Fisher-Price X2245 User manual

X2245
www.fisher-price.com
Pleasekeepthisinstructionsheetforfuturereference,
asitcontainsimportantinformation.
Adultassemblyisrequired.
Requiredtools:Hammer,PhillipsScrewdriver
andScrapBlockofWood(notincluded).
Age:2-6years;WeightLimit:60lbs(27kg).
X2244

2
Handlebar
FrontWheel 4PedalHubs
PedalAxle
2Pedals
Fork
2ForkCovers
Frame
Seat
SeatRetainer
RearWheel
StraightAxle
2Hubcaps
Cap
Part Not Shown: Label Sheet
CapNut
CapNutAssemblyTool
2Covers
Consumer Information
WARNING
TO AVOID SERIOUS INJURY:
• Continuousadultsupervisionisrequired.
•
Neverusenearcarsandothermotor
vehicles,nearstreets,steps,sloped
driveways,hills,roadways,alleys,swimming
poolsorotherbodiesofwater.
• Alwayswearshoes.
• Neverallowmorethanonerider.
Parts
•Pleasesaveallpackagingmaterialuntilassemblyiscompletetoensurethatnopartsarediscarded.
•Pleasewipeeachpartwithaclean,dryclothbeforeassembly.
•Somepartsshownareassembledtobothsidesofthetrike.
•TightentheassembledscrewswithaPhillipsscrewdriver.Donotover-tightenthescrews.
#8x3"(7,6cm)Screw–1
#8x3/4"(1,9cm)Screw–4
FASTENERS SHOWN ACTUAL SIZE
CapNut

3
Assembly
• Slideahubcap(pegsideup)ontothestraightaxle.
• Slidearearwheel(indentedsidedown)ontothe
straightaxle.
RearWheel
IndentedSideDown
• Placeascrapblockofwoodonaatsurface.
• Turntheframeonitssidewiththeexposedendofthe
straightaxleup.
• Placethecapnutassemblytoolundertheassembledrear
wheelandontothecapnut.
• Slidearearwheel(indentedsideup)ontotheendofthe
straightaxle.
• Slideahubcap(pegsidedown)ontothestraightaxle.
• Placeacapnutontheendofthestraightaxle.
• Tapthecapnutwithahammer.Gently pull the rear
wheel up to be sure the cap nut is securely attached
to the straight axle.
• Disposeofthecapnutassemblytoolproperly.
• Insertoneofthetabsonacoverintoaslotinthehubcap.
Pushto"snap"thecoverinplace.Repeatthisprocedure
toattachtheothercovertotheotherhubcap.
• Settheframeassemblyaside.
CapNut
RearWheel
IndentedSideUp
CapNut
AssemblyTool
Assembled
RearWheel
StraightAxle
• Turntheframeupsidedown.
• Insertthestraightaxlethroughtheholesintherearof
theframe.
Hole Hole
Frame
StraightAxle
Hubcap
Hubcap
Frame
StraightAxle
Cover
Hubcap
1
2BOTTOM VIEW
3
CAUTION
Thisproductcontainssmallparts
inanunassembledstate.
Adultassemblyisrequired.
• Fittwopedalhubsontothepedalaxletabs.Makesurethe
tabstintotheslotineachpedalhub.
PedalHub
PedalHub
PedalAxle
Ta b
Ta b
Slot
4

4
Assembly
• Whileholdingthepedalhubsonthepedalaxle,insertthe
pedalaxlethroughtheholeinthecenterofthefrontwheel.
• Pushthepedalhubsintothecenterofthefrontwheeluntil
theyareushwiththesurfaceofthefrontwheel.
Hole
PedalAxle
PedalHubs
FrontWheel
• Placeascrapblockofwoodunderthefrontwheelassembly
withtheexposedendup.
• Fitapedalonthepedalaxle.
• Tapthepedalwithahammeruntilitissecure.
PedalAxle
FrontWheelAssembly
Pedal
PedalHub
PedalHub PedalAxle
• Turnthefrontwheelassemblyover.
• Insertapedalhubontothetopofthepedalaxleandinto
theholeinthecenterofthefrontwheel.
• Inserttheremainingpedalhubbelowthepedalaxleand
intotheholeinthecenterofthefrontwheel.
• Pushthepedalhubsintothecenterofthefrontwheeluntil
theyareushwiththesurfaceofthefrontwheel.
5
6
7
• Placethefrontwheelassemblybetweentheforkarms.
Makesurethepedalaxletsintothegrooveatthebottom
ofeachforkarm.
• Placeaforkcoveroverthepedalaxleononeforkarm.
• Inserttwo#8x3/4"(1,9cm)screwsthroughtheforkcover
andintotheforkarm.TightenthescrewswithaPhillips
screwdriver.Donotover-tighten.
• Repeatthisproceduretoattachtheotherforkcovertothe
otherforkarm.
ForkArms
PedalAxle
Groove
ForkCover
8

5
Assembly
• Turntheframeupright.
• Inserttheforkpostupthroughtheholeintheneckofthe
frame.Make sure the fork is positioned so that the fork
covers face the rear wheels.
• Placethehandlebarovertheforkpostandpushitdown
ontotheframe.Makesurethehandlebarispositionedso
thatthescrewholefacestherearwheelsandalignswith
thescrewholeintheforkpost.
Hint: You may need to rotate the handlebar to align
the holes.
• Insertthe#8x3"(7,6cm)screwthroughtheholeinthe
handlebarandintotheforkpost.Tightenthescrewwitha
Phillipsscrewdriver.Donotover-tighten.
Handlebar
FrameNeck
ForkPost
ForkCover
RearofTrike • Positiontheseatupsidedown.
• Fitthesmallpegsontheseatretainerintotheholesin
theseat.
• Insertand“snap”thecapintotheholeintheframe.
Cap
SeatRetainer
Seat
Peg
Holes
9
10
11
12
• Makesuretheareaswherethelabelswillbeappliedare
cleananddry.Wipeyourvehiclewithaclean,soft,dry
clothtoremoveanydustoroils.
• Forbestresults,avoidapplyingalabelmorethanonce.
• Applythelabelsasshownintheillustrationabove.
(Label 6onotherside)
(Label 2onotherside)
8
3
5
5
1
4
7

• Atanangle,insertthetabsontheseatintoanyofthetop
threesetsofslotsforthelower,middleorupperposition.
• Lowertheseatsothattheseatretainerinsertsandsnaps
intotheslotsintheframe.
• Pullupontheseattobesureitissecure.
Seat
Helpful Hint: The seat can be attached to the frame in any
of three positions, depending on the size of your child. Check
your child’s t on the trike by observing the seat to pedal
distance, as it is being ridden. If the pedals seem too far away
or too close for your child, move the seat up or down.
Attaching and Removing
the Seat
Lower Position Middle Position Upper Position
Tabs
Slots
Seat
Retainer
IMPORTANT!Itisagoodpracticetostarttrainingchildren
veryyoungregardingtheimportanceofhelmetuse.When
childrenareolderandridingbicyclesandfastervehicles,
itisimportantthattheyuseahelmeteachandeverytime
theyride.Forthisreason,evenwhileridingatricycle,itis
agoodideatofamiliarizeyourchildwithhelmetuse,sothat
itbecomesahabitforlife.Chooseahelmetthatcomplies
withrequirementsoftheapplicablecertifyingagencyfor
bicyclehelmets.
•Periodically,checktheplasticpartsandifbrokenorcracked,
disposeofthemproperly.
•Checkallfastenersregularlytobesuretheyaretight.Ifthe
fastenersarenottight,tightenthemasnecessary.
•Toclean,useamildsoapandwatersolutionandaclean
cloth.Rinsecleanwithwatertoremovesoapresidue.
SeatRetainer
Ta b
• Turntheframeonitsside.
• Squeezetheseatretainertabstowardoneanotherandlift
theseatfromtheframe.
Care
Consumer Information
SeatRetainerTab
Frame
Seat
Fisher-Price, Inc., a subsidiary of Mattel, Inc. East Aurora, New York 14052, U.S.A. PRINTED IN MEXICO
©2011 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. X2244pr-0920
