Qilive Q.6641 User manual

PL Pralka WIFI ładowana od przodu 9 kg
Front Wifi washing machine 9 Kg
Q.6641

EN
User manual P. 4
Instrukcja użytkownika P. 33
PL

EN
1
2
8
3
4
5
6
9
10
11
12
7
4
AKBCDE
FGHIJ
5321
PL

4
EN
1. SAFETY INSTRUCTIONS
Before using this electrical appliance, read the instructions
below carefully and keep them for future reference:
1. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
2. Before plugging the appliance into a wall socket,
check that the local electric current corresponds to
the current specied on the rating plate a󰀩xed to
the appliance. Always plug your appliance into an
earthed wall socket.
3. Unplug the mains cable from the mains when you are
not using the appliance and before performing any
cleaning or maintenance work.
4. Use the new hose sets supplied with the appliance.
Do not reuse old hose sets.
5. Always unplug the machine and turn o󰀨 the water
supply after use.
6. Ensure that the water pressure of your water supply
is between the stated min. inlet water pressure and
the max. inlet water pressure.
7. For your safety, the power plug must be inserted into
an earthed three-pole socket. Make sure that your
socket is properly and reliably earthed.
8. The water connections and electrical cables must be
connected by a qualied technician in accordance
with the manufacturer’s instructions and local safety
regulations.
9. Child safety hazard!
10. This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or

5
EN
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Cleaning
and user maintenance shall not be made by children
without supervision.
11. Children of less than 3 years should be kept away
unless continuously supervised. Children shall not
play with the appliance.
12. Pets and children may climb into the machine. Check
the machine carefully before use.
13. The glass door may get very hot during use. Keep
children and pets away from the machine during use.
14. Risk of su󰀨ocation! Keep all packaging materials out
of the reach of children and babies!
15. Make sure that you can reach the mains plug of the
appliance after installation.
16. Risk of explosion!
17. Do not wash or dry items that have been dabbed
with or cleaned, washed or soaked in combustible
or explosive substances (such as wax, oil, paint,
gasoline, degreasers, dry-cleaning solvents and
kerosene) This may cause a re or explosion.
18. The maximum mass of dry clothes to be washed in
the appliance is 9.0 kg.
Installation
1. The appliance is for indoor use only.
2. This appliance is not designed for built in.
3. The venting openings must not be obstructed by
carpet.
4. The washing machine must not be installed in
bathrooms or very wet rooms or rooms containing
explosive or caustic gases.
5. Models with a single inlet valve should be connected
to the cold water supply. Models with double inlet
values should be correctly connected to the hot water
and cold water supply.

6
EN
6. The mains plug must be accessible after installation.
7. To prevent damage to the product, remove all
packaging and transport bolts before use.
8. This product is for home use only and is only designed
for machine-washable textiles.
9. This appliance is intended to be used in household
and similar applications such as:
– sta󰀨 kitchen areas in shops, o󰀩ces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– areas for communal use in blocks of ats.
10. Do not lean against the machine door.
11. Handling precautions:
12. Transport bolts must be reinstalled by a technician.
13. Accumulated water must be drained out of the
machine.
14. Handle the machine carefully. Never hold any
protruding parts of the machine while lifting. Do not
use the machine door as a handle when moving the
appliance.
15. This appliance is heavy. Exercise care during
transport.
16. Do not close the door with excessive force. If it is
di󰀩cult to close the door, check if the clothes are fully
inserted into the drum and evenly distributed.
17. Do not use the machine to wash carpets.
18. The washing machine must be calibrated before use.
19. Before washing clothes for the rst time, the washing
machine should be run for one full cycle with no
clothes inside.
20. Do not place ammable, explosive or toxic solvents
into the machine (e.g. gasoline or alcohol) or use

7
EN
them as detergents. Only use detergents which are
suitable for machine washing.
21. Make sure that all pockets are emptied. Sharp and
rigid items such as coins, jewelry, nails, screws or
stones may cause serious damage to the machine.
22. Check whether the water inside the drum has been
drained before opening the door. Do not open the
door if there is any water visible.
23. Take care not to burn yourself when the product is
draining hot water.
24. Never rell the water by hand during washing.
25. Adequate ventilation must be provided to prevent the
ow of gases into the room from appliances burning
other fuels (including open res).
26. Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount
of detergent before being dried in the appliance.
27. Items such as foam rubber (latex foam), shower
caps, waterproof textiles, rubber backed articles and
clothes or pillows with foam rubber pads should not
be dried in the machine.
28. Fabric softeners or similar products should be used
as specied in the instructions.
29. The door of the appliance can be opened during the
cycle, after the drum has emptied the water from the
machine. This takes approximately 15 seconds.
30. Before using the appliance, remove all objects from
pockets such as lighters and matches.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the

8
EN
sustainable reuse of material resources. To return
your used device, please use the collection systems
or contact the retailer where the product was
purchased. They return and can take this product for
environmental safe recycling.
2. TECHNICAL DATA
2.1. TECHNICAL SPECIFICATIONS
Power supply 220-240 V~,50 Hz
Rated power 1950 W 1950 W
Max. current 10 A 10 A
Standard water pressure
0.05 MPa~1 MPa 0.05 MPa~1 MPa
Model
600082841
Washing capacity 9.0 kg 9.0 kg
Dimensions (W x D x H in mm) 594 x 585 x 845
Net weight 65 kg 65 kg
2.2. PRODUCT FICHE
Energy test program: Intensive 60/40°C. Speed: Maximum speed; Other specications
as default.
Supplier’s name or trade mark:Auchan
Supplier’s address (b): SAS OIA, 200, rue de la Recherche, Le Colibri BP 169, 59650
Villeneuve d’Ascq, France
Model identier: 600082841
General product parameters:
Parameter Value Parameter Value
Rated capacity (a)
(kg) 9.0 Dimensions in cm
Height 85
Width 59
Depth 59
EEIW (a)60.0 Energy e󰀩ciency class (a)B
Washing
e󰀩ciency index (a)1.031 Rinsing e󰀨ectiveness (g/
kg) (a)5.0

9
EN
Energy
consumption
in kWh per
cycle, based on
the eco 40-60
programme.
Actual energy
consumption will
depend on how
the appliance is
used.
0.571
Water consumption in litres
per cycle, based on the
eco 40-60 programme.
Actual water consumption
will depend on how the
appliance is used and on
the hardness of the water.
50
Maximum
temperature
inside the treated
textile (°C)
Rated
capacity 37
Remaining moisture
content 0 (%) 53.9Half 34
Quarter 22
Spin speed ft
(rpm)
Rated
capacity 1400
Spin-drying e󰀩ciency class
(a)BHalf 1400
Quarter 1400
Programme
duration O (h:min)
Rated
capacity 3:48
Type Free-standingHalf 2:54
Quarter 2:54
Airborne
acoustical noise
emissions in the
spinning phase
(a) (dB(A) re 1
pW)
76
Airborne acoustical
noise emission class (a)
(spinning phase) B
O󰀨-mode (W) 0.50 Standby mode (W) N/A
Delay start (W) (if
applicable) 4.00 Networked standby (W) (if applicable) 2.0
Minimum duration of the guarantee o󰀨ered by the supplier (b).
This product has been designed to
release silver ions during the washing
cycle No

10
EN
Additional information:
Weblink to the supplier’s website, where the information in point 9 of Annex II to
Commission Regulation (EU) 2019/2023 (1) is found:
(b) for the eco 40-60 programme.
(c) changes to these items shall not be considered relevant for the purposes of
paragraph 4 of Article 4 of Regulation (EU) 2017/1369.
(d) if the product database automatically generates the denitive content of this cell,
the supplier shall not enter these data.
3. INSTALLATION
3.1. INSTALLATION AREA
Warning!
■ Stability is important to prevent the product from
wandering! Make sure the machine is standing leveled and
stable.
■ Make sure that the product does not stand onto the power
cord.
■ Make sure to maintain the minimum distances from the
walls as shown in the picture.
Before installing the machine, follow the steps below to select a
suitable location:
1. Rigid, dry, and level surface
2. Avoid direct sunlight
3. Su󰀩cient ventilation
4. Room temperature is above 0°C
5. Keep far away from the heat sources such as coal or gas
burning appliances.
3.2. UNPACKING THE WASHING MACHINE
Warning!
■ Packaging material (e.g. lm, polystyrene foam) can be
dangerous for children.
■ Risk of su󰀨ocation! Keep all packaging materials out of the
reach of children.
1. Remove the cardboard box and polystyrene foam.
2. Lift the washing machine and remove the base packing.
Make sure the small triangle foam is removed with the
bottom piece together. If not, lay the unit down on its side,
and then remove the small piece of foam from the bottom
of the unit.
3. Remove the tape securing the power supply cord and drain
hose.
4. Remove the inlet hose from the drum.

11
EN
3.2.1. REMOVE THE TRANSPORT BOLTS
Warning!
■ You must remove the transport bolts from the backside
before using the product
Follow the steps below to remove the bolts:
1. Loosen the 4 transport bolts with a spanner.
2. Remove the bolts including the rubber parts and keep them
for future use.
3. Close the holes using the cover caps..
3.3. LEVELLING THE WASHING MACHINE
Warning!
■ The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are securely attached to the
housing. If not, turn them to their original positions
and tighten the nuts.
2. Loosen the lock nut and turn the foot until it is in
close contact with the oor.
3. Adjust the legs and lock them with a spanner,
making sure that the machine is steady.
3.4. CONNECTING THE WASHING MACHINE
3.4.1. CONNECTING THE WATER SUPPLY HOSE
Warning!
■ To prevent leakage or water damage, follow the instructions in this chapter!
■ Do not kink, crush or modify water inlet hose.
■ Connect manually, do not use tools. Check if the connections are tight.
Connect the water supply hose to the water inlet valve and a water tap with cold water
as indicated.
3.4.2. DRAIN HOSE
Warning!
■ Do not bend or stretch the drain hose.
■ Position the drain hose properly, otherwise damage may be caused due to water
leakage.
There are two ways to position the end of the drain hose:
1. Put it into the water trough 2. Connect it to the branch drain pipe of
the trough..

12
EN
Water
trough
4. USE
4.1. QUICK START
Caution!
■ Before washing, please make sure the washing machine is installed properly.
■ Your appliance was thoroughly checked before it left the factory. To remove any
residual water and to neutralize potential odors, it’s recommended to clean your
appliance before rst use. For this reason, start the Cotton program at 90°C
without laundry and detergent.
Calibration
It’s recommended to calibrate the washing machine, so that provide the best
performance.
The appliance is able to detect the amount of laundry loaded. This function is
optimizing the product performance by minimizing energy and water consumption,
saving you money and time. For this reason it’s recommended to calibrate the
appliance for best use.
1. Remove all accessories from the drum and close the door
2. Insert the mains plug to the socket;
3. Switch on the washing machine and press “Delay” and “Spin”
simultaneously for 10 seconds until “t19” is displayed;
4. Press [ ] to start the appliance and wait till “****” is displayed
4.1.1. BEFORE WASHING
1.Plug in 2.Open tap 3.Load 4.Close door 5.Add detergent
Note: Detergent only needs to be added in “compartment I” if you have selected the
pre-washing function (not available on all machines).
4.1.2. WASHING

13
EN
1.Power On 2.Select Programme 3.Select function or
default 4.Start
4.1.3. AFTER WASHING
Buzzer beep and “End” on display.
4.2. BEFORE EACH WASHING
■ The ambient temperature of the washing machine should be 5-40°C. If used under 0°C, the
inlet valve and draining system may be damaged. If the machine is installed under freezing
conditions, it should be transferred to normal ambient temperature to ensure the water
supply hose and drain hose can unfreeze before use.
■ Please check your laundry care labels and the detergent use instructions before wash. Use
non-foaming or less-foaming detergent suitable for machine washing properly.
1. Check the carelabel 2. Sort laundry according
to color and textile type 3.
Take all items out of the
pockets
4. Tie together long textile
strips and belts, close zips
and button
5. Put small items into a
laundry bag
6. Turn easy-pilling and
long-pile fabric inside out
Warning!
■ Do not wash or dry articles that have been cleaned in, washed in, soaked in, or
dabbed with combustible or explosive substances like wax, oil, paint, gasoline,
alcohol, kerosene, and other ammable materials.
■ Washing single clothes items may easily create big eccentricity and cause alarm
due to unbalance. Therefore it is suggested to add one or two more laundry items
to the wash so that spin can be done smoothly.
4.3. DETERGENT DISPENSER

14
EN
Powder detergent
( )
Softener Liquid
detergent
AUTO
Caution!
■ Liquid detergent need to be added after selecting pre-washing for machines
Programme Option
Cotton ○
Synthetic ○
Mix ○
20 °C ○
Steam Wash ○
Drum Clean
Spin Only
Rinse&Spin ○
Sterilization ○
Sports ○
Wool ○
Eco 40-60 ○
15’Quick ○
Means must ○ Means optional
4.4. DETERGENT RECOMMENDATION
Recommended washing
detergent Wash cycles Washing temp Type of laundry and textile
Heavy-duty detergent
with bleaching
agents and optical
brighteners
Cotton, ECO 40-60,
Intensive 40/60 White laundry made
from boil-proof cotton
or linen

15
EN
Recommended washing
detergent Wash cycles Washing temp Type of laundry and textile
Colour detergent
without bleaching
agent and optical
brighteners
Cotton, ECO 40-60,
Intensive 20/30/40 Coloured laundry
made from cotton or
linen
Color or mild
detergent without
optical brighteners 20°C,Synthetic Cold/20/
30/40
Coloured laundry
made from easy care
bres or synthetic
materials
Mild washing
detergent Synthetic Cold/20/3 Delicate textiles, silk, viscose
Special wool
detergent Wool 20/30/40 Wool
Note!
■ Agglomerating or ropy detergent or additive can be diluted in some water before
pouring it into the detergent dispenser, to avoid its inlet to get blocked and thus
cause a water overow.
■ Please choose the suitable type of detergent to get a maximum of washing
performance and a minimum of water and energy consumption
■ To achieve the best cleaning result a proper detergent dosing is important.
■ Use a reduced detergent amount if the drum is not lled completely.
■ Always adjust the amount of detergent to the water hardness, if your tap water is
soft, use less detergent.
■ Dose according to how dirty your laundry is, less dirty clothes require less
detergent.
■ Highly concentrated (compact detergent) requires particularly accurate dosing.
Following symptoms are a sign of detergent overdosing:
- heavy foam formation
- poor washing and rinsing result
Following symptoms are a sign of detergent underdosing:
- laundry turns grey
- built-up of limescale deposits on the drum, the heating element and/or the laundry

16
EN
5. PRODUCT DESCRIPTION
1
2
8
3
4
5
6
9
10
11
12
7
5.1. FRONT VIEW
The product diagram is for reference only and may di󰀨er from the actual product.
1. Top cover
2. Control panel
3. Power supply cord
4. Drum
5. Service lter
6. Drain hose
7. Door
8. Detergent dispenser
9. Water supply hose
5.2. ACCESSORIES
1. Transport hole plug
2. Supply hose (cold water) 3. Owner’s manual
2
10
11
4
5321

17
EN
5.3. CONTROL PANEL
1. Power: Switches the product on or o󰀨.
2. Start/Pause: Press the button to start or pause the washing cycle.
3. Option: This allows you to select an additional function; it will light up when selected.
4. Programmes: Available according to the laundry type.
5. Display: The display shows the settings, estimated time remaining, options, and
status messages for your washer. The display will remain on through the cycle.
AKBCDE
FGHIJ
5.4. DISPLAY
A. Display
Wash time
Delay time
Speed
Error
End
Temp
B. Delay
C. Door lock
D. Child lock
E. WiFi
F. Auto dose
G. Speed wash
H. Rinse+
I. Night wash
J. Soil level
K. Remote control
6. PROGRAMMES
Washing Programmes Table
Programme Load(kg) Display Time
My cycle 9.0 10.0
Cotton 9.0 10.0 3:39 3:39
Synthetic 4.5 5.0 3:17 3:17
Mix 9.0 10.0 1:20 1:20
20°C 4.5 5.0 1:01 1:01
Steam Wash 4.5 5.0 1:47 1:47
Drum Clean - - 1:18 1:18
Spin Only 9.0 10.0 0:12 0:12

18
EN
Programme Load(kg) Display Time
Rinse&Spin 9.0 10.0 0:20 0:20
Sterilization 4.5 5.0 2:27 2:27
Sports 4.5 5.0 0:58 0:58
Wool 2.0 2.0 1:07 1:07
Eco 40-60 9.0 10.0 3:48 3:59
15’Quick 2.0 2.0 0:15 0:15
Note!
■ The parameters in this table are for the user’s reference only. The actual
parameters may be di󰀨erent from the parameters in the table.
Cycle Nominal
capacity in kg
Cycle duration
in hours and
minutes
Energy
consumption in
KWh/opera ing
cycle
Water
consumption in
milter// operating
cycle
Highest
temperature
°C
Residual
moisture in %/
spin speed
20°C Half 01:01 0.189 48 20 65%/1000
Cotton
(60°C) Full 03:44 1.620 78 60 53%/1400
Sterilization Half 02:27 1.158 60 70 70%/800
Mix Full 01:20 0.813 78 40 70%/800
Quick15’ 2.0 0:15 0.030 31 15 70%/800
ECO 40-60
Full 03:48 0.948 64 37 53.9%/1300
Half 02:54 0.589 49.5 34 53.9%/1300
Quarter 02:54 0.240 39 22 53.9%/1300
■ The above data is for reference only, and the data may change due to di󰀨erent
actual use conditions.
■ The valves given for programmes other than the ECO 40-60 programme are
indicative only.
■ Concerning to EN 60456:2016/prA2019 With (EU)2019/2014, (EU)2019/2023,
The EU energy e󰀩ciency class is: B
Energy test program: ECO 40-60. Other as the default.
Half load for 9.0Kg machine: 4.5Kg.
Quarter load for 9.0Kg machine: 2.25Kg.
1) The highest temperature reached by the laundry in the wash cycle for at least
5 minutes.
2) Residual moisture after the wash cycle in water content percent and the spin
speed at which this was achieved.
3) The ECO 40-60 programme is able to clean normally soiled cotton laundry
declared to be washable at 40°C or 60°C, together in the same cycle. This
programme is used to assess the compliance with the regulation (EU) 2019/2023.
The most e󰀩cient programmes in terms of energy consumption are generally those
that perform at lower temperatures and longer duration.
Loading the household washing machine up to the capacity indicated for the respective
programmes will contribute to energy and water savings.
Noise and remaining moisture content are inuenced by the spinning speed: the higher
the spinning speed in the spinning phase, the higher the noise and the lower the
remaining moisture content.

19
EN
Caution!
■ If there is any break in the power supply while the machine is operating, a
special memory stores the selected programme. The machine will continue the
programme when the power supply is re-established.
Programmes are available according to the laundry type.
Programmes
Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen.
Synthetic
Wash synthetic articles, for example: shirts, coats, blending.
While washing the knitting textiles, detergent quantity shall be
reduced due to its loose string construction and easily forming
bubbles.
Steam Wash
Steam is applicable for daily laundries.
The steam can deeply penetrate the ber, which e󰀨ectively
eliminate bacteria and germs, preventing odors and protecting your
health.
Mix Mixed load consisting of textiles made of cotton and synthetics
Sports Washing the activewear.
20°C 20°C default, can choose cold water.
ECO 40-60 Suitabale for laundry washing at about 40°C-60°C.
15’ Quick Extra short programme approx, suitable for lightly soiled washing as
a small amounts of laundry.
Wool Hand or machine-washable wool or richwool textiles.Especially gentle wash programme to prevent shrinkage, longer
programme pauses (textiles rest in wash liquor).
Spin Only Extra spin with selectable spin speed.
Rinse&Spin Extra rinse with spin.
Sterilization Keep the washing temperature above 60 degrees for more than
30 minutes, e󰀨ectively remove harmful bacteria.
Drum Clean
Specially set in this machine to clean the drum and tube. It applies
90 °C high temperature sterilization to make the clothes washing
more green. When this programme is performed, the clothes or
other washing cannot be added.
When proper amount of chlorine bleaching agent is put in, the barrel
cleaning e󰀨ect will be better. The customer can use this programme
regularly according to the need.
■ For the maximum spin speed, program time, and other details of the ECO
40-60 program, please refer to the content on the Product Fiche page.
■ The table shows which cycle o󰀨ers which options for adjustment. If an adjustment
is not possible for a cycle
Loading the household washer up to the capacity indicated for the respective
programmes will contribute to energy and water savings.
Cycle Default
Temp.(°C)
Default
spin speed
in rpm Additional functions
Wash cycles 1400
Cotton 40 1400

20
EN
Cycle Default
Temp.(°C)
Default
spin speed
in rpm Additional functions
Synthetic 40 1200
Mix 40 800
20°C 20 1000
Steam Wash 40 800
Drum Clean 90 --
Spin Only -- 1000
Rinse&Spin -- 1000
Sterilization 70 800
Sports 20 800
Wool 40 600
ECO 40-60 -- 1400
15’Quick Cold 800
Note!
■ For the maximum spin speed, program time, and other details of the ECO
40-60 program, please refer to the content on the Product Fiche page.
■ The table shows which cycle o󰀨ers which options for adjustment. If an adjustment
is not possible for a cycle
SPIN
Spin When needed, the spinning speed can be adjusted pressing the Speed
button in the following steps: 1400: 0-400-600-800-1000-1200-1400
DELAY
1. Select a programme
2. Press the Delay button to choose the delaying time 0-24h
3. Press [Start/Pause] to start the delay operation
Delay
Choose programme Setting time Start
EXTRA RINSE
The laundry will undergo an extra rinse after selecting this function.
You can also turn o󰀨 the WiFi function by pressing the button for
3 seconds.
