Quantum Trinity F90+ User manual

It is saftey-relevant to strictly follow the Quick-Start-Guide
FLIGHT PLANNING
Weather conditions
• Wind ground: max. 9 m/s (17.5 kn) (see picture)
• Wind in flight: max. 12 m/s (23 kn)
• Temperature: -12 °C to 50 °C (10.4 °F to 122 °F)
• Do not y in rain or snow.
Be aware that there is no software restriction between
1500 m – 4000 m regarding the wind tolerance (ground).
0 m
2 m
(6.6 ft)
1500 m
(4921.3 ft)
3000 m
(9842.5 ft)
4500 m
(14763.8 ft)
4000 m
(13123.4 ft)
Wind tolerance (ground)
max. 9 m/s (17.5 kn)
Wind tolerance (ground)
max. 7 m/s (13.6 kn)
Wind tolerance (ground)
max. 5 m/s (9.7 kn)
Take-off MSL Flight timeWind speed
* Check the actual windspeed
by using the anemometer at 2 m (6.6 ft) AGL
Maximum take-off and landing altitude (max. 4000 m / 13123.4 ft)
Maximum ight altitude (max. 4500 m / 14763.8 ft)
*
MODE SET
*
MODE SET
*
MODE SET
Max. ight time
90 minutes
Max. ight time
90 minutes
Max. ight time
75 minutes
Check
Batteries Charged
• UAV battery packs (fully charged)
• RC Transmitter • Laptop • Powerbank for iBase
Firmwares Updated
QBase software Updated
Mission planning in QBase 3D Check
UAV ASSEMBLY
Set up the laptop and open QBase Check
Set up the QBase modem and connect it to the Laptop Check
Set up the ADS-B receiver Check
Set up the iBase
• Micro SD-card is inserted
• Antenna center is exactly above the reference mark
• Not shaded by objects
• Stay away min. 5 meters
• Power bank is connected and powered
• iBase is recording (blue LED blinking)
Check
Turn on the RC Transmitter Check
Check the UAV for damages (e.g. surfaces, propeller) Check
Magnetometer Calibration (If required)
• Obligatory: ight location > 50 km away from the last ight location
• Calibration and take-off area is free of metal (parking decks, cars, metal structures) or
any devices causing electric or magnetic elds (power lines, generators, mobile phones)
Calibrated
to location
All parts assembled and locked Check
Remove the payload transport lock Check
Battery pack is connected (UAV will start automatically) Check
Take-off position
• Take-off from the UAV transportation box.
• Optional: Cover the ground with a canvas cover. Fix it with weights.
Check
TAKE-OFF
RC and QBase Modem connection Established
Camera detected
• Camera > Trigger: Triggers and exposures count up in QBase and on the RC Check
QBase nal Check
Obstacle clearance in reality
• No obstacle within a radius of 20 m around Home Waypoint
• Re-/transition, descent circle, flight paths: altitude 20 m higher than obstacles
Check
UAV heading
• Ensure the direction of the displayed UAV corresponds with the direction of the UAV on the ground
• Do not fly if the heading on the ground is not correct: critical deviation ≥ 10°
Check
Trinity F90+
QUICK-START-GUIDE

Wind direction
• Re-/transition is set against the wind direction!
• Retransition with tailwind: per 1m/s tailwind ~ 20 meter deviation
• Windcheck in the immediate surrounding
• Do not take-off in a wind sheltered area (lee) as turbulances may occur
Check
Upload the mission Upload Synced Upload  Check
• Make sure the UAV is not moving during Preflight
Select
• Control surfaces with the right stick
(Aileron, Elevator)
translate
right
translate
left
Forward
Backward
Check
Propeller & Take-off area
• Never arm with a damaged propeller! Clear
Arm Select  Conrm
Motors running freely and tilted 90° upwards Check
Take-off Select  Conrm
Please always wait at least 15 minutes between two ights!
IMPORTANT MESSAGES
Aileron malfunction Come Home is automatically initiated. Wait for the UAV to Come Home.
Do not y again, contact your reseller.
Airspeed sensor
malfunction
No manual input necessary except for collision avoidance.
The UAV will return home and land automatically. The mission cannot be continued.
Battery critical No manual input necessary except for collision avoidance.
The UAV will return home and land automatically. The mission cannot be continued.
Battery low A warning 10 minutes before the UAV returns home due to battery capacity. Please select Come Home.
Hover time
exceeded
No manual input necessary except for collision avoidance. The UAV will land automatically.
 The flight cannot be continued.
Elevator malfunction Come Home is automatically initiated. In severe cases, an immediate retransition and landing is performed.
Do not y again, contact your reseller.
Link lost No manual input necessary.  Wait until link reconnects.  The UAV will perform the mission as planned in
the meantime or come back home and land automatically (depending on link-lost setting).
Motor temperature
too high
No manual input necessary except for collision avoidance. The UAV will land automatically.
 The flight cannot be continued.
Transition
airspeed too low
No manual input necessary except for collision avoidance.
The UAV will return home and land automatically.  The mission cannot be continued.
Wrong
direction
No manual input necessary except for collision avoidance. The UAV will automatically try to turn into the
transition cone to continue with the transition.  If this is not possible it will automatically return home and
land.
Wind speed No manual input necessary.  The mission is automatically continued.
Wind too strong No manual input necessary except for collision avoidance.
The UAV will return home and land automatically.  The mission cannot be continued.
EMERGENCY COMMANDS DURING THE MISSION
Transition altitude
Automatic
hover
Base
0 m
10 m
20 m
Free of obstacles
Retransition
Waypoint
Descent circle
Retransition
Emergency Commands Mission Commands
current
altitude
or climb up to 30m
above retransition
altitude
Loiter at current
altitude & location
Mission
or Manual commands
Continue
Hold
The UAV
will crash!
The UAV will crash!
Switch off
the motors &
enter spiral dive
Hard Abort
Come Home
Immediate
retransition
Descent in assisted
flight mode
Descent &
land at
current location
Land Now
Come Home Eagle
Continue Land Now
Hold Hard Abort
Mission Emergency
Auto climb
15 sec.
max. climb angle
Abort:
Left stick
Eagle
N
return to
planned mission.
No mannual
commands for
>5 seconds
return to
planned mission.
Min. flight altitude is 40 meters
(ATO = above take-off)
Manual Commands
!!It is always necessary to keep
the hover time as short as possible
to avoid extensive heating of
internal electronic components!!
Climb
Descend
Left Stick Right Stick
Fly
right
Fly
left
Continue
Copyright © 2021 Quantum-Systems GmbH. All rights reserved. • Document number: TF90+_QSG_V003_210707_V2.2.0.46
Quantum-Systems GmbH • Dornierstrasse 11 • 82205 Gilching • Germany • www.quantum-systems.com
