Qilive Q.6710 User manual

Front washing machine 9 Kg
Q.6710
FR Lave-linge hublot 9 Kg
ES Lavadora carga frontal 9 Kg
PT Máquina de lavar roupa com porta frontal 9 Kg
PL Pralka automatyczna 9 Kg
HU Ablakos mosógép 9 кг
RO Maşină de spălat rufe cu încărcare față 9 Kg

EN User manual P. 4
Manuel d’utilisation P. 29
Manual del usuario P. 55
Manual do utilizador P. 81
Instrukcja użytkownika S. 107
Használati útmutató 134. o.
Manual de utilizare P. 161
PT
PL
HU
RO
FRFR
ESES
PT
PL
HU
RO

1
2
3
4
5
6
9
8
7

44
EN
1. SAFETY INFORMATION
Before using this electrical appliance, carefully read
these instructions and keep the user manual for future
reference:
1. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- farm houses;
- by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- areas for communal use in blocks of flats.
2. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
3. Before connecting the appliance to a wall socket,
ensure that the local electrical current matches the
one specified on the appliance’s nameplate. This
appliance should only be connected to a grounded
socket.
4. Unplug the mains cable from the mains as soon
as you stop using it and before any cleaning or
maintenance operation.
TABLE OF CONTENTS:
1. SAFETY INFORMATION P. 4
2. TECHNICAL DATA P. 8
3. DESCRIPTION P. 14
4. INSTALLATION P. 18
5. USE P. 21
6. MAINTENANCE AND CLEANING P. 25
7. GUARANTEES AND LIMITATIONS OF LIABILITY P. 28

55
EN
5. This appliance can be used by children aged from
8yearsandabove and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision. Keep the appliance and its cord
out of reach of children less than 8 years.
6. WARNING: To avoid deteriorating the appliance,
transport it in its operating position, along with its
transport brackets (depending on model). At the time
of unpacking, and to prevent risks of suffocation or
injury, keep packaging materials out of children’s
reach.
7. WARNING: When disposing of your appliance, and
to avoid any risk of injury, remove what may be
hazardous: cut the power cable so it is flush with the
appliance. Check with your local services for places
where you are allowed to dispose of the appliance.
Remove the door lock in order to prevent children
from becoming trapped inside.
8. Instructions for installing, using, and performing
maintenance on the appliance are provided in
the sections titled “INSTALLATION”, “USE”, and
“MAINTENANCE AND CLEANING”.
9. The appliance is designed for a maximum load
weight of 9 kg of dry laundry for cotton items, 3.5 kg
for synthetics and delicates, and 2.5 kg for wool.
10. The appliance must be connected to the water
distribution network using a new set of pipes. It is
recommended to not reuse old pipe sets.
11. The minimum inlet water pressure permitted is
0.05 MPa .
12. The maximum permitted water pressure of the water
supply is 1 MPa.

66
EN 13. Never force the door open when the appliance is
running.
14. Never open the laundry drawer while the appliance
is running.
15. Keep pets away from the appliance.
16. RISK OF BURNS!
Do not touch the drain hose or the water supply
hose. The appliance may reach high temperatures
while operating.
17. RISK OF DEATH BY ELECTRIC SHOCK!
Avoid using multiple plugs or extension cords.
Do not connect the appliance to damaged outlets.
Never pull the cable to disconnect the appliance -
always disconnect from the plug.
Avoid connecting or disconnecting the appliance
with wet hands as this poses a risk of electrocution.
Never touch the appliance with wet hands or feet.
18. Risk of flooding!
Take all necessary measures to prevent the hose
from slipping.
19. Risk of fire!
Do not leave flammable liquids within close proximity
of your appliance.
The openings must not be obstructed by a carpet.
20. Child safety!
Never leave children unattended near the appliance.
Children may lock themselves inside the appliance,
with a risk of death.
The door glass and its surface may become extremely
hot while the unit is operating. Therefore, touching
the appliance may cause burns to children’s skin.
Keep packaging materials out of the reach of children.
Children of less than 3 years should be kept away
unless continuously supervised.

77
EN
Disposal
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product
for environmental safe recycling.

88
EN 2. TECHNICAL DATA
2.1 Product Data Sheets (I)
Rated capacity in kg of cotton laundry 9
Energy efficiency class on a scale from A+++ (most efficient) bis D (least
efficient) A+++
Energy consumption 218 kWh per year, based on 220 standard washing cycles for
the standard cotton programmes at 60 °C and 40 °C at full and partial load, and the
consumption of the low-power modes.Actual energy consumption will depend on how
the appliance is used.
Energy consumption of the standard 60°C cotton programme at full load 1.04kwh
Energy consumption of the standard 60°C cotton programme at partial
load 0.95kwh
Energy consumption of the standard 40°C cotton programme at partial
load 0.86kwh
Weighted power consumption of the off-mode 0.50W
Weighted power consumption of the left-on mode 1.00W
Water consumption 11800 litres per year, based on 220 standard washing cycles for
standard cotton programmes at 60 °C and 40 °C at full and partial load. Actual water
consumption will depend on how the appliance is used.
Spin-drying efficiency class B on a scale from G (least efficient) to A (most efficient)
Maximum spin speed 1200
Remaining moisture content 53%
“Intensive 60°C programme” and the “intensive 40°C programme” are the standard
washing programmes to which the information in the label and the fiche relates,
that these programmes are suitable to clean normally soiled cotton laundry and
that they are the most efficient programmes in terms of combined energy and water
consumption.
Programme time of standard 60°C cotton programme at full load 245min
Programme time of standard 60°C cotton programme at half load 245min
Programme time of standard 40°C cotton programme at half load 235min
Duration time of left-on mode -
Airborne acoustical noise emissions during washing phase 65dB
Airborne acoustical noise emissions during spinning phase 79dB
“Built-in” washing machine no
Energy test program is Intensive; speed is set as the highest; temperature is set as
60°C/40°C. The other settings are set as default.

99
EN
2.2 Product Data Sheets (II)
Supplier’s name or trademark: Auchan
Supplier’s address b): SAS OIA, 200, rue de la Recherche, Le Colibri BP 169, 59650 Villeneuve
d’Ascq, France
Model identifier: MFN90-S1203/C31E-EU(NE)
General product parameters:
Parameter Value Parameter Value
Rated capacity a) (kg) 9.0 Dimensions (cm) Height 85
Width 60
Depth 57
EEIwa) 91.0 Energy efficiency class a) E
Washing efficiency index a) 1.04 Rinsing effectiveness
(g/kg) a) 5.0
Energy consumption in
kWh per cycle based
on the eco 40-60
programme. Actual energy
consumption will depend
on how the appliance is
used.
0.865 Water consumption in litre
per cycle based on the
eco 40-60 programme.
Actual water consumption
will depend on how the
appliance is used and on
the hardness of the water.
50
Maximum temperature
inside the treated textile
a) (°C)
Rated capacity 41 Remaining moisture
content a) (%) Rated
capacity 53
Half 35 Half 53
Quarter 25 Quarter 53
Spin speed a) (rpm) Rated capacity 1200 Spin-drying efficiency
class a) B
Half 1200
Quarter 1200
Programme duration a)
(h:min) Rated capacity 3:48 Type Free-standing
Half 2:54
Quarter 2:54
Airborne acoustical noise
emission in the spinning a)
phase (dB (A) re 1 pW)
80 Airborne noise emission
class a) (spinning phase) C
Off-mode (W) 0.50 Standby mode (W) 1.00
Delay start (W) (if
applicable) 4.00 Network standby (W) (if applicable) N/A
Minimum duration of the guarantee offered by the supplier b):
This product has been designed to release silver ions
during the washing cycle. No
Additional information:
Weblink to the supplier’s, where the information in point 9 of Annex II to Commission Regulation (EU)
2019/2023 (1) b) is found
a) for the eco 40-60 programme.
b) changes to these items shall not be considered relevant for the purposes of paragraph 4 of Article
4 of Regulation (EU) 2017/1369.
c) if the product database automatically generates the definitive content of this cell the supplier shall not
enter these data.

1010
EN Note!
• Programme setting for testing in accordance with applicable standard EN60456 for
wash.
• Programme setting for testing in accordance with applicable standard EN50229 for
wash and dry.
• When using the test programmes, wash the specified load using the maximum spin
speed.
• The actual parameters will depend on how the appliance is used, and may differ from
above table.
• The noise emissions during washing/spinning are for standard washing cycle at full
load.
• The actual energy consumption will depend on how the appliance is used.
• The actual water consumption will depend on how the appliance is used and on the
hardness of the water.
• 10 years availability to key spare parts.
2.3 Product Data Sheet concerning (EU) 2019/2014
The product data sheet for this appliance can be found online.
Go to https://eprel.ec.europe.eu, and enter the model indentifier for this appliance to
download the data sheet. The model identifier can be found in the Technical Data section
of this manual.
2.4 General Information
Power supply 220 - 240 V~,50 Hz
Rated power 2000 W
Current Max. 10 A
Washing Capacity 9 kg
Standard water pressure 0.05 MPa - 1 MPa
Dimensions (WxDxH) 60 x 57 x 85 cm
Weight 71 kg

1111
EN
2.5 Explanation of Programmes
Programmes are available according to the type of laundry.
Programmes
Cotton For hard-wearing garments, heat-resistant fabrics made of
cotton or linen.
Synthetic For washing synthetic articles, for example shirts, coats,
blended fabric. When washing knitwear, detergent quantity
should be reduced due to it easily forming bubbles.
Baby Care For washing baby clothing, it cleans and rinses more
intensive to protect the baby skin.
Rapid 45’ For quickly washing a small load of slightly dirty clothes
within 45 minutes.
Mix Mixed loads consisting of garments made of cotton and
synthetics.
Jeans Programme especially for denims.
20°C For washing brightly coloured garments, protecting the
colours.
Quick 15’ For quickly washing a small load of slightly soiled garments
within 15 minutes.
Wool For hand or machine-washable wool or rich wool textiles;
for washing gently to prevent shrinkage with longer
washing time (textiles rest in wash liquor).
Spin Only Only spinning with selectable spin speed.
Rinse & Spin Only rinsing and spinning.
Sport Wear For washing active and sportswear.
Bulky/Bedlinen Specially designed for washing bulky/bedlinen.
Intensive To increase the washing effects, the washing time is
increased.
ECO 40-60 The temperature is fixed as 40°C. Suitable for washing
garments which are washable at 40 - 60°C.
Note!
Select a wasing programme according to types of your farbics.

1212
EN 2.6 Wash Cycle Table
Programme
Nominal
capacity
(kg)
Duration
(h:min) Energy (kWh)
Water
(l)
Highest
Tempt.
(°C) 1)
Residual
moisture
/spin
speed
(%) 2)
Cotton 9.0 2:40 1.15 75 40 60.0
Synthetic 4.5 2:20 0.7 60 40 35.0
Baby Care 9.0 1:43 1.5 70 60 70.0
Jeans 9.0 1:48 1.5 70 60 70.0
Mix 9.0 1:20 0.9 70 40 70.0
20°C 4.5 1:01 0.25 60 20 65.0
Rinse & Spin 9.0 0:20 0.065 25 15 60.0
Spin Only 9.0 0:12 0.055 -- 60.0
Intensive 9.0 3:48 1.2 70 40 70.0
ECO 40-60 3) 9.0 3:48 1.295 64 41 53.0
4.5 2:54 0.848 50 35 53.0
2.5 2:54 0.51 38 25 53.0
Bulky/Bedlinen 9.0 1:48 1 70 40 70.0
Wool 2.0 1:07 0.5 55 40 80.0
Sport Wear 4.0 0:45 0.25 50 20 65.0
Rapid 45’ 2.0 0:45 0.75 40 40 70.0
Quick 15’ 2.0 0:15 0.05 40 15 75.0
1. The highest temperature reached by the laundry in the wash cycle for at least
5 minutes.
2. Residual moisture after the wash cycle in water content percent and the spin speed
at which this was achieved.
3. The ECO 40-60 programme is able to clean normally soiled cotton laundry declared
to be washable at 40°C or 60°C together in the same cycle. This programme is used
to assess the compliance with the regulation (EU) 2019/2023.
Note!
• The most efficient programmes in terms of energy consumption are generally those
that perform at lower temperatures and longer duration.
• Loading the household washer-dryer up to the capacity indicated for the respective
programmes will contribute to energy and water savings.

1313
EN
• Noise and remaining moisture content are influenced by the spinning speed: the
higher the spinning speed in the spinning phase, the higher the noise and the lower
the remaining moisture content.
• The parameters in the table above are only for reference. The actual parameters
may differ.
Information related to EN 60456:2016 With (EU) No 1061/2010
• The EU energy efficiency class is: A+++.
• Energy test program is Intensive; speed is set as the highest; temperature is set as
60°C/40°C. The other settings are set as default.
• Half load for 9.0 kg machine: 4.5 kg
Information related to EN 60456:2016/prA:2019 With (EU) 2019/2014, (EU) 2019/2023
• The EU energy efficiency class is: E.
• Energy test program is ECO 40-60. The other settings are set as default.
• Half load for 9.0 kg machine: 4.5 kg
• Quarter load for 9.0 kg machine: 2.5 kg

1414
EN 3. DESCRIPTION
3.1 Product Overview
1
2
3
4
5
6
9
8
7
1. Top cover
2. Control panel
3. Power supply cord
4. Drum
5. Service filter
6. Drain hose
7. Door
8. Detergent dispenser
9. Water supply hose
3.2 Control Panel

1515
EN
1. On/Off
Switch the product on or off.
2. Start/Pause
Press this button to start or pause the washing cycle.
3. Option
This allows you to select an additional function; it will light up when selected.
4. Programmes
Available according to the laundry type.
5. Display
The display shows the settings, estimated remaining time, options, and status messages
for your washing machine. The display will remain on during the entire cycle.
6. Drum Clean
Clean the drum and tube of the appliance.
3.3 Display
G
A Display
Wash Time Delay Time
Speed Error
End
B Child Lock
C Door Lock
D Delay
E Temp.
F Pre Wash
G Extra Rinse
Note!
The line drawings are for reference only. Refer to real product as standard.
3.4 Detergent Dispenser
Pull out the dispenser
Caution!
Detergent only needs to be added in “compartment I” after selecting pre-washing for
washing machines with this function.
I:Pre wash detergent
II: Main wash detergent
: Softener

1616
EN
Programme I II Programme I II
Cotton Bulky/Bedlinen
Synthetic Baby Care
Mix Wool
Jeans Sport Wear
Spin Only Rapid 45’
Rinse & Spin Quick 15’
ECO 40-60 Intensive
20°C
Means must Means optional
3.5 Detergent Recommendation
Recommended washing
detergent Washing temp. (°C) Type of laundry and textile
Heavy-duty detergent with
bleaching agents and optical
brighteners
40/60/90 White laundry made from
boil-proof cotton or linen
Colour detergent without
bleaching agent and optical
brighteners
20/30/40 Coloured laundry made from
cotton or linen
Colour or mild detergent without
optical brighteners 20/30/40 Coloured laundry made from easy care fibres or synthetic
materials
Mild washing detergent 20/30 Delicate textiles, silk,
viscose
Special wool detergent 20/30/40 Wool
Note!
• As for the clumped together or tacky detergent or additive, before they are poured
into the detergent dispenser, we suggest using some water for dilution to prevent
the inlet of the detergent dispenser from being blocked and overflowing while filling
water.
• Please choose a suitable type of detergent for the various washing temperatures to
get the best performance with less water and energy consumption.
• To achieve the best cleaning result, a proper amount of detergent is important.
• Use a reduced detergent amount if the drum is not fully filled.
• Always adjust the amount of detergent to the water hardness. Use less detergent if
your tap water is soft.

1717
EN
• The amount of detergent depends on how dirty your laundry is. Less dirty clothes
require less detergent.
• Highly concentrated detergent (compact detergent) requires particularly accurate
quantity.
Following symptoms are a sign of overdose of detergent.
• Heavy foam formation.
• Poor washing and rinsing result.
Following symptoms are a sign of underdose of detergent.
• Laundry turns grey.
• Build-up of limescale deposits on the drum, the heating element and/or the laundry.
3.6 Accessories
Transport hole
plug Supply hose cold water Supply hose hot water (optional) Drain hose support
(optional)
Owner’s manual

1818
EN 4. INSTALLATION
4.1 Installation Area
Warning!
• Stability is important to prevent the product from wandering!
• Make sure that the product should not stand on the power cord.
Before installing the washing machine, the location characterized as
follows shall be selected:
1. Rigid, dry, and level surface.
2. Avoid direct sunlight.
3. Sufficient ventilation.
4. Room temperature is above 0°C.
5. Keep far away from heat resources such as coal or gas.
4.2 Unpacking the Washing Machine
Warning!
• Packaging material (e.g. films, styrofoam) can be dangerous for
children.
• There is a risk of suffocation! Keep all packaging well away from
children.
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing. Make
sure the small triangle foam is removed with the bottom one
together. If not, lay the unit down on its side surface and then
remove the small foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
4.2.1 Removing the Transport Bolts
Warning!
• You must remove the transport bolts from the backside before using the product.
• You will need the transport bolts again if you move the product, so make sure you
keep them in a safe place.
Please take the following steps to remove the bolts:
1. Loosen 4 bolts with a spanner and then remove them.
2. Stop the holes with the transport hole plugs.
3. Keep the transport bolts properly for future use.
4.3 Levelling the Washing Machine
Warning!
• The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to their
original positions and tighten the nuts.
2. Loosen the lock nut and turn the foot until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
Raise Lower
foot
Lock nut

1919
EN
4.4 Connecting the Washing Machine
4.4.1 Connecting the Water Supply Hose
Warning!
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, modify or sever the water inlet hose.
• For models equipped with hot water valve, connect it to a hot water tap with the
hot water supply hose. Energy consumption will decrease automatically for some
programmes.
Connect the inlet pipe as indicated. There are two ways to connect the inlet pipe.
4.4.1.1 Connection between ordinary tap and inlet hose
clamp nut
slide bushing
Loosen clamp nut
and four bolts Tighten clamp nut Press slide bushing, insert inlet hose into
connecting base
Connection finished
4.4.1.2 Connection between screw tap and inlet hose
slide bushing
Tap with threads and inlet hose Special tap for washing machine
Connect the other end of the inlet pipe to the inlet valve at the back of the product and
fasten the pipe tightly clockwise.
water Inlet valve water supply hose

2020
EN 4.4.2 Connecting the Drain Hose
Warning!
• Do not kink or protract the drain hose.
• Position the drain hose properly, otherwise damage might result of water leakage.
There are two ways to place the end of the drain hose:
1. Put it into the water trough. 2. Connect it to the branch drain pipe of
the trough.
Water
trough
Max. 100cm
Min. 60cm
Note!
If the washing machine has drain hose support, please install it as follows.
Max. 100cm
Min. 60cm
Trough
Hose Retainer
Bind
Max. 100cm
Min. 60cm
Warning!
• When installing the drain hose, fix it properly with a rope or chain.
• If the drain hose is too long, do not force it into the washing machine as it will cause
abnormal noises.
