Qdot QB-1010F User manual

KEEP THIS MANUAL FOR FUTURE NEEDS
Version 1.0
www.qdot-lighting.com
Qdot Lighting Limited
Tel: [phone]
Email: [e-mail]
Website: www.qdot-lighting.com
Sales Office Location: Room 402, Building B, Taoshang City, Nanxin Dajie,
Qiaonan Road, Panyu District, Guangzhou, China
Zip Code: 511400
Factory Location: 2nd-3rd Floor, No.288, Guangzhu East Line, Pingwen, Lanhe Town,
Nansha District, Guangzhou, China
Zip Code: 511473
Qdot Lighting Limited
QB-1010F
EYEBEAM 1010F
CAUTION !
Disconnect from mains before starting maintenance operation.
The following points have to be considered during the inspection:
<1> All screws for installing the devices or parts of the device have to be tightly
and must not be corroded.
<2> There must not be any deformations on the housing, color lenses, fixations and
installation spots (ceiling, suspension, trussing).
<3>Mechanically moved parts must not show any traces of wearing and must not rotate with
unbalances.
<4>The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
In order to make the lights in good condition and extend the life time, we suggest a regular
cleaning to the lights.
<1> Clean the inside and outside lens each week to avoid the weakneness of the lights due
to accumulation of dust.
<2> Clean the fan each week.
<3> A detailed electric check by approved electrical engineer each three month, make sure
that the circuit contacts are in good condition, prevent the poor contact of circuit from
overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth.
Never use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under
“Installation instructions”.
Should you need any spare parts, please order genuine parts from your local dealer.
connected
10. MAINTENANCE AND CLEANING

.01.
CAUTION !
Becareful with your operations.With a dangerous voltage you cansuffer a
dangerous electric shock when touching wires!
IMPORTA N T !
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems.
This device has left the factory in perfect condition. In order to maintain this condition and
to ensure a safe operation, it is absolutely necessary for the user to follow the safety
instructions and warning notes written in this user manual.
01. SAFETY INSTRUCTIONS
If the device has been exposed to temperature changes due to environmental changes,
do not switch it on immediately. The arising condensation could damage the device.
Leave the device switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be
earthed.
The electric connection must carry out by qualified person.
The device shall only be used with rate voltage and frequency.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would be
the case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Only handle the power cord by the plug. Never pull out the plug by tugging the power cord.
During initial start-up some smoke or smell may arise. This is a normal process and does
not necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm distance
with wall for smooth air flow, so there should be no shelter for fans and ventilation for heat
radiation.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in order to
avoid a hazard.
.10.
Green in pixel 7 saturation control(0-100%)
Blue in pixel 7 saturation control(0-100%)
White in pixel 7 saturation control(0-100%)
Red in pixel 8 saturation control (0-100%)
Green in pixel 8 saturation control(0-100%)
Blue in pixel 8 saturation control(0-100%)
White in pixel 8 saturation control(0-100%)
Red in pixel 9 saturation control (0-100%)
Green in pixel 9 saturation control(0-100%)
Blue in pixel 9 saturation control(0-100%)
White in pixel 9 saturation control(0-100%)
Red in pixel 10 saturation control (0-100%)
Green in pixel 10 saturation control(0-100%)
Blue in pixel 10saturation control(0-100%)
White in pixel 10 saturation control(0-100%)
No function
Marcro 1 from slow to fast
Marcro 2 from slow to fast
Marcro 3 from slow to fast
Marcro 4 from slow to fast
Marcro 5 from slow to fast
Marcro 6 from slow to fast
Marcro 7 from slow to fast
Marcro 8 from slow to fast
Marcro 9 from slow to fast
Marcro 10 from slow to fast
Marcro 11 from slow to fast
Marcro 12 from slow to fast
No function
No function
No function
No function
Motor reset
Internal program 1
No Function
Fixture ID 1
Fixture ID 2
Fixture ID 3
Fixture ID 4
Fixture ID 5
Fixture ID 6
Fixture ID 7
Fixture ID 8
Fixture ID 9
Fixture ID 10
Fixture ID 11
Fixture ID 12
Fixture ID 13
Fixture ID 14
Fixture ID 15
Fixture ID 16
Fixture ID 17
Fixture ID 18
Fixture ID 19
Fixture ID 20
Fixture ID 21
Fixture ID 22
Fixture ID 23
Fixture ID 24
Fixture ID 25
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-15
16-35
36-55
56-75
76-95
96-115
116-135
136-155
156-175
176-195
196-215
216-235
236-255
0-19
20-29
30-39
40-79
80-99
100-255
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-209
210-219
220-229
230-239
240-249
250-255
Green in pixel 7
Blue in pixel 7
White in pixel 7
Red in Pixel 8
Green in pixel 8
Blue in pixel 8
White in pixel 8
Red in Pixel 9
Green in pixel 9
Blue in pixel 9
White in pixel 9
Red in Pixel 10
Green in pixel 10
Blue in pixel10
White in pixel 10
Pixel Macro
Special function
Fixture
ID
Address
Selection
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
.
55
13
14
15

.02.
Thank you for choosing our EYEBEAM 1010F. For your own safety, please read this
manual before installing the device. This manual covers the important information on
installation and applications. Please install and operate the fixture with following
instructions. Meanwhile, please keep this manual well for future needs.
The EYEBEAM 1010F is made of a new type of high temperature strength of engineering
plastics and cast aluminum casing with nice outlook. The fixture is designed and
manufactured strictly following CE standards, complying with international standard
DMX512 protocol. It’s available independently controlled and linkable with each other for
operation. And it is applicable for large-scale live performances, theater, studio,
nightclubs and discos.
The EYEBEAM 1010F adopts 10PCS CREE XLamp XML 4-IN-1 10W LEDs which
features high brightness and stability. Please carefully unpack it when you receive the
fixture and check whether it is damaged during the transportation. And please check
whether the following items are included inside the box:
Euro Standard UK StandardUSA Standard
02. UNPACKING
●Power Connector OPTIONAL *1
● *1 Moving Head
● *1 Signal Cable
● *2 Omega Clamp
● *1 Safety Cable
● *1 User Manual
.09.
09. DMX CHANNELS
