Qilive Q.6248 User manual

FR Lave-linge top 6,5 kg
Top loading washing machine
6.5 Kg
Q.6248

EN
User manual P. 4
Manuel d’utilisation P. 30
FR

EN
FR

4
EN
1. SAFETY INSTRUCTIONS
Before using this electrical appliance, read the instructions
below carefully and keep them for future reference:
1. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
2. Before plugging the appliance into a wall socket,
check that the local electric current corresponds to
the current specied on the rating plate a󰀩xed to
the appliance. Always plug your appliance into an
earthed wall socket.
3. Unplug the mains cable from the mains when you are
not using the appliance and before performing any
cleaning or maintenance work.
4. Use the new hose sets supplied with the appliance.
Do not reuse old hose sets.
5. Always unplug the machine and turn o󰀨 the water
supply after use.
6. Ensure that the water pressure of your water supply
is between the stated min. inlet water pressure and
the max. inlet water pressure.
7. For your safety, the power plug must be inserted into
an earthed three-pole socket. Make sure that your
socket is properly and reliably earthed.
8. The water connections and electrical cables must be
connected by a qualied technician in accordance
with the manufacturer’s instructions and local safety
regulations.
9. Child safety hazard!
10. This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe

5
EN
way and understand the hazards involved. Cleaning
and user maintenance shall not be made by children
without supervision.
11. Children of less than 3 years should be kept away
unless continuously supervised. Children shall not
play with the appliance.
12. Pets and children may climb into the machine. Check
the machine carefully before use.
13. The glass door may get very hot during use. Keep
children and pets away from the machine during use.
14. Risk of su󰀨ocation! Keep all packaging materials out
of the reach of children and babies!
15. Make sure that you can reach the mains plug of the
appliance after installation.
16. Risk of explosion!
17. Do not wash or dry items that have been dabbed
with or cleaned, washed or soaked in combustible
or explosive substances (such as wax, oil, paint,
gasoline, degreasers, dry-cleaning solvents and
kerosene) This may cause a re or explosion.
18. The maximum mass of dry clothes to be washed in
the appliance is 6.5kg.
Installation
1. The appliance is for indoor use only.
2. This appliance is not designed for built in.
3. The venting openings must not be obstructed by
carpet.
4. The washing machine must not be installed in
bathrooms or very wet rooms or rooms containing
explosive or caustic gases.
5. Models with a single inlet valve should be connected
to the cold water supply. Models with double inlet
values should be correctly connected to the hot water
and cold water supply.
6. The mains plug must be accessible after installation.

6
EN
7. To prevent damage to the product, remove all
packaging and transport bolts before use.
8. This product is for home use only and is only designed
for machine-washable textiles.
9. This appliance is intended to be used in household
and similar applications such as:
– sta󰀨 kitchen areas in shops, o󰀩ces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– areas for communal use in blocks of ats.
10. Do not lean against the machine door.
11. Handling precautions:
12. Transport bolts must be reinstalled by a technician.
13. Accumulated water must be drained out of the
machine.
14. Handle the machine carefully. Never hold any
protruding parts of the machine while lifting. Do not
use the machine door as a handle when moving the
appliance.
15. This appliance is heavy. Exercise care during
transport.
16. Do not close the door with excessive force. If it is
di󰀩cult to close the door, check if the clothes are fully
inserted into the drum and evenly distributed.
17. Do not use the machine to wash carpets.
18. The washing machine must be calibrated before use.
19. Before washing clothes for the rst time, the washing
machine should be run for one full cycle with no
clothes inside.
20. Do not place ammable, explosive or toxic solvents
into the machine (e.g. gasoline or alcohol) or use

7
EN
them as detergents. Only use detergents which are
suitable for machine washing.
21. Make sure that all pockets are emptied. Sharp and
rigid items such as coins, jewelry, nails, screws or
stones may cause serious damage to the machine.
22. Check whether the water inside the drum has been
drained before opening the door. Do not open the
door if there is any water visible.
23. Take care not to burn yourself when the product is
draining hot water.
24. Never rell the water by hand during washing.
25. Adequate ventilation must be provided to prevent the
ow of gases into the room from appliances burning
other fuels (including open res).
26. Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount
of detergent before being dried in the appliance.
27. Items such as foam rubber (latex foam), shower
caps, waterproof textiles, rubber backed articles and
clothes or pillows with foam rubber pads should not
be dried in the machine.
28. Fabric softeners or similar products should be used
as specied in the instructions.
29. The door of the appliance can be opened during the
cycle, after the drum has emptied the water from the
machine. This takes approximately 15 seconds.
30. Before using the appliance, remove all objects from
pockets such as lighters and matches.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the

8
EN
sustainable reuse of material resources. To return
your used device, please use the collection systems
or contact the retailer where the product was
purchased. They return and can take this product for
environmental safe recycling.
2. TECHNICAL DATA
2.1. TECHNICAL SPECIFICATIONS
Power supply 220-240 V~,50 Hz
Rated power 2100 W
Max. current 10 A
Standard water pressure 0.1~1 Mp
Model
600126045
Washing capacity 6.5 kg
Dimensions (W x D x H in mm) 400 × 610× 875
Net weight 56 Kg
2.2. PRODUCT FICHE
Energy test program: Intensive 60/40°C. Speed: Maximum speed; Other specications
as default.
Supplier’s name or trade mark:Auchan
Supplier’s address (b): SAS OIA, 200, rue de la Recherche, Le Colibri BP 169, 59650
Villeneuve d’Ascq, France
Model identier: 600126045
General product parameters:
Parameter Value Parameter Value
Rated capacity (a)
(kg) 6.5 Dimensions in cm
Height 88
Width 40
Depth 61
EEIW (a) 80.0 Energy e󰀩ciency class (a) D
Washing
e󰀩ciency index (a)1.031 Rinsing e󰀨ectiveness (g/
kg) (a)5.0

9
EN
Energy
consumption
in kWh per
cycle, based on
the eco 40-60
programme.
Actual energy
consumption will
depend on how
the appliance is
used.
0.669
Water consumption in litres
per cycle, based on the
eco 40-60 programme.
Actual water consumption
will depend on how the
appliance is used and on
the hardness of the water.
44
Maximum
temperature
inside the treated
textile (°C)
Rated
capacity 36
Remaining moisture
content 0 (%) 62.9
Half 29
Quarter 23
Spin speed ft
(rpm)
Rated
capacity 1200
Spin-drying e󰀩ciency class
(a)C
Half 1200
Quarter 1200
Programme
duration O (h:min)
Rated
capacity 3:23
Type Free-standing
Half 2:39
Quarter 2:39
Airborne
acoustical noise
emissions in the
spinning phase
(a) (dB(A) re 1
pW)
80 Airborne acoustical noise emission class (a)
(spinning phase) C
O󰀨-mode (W) 0.50 Standby mode (W) 1.00
Delay start (W) (if
applicable) 4.00 Networked standby (W) (if applicable) N/A
Minimum duration of the guarantee o󰀨ered by the supplier (b).
This product has been designed to
release silver ions during the washing
cycle No

10
EN
Additional information:
1) The actual energy consumption will depend on how the appliance is used.
2) The actual water consumption will depend on how the appliance is used and on
the hardness of the water.
3) Product Data Sheet concerning (EU) 2019/2014
The product data sheet for your appliance can be found online.
Go to https://eprel.ec.europe.eu and enter the model identier for your appliance to
download the data sheet.
The model identier for your appliance can be found in the technical specications
section.
3. INSTALLATION
3.1. INSTALLATION AREA
Warning!
■Stability is important to prevent the product from
wandering!
■Make sure that the product should not stand on the power
cord.
20mm
w
w
W>
Before installing the machine, the location characterized as
follows shall be selected:
1. Rigid, dry, and level surface
2. Avoid direct sunlight
3. Su󰀩cient ventilation
4. Room temperature is above 0°C
5. Keep far away from the heat resources such as coal or
gas.
3.2. UNPACKING THE WASHING MACHINE
Warning!
■ Packaging material (e.g. Films, Styrofoam) can
bedangerous for children.
■ There is a risk of su󰀨ocation ! Keep all packaging well
away from children.
1. Remove the cardboard box and polystyrene foam.
2. Lift the washing machine and remove the base packing.
Make sure the small triangle foam is removed with the
bottom piece together. If not, lay the unit down on its side,
and then remove the small piece of foam from the bottom
of the unit.
3. Remove the tape securing the power supply cord and drain
hose.
4. Remove the inlet hose from the drum.

11
EN
3.2.1. REMOVE THE TRANSPORT BOLTS
Warning!
■You must remove the transport bolts from the backside
before using the product
■You’ll need the transport bolts again if you move the
product, so make sure you keep them in a safe place.
Please take the following steps to remove the bolts:
1. Loosen 4 bolts with spanner and then remove them.
2. Stop the holes with transport hole plugs.
3. Keep the transport bolts properly for future use.
Warning!
■You must remove the transport bolts from the backside
before using the product.
Loosen the 4 transport
bolts with a spanner.n
Remove the bolts
including the rubber parts
and keep them for future
use.
Close the holes using the
cover caps.
3.3. LEVELLING THE WASHING MACHINE
Warning!
■The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are securely attached to the
housing. If not, turn them to their original positions
and tighten the nuts.
2. Loosen the lock nut and turn the foot until it is in
close contact with the oor.
3. Adjust the legs and lock them with a spanner,
making sure that the machine is steady.
3.4. CONNECTING THE WASHING MACHINE
3.4.1. CONNECTING THE WATER SUPPLY HOSE
Warning!
■ To prevent leakage or water damage, follow the instructions in this chapter!
■Do not kink, crush or modify water inlet hose.
■Connect manually, do not use tools. Check if the connections are tight.

12
EN
Connect the water supply hose to the water inlet valve and a water tap with cold water
as indicated.
3.4.2. DRAIN HOSE
Warning!
■Do not bend or stretch the drain hose.
■Position the drain hose properly, otherwise damage may be caused due to water
leakage.
There are two ways to position the end of the drain hose:
1. Put it into the water trough. 2. Connect it to the branch drain pipe of
the trough.
Water
trough
Noted !
■If the machine has drain hose support, please install it like the following.
Trough
Hose Retainer
Min.60cm
Max.100cm
Max.100cm
Min.60cm
Bind
Warning!
■ When installing drain hose, x it properly with a rope.
■If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.

13
EN
4. USE
4.1. QUICK START
Caution!
■Before washing, please make sure the washing machine is installed properly.
■Your appliance was thoroughly checked before it left the factory. To remove any
residual water and to neutralize potential odors, it’s recommended to clean your
appliance before rst use. For this reason, start the Cotton program at 90°C
without laundry and detergent.
4.1.1. BEFORE WASHING
earth
terminal
ewash Sot ne Ma n wash 6
1.Plug in 2.Open tap 3.Load 4.Add
detergent 5.Close drum door
6.Close
machine
door
Note!
• Detergent need to be added in “case I “after selecting pre-washing for machines
with this function.
• Make sure that the drum aps are properly locked.
• All metal hooks must be properly hooked inside the rear door ap.
• Check the roller before each laundry ,it must roll smoothly

14
EN
4.1.2. WASHING
1.Power On 2.Select Programme 3.Select function or
default 4.Start
Note!
• If default is selected, step 2 can be skipped.
4.1.3. AFTER WASHING
All lights o󰀨.
4.2. BEFORE EACH WASHING
■The ambient temperature of the washing machine should be 5-40°C. If used under 0°C, the
inlet valve and draining system may be damaged. If the machine is installed under freezing
conditions, it should be transferred to normal ambient temperature to ensure the water
supply hose and drain hose can unfreeze before use.
■Please check your laundry care labels and the detergent use instructions before wash. Use
non-foaming or less-foaming detergent suitable for machine washing properly.
1. Check the carelabel 2. Sort laundry according
to color and textile type
3. Take all items out of the
pockets
4. Tie together long textile
strips and belts, close zips
and button
5. Put small items into a
laundry bag
6. Turn easy-pilling and
long-pile fabric inside out
Warning!
■Do not wash or dry articles that have been cleaned in, washed in, soaked in, or
dabbed with combustible or explosive substances like wax, oil, paint, gasoline,
alcohol, kerosene, and other ammable materials.
■Washing single clothes items may easily create big eccentricity and cause alarm
due to unbalance. Therefore it is suggested to add one or two more laundry items
to the wash so that spin can be done smoothly.

15
EN
4.3. DETERGENT DISPENSER
Prewash Softener Main wash
Caution!
■Detergent only need to be added in “case I “after selecting pre-washing for
machines with this function.
■ Do not exceed the “MAX”level mark when lling in detergent,additives or softener.
Programme Programme
Cotton Spin Only
Synthetic Rinse & Spin
Mix Wool
Jeans Delicate
Sportswear Rapid 45’
Baby Care Quick 15’
Drum Clean ECO 40-60
20°C Intensive
Means must ○ Means optional
4.4. DETERGENT RECOMMENDATION
Recommended washing
detergent Wash cycles Washing temp Type of laundry and textile
Heavy-duty detergent
with bleaching
agents and optical
brighteners
Cotton, ECO 40-60,
Mix 20/40/60
White laundry
made from boil-
proof cotton or
linen
Colour detergent
without bleaching
agent and optical
brighteners
Cotton, ECO 40-60,
Mix Cold/20/40 Coloured laundry
made from cotton
or linen

16
EN
Recommended washing
detergent Wash cycles Washing temp Type of laundry and textile
Color or mild
detergent without
optical brighteners Synthetic Cold/20/40
Coloured laundry
made from easy
care bres or
synthetic materials
Mild washing
detergent Synthetic 20/40 Delicate textiles, silk, viscose
Special wool
detergent Wool 20/40 Wool
Note!
■Agglomerating or ropy detergent or additive can be diluted in some water before
pouring it into the detergent dispenser, to avoid its inlet to get blocked and thus
cause a water overow.
■ Please choose the suitable type of detergent to get a maximum of washing
performance and a minimum of water and energy consumption
■To achieve the best cleaning result a proper detergent dosing is important.
■ Use a reduced detergent amount if the drum is not lled completely.
■Always adjust the amount of detergent to the water hardness, if your tap water is
soft, use less detergent.
■Dose according to how dirty your laundry is, less dirty clothes require less
detergent.
■ Highly concentrated (compact detergent) requires particularly accurate dosing.
Following symptoms are a sign of detergent overdosing:
- heavy foam formation
- poor washing and rinsing result
Following symptoms are a sign of detergent underdosing:
- laundry turns grey
- built-up of limescale deposits on the drum, the heating element and/or the laundry

17
EN
5. PRODUCT DESCRIPTION
1
2
3
4
5
7
6
5.1. FRONT VIEW
The product diagram is for reference only and may di󰀨er from the actual product.
1. Power supply cord
2. Control panel
3. Drain hose
4. Door
5. Detergent dispenser
6. Drum
7. Service lter
5.2. ACCESSORIES
1. Transport hole plug
2. Supply hose (cold water) 3. Owner’s manual

18
EN
53 2
41
5.3. CONTROL PANEL
1. Power: Product is on/o󰀨
2. Start/Pause: Press the button to start or pause the washing cycle.
3. Option: This allows you to select an additional function and will light when selected.
4. Programmes: Available according to the laundry type.
5. Display: The display shows the settings, options, and status messages for your
washer. The display will remain on through the cycle.
5.4. DISPLAY
A
B D
C
A. Door Lock
B. Child Lock
C. Pre Wash
D. Extra Rinse

19
EN
6. PROGRAMMES
Washing Programmes Table
Programme Load(kg) Display Time
6.5 6.5
Cotton 6.5 2:40
Quick 15’ 2.0 0:15
Rapid 45’ 2.0 0:45
ECO 40-60 6.5 3:21
Intensive 6.5 3:48
20°C 3.25 1:01
Rinse & Spin 6.5 0:20
Spin Only 6.5 0:12
Drum Clean - 1:18
Baby Care 6.5 1:42
Sportswear 3.25 1:31
Jeans 6.5 1:45
Wool 2.0 1:07
Delicate 2.0 0:49
Synthetic 3.25 2:20
Mix 6.5 1:37
Note!
■The parameters in this table are for the user’s reference only. The actual
parameters may be di󰀨erent from the parameters in the table.
Cycle Nominal capacity
in kg
Temperature
setting
Cycle duration
in hours and
minutes
Energy
consumption in
KWh/operating
cycle
Water consumption
in mi ter// operating
cycle
Highest
temperature °C Residual moisture in %/ spin speed
Quick 15’ 2.0 cold 0:15 0.035 32 cold 70%/800
20°C 3.3 20 1:01 0.210 40 20 65%/1000
Cotton (60°C) 6.5 60 2:45 1.368 61 60 60%/1200
Sterilization 6.5
40 3:48 1.059 61 40 70%/800
Mix 6.5
40 1:37 0.753 61 40 70%/800
ECO 40-60
6.5 - 3:23 0.945 55.2 36 62%/1200
3.25 - 2:39 0.549 39.3 29 62%/1200
1.5 - 2:39 0.355 36.5 23 62%/1200
■ The above data is for reference only, and the data may change due to di󰀨erent
actual use conditions.
■The valves given for programmes other than the ECO 40-60 programme are
indicative only.

20
EN
■ Concerning to EN 60456:2016/prA2019 With (EU)2019/2014, (EU)2019/2023,
The EU energy e󰀩ciency class is: D
Energy test program: ECO 40-60. Other as the default.
Half load for 6.5Kg machine:3.25Kg.
Quarter load for 6.5Kg machine:1.5Kg.
1) The highest temperature reached by the laundry in the wash cycle for at least
5 minutes.
2) Residual moisture after the wash cycle in water content percent and the spin
speed at which this was achieved.
3) The ECO 40-60 programme is able to clean normally soiled cotton laundry
declared to be washable at 40°C or 60°C, together in the same cycle. This
programme is used to assess the compliance with the regulation (EU) 2019/2023.
The most e󰀩cient programmes in terms of energy consumption are generally those
that perform at lower temperatures and longer duration.
Loading the household washing machine up to the capacity indicated for the respective
programmes will contribute to energy and water savings.
Noise and remaining moisture content are inuenced by the spinning speed: the higher
the spinning speed in the spinning phase, the higher the noise and the lower the
remaining moisture content.
Caution!
■If there is any break in the power supply while the machine is operating, a
special memory stores the selected programme. The machine will continue the
programme when the power supply is re-established.
Programmes are available according to the laundry type.
Programmes
Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen.
Synthetic
Wash synthetic articles, for example: shirts, coats, blending.
While washing the knitting textiles, detergent quantity shall be
reduced due to its loose string construction and easily forming
bubbles.
Baby Care Washing the baby’s clothes, it can make the baby’s wear cleaner
and make the rinse performance better to protect the baby skin.
Rapid 45’ Washing few and not very dirty clothes quickly.
Mix Mixed load consisting of textiles made of cotton and synthetics
Sportswear Washing the activewear.
Jeans Specially for jeans.
Quick 15’ Extra short programme approx, suitable for lightly soiled washing as
a small amounts of laundry.
Delicate For delicate, washable textiles, e.g. made of silk, satin, synthetic
bres or blended fabrics.
Wool Hand or machine-washable wool or richwool textiles.Especially gentle wash programme to prevent shrinkage, longer programme
pauses (textiles rest in wash liquor).
Spin Only Extra spin with selectable spin speed.
Rinse&Spin Extra rinse with spin.
