Qazqa Flore WL Gold Opal User manual

E14 Max.25W
220-240V~
50Hz
6
7
21.3CM
20.9CM
150CM
1
2
3
4
5
8
Flore WL Black Smoke 105466
Flore WL Gold Opal 105465

FittinQ B.V.
Smaragdweg 52, 5527 LB Hapert, The Netherlands
www.qazqa.nl
Please study the instruction manual and below information carefully before installing or using this product.
Please keep this user manual for further reference
1. The luminaires may only be installed by authorized and qualied technicians according the valid
regulations for electrical installation.
2. Maintenance of the luminaires is limited to their surfaces. During maintenance no moisture can come
into contact with any areas of the terminal connections or voltage control parts.
3. The electrical supply must be switched off at the outset, preferably by means of a switch in the distribution
box, before any installation, maintenance or repair work is undertaken.
4. Exterior lighting must not be installed during rain.
5. Take account of the minimal separation distance from other objects and the room required around the tting.
6. If in any doubt, consult a professional, taking local installation requirements into account. Some countries
stipulate that lighting may be installed only by registered installers.
7. Clamping screws in electrical connections must be adequately tightened. This is particularly the case with 12V
low voltage conductors.
8. Clean with a clean, dry cloth or brush, use no solvents or abrasives. Avoid dampness on all electrical
components
9. Take account of all available technical information.
10.Meaning of symbols:
SAFETY INSTRUCTION
III
220-240V~
50Hz
Max.ø50mm
GU10
2Max.50W
IPXX
Light Angle
35cm²
55º
0.5m
For indoor use only, where direct contact with water is impossible
Protection Class I: the tting must be earthed
Protection Class II: the tting is doubled insulated and does not require earthing
Protection Class III: the tting is low voltage
Minimum distance from lighted objects (meters)
The type of lamp and maximum size and wattage indicated in each lighting unit must not
be exceed; different items require different kind of light sources with different bulb icons
The armature is designed to work only with the indicated voltage. Different items require
different working voltage.
The luminaire can be used in combination with a dimmer
The reference light angle and light space of the luminaire
This luminaire cannot be disposed together with normal domestic waste in standard rubbish
can, but you have to bring it to a staging area for electrical waste
This icon indicates the level of water-proof and dust-proof
11.Take note of the symbols when connecting wires:
