Quantech QWC4 Owner's manual

MODEL QWC4
SINGLE COMPRESSOR
60 HZ
120 TONS TO 200 TONS
WATER-COOLED SCREW
LIQUID CHILLERS
INSTALLATION, OPERATION, MAINTENANCE New Release Form QWC4-NM1 (221)
Issue Date:
February 28, 2021
035-28391-000
R-134a

QUANTECH
2
FORM QWC4-NM1 (221)
ISSUE DATE: 02/28/2021
This equipment is a relatively complicated apparatus.
During rigging, installation, operation, maintenance,
or service, individuals may be exposed to certain com-
ponents or conditions including, but not limited to:
heavy objects, refrigerants, materials under pressure,
rotating components, and both high and low voltage.
Each of these items has the potential, if misused or
handled improperly, to cause bodily injury or death. It
is the obligation and responsibility of rigging, instal-
lation, and operating/service personnel to identify and
recognize these inherent hazards, protect themselves,
and proceed safely in completing their tasks. Failure
to comply with any of these requirements could result
in serious damage to the equipment and the property in
IMPORTANT!
READ BEFORE PROCEEDING!
GENERAL SAFETY GUIDELINES
which it is situated, as well as severe personal injury or
death to themselves and people at the site.
This document is intended for use by owner-authorized
rigging, installation, and operating/service personnel. It
is expected that these individuals possess independent
training that will enable them to perform their assigned
tasks properly and safely. It is essential that, prior to
performing any task on this equipment, this individual
shall have read and understood the on-product labels,
this document and any referenced materials. This in-
dividual shall also be familiar with and comply with
all applicable industry and governmental standards and
regulations pertaining to the task in question.
SAFETY SYMBOLS
The following symbols are used in this document to alert the reader to specific situations:
Indicates a possible hazardous situation
which will result in death or serious injury
if proper care is not taken.
Indicates a potentially hazardous situa-
tion which will result in possible injuries
or damage to equipment if proper care is
not taken.
Identies a hazard which could lead to
damage to the machine, damage to other
equipment and/or environmental pollu-
tion if proper care is not taken or instruc-
tions and are not followed.
Highlights additional information useful
to the technician in completing the work
being performed properly.
External wiring, unless specied as an optional connection in the manufacturer’s product line, is
not to be connected inside the control cabinet. Devices such as relays, switches, transducers and
controls and any external wiring must not be installed inside the micro panel. All wiring must be
in accordance with Quantech’ published specications and must be performed only by a qualied
electrician. Quantech will NOT be responsible for damage/problems resulting from improper con-
nections to the controls or application of improper control signals. Failure to follow this warning
will void the manufacturer’s warranty and cause serious damage to property or personal injury.

QUANTECH 3
FORM QWC4-NM1 (221)
ISSUE DATE: 02/28/2021
MANUAL DESCRIPTION FORM NUMBER
QWC4 Chiller Installation Checklist QWC4-CL1
QWC4 Chiller Start-up Checklist and Request for Authorized Start-up Technician QWC4-CL3
QWC4 Renewal Parts QWC4-RP1
Limited Warranty QTC-NM2
ASSOCIATED LITERATURE
CHANGEABILITY OF THIS DOCUMENT
In complying with Quantech’s policy for continu-
ous product improvement, the information contained
in this document is subject to change without notice.
Quantech makes no commitment to update or provide
current information automatically to the manual or
product owner. Updated manuals, if applicable, can be
obtained by contacting the nearest Quantech Service
office or accessing the Johnson Controls Knowledge
Exchange website at https://docs.johnsoncontrols.com/
chillers/.
It is the responsibility of rigging, lifting, and operating/
service personnel to verify the applicability of these
documents to the equipment. If there is any question
regarding the applicability of these documents, rig-
ging, lifting, and operating/service personnel should
verify whether the equipment has been modified and
if current literature is available from the owner of the
equipment prior to performing any work on the chiller.

QUANTECH
4
FORM QWC4-NM1 (221)
ISSUE DATE: 02/28/2021
QWC4
MOD
LEVEL
EVAP
TUBES*
BB
BC
BD
CB
CC
CD
DB
DC
DD
MB
MC
MD
ME
NB
NC
ND
NE
M2
M3
M4
M5
N2
N3
N4
N5
UNIT TYPE
Quantech Variable Speed
Screw Water-Cooled Chiller
Design Series
MB
COND
TUBES*
BB
BC
BD
CB
CC
CD
DB
DC
DD
MB
MC
MD
ME
NB
NC
ND
NE
M2
M3
M4
M5
N2
N3
N4
N5
MB
APPLICATION
S=Std Water Chiller
D=Dry Tower/Radiator
P=Process Brine
T=Ice Thermal Storage
A=Heat Pump
S
X=NO SELECTION
Q=SPECIAL
QUOTE
XA
CMPR
FX=(1) 145 mm
GX=(1) 151 mm
EE=(2) 136/136 mm
FE=(2) 145/136 mm
FF=(2) 145/145 mm
EE
PASS
A=Evap: 1-pass; Cond: 1 pass
B=Evap: 2-pass; Cond: 1 pass
C=Evap: 3-pass; Cond: 1 pass
D=Evap: 1-pass; Cond: 2 pass
E=Evap: 2-pass; Cond: 2 pass
F=Evap: 3-pass; Cond: 2 pass
G=Evap: 1-pass; Cond: 3 pass
H=Evap: 2-pass; Cond: 3 pass
I =Evap: 3-pass; Cond: 3 pass
B
STARTER
A=2 CMPR VSD Frame A
B=2 CMPR VSD Frame B
C=2 CMPR VSD Frame C
D=2 CMPR VSD Frame D
J=1 CMPR VSD Frame B
L=1 CMPR VSD Frame D
R=1 CMPR Air Cooled Frame A
S=1 CMPR Air Cooled Frame B
T=1 CMPR Air Cooled Frame C
U=1 CMPR Air Cooled Frame D
A
NOMINAL
CAP
0150
*First letter represents tube size. The second
letter designates the number of tubes.
Nomenclature

QUANTECH 5
FORM QWC4-NM1 (221)
ISSUE DATE: 02/28/2021
