QUANTA S100-L11D User manual

Quanta
S100-L11D
1U Server
User's Guide
Date Modified: March 13, 2014 2:38 pm Document Version: 1.0

CONVENTIONS
Conventions
Several different typographic conventions are used throughout
this manual. Refer to the following examples for common
usage.
Bold type face denotes menu items, buttons and application
names.
Italic type face denotes references to other sections, and the
names of the folders, menus, programs, and files.
<Enter> type face denotes keyboard keys.
WARNING!
Warning information appears before the text it references and
should not be ignored as the content may prevent damage to
the device.
CAUTION!
CAUTIONS APPEAR BEFORE THE TEXT IT REFERENCES, SIMILAR TO
NOTES AND WARNINGS. CAUTIONS, HOWEVER, APPEAR IN CAPITAL
LETTERS AND CONTAIN VITAL HEALTH AND SAFETY INFORMATION.
Note:
Highlights general or useful information and tips.
!
!

SAFETY INFORMATION
Safety Information
Important Safety Instructions
Read all caution and safety statements in this document before
performing any of the instructions.
Warnings
Heed safety instructions: Before working with the server,
whether using this manual or any other resource as a refer-
ence, pay close attention to the safety instructions. Adhere to
the assembly instructions in this manual to ensure and maintain
compliance with existing product certifications and approvals.
Use only the described, regulated components specified in this
manual. Use of other products / components will void the UL
listing and other regulatory approvals of the product and will
most likely result in non-compliance with product regulations in
the region(s) in which the product is sold.
System power on/off: The power button DOES NOT turn off
the system AC power. To remove power from system, you must
unplug the AC power cord from the wall outlet. Make sure the
AC power cord is unplugged before opening the chassis, add-
ing, or removing any components.
Hazardous conditions, devices and cables: Hazardous elec-
trical conditions may be present on power, telephone, and com-
munication cables. Turn off the server and disconnect the
power cord, telecommunications systems, networks, and
modems attached to the server before opening it. Otherwise,
personal injury or equipment damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can
damage drives, boards, and other parts. We recommend that
you perform all procedures in this chapter only at an ESD work-
station. If one is not available, provide some ESD protection by
wearing an antistatic wrist strap attached to chassis ground any
unpainted metal surface on the server when handling parts.
ESD and handling boards: Always handle boards carefully.
They can be extremely sensitive to electrostatic discharge
(ESD). Hold boards only by their edges. After removing a board
from its protective wrapper or from the server, place the board
component side up on a grounded, static free surface. Use a
conductive foam pad if available but not the board wrapper. Do
not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic
encased conductor that slips over two jumper pins. Some jump-
ers have a small tab on top that can be gripped with fingertips
or with a pair of fine needle nosed pliers. If the jumpers do not
have such a tab, take care when using needle nosed pliers to
remove or install a jumper; grip the narrow sides of the jumper

SAFETY INFORMATION
with the pliers, never the wide sides. Gripping the wide sides
can damage the contacts inside the jumper, causing intermit-
tent problems with the function controlled by that jumper. Take
care to grip with, but not squeeze, the pliers or other tool used
to remove a jumper, or the pins on the board may bend or
break.

REVISION HISTORY
Revision History
Refer to the table below for the updates made to this manual.
Copyright
Copyright © 2014 Quanta Computer Inc. This publication,
including all photographs, illustrations and software, is pro-
tected under international copyright laws, with all rights
reserved. Neither this manual, nor any of the material contained
herein, may be reproduced without the express written consent
of the manufacturer. All trademarks and logos are copyrights of
their respective owners.
Version 1.0 / March 13, 2014
Disclaimer
The information in this document is subject to change without
notice. The manufacturer makes no representations or warran-
ties with respect to the contents hereof and specifically dis-
claims any implied warranties of merchantability or fitness for
any particular purpose. Furthermore, the manufacturer
reserves the right to revise this publication and to make
changes from time to time in the content hereof without obliga-
tion of the manufacturer to notify any person of such revision or
changes.
For the latest information and updates please refer to
http://www.QuantaQCT.com
All the illustrations in this technical guide are for reference only
and are subject to change without prior notice.
DATE CHAPTER UPDATES

About the Server
Chapter 1

ABOUT THE SERVER INTRODUCTION
1-1
1.1. Introduction
The S100-L11D Server System is a 1U, high-density, rack-
mount server system with support for one Intel®Xeon®E3-
1200 v3 series processor and up to twelve 3.5" HDDs. The sys-
tem comes in one of two configurations: fixed PSU SKU and
redundant PSU SKU. Shared features include the following:
Chipset
C226
Processor
Intel®Xeon®processor E3-1200 v3 family, up to 95W
PCIe
PCIe x8 G3 Low Profile, MD-2 slot
Memory
Up to four DDR3 1333/1600 MHz ECC UDIMM
Storage
Twelve 3.5" SATA fixed drives or eight * 3.5" SAS + 4 *
3.5" SATA (*see Hard Disk Drives on page 2-21).
One 2.5" SSD fixed drive (Fixed SKU only)
SATADOM support
Network
Four Intel (Haswell) i210 RJ45 GbE ports
Intel 82599 10GbE SFP+ (optional)
Power Sub-system
400W fixed power supply system (Fixed PSU SKU only)
450W redundant power supply system (Redundant PSU
SKU only)
System Features
Features
SPECIFICATION DESCRIPTION
Form Factor L1 (1U Chassis)
Chassis Size
(W x H x D)
430 mm x 43.2 mm x 812.8 mm
16.92" x 1.7" x 32.0"
Mainboard Size
(W x L)
243 mm × 243 mm
9.6” × 9.6”
Processor Intel®Xeon®processor E3-1200 v3 family,
(LGA 1150)
Chipset C226
SAS Controller LSISAS 2008 onboard
Memory (4) DDR3 UDIMM, 1333 / 1600 MHz

ABOUT THE SERVER SYSTEM FEATURES
1-2
Drive Bays
(12) fixed 3.5" or 2.5" SATA HDD/SSD bays*
(1) fixed 2.5" SATA/SAS fixed HDD/SSD bay
(1) SATADOM support
* HDD0~HDD3 only support SATA HDD.
HDD4~HDD11 support both SATA and SAS
HDDs.
Onboard Storage
Device
(2) Mini-SAS connectors signal from
LSISAS 2008
(6) SATA 6Gb from Intel C226
HDD Backplane 1 to 1
PCIe Expansion Slot (1) PCIe Gen3 x8 slot (x8 signals) support only
regular Riser
SW RAID Options Intel®SW RAID
Intel®RSTe SATA RAID 0/1/10
Network
(4) Springville 1GbE RJ45 ports
(1) Intel 82599 10GbE SFP+ port
Management Port (1) Dedicated 10/100 BASE-T RJ45 manage-
ment port
Integrated Graphics
BMC Aspeed AST2300 8MB DDR3 Video memory
Features
SPECIFICATION DESCRIPTION
Rear I/O
(2) USB 3.0 ports
(1) VGA port
(1) RS232 serial port
(4) 1GbE RJ45 ports
(1) 10/100Base-T RJ45 management port
(1) 10GbE SFP+ port (optional)
Power Supply
(1) 400W high efficiency PSU, 100-240VAC
50/60Hz (for fixed PSU SKU only)
(1) or (2) 450W high efficiency redundant
PSUs, 100-240VAC 50/60Hz (for redundant
PSU SKU only)
Note:
A redundant PSU is not supported in a fixed
PSU SKU. A fixed PSU is not supported in a
redundant PSU SKU.
TPM Support Yes
RoHS Yes
Intel Node Manage-
ment support Yes
System Management Aspeed AST2300 8MB DDR3 Video memory
Features
SPECIFICATION DESCRIPTION

ABOUT THE SERVER PACKAGE CONTENTS
1-3
1.2. Package Contents
(1) 1U server chassis
(1) Heat sink
(4) Dummy DIMMs (installed)
(1) Fixed Power Supply (fixed PSU PSU only)
(1) or (2) Redundant Power Supply (redundant PSU SKU
only)
(1) Power cord
Utility CD (Technical Guide included)
Rail kit

ABOUT THE SERVER A TOUR OF THE SYSTEM
1-4
1.3. A Tour of the System
System Overview
The S100-L11D is available in two SKUs, fixed and redundant
PSU SKUs. For further reference, in this manual SKU1 is desig-
nated as the fixed PSU model, while SKU2 is the redundant
one.
System Overview (SKU1: Fixed PSU)
System Overview (SKU2: Redundant PSU)
4
1
5
2
6
2
2
3
Component Overview
NO.ITEM DESCRIPTION
1 3.5” HDDs (12) 3.5” hard disk drive (HDD)
2 HDD board Connect to HDDs
1
5
2
2
2
3
6
54
7

ABOUT THE SERVER SYSTEM OVERVIEW
1-5
3Fans (x5) Fan modules (Fixed PSU SKU only)
(x6) Fan modules (Redundant PSU SKU only)
4 Mainboard Provide all the basic function and information for
system operation.
5
Fixed PSU SKU1 only: Fixed Power Supply Unit (PSU).
Redundant
PSU
SKU2 only: Redundant Power Supply Unit (PSU).
450W high efficiency redundant PSU, 100-
240VAC 50/60Hz
Note:
A redundant PSU is not supported in a fixed PSU SKU. A fixed
PSU is not supported in a redundant PSU SKU.
6
2.5” HDD
bay SKU1 only: (1) 2.5" HDD/SSD
Air Duct SKU2 only: Redundant PSU SKU only
7PDB
SKU2 only: power distribution board. Provides
power connectivity for PSU, fan, HDD, MB 12V,
MB power, and MB PMBus.
Component Overview (Continued)
NO.ITEM DESCRIPTION

ABOUT THE SERVER SYSTEM FRONT VIEW
1-6
System Front View
System Front View
10 2 3 4 5 7 8 9 10 116
2 1
1
System Front View
NO.FEATURE DESCRIPTION
1Control
Panel
Control system and status display. See Front
Control Panel LED on page 1-11.

ABOUT THE SERVER SYSTEM FRONT VIEW
1-7
Front Control Panel
Front Control Panel
Front Control Panel
NO.ICON NAME DESCRIPTION
1 Reset Button Base system On
Push button to Reset system
2HDD Activity
LED
Blue Blinking, HDD access
OFF, no access
3BMCLED
Blue On, link
Blinking, LAN access
4LAN LED 2
(LAN 3/4)
Blue On, link
Blinking, LAN access
5LAN LED 1
(LAN1/2)
Blue On, link
Blinking, LAN access
6StatusLED
See LEDs on page 4-2 for more informa-
tion.
Note:
See event log for more information after
the table Status LED activity.
10 2 3 4 5 7 8 9 10 116
2 1
12 346789105
7IDLED
Blue ON, selected unit ID
OFF, no ID requested
8 Power LED
Blue ON, S0 SYSTEM POWER ON
OFF, S4/S5 SYSTEM POWER OFF
Blinking, S1 Standby/Sleep
9 ID Button Push button to light up / off the ID LED.
10 Power
Button
Push button to power the system on /off.
Press more than 4 sec. to shut down the
system.
Front Control Panel (Continued)
NO.ICON NAME DESCRIPTION

ABOUT THE SERVER SYSTEM REAR VIEW
1-8
System Rear View
System Rear View (SKU1)
System Rear View (SKU2)
12 3
12 3
System Rear View
NOFEATURE DESCRIPTION
1
Fixed PSU Fixed Power Supply Unit (PSU), for fixed PSU
SKU only.
Redundant
PSU
Redundant Power Supply Unit (PSU), for redun-
dant PSU SKU only.
Note:
A redundant PSU is not supported in a fixed PSU SKU. A fixed
PSU is not supported in a redundant PSU SKU.
2System Rear
I/O Mainboard (MB) I/O features
3Expansion
Card (1) PCIe Gen3 x8 card
System Rear View (Continued)
NOFEATURE DESCRIPTION

ABOUT THE SERVER SYSTEM REAR VIEW
1-9
Power Sub-System
The following describes the fixed and redundant offerings avail-
able for the system
Power Supply Unit (SKU1)
A system has one fixed power supply unit (PSU).
Power Supply Unit (SKU2)
A system has one or two redundant power supply unit (PSU)
and a single power distribution board (PDB).
PSU
PSU
Power Supply Units by Model
MODEL PSU AC INPUT
S100-L11D
(1) 400W high efficiency PSU,
100-240VAC 50/60Hz
Or
(1) or (2) 450W high efficiency
redundant PSU, 100-240VAC 50/
60Hz (optional)
110/220V
Note:
A redundant PSU is not supported in a fixed PSU SKU. A fixed
PSU is not supported in a redundant PSU SKU.

ABOUT THE SERVER SYSTEM REAR VIEW
1-10
System Rear I/O
System Rear I/O
Expansion Slot
Expansion Slot
System Rear I/O
NOFEATURE DESCRIPTION
1 NIC1/NIC2 1 G BASE-T RJ45 port
2 NIC3/NIC4 1 G BASE-T RJ45 port
3COM/VGA
Ports Connect a monitor or serial devices to this port
4 NIC5 10G BASE-T SFP+ port
5 Dedicated Management LAN Port
6 USB port
2 USB ports (3.0 compliant)
Note:
The width of the USB drive needs to be lower than
17mm to avoid interfering with the use of the other
port.
126345
Expansion Slot
ITEM NAME DESCRIPTION
1PCIe expan-
sion slot (1) PCIe Gen3 x8 Riser Card (optional)
1

ABOUT THE SERVER LED STATUS DEFINITIONS
1-11
LED Status Definitions
Front Control Panel LED
HDD LED
Note:
See Front Control Panel on page 1-7 for more information.
Front Control Panel LED Behavior
ITEM STATE DESCRIPTION
BMC LAN
LED
Blue LAN Link to NIC6 (LAN9303)
Blinking LAN Link to NIC6 (LAN9303) ACTIVE
OFF NIC6 (LAN9303) NO FUNCTION
LAN LED 2
Blue LAN Link to NIC3 or NIC4
Blinking LAN Link to NIC3 or NIC4 active
OFF NIC3 and NIC4 do not function
LAN LED 1
Blue LAN Link to NIC1 or NIC2
Blinking LAN Link to NIC1 or NIC2 active
OFF NIC1 and NIC2 do not function
Fault LED
Amber Blinking Critical Error
OFF System OK
ID LED
Blue Identify this system
OFF No identification
Power LED
Blue S0 system power on.
OFF S5 system power off
Blinking S1 Standby/Sleep.
HDD LED Behavior
HDD STATUS BLUE LED AMBER LED
Slot Empty OFF OFF
Drive Online Blinking when activ-
ity is present. OFF
Drive Rebuilding Blinking when activ-
ity is present. OFF
Drive Failed OFF On: 150 msec
Off: 150 msec
Front Control Panel LED Behavior (Continued)
ITEM STATE DESCRIPTION

ABOUT THE SERVER LED STATUS DEFINITIONS
1-12
Redundant PSU LED LAN Port LED
The system mainboard has four i210 or one 82599EN (optional)
Ethernet controller and one 10 GbE (optional) ports. Each RJ45
connector has two built-in LEDs. See the following illustration
and table for details.
RJ45 LAN Connector
Redundant PSU LED Behavior
STATE CONDITION DESCRIPTION
On Green Power on
Off Power off
Blinking Green AC present / only 5VSB on (PS off)
On Amber AC core unplugged / AC power loss; sec-
ond PSU in parallel with AC input power
Blinking Amber PSU fault, high temp., high power, high
current, slow fan
On Amber Critical fault with shutdown: failure, OCP,
OVP, fan fail and OTP RJ45 LED Description
STATUS LINK LED ACTIVITY LED
Unplug Off Off
1G Link with Active Amber Green blinking
100M Link with Active Green Green blinking
10M Link with Active Off Green blinking
Link Activity
PIN 1
Location

ABOUT THE SERVER LED STATUS DEFINITIONS
1-13
10G SFP+
82599 10G SFP+
BMC Management Port (LAN9303)
LED
Management Port LED
SFP+ LED Description
STATUS LINK LED ACTIVITY LED
Unplug Dark Dark
10G Link with Active Green blinking Blue
Link
Activity
Management Port LED Behavior
STATUS LINK LED ACTIVITY LED
Unplug Off Off
100M Link + Active Green: on Green: blinking
10M Link + Active Off Green: blinking
PSU1
Link Activity

Installation and Assembly Safety
Instructions
Chapter 2
