Quartzlock E5000 Instruction Manual

Model E5000 Operation Manual
MODEL E5000
12 Way Distribution Amplifier
USER’S HANDBOOK
Quartzlock UK Ltd
179 Junction Road
Burgess Hill
West Sussex
RH15 0JW
England.
Tel: [phone]
Web: www.quartzlock.com
E-mail: [e-mail]
E5000 Manual.doc 9 January 2012
Page 1 of 8

Model E5000 Operation Manual
Contents
Safety Considerations ......................................................................................................................3
Voltage, Frequency and Power Characteristics ...........................................................................4
Environmental Conditions ................................................................................................................4
Replaceable Fusing Characteristics ...............................................................................................4
Cleaning Instructions ........................................................................................................................4
Distribution Amplifier E5000 ............................................................................................................5
Operating Procedure ....................................................................................................................5
Specification ...................................................................................................................................6
E5000 Manual.doc 9 January 2012
Page 2 of 8

Model E5000 Operation Manual
Safety Considerations
General
This product and related documentation must be reviewed for familiarisation before operation. If
the equipment is used in a manner not specified by the manufacturer, the protection provided by the
instrument may be impaired.
Before Applying Power
Verify that the product is set to match the available line voltage and the correct fuse is installed.
Before Cleaning
Disconnect the product from operating power before cleaning.
WARNING
Bodily injury or death may result from failure to heed a warning. Do not proceed beyond a warning
until the indicated conditions are fully understood and met.
CAUTION
Damage to equipment, or incorrect measurement data, may result from failure to heed a caution. Do
not proceed beyond a caution until the indicated conditions are fully understood and met.
This equipment must be earthed
An uninterruptible safety earth ground must be maintained from the mains power source to the
product’s ground circuitry.
WARNING
When measuring power line signals, be extremely careful and use a step down isolation transformer
whose output is compatible with the input measurement capabilities of this product. The product’s
front and rear panels are typically at earth ground. Thus, never try to measure AC power line signals
without an isolation transformer.
WARNING
Instructions for adjustments when covers are removed and for servicing are for use by service-
trained personnel only. To avoid dangerous electrical shock, do not perform such adjustments or
servicing unless qualified to do so.
WARNING
Any interruption of the protective grounding conductor (inside or outside the instrument) or
disconnecting of the protective earth terminal will cause a potential shock hazard that could result in
personal injury. Grounding one conductor of a two conductor out-let is not sufficient protection.
Whenever it is likely that the protection has been impaired, the instrument must be made
inoperative and be secured against any unintended operation.
If the instrument is to be energised via an autotransformer (for voltage reduction) make sure the
common terminal is connected to the earthed pole terminal (neutral) of the power source.
Instructions for adjustments while the covers are removed and for servicing are for use by service-
trained personnel only. To avoid dangerous electrical shock, do not perform such adjustments or
servicing unless qualified to do so.
E5000 Manual.doc 9 January 2012
Page 3 of 8

Model E5000 Operation Manual
For continued protections against fire, replace the line fuse(s) with fuses of the same current rating
and type (for example, normal blow time delay). Do not use repaired fuses of short-circuited fuse
holders.
Voltage, Frequency and Power Characteristics
Voltage 85-240V AC
Frequency 40-50Hz
Power characteristics 500mA Max
Environmental Conditions
Temperature
Operating (ambient) -10°C to +55°C (-65 to +65 op)
Storage -40°C to +85°C
Replaceable Fusing Characteristics
800mA time-lag HBC
Cleaning Instructions
To ensure long and trouble operation, keep the unit free from dust and use care with liquids around
the unit.
Be careful not to spill liquids onto the unit. If the unit does get wet, turn the power off immediately
and let the unit dry completely before turning it on again.
Clean with a damp (with water) cloth.
Never spray cleaner directly onto the unit or let liquid run into any part of it. Never use harsh or
caustic products to clean the unit.
E5000 Manual.doc 9 January 2012
Page 4 of 8

Model E5000 Operation Manual
Distribution Amplifier E5000
Operating Procedure
Introduction
The Quartzlock model E5000 is a distribution amplifier designed for standard frequency
distribution between 1 MHz and 100 MHz.
Input
One input is provided. This has input impedance of 50. The input level should be between +7 and
+13 dBm.
Outputs
Up to twelve outputs are provided. These have source impedance of 50, and will provide between
+7 and +13 dBm into a 50 load.
E5000 Manual.doc 9 January 2012
Page 5 of 8

Model E5000 Operation Manual
Specification
1.
No of outputs:
12
2. No of inputs:
1
3. Input Characteristics:
a. Impedance: 50

nominal
b. Level: +10dBm nominal
+7 dBm to +13 dBm adjustable, sine wave
c. Input SWR: <1.2:1 at 10MHz
4. Output Characteristics:
a. Impedance: 50

nominal
b. Level: +13 dBm nominal into 50  at 10MHz
c. Output SWR: <1.2:1
d. Maximum Output: 15dBm into 50 ohms at 10MHz typical
5. Frequency Response:
a. 1MHz to 70MHz: +/-1.0dB
b. 1MHz to 110MHz: +2.0/-1.0dB
6. Harmonics:
(at rated output,10MHz)(source harmonics less than -60dBc
a. Second Harmonic <-55dBc
b. Third Harmonic <-35dBc
7. Isolation:
a. Output to Output >75dB (adjacent outputs) at 10MHz typically>85dB
b. Output to Input >75dB at 10MHz
8. Short Term Stability:(at 10MHz)
a. 1 Sec 2 x 10
-13
tau
b.
10 Sec
2 x 10-14 tau
c.
100 Sec
5 x 10
-15
tau
9. Phase Noise:
Offset Typical phase Noise, dBc/Hz
a. 1Hz <-130
b. 10Hz <-145
c. 100Hz <-150
d. 1KHz &10KHz <-155
10. Noise Floor: <-150
11. Spurious Outputs: <-160dBc
12. Broadband Noise: <-145dBm/Hz
13. Delay Match between Outputs: <1ns
14. Delay Input to Output: <6ns
15. Supply: 85....240V ac
