Quick Eagle Networks 4262 User manual

The 4262 Network WAN ProbeTM (T1 to T1 or E1 to E1) is the newest
addition to Quick Eagle Networks’ family of intelligent WAN access and IP
probe devices.
Sitting at the line of demarcation, Quick Eagle’s end-to-end IP Service Level
Verification (IP SLV) WAN probes provide accurate and reliable network
performance metrics. Throughput, availability, and latency are measured in
real time on the entire IP link between any or all known endpoints of the IP
network. Using IP SLV, enterprises, service providers, and government
agencies can define and measure Service Level Agreements (SLAs) for
Virtual Private Networks or IP-based networks.
At remote sites already equiped with routers and CSU/DSUs, the 4262
Network WAN Probe installs in-line on the T1/E1 connection, using a
proprietary layer-3 signalling protocol to measure and exchange network
performance data with other Quick Eagle Networks WAN probes on your IP
network.
The 4262 Network WAN Probe is SNMP-manageable, offers menu-driven configuration,
includes comprehensive diagnostics, and complies with industry and regulatory
standards. Additional network performance monitoring features include RMON-
1 transport protocol performance statistics and RMON-2 applications and
protocols monitoring, providing network visibility up to the application layer.
The 4262 Network WAN Probe
T1 / E1 intelligent WAN IP probe.
Main Features:
•In-line T1/E1 WAN Probe
•End-to-end IP Service Level
Verification
•Accurate and resilient
measurements
•Frame Relay, PPP, and Cisco
HDLC support
•Ethernet management port
•Embedded SNMP agent
•DiffServ monitoring
•Protocol and applications
monitoring (RMON-1, RMON-2)
•Frame Relay Service Level
Agreement FRF.13 compliant
•User level security

4262 Network WAN Probe
1xT1/E1
Nx56/64bk
p
s
E1/
FE1
Euro
p
ean Remote Sit
e
IP
AccessESSPla
IPA ESSPl
NT
U
X.21
/
WAN Probe
2 Network WA
4262 Network
N
ork W
W
Router
R
Rou
r
o
4
2
1
IP
Acce
IPA
Northern, Central & Eastern Europe
[email protected]
Southern Europe, Middle East & Africa
[email protected]
Asia / Pacific Rim
[email protected]
Latin, Central & South America
[email protected]
Canada
[email protected]
© 2007 Quick Eagle Networks. All rights reserved.
PDF/05/07
The information presented herein may change without notice
and should be used for informational purposes only. 4262 WAN
Network Probe is a trademark of Quick Eagle Networks.
Headquarters
Quick Eagle Networks (USA)
830 MaudeAvenue
Mountain View, CA94043
[phone] Phone
[phone] Fax
[email protected]
www.quickeagle.com
Access Speed
Network Interface
Network Port
Line Rate
Connector Type
Line Code
Framing
Output Level
Input Level
System Timing
Data rates
Management Connectors
COMM Port
Ethernet
WAN Protocols
Power Requirements
Voltage
Consumption
Regulatory
Diagnostics
Loopback Tests
Loopback Control
Test Patterns
NetworkAlarms
Physical
Dimensions
Weight
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
MaximumAltitude
. T1
1 T1ANSI 403 port
T1 (1.544 Mbps ± 50 bps)
100 ohm RJ-48C socket
AMI or B8ZS
D4 or ESF
0 db, -7.5 db, or -15 db LBO
0 to -26 db
Network,Aux, internal
Nx56/64 kbps (N=1 through 24)
RJ-45 socket
RJ-45 socket
PPP, Frame Relay, and Cisco-HDLC
100 VAC to 240 VAC, 50-60 Hz or -40
VDC to -72 VDC (both on the same platform)
9 W maximum
FCC Part 15, FCC Part 68, UL 1950
Third Edition, Industry Canada CS-03
VCCI Class 1 CAN/CSAC22.2 No. 950-95
T1 network, T1 payload, fractional T1
payload, loop-up/loop-down commands
T1 set/reset codes, ESF FDL per
AT&T 54016 and ANSI T1.403Annex B
1:1, 1:2, 1:4, 1:7, 3:24, QRW, all 0s, all 1s,
smart jack, two user-programmable 24-bit
patterns, bit error injection
Net carrier loss, net sync loss, netAIS
received, net yellow received, CRC,
BPV, OOF threshold
1 RU, rack mountable
22.3 cm (8.75 in ) W, x 33 cm (13 in) D, x 4.13
cm (1.63 in) H
2.27 kg (5 lbs.)
0º - 50º C
-20º - 60º C
0 - 95% non-condensing
4.6 Km (15,000 ft)
E1
1 E1 G703/G704 port
E1 (2.048 Mbps ± 50 bps)
120 ohm RJ-48C socket or 75 ohm BNC
HDB3
ITU-T G.704/CTR 12
ITU-T G.703/CTR 12
0 to 20 dB
Network, DTE,Aux, internal
Nx64 kbps (N=1 through 31) (structured),
32x64 kbps (unstructured)
RJ-45 socket
RJ-45 socket
PPP, Frame Relay, and Cisco-HDLC
100 VAC to 240 VAC, 50-60 Hz or -40
VDC to -72 VDC (both on the same platform)
9 W maximum
European harmonized standards 73/23 EEC,
91.31/EED, 89/336/EED, 93/68/EEC, and
91/263/EEC; UL 1950 3rd Ed.; CAN/CSA
C22.2 No. 950-95; Comision Federal de
Telecommunicaciones; CISPR 22 Level B
(EN 55022), RoHS compliant
E1 network, E1 payload, fractional E1
payload, loop-up/loop-down commands
E1 set/reset codes
1:1, 1:2, 1:4, 1:7, 3:24, QRW, all 0s, all 1s, two
user-programmable 24-bit patterns, bit error
injection
Loss of signal, loss of frame, remote
alarm indication, alarm indication
signal, CRC4, CV, FE
1 RU, rack mountable
22.3 cm (8.75 in ) W, x 33 cm (13 in) D, x 4.13
cm (1.63 in) H
2.27 kg (5 lbs.)
0º - 50º C
-20º - 60º C
0 - 95% non-condensing
3048 m (10,000 ft)
