.6’’ x 1.97’’ –inches
PLUTV471AR WIRE DIAGRAM
