Qpad MK-90 User manual

QUICK START GUIDE
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
LASER ENGRAVED
L
60
RGB COLOR LED

2
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
You are now the owner of a piece of premium gaming equipment, designed with the
utmost attention to performance. When I first started QPAD back in 1992, it was with
one goal in mind. I wanted to create computer gear especially designed for gaming
purposes.
Being a die-hard gamer and computer enthusiast myself, I know just how much it means
to have gear that can stand the heat of battle. Gaming is all about feel, passion and love
of the game.
Over the years, my view on this has not changed, and I am truly proud to say that all of
the products in the QPAD family carry the same legacy: passion for gaming and a true
commitment to the gaming and eSport community.
Thank you for trusting QPAD - see you on the battlefield!
Sincerely
Christer MrMouse Körnbäck
Founder of QPAD
CONGRATULATIONS!

3
English
QPAD MK-90
The MK-90 is built with superior quality, durability, well-conceived design and layout. It features an exciting
new RGB LED concept with a multitude of lighting options and a white plate built into a strengthened
keyboard to enhance the clarity and impact of the lighting. The new RGB LED allows gamers to
individualize their experience by choosing any color in the spectrum and displaying them in a variety of
modes. For example, you can choose breathing, trigger, explosion, rainbow, audio beat, wave or random
in any of 16.8 million colors! MK-90's customized, programmable features lets you individually light up
different colors and modes across the entire keyboard, or parts of it. More impressive is the ability to
coordinate the lighting with the beat of your favorite song, lifting the spirit of the game to an even higher
level!
MK-90 has a built in "instant control" functionality allowing you to toggle between different color modes,
add a macro on the fly or change repetition speed. Simply press FN key + plus different key combinations
and take control! The MK-90 comes with gaming grade mechanical switches with unmatched accuracy
and feel. No more pressing with full-force in order to activate the keys. The keyboard will respond to your
every stroke in an instant. MK-90 is designed to last 60 million strokes, built on a steel plate, making it
robust enough to withstand the most serious keyboard abuse. MK-90 also features full N-Key rollover
anti-ghosting technology. (Even if you hit all keys at the same time
they will all register). MK-90 also features pass through audio and
USB ports, enabling you to connect your mouse, headset,memory
sticks or other options. Other features include gold-plated
connectors, removable wrist rest and media keys for easy control of
playback, pause, skip track, etc. MK-90 is designed to give you total
gaming control while giving you the thrill of movement at the
speed of light.
Fullsize 3 section keyboard Mechanical switches
RGB LED 16.8 million colors
Multimedia functionality Gold plated connectors USB 2.0 Hub & audio ports
Laser engraved key caps

4
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
NOTICE! USB HUB on keyboard is available for portable USB devices: earphone, headphone,
speaker, pen drive or MP3, Do not use for high power demanding devices.
®
Connect your USB plug to any available USB port. Windows will
automatically install all the necessary driver for the keyboard without restart.
PACKAGE CONTENTS
1 x Mechanical keyboard MK-90.
1 x Detachable wrist rest
COMPATIBILITY
USB 1.1/2.0 Compatible with Windows® XP / Vista / 7 / 8
SYSTEM REQUIREMENTS
 PC with built-in at least two USB, earphone-out and microphone-in ports
 Windows® XP / Vista / 7 / 8
OVERVIEW
1.8 meter cable with USB plugs
USB port on
your computer
Keyboard function
USB port on
your computer
power for hub
Audio port on
your computer
Mic port on
your computer
INSTALLATION
HUB

5
English
MULTIMEDIA CONTROL
Fn +
Fn +
+
Fn +
Fn +
Fn +
+
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Mute
Volume
Down
Volume Up
Play/Pause
Previous Track
Next Track
Prole 1
(Red)
Prole 2
(Cyan)
Prole 3
(White)
Prole 4
(Green)
Prole 5
(Yellow)
PROFILE CONTROL
WIN KEY LOCK ON/OFF
Fn F7
F8
F9
F1
F2
F3
F5
F4
PF4
PF5
PF3
PF2
PF1
F12
F11
F10
NOTICE! When enabeling Profile 1 to Profile 5 or G mode. Windows-key function will be automaticly
locked. You can enable or disable Windows key by pressing FN+Left Win.
Windows key ON/OFF in G mode G

6
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
System default. No repeat
Double repeat
Triple repeat
Quadruple repeat
Fn +
Fn +
Fn +
Fn +
NKEY CONTROL
REPEAT DELAY CONTROL
NOTICE! Repeat function may not suit all games or software, if it cause unexpected problems,
please use default repeat mode.
NOTICE! Some motherboards are having problem with full N-Key rollover. If you experience
problems try to change to 6-Key rollover.
Fn +Fn +
6-Key
(Default) N-Key
Ins
6-Key
Del
Nkey

7
English
G
Num lock LED on = Num Lock function active
Caps Lock LED on = Caps Lock function active
Game Mode Led on = Game Mode function active
Lighting strength up
Lighting strength down
Fn +
Fn +
LIGHTING STRENGTH

Fn +PC Mode or Game Mode ON/OFF
PC MODE
F6
G/PC
LED INDICATION
NOTICE! When G-mode is enabled. Windows-key function will be locked automaticly.
You can enable or disable Windows key by pressing FN+Left Win key.

8
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
LED mode change left
LED mode change right
Activate Macro recording
Fn +
Fn +
NOTICE!
Step 1: Lighting, keyboard LED are in steady mode. All keycap in the same color.
Step 2: Breathing, keyboard LED are in breathing mode, All keycaps have same color.
Step 3: Trigger, all LED are off, when key is pressed LED will light up.
Step 4: Explosion, all LED are off, when key is pressed LED will explode and spread.
Step 5: Random color breathing, LED color change in a breathing mode randomly.
Step 6: Audio, all LED are off, when music are played, led will flash to the beat of the music.
Step 7: Rainbow wave, keyboard LED move from left to right in all colors.
Step 8: Customized, user defined in any color any key.
NOTE! Audio mode requires that the 3.5mm audio plug is connected to a sound source.
If the light response is low. Increase the volume to increase lighting effect.
LIGHTING MODES
Fn +
INSTANT MACRO RECORDING
Alt Gr
Macro
NOTICE! Macro recording under Profile1 to Profile5
Step 1: Press FN+Alt Gr to start Macro Record process, G-mode LED will start flashing.
Step 2 : Type any key you want to record.
Step 3 : Press FN+Alt Gr again, G-mode Led will flash more quickly
Step 4 : Assign a key you want to save this record.
Step 5 : G-mode LED will stop flash, Macro record process finish.
FN and Win Key can't be assign to macro key.

9
English
FN + ESC for 3 seconds for reset
Fn +
WRIST REST
NOTICE! When keyboard has unexpected problem, you can reset keyboard by holding
FN+ESC for 3 second, LED will flash once, current profile will be reset to default setting.
Reset function only working under current profie.
1. Place the keyboard on top of the wrist rest pins
2. Press on the keyboard with your tumbs above the pins A and B until you snap it into place
3. When removing just bend the wristpad
4. Bend 360 degrees until it snaps of its position
HARDWARE RESET

10
WARRANTY
 QPAD warrants this product against defects in workmanship and materials for one
(1) year from purchase date under normal consumer use conditions.
 If the product fails during normal and proper use within the warranty period, QPAD
will, at its option, repair or replace the product. This QPAD warranty does not
include failiure caused by improper operation, cleaning or maintenance, accident,
damage, missuse, abuse, non- QPAD modifications to the product, normal wear and
tear or any other event, act or omission outside QPADs control.
 Parts repaired or replaced by the QPAD service site are covered for three (3)
months or for the remainder of the original warranty period, whichever is longer.
If warranty servicing is required, you may do following.
 Contact your local QPAD authorized dealer/retailer, from where you bought the
product, for repair or replacement.
Warranty limitations
The warranty only covers failiures or malfunctions occured during the warranty
period and in normal use conditions as well as for material or workmanship defect.
The warranty will not apply if:
1. The products been tampered, repaired, and or modified by non authorized
personal.
2. The serial number of the product has been altered, cancelled or removed.
3. There is damaged caused by accident, natural disasterintentional or accidental
misuse, abuse, neglect or improper maintenance, or use under abnormal conditions.
REGISTER YOUR PRODUCT
 Please visit www.QPAD.com/register/ for online product registration
QP ®
AD MK-90
P R O G A M I N G M E C H A N I C A L K E Y B O A R D

11
English
QPAD STORY
We at QPAD build our success on a grass roots commitment to the gaming community.
We thrive in competition and embrace the free spirit of gaming. We provide the gaming
world with premium high-quality equipment, giving eSporters, enthusiasts and casual
gamers all over the world a winning edge.
In an industry dominated by gigantic multi-national corporations, QPAD is a breath of
fresh air. The story of QPAD started in Stockholm, Sweden, back in 1992 when
computer enthusiast and hardcore gamer Christer Kornback founded the company.
The idea Christer had was to produce high-quality mouse pads suitable for gaming. Back
in those days, gamers had no choice but to use standard office-grade mice and mouse
pads.
In 1997, one of the Worlds first eSport events was held in Stockholm; the Swedish
Quake Championships. Christer - being a prominent member of the Swedish online
gaming scene - was asked to produce a custom-sized mouse pad, considerably larger
than the models available at the time. This was the birth of the first piece of premium
eSport equipment designed with only gaming in mind. The mouse pad was the core of
the QPAD product line for years, as the small one-man-business grew in both size and
fame, earning respect amongst eSport athletes, gamers and computer enthusiasts all
over the world.
Now QPAD has widened the product line to also include award-winning gaming-grade
mice, headsets and keyboards. These include the Worlds first mechanical gaming
keyboard offering full NKRO through usb only, (QPAD MK-85) and the first laser gaming
mouse actually usable for professional gaming purposes (QPAD 5K). With the launch of
the QPAD Professional Gaming Headset 1339 the company further consolidated its
place as a leading provider of premium gaming gear. The 1339 headset, based on the
industry-leading technology of Beyerdynamics, is by many gamers considered the best
gaming headset on the market today.
All of the products in the QPAD family carry the same legacy: passion for gaming and a
true commitment to the gaming and eSport community. This is reflected in our
sponsorship of the QTOUR, eSport athletes, communities, cups, tournaments, teams
and LAN parties all over the world.

12
QP ®
AD MK-70
P R O G A M I N G M E C H A N I C A L K E Y B O A R D
TECHNICAL SPECIFICATION
Gaming grade mechanical switch technology
Full N-Key roll over via USB
60 Million
Individual RGB LED backlight on every key for enhanced visuals
16.8 million colors with a multitude of lighting options
Breathing, trigger, explosion, random, audio, rainbow, customize
On the fly macro recording, repeat speed, color modes, profiles
Profiles, key binding, LED settings, macro recording, color modes
Gold plated USB connectors.
Media keys for volume control, play, pause and skip tracks
Two high speed USB 2.0 ports
3.5mm headphone-out and microphone-in jacks
2 meter braided cable
Key cap puller
44,8 x 14,9 x 3,5 cm (17,6 x 5,8 x 1,37 inch)
44,8 x 6,6 x 1,7 cm (17,6 x 2,48 x 0,66 inch)
1.27 Kg (2.8 LBS)
Key switch:.......................
N Key Roll over:.................
Key strokes:......................
Lighting:...........................
Lighting features:...............
Lighting modes:.................
Instant control:..................
Software:..........................
Connectors:......................
Media keys:.......................
USB Hub:..........................
Audio ports:......................
Cable:..............................
Extras:.............................
Keyboard:.........................
Wrist rest:........................
Weight:.............................

®
QPAD CT
PROFESSIONAL GAMING MOUSE PAD
®
QPAD FX
PROFESSIONAL GAMING MOUSE PAD
®
QPAD QH-85
®
QPAD QH-85 ®
QPAD QH-90 ® QPAD QH-90
®
QPAD QH-1339
PROFESSIONAL GAMING HEADSET
PROFESSIONAL GAMING HEADSET
PROFESSIONAL GAMING HEADSET PROFESSIONAL GAMING HEADSET PROFESSIONAL GAMING HEADSET
QPAD PRODUCTS
®
QPAD MK-80
®
QPAD MK-50 ®
QPAD MK-85
PROFESSIONAL GAMING KEYBOARD
PROFESSIONAL GAMING KEYBOARD
PROFESSIONAL GAMING KEYBOARD
®
QPAD UC
PROFESSIONAL GAMING MOUSE
®
QPAD 5K
PROFESSIONAL GAMING MOUSE
®
QPAD OM-75
PROFESSIONAL GAMING MOUSE
91
®
QPAD CT
PROFESSIONAL GAMING MOUSE PAD
MADE IN SWEDEN MADE IN SWEDEN
MOUSE PADS
MICE
KEYBOARDS
HEADSETS
Visit www.QPAD.com
for more products.
English
®
QPAD 8K
PROFESSIONAL GAMING MOUSE
®
QPAD 8K
PROFESSIONAL GAMING MOUSE
®
QPAD MK-90
PROFESSIONAL GAMING KEYBOARD
®
QPAD MK-70
PROFESSIONAL GAMING KEYBOARD

QPAD AB
Botkyrkavägen 4  S-143 30 Vårby  Sweden
Tel: [phone]  Fax: [phone]
E-mail: [email protected]  www.QPAD.com
www.facebook.com/QPAD  www.youtube.com/QPADse
