Pyle PDWR30B User manual

www.PyleUSA.com
PDWR30B
• Excellent for Use On Boats/ Marine/ Decks/ Patios/ Poolside/ Outdoors
• Completely Water Proof
• 3.5'' Aluminum Injection Cone Woofer
• 40 Oz. Magnet Structure
• 1'' High Compliance Myiar Tweeter
• Capacitor Crossover Network
• Bass Reex Vent for Added Bass Response
• Heavy Duty ASB Construction
• Quick Connect/ Disconnect Speaker Terminals
• Unique Spring Loaded Mounting System
• Removable Rustproof Mesh Grills
• Power: 150Watts RMS/ 300Watts Peak
• Frequency Response: 60-20K Hz
• Impedance: 4 Ohms
• Dimensions: 4.75''(W)x 7.25''(H) x 4.75''(D)
HOW TO INSTALL
MOUNTING THE BRACKET
4. DrIII pllot holes Into the mounting surface.
5. Gently pull the speaker wire though the wire hole in the center of the mounting bracket,
so that the holes all line up.
6. Use your hardware to attach the bracket to the mounting surface.
1. Remove the bracket knobs and the bracket from the speaker.
2. Hold the bracket up to the mounting surface. "PDWR30B
Waterproof Speakers" can be mounted either horizontally
or verticalIy, hold the bracket so that the speaker wire ts
through the large, circular wire hole in the bracket, align the
bracket to be square with the surrounding (Use A level for
accuracy)
3. Mark the locations of the three shaped screw holes, use all of
the holes.
MOUNTING

www.PyleUSA.com
FINAL ADJUSTMENTS
1. After checking that the speaker is in-phase and works correctly, angle the speaker for the
best sound.
2. Hand tighten rhe bracket knobs only, power tools may over-tighten rhe knob, and strip
the threads of the insert.
3. Check that the entire installatlon is safe and secure.
CONNECTING YOUR SPEAKERS
Connecting the speakers to your amplier or receiver.
Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
3
• First turn your amplier OFF to avoid
damage which may result from accidental
shorting of the speaker leads.
• Correct phase polarity is critical for proper
stereo imaging and bass performance.
The red (+) terminal on your amplier or
receiver must be connected to the red (+)
terminal on your speaker, the same
applies for the balck (-) terminal.
• Connect one loudspeaker at a time to
ensure proper connection of left and
right channels. Make sure all wires are
rmly fastened.
• If you notice a high lavel of bass or
central image focus, double check your
connections for proper polarity.
