Brief Introduction
Please read this manual in detail before use in order to operate and
use it correctly, and bring the superior performance of the product
into full play. The descriptions in this Manual are based on the default
settings of the device; all the pictures, statements and text information
in this Manual are for reference only. Please refer to the actual product.
The content is subject to update without further notice.
The update will be included in the new version of the Manual and
the Company reserves the right of nal interpretation.
Available functions and additional services may vary by device
software or service provider. Please fully charge the Switch Controller
before use! If there are typographical errors or translation errors, we
sincerely hope for all users' understanding!
Controller Button Description
HOME Button
Mode Indicator
- Button
Screenshot
Button
Left Joystick
D-Pad
+ Button
TURBO
Button
A/B/X/Y
Button
Right
Joystick
Pair/Reset Button
Left R button
Left ZR button
Right R button
Right ZR button
USB Type-C

www.PyleUSA.com
3
Mode and Connection Instruction
Wireless BT Switch mode
1. Turn on the Switch console, click the System Settings Menu Button
on the Main Page interface and click the Airplane Mode option on
the next-level option menu, and then click the Controller Connection
(BT) to turn ON the Wireless BT function.
2. Enter the Wireless BT pairing mode of the Switch Controller, click
the Controllers menu on the Switch main page interface and then
click the Change Grip/Order on the next level option menu, the
Switch will automatically search for the paired controller.

www.PyleUSA.com
4
3. Press and hold the Y Button and then press the HOME Button for 2
seconds or press and hold the Pairing Button for 3 seconds to enter
the Wireless BT search mode, LED 1 - LED 4 running lamp ashed.
After successful connection, the Switch automatically distributes
controller channel and the corresponding channel indicator light
will always be on. Synchronous state or the Switch is pairing
connection with controller, LED 1 - LED 4 running lamp ashing.
Note:
After the controller enters the pairing mode, it will automatically
sleep if there is no synchronization within 3.5 minutes. Press and
hold the Pairing button for 3 seconds to enter the pairing mode,
short press the button to reset the controller. In case of malfunction
or crash of the controller function, press this button for short to reset
the controller.
Wireless BT Android Mode:
Press A + HOME button for 2 seconds to enter Wireless BT search
mode, LED 2 + LED 3 ash when pairing, LED 2 + LED 3 indicator light
is on after successful connection.

www.PyleUSA.com
5
2.4G D-INPUT Mode:
Press “-”+ HOME button for 2 seconds to enter 2.4G search mode,
LED 2 + LED 3 ash when pairing, LED 2 + LED 3 light is on after
successful connection.
2.4G X-INPUT Mode:
Press “+”+ HOME button for 2 seconds to enter 2.4G search mode,
LED 1 + LED 4 ash when pairing, LED 1 + LED 4 light is on after
successful connection.
2.4G Android Mode:
Press“-” + HOME button for 2 seconds to enter 2.4G search mode:
LED 2 + LED 3 ash when pairing LED 2 + LED 3 light is on after
successful connection.
2.4G PS3 Mode:
Press L + HOME button for 2 seconds to enter 2.4G search mode, four
LEDs ash at the same time, after successful connection, the Switch
automatically distributes controller channel and the corresponding
channel indicator light will always be on.
Remark: 2.4G Dongle is an optional and not standard conguration!
Re-connection Mode
Press the HOME button for 1 second to wake up the controller, and it
will automatically connect to the paired console. It will automatically
sleep if it fails to connect back for 10 seconds, it hasn't wake-up
function when press other buttons.
Charging Indication
When the controller is power o, LED 1 - LED 4 mode indicator light
ashes slowly when charging, and the fully charged LED goes out.
Battery low voltage alarm: indicator light ashes; and indicator
ashes slowly under charging condition, and the indicator light is on
when fully charged.
Automatic sleep/Power on/Power o
The Switch screen is o and the controller automatically sleeps; the
controller automatic sleep (including sensor action) if there is no
keystroke within 5 minutes.

www.PyleUSA.com
6
In Wireless BT mode, press the HOME button for 5 seconds to shut
down the controller and disconnect from the Switch. Short press the
Pairing button could to shut down the controller directly, short press
the HOME button for 1 second to turn on and wake up the controller.
Low Voltage Alarm
When the battery of the controller is lower than 3.55V±0.1V, the
current working channel light ash to indicate low battery.
If continue to use the controller until the voltage lower than 3.45 V,
the controller is automatically entered into sleep state.
USB Mode Function
Connect the controller with USB cable and insert the cable to Switch
USB port, the controller will be automatic identication as a wired
game pad, and you want open the switch cable connection function
in USB cable mode. Connect USB cable with the controller and insert
it to PC, it will be automatic identication as an X-INPUT Game pad
mode, LED 1 + LED 4 ash. On PC X-INPUT mode, long press the "-" +
"+" button for 3 seconds to switch to D-INPUT mode and LED 2 +
LED 3 indicator light ash. Connect USB cable with the controller
and insert it to PS3 console and press the L button together, it will be
automatic identication as a PS3 Game pad. Connect USB cable with
the controller and insert it into the USB port of Android device, it will
be automatically recognized as Android Game pad mode, and LED 1
+ LED 4 light will be on.
LED indication of each USB cable mode: Switch game pad is be
automatically assigned the corresponding channel indicator by the
Switch;
X-input mode: LED 1 + LED 4 indicator light on;
D-input mode: LED 2 + LED 3 indicator light on;
PS3 mode: Gamepad channel indicator allocated by PS3 console.
TURBO speed adjustment, 3 gears speed, 8Hz-12Hz-15Hz,
Default to 12Hz.
Press the TURBO button and press the corresponding button to set
TURBO; You can set A, B, X, Y, L, ZL, R, ZR; If you want to cancel the
setting, repeat the setting operation; Adjust TURBO speed:
TURBO+UP: Increase one gear speed; TURBO+DOWN: Decrease one
gear speed.

www.PyleUSA.com
7
SWITCH Motor Vibration Strength Adjustment
Press and hold the L+ZL+R+ZR button for 3 seconds for adjustment,
there are 3 levels of strength, 25%-50%-100% Default to 50% strength.
After setting, the corresponding level lamp is always on for 1 second,
and the motor vibrates for 1 second.
Six-Axis Sensor Adjustment
Press the“B” + “-”+ HOME button for power on, two sets of lights
ash each other, press again “+”button for adjustment.
Reset Function
When the controller function is abnormal or crashes, you can short
press the Pairing button to reset the controller.
Controller Reference Current
ELECTRICAL SPECIFICATIONS

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
