R.P.S. Corporation XR 2010 User manual

seireS
Operator Manual
Model
2010 Version 1.0
R.P.S. Corporation Phone: [phone]
Mailing: P.O. Box 368 Fax: [phone]
Racine, Wi. 53401
Shipping: 1711 South st.
Racine, Wi. 53404

HOW TO USE THIS MANUAL
This manual contains the following sections:
- HOW TO USE THIS MANUAL
- SAFETY
- OPERATIONS
- MAINTENANCE
- PARTS LIST
The HOW TO USE THIS MANUAL section will tell
you how to find important information for
ordering correct repair parts.
Parts may be ordered fromauthorized dealers.
When placing an order for parts,
the machine model and machine serial number
are important. Refer to the MACHINE
INFORMATION page which is filled out during the
installation of your machine. The MACHINE
INFORMATION is located on page one of this
manual.
The serial number of your machine is located on
the lower steering pedestal of the steering
column of the machine. (See Picture Below)
The SAFETY section contains important information
regarding hazard or unsafe practices of the machine.
Levels of hazards are identified that could result in product
or personal injury, or severe injury resulting in death.
The OPERATIONS section is to familiarize the operator with the
operation and function of the machine.
The MAINTENANCE section contains preventative
maintenance to keep the machine and its components in
good working condition. They are listed in this general order:
- Batteries
- Scrub Brushes
- Adjusting Squeegee
- Service Schedule
- Machine Trouble shooting
The PARTS LIST section contains assembled parts illustrations and
corresponding parts list. The parts lists include a number of
columns of information:
- ITEM - column refers to the reference number on the
parts illustration.
- PART NO. - column lists the part number for the part.
- QTY - column lists the quantity of the part used in that
area of the machine.
- DESCRIPTION - column is a brief description of the part.
- COMMENTS - column for information not noted by the
other columns.
NOTE: If a service or option kit is installed on your machine, be
sure to keep the KIT INSTRUCTIONS which came with the
kit. It contains replacement part numbers needed for
ordering future parts.

STANDARD WARRANTY POLICY (RPS Corporation)
RPS Corporation warrants its machines, parts and accessories to be free of manufacturer’s
defects for the periods specified below. Warranty will be granted at the sole discretion of
RPS Corporation and is subject to final claim and parts review by R.P.S. Corporation and its
vendors. This policy is effective January 1, 2010 and is subject to change on production units
at a future date.
COVERAGE, EXCLUSIONS AND LIMITATIONS:
Coverage: All Models sold (Sweepers, Scrubbers, Burnishers)
Parts: 36 months / 1,500 hours on “Power On” hour meter
Labor: 12 months
Travel: 3 months (150 mile maximum)
Poly Tanks: 7 Years
OEM Parts: 3 months
Validity: Fully completed Machine Delivery Form (online or fax) is on record at RPS.
Limitation: Warranty will begin on date of machine installation to end-user or 6 months
after shipment from RPS Corp to the distributor if unsold at that time.
This warranty includes all parts on the machine except normal wear parts. Some of these
exceptions are:
1. Any Brooms, Brushes, Pads or Pad Drivers including Center Clip Retainers
2. Floor Seals, Wipers, Splash Curtains, Squeegees or Gaskets.
3. Filters, Dust Collection Bags or Screens
4. The safety pins design to fail in shear, which are a fail-safe device
5. Belts, Hoses or Tubing.
6. Caster Wheels, Tires or internal tire tubes.
7. Vacuum motors with evidence of water/foam passage or more than 450
hours
8. Lights (Strobe, Headlights or bulbs).
9. The Batteries (see below).
NOT COVERED: Routine maintenance, adjustments or parts damaged from
abuse, neglect, improper use of the machine, or lack of scheduled “daily,
weekly, monthly” maintenance in accordance with our published PM Sheets.
POLY TANKS: 7 Years Coverage against leakage due to manufacturer’s defect in materials or
workmanship. NOTE: Freight coverage for 3-Years under the parts section of warranty.
BATTERIES: Warranted through battery manufacturer for One (1) Year (prorated) from the date of
delivery. The battery manufacturer approves or denies the warranty coverage after analysis. We rely
on solely on their review. NOTE NOT COVERED: Damage from lack of water, failure to use OEM
charger, or non-distilled water.

Machine Information
Machine delivery form
Machine specifications
Common wear parts/scrub brushes
Safety messages
!!Safety precautions!!
Machine controls and features
Lcd screen menu displays
Machine setup
Attaching squeegee
Adjusting squeegee
Leveling scrub deck
Attaching brushes
Adjusting shrouds
Adjusting cylindrical side wipers
Solution system
Vacuum system
Machine operation
Draining recovery & solution tanks
Rec. Float shut off
Drain saver
Standard battery charging
Optional battery charging
On-Board charger operator manual
Changing batteries
Side broom system
Overhead guard
HD Side doors
On-board Soap
Spray hose
Vac wand
Diffuser exhaust bar
Stainless steel recovery tank
Stainless steel solution tank
Industrial battery
Removable battery box
On-Board soap
Spray hose
Vac wand
Maintenance & storing machine
Preventative maintenance records
Troubleshooting central command ii
Troubleshooting
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7-8
Page 9
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19-21
Page 22
Page 23
Page 23
Page 24
Page 25
Page 26-28
Page 29
Page 30
Page 31
Page 31
Page 31
Page 31
Page 32
Page 32
Page 32
Page 32
Page 32
Page 32
Page 33
Page 33
Page 33
Page 34-35
Page 36-37
Page 38-39
Page 40-41
Table of Contents

PAGE 1
Machine Information
Model number_____________________________________________________________
Serial number:______________________________________________________________
Installation date:___________________________________________________________
Installing dealer:____________________________________________________________
Dealer contact: ___________________________________________________________
Address:___________________________________________________________________
City, state, zip: _____________________________________________________________
Phone number:_____________________________________________________________
To register for warranty, fax your warranty registration form today! Fax # [phone]
This operator and parts manual should be considered a permanent part of the unit and should
remain with the unit at all times. This operator and parts manual covers all the XR series scrubbers.
You may find descriptions and features that are not on your particular model. The information
and specifications included in this publication were in effect at the time of printing.
R.P.S. Corporation reserves the right to make changes without notice incurring any obligation.

1-800-634-4060 Machine Install / Warranty Registration www.factorycat.com
Installing Dealer: Installed By:
Location: (City, State): Install Date:
End-User Company Name End-User Contact:
Address: City/State: Zip
Phone: Fax: Email:
Model: Serial #: Hour Meter:
BUYER’S REPRESENTATIVE HAS RECEIVED INSTRUCTION IN PROPER OPERATION OF THE FOLLOWING CONTROLS AND FEATURES:
SCRUBBERS
Filling solution tank, Solution tank sight tube, Solution drain hose or valve for flushing and freezing conditions
Adjusting controls & operation, Double scrubbing, Squeegee lift delay, vacuum switch (horn honking) and vacuum timer
Recovery tank draining & cleaning, vacuum screen removal and cleaning, drain saver basket emptied.
Shroud and pad/brush removal and installation
Side Wiper and Curtain adjustment and maintenance for water control
Solution valve and filter operation (removal and cleaning)
LCD display operation, 4 hour meters (key switch, brush, traction drive, vacuum)
Tank tilt back feature, only when both tanks are fully drained
Squeegee hose removal and checking for clogs
BURNISHERS
Train and have customer demonstrate proper removal and replacement of burnishing pad
Pad pressure gauge and proper operating range to avoid tripping the circuit breaker
SWEEPERS
Demonstrate proper removal and replacement of main broom and side brooms
Method for cleaning the dust filter, empting out the debris hopper and correct installation
Correct operation of the main broom and side broom levers, and understands to park with brushes in UP position
Trained on the “Wet-Sweep” bypass door and not to operate through standing water
ALL MACHINES
Checking battery electrolyte level and confirm monthly check that battery terminals are tight
Parking brake override
Charging operation and customer understands batteries have limited “cycles” and recharging = 1 cycle
Seat and steering wheel adjustment
Customer has read and understands the list of WARNINGS in the Operator manual
Battery and Machine Maintenance Guide posters hung up and reviewed
Manufacturer’s website is a good source of information and sign up for quarterly newsletters
In addition to the above items the buyers representative has received the operator’s manual and been advised to read the manual before
operating the machine.
Installed By (print) Signature
Buyers Representative (print) Signature
Buyer agrees to pay for any repairs, adjustments, or secondary training that manufacturer determines is excluded from the warranty.
COMPLETE AND FAX FORM TO 1-866-632-6961 or online www.factorycat.com

PAGE 3
SPECS Disk Cylindrical
BODY CONSTRUCTION
Tank Material: (3/8”) Roto-Poly (3/8”) Roto-Poly
Frame Construction: 3/16” Coated Steel 3/16” Coated Steel
Front Wheel: 12” x 4” 12” x 4”
Rear Wheel: (2) 14” x 5” (2) 14” x 5”
Body Dimensions (
L x W x H ): 69” x 36” x 59” 69” x 36” x 59”
Width (squeegee): 46”, 53” or 60” 46”, 53” or 60”
Weight (w/out batteries): 1,230 pounds 1,230 pounds
Weight (w/ standard batteries): 1,950 pounds 1,950 pounds
BRUSH/PAD SYSTEM
Brush/Pad Diameter: XR-34D - (2) 17 inches XR-34C - (2) 32” x 7.0”
XR-40D - (2) 20 inches XR-40C - (2) 42” x 7.0”
XR-46C - (2) 44” x 7.0”
Motor Power (standard): (2) 1.5 hp / 270 rpm (2) 1.5 hp /750 rpm
Brush Pressure: 0-350 pounds 0-350 pounds
Brush Pressure Settings: (1-5) automatic (1-5) automatic
A
ctuator Rating: 500 lbs. 500 lbs.
BATTERY SYSTEM
System Voltage: 36 volts 36 volts
Battery AH Rating (Standard): (6) 325 AH (6) 325 AH
Battery AH Rating (Optional): (6) 395 AH (6) 395 AH
Battery AH Rating (Industrial): (1) 440 AH/1,280 lbs (1) 440 AH/1,280 lbs
Battery Run Time: Up to 7 hours Up to 7 hours
Charger (110v / 60 Hz / auto): 36-v / 36-amp 36-v / 36-amp
SOLUTION SYSTEM
Solution Tank Capacity: 68-gallons 68-gallons
Solution Flow Rate: 0–1.5 gal/min. 0–1.5 gal/min.
Solution Filter: Stainless Inline Stainless Inline
RECOVERY SYSTEM
Recovery Tank Capacity: 68-gallons 68-gallons
Vacuum Horsepower: 1.6 hp 1.6 hp
Drain Hose: 2.0” Diameter 2.0” Diameter
Vacuum (
Water Lift / Cubic ft/min ): 68” / 140 cfm 68” /140 cfm
Demisting Chamber: 2.5 Gallons 2.5 Gallons
Drain Saver: 30 cubic inches 30 cubic inches
DRIVE SYSTEM
Standard Drive: 3 hp, Front Motor Wheel 3 hp, Front Motor Wheel
Speed Control: Variable 0-320 ft. Variable 0-320 ft.
Forward Speed: 0 – 320 ft/min 0 – 320 ft/min
Reverse Speed: 0 – 200 ft/min 0 – 200 ft/min
Minimum Aisle U-Turn: 56” 56”
Sound Level: 68 dBA 68 dBA
PRODUCTIVITY
Cleaning Width & Rate/Hour: 34” / 36,720 sq.feet / hour 34” / 36,720 sq.feet / hour
40” / 43,200 sq.feet / hour 40” / 43,200 sq.feet / hour
46” / 49,680 sq.feet / hour
R.P.S. Corporation Phone: [phone]
P.O. Box 368 Fax: [phone]
Racine, WI 53401
Copyright R.P.S. Corporation 2006. All rights reserved.
Since our policy is one of constant improvement, all
specifications are subject to change without notice.

Common Wear Parts
PAGE 4
NOTE: Squeegee blade kits include (1) Rear Blade, (1) Front Blade, and (2) Backup Wheels with harware.
NOTE: Squeegee Assemblies (complete) listed above all come with Linatex blades.
NOTE: Size is stamped into the top of the painted steel squeegee body on all squeegee's.
NOTE: The squeegee is designed for narrow isles and may not have the same water control around tight turns
as the larger squeegees.
Brush repair kit: 40-423 Replacement locating clip for all brushes.
Squeegee blade kits & Complete Squeegee assemblies
SOAP
Heavy Duty Degreaser
Citrus
Freezer
Tire Mark Remover
NOTE: # In Disk Column Denotes Pad Size: 17,20, 23
Pads Disk Level Color
Super-Black ##-422 BB Very High Black
Black ##-422 B High Black
Brown ##-422 BR High Brown
Green ##-422 G Medium Green
Blue ##-422 BL Moderate Blue
Red ##-422 R Moderate Red
White ##-422 W Light White
Squeegee size Model
34"-Cyl
34"-Disk
Model
40"-Cyl
40"-Disk
Model
46" Disk
46"- Cyl
Gum Rubber
blade kit
Linatex
blade kit
Complete
squeegee
assemblies
46" squeegee Standard N/A N/A 360-770 G 360-770 L 360-7180
53" squeegee Optional Standard Optional 370-770 G 370-770 L 370-7180
60" squeegee Optional Optional Standard 380-770 G 380-770 L 380-7180
Brushes Model
34"-Cyl
Model
40"-Cyl
Model
46"-Cyl
Super-Grit N/A N/A N/A
Tough-Grit 327-821S 387-821S 447-821S
Midi-Grit 327-821C 387-821C 447-821C
Light-Grit 327-821PS 387-821PS 447-821PS
Poly (.028) N/A N/A N/A
Nylon (.016) 327-821N 387-821N 447-821N
Brushes Model
34"-Disk
Model
40"-Disk
Model
46"-Disk
Super-Grit 17-421 SS 20-421 SS 23-421 SS
Tough-Grit 17-421 S 20-421 S 23-421 S
Midi-Grit 17-421 C 20-421 C 23-421 C
Light-Grit 17-421 PS 20-421 PS 23-421 PS
Poly (.028) 17-421 P 20-421 P 23-421 P
Nylon (.016) 17-421 N 20-421 N 23-421 N
Tampico 17-421 T 20-421 T 23-421 T
Pad Driver 17-421 D 20-421 D 23-421 D
Diamond Driver 17-421 DD 20-421 DD 23-421 DD
For more soap information call PowerCat 414-745-9337
www.powercatsolutions.com
Extra pad driver retaining clip: 40-433

PAGE 5
Your safety, and the safety of others, is very important, and operating this unit safely is an
important responsibility.
To help you make informed decisions about safety, we have provided operating procedures
and other safety information in the manual. This information informs you of potential hazards
that could hurt you or others.
It is not practical or possible to warn you of all the hazards associated with operating this
unit. You must use your own good judgment.
This is intended for commercial use. It is designed to be used on hard floors in an indoor
environment, with the recommended pads or brushes.
1. Do not operate unit:
Unless trained and authorized.
Unless operator manual is read and understood.
If unit is not in proper operating condition.
Outdoors or exposed to rain.
For picking up hazardous materials/dust.
On surfaces having a gradient exceeding 2% unless the optional
Parking brake is functioning on the machine.
2. When operating unit:
Remove loose objects from the floor that may be projected from the
revolving brushes.
Keep hands and feet away from revolving brushes.
Do not operate machine where flammable liquids are present.
Use extreme caution when maneuvering.
3. Before leaving:
Make sure machine is turned off.
Stop on level surfaces.
Disconnect batteries.
4. Before servicing:
Stop on level surface, and secure machine.
Disconnect batteries.
5. Before discarding machine:
The batteries must be removed and properly disposed of.
Safety Message

PAGE 6
!! Safety Precautions!!
Warning: Hazardous voltage. Shock, burns or
electrocution can result. Always disconnect the
batteries before servicing machine.
Warning: Batteries emit hydrogen gases, explosion or
fire can result. Keep sparks and open flames away.
Warning: Charge unit in a well ventilated area, and
keep battery compartment open when charging.
Explosion or fire could result.
Warning: Battery acid can cause burns. Wear
protective eye wear and gloves when servicing
batteries.
Warning: Do not store outdoors or pressure wash.
Prevent from getting electronic components wet.
Warning: The use of parts and solutions other than
recommended by the manufacturer may cause
damage or endanger people.
Warning: Dress safely. Do not wear rings or metal wrist
watches while working on this machine. They can
cause an electrical short, which can cause serious
burns. Do not work on this machine while wearing a
tie, scarf or other loose, dangling neckwear or
clothing. These loose items can tangle in the rotating
parts and cause serious injury or even death.
Warning: Do not use the machine as a step ladder or
chair.
Warning: Only operate this machine from the
operator's seat. It was not designed to carry
passengers.
Warning: Do not operate this machine on ramps or
uneven surfaces. When climbing a ramp, always drive
the machine in forward straight up or down the ramp.
Never drive across the incline. Do not back down or
turn on ramps!
Warning: Do not attempt to push or pull the machine
without first manually overiding the parking brake and
disconnecting both leads to the traction motor.
(See page 21 for pictures)
Warning: Always use the charger provided by the
manufacturer to charge the machine. It is an
automatic charger, specifically designed to charge
at the appropriate rate. If you must use a different
charger, disconnect the batteries before charging.
This will prevent damage to the electronic speed
controller.
Warning: Understand the dynamic braking system
before you operate the machine on ramps. Machine
does not coast. Releasing the foot pedal will
automatically apply braking force, and stop the
machine.
Warning: Do not park the machine on ramps or
slopes. The machine has a parking brake, but it is
recommended that it is always parked on level
ground.
Warning: Do not operate the machine if any parts
have been removed or damaged.
Warning: Do not remove, paint over, or destroy
warning decals. If warning decals become
damaged, they must be replaced.
Warning: Do not operate machine in unsafe
condition. If the machine is in need of repair or is in
any way unsafe to operate, the matter should be
reported immediately to the shift supervisor. Do not
operate the machine until it is returned to proper
operating condition.
Warning: This machine must only be operated by
trained operator. As part of his or her training, they
must read this manual thoroughly. If extra copies are
needed, contact your local dealer.
Warning: Always turn off the machine, before leaving
it unattended.
Warning: Do not operate over electrical floor outlets,
may result in serious injury.

PAGE 7
Machine Controls and Features
12
3
456
19
20
23
17
18
21
24
28 29 30
32
31
26
25
27
26
8
7
9
10
11 12
13
14
16
15
37
33
34 35 36
39 40
38
43
41
46
44
42
45
47
56
48 51
53
49 50
54 55
52
57 58
22

PAGE 8
Controls and Functions
1. Steering wheel: Steers the machine.
2. Adjustable seat with arm rests: Your machine is equipped with an adjustable seat with arm rests.
3. Recovery tank lid: Latch must be secured for recovery tank to seal properly.
4. Polyurethane rollers: Helps prevent damage to machine and objects you may drive close to.
5. Adjustable disk deck side wipers: Controls water on turns by directing it to the squeegee.
6. On board charger (optional): Plugs into any three pronged 20 amp dedicated outlet to charge machine
7. Horn button: Sounds the horn for warning oncoming traffic.
8. Headlight switch: Turns headlight on and off.
9. Adjustable steering: Four settings for operator comfort and ease of entry.
10. Hour meter: Keeps track of total hours of use on the machine.
11. Battery hour meter: keeps track of total hours of use on the batteries.
12. Water control lockout: locks out the solution flow control so it cannot be changed.
13. Down pressure lockout: locks out the scrub deck down pressure so it cannot be changed.
14. Serial # plate: Have machines individual serial number stamped on it.
15. Headlight: helps you see in low light areas and to warn oncoming traffic.
16. Foot pedal: Controls the acceleration and deceleration of the machine.
17. Cup holder: Holds beverage container.
18. Pre-Treat soap door: Holds (2) pre-treat soap jugs.
19. Strobe light: (optional) Warns people that the machine is in operation.
20. Recovery drain hose: Allows for controlled draining of recovery tank dirty water.
21. Site tube/ sol. drain hose: Shows how much solution is in the tank and drains the solution tank.
22. Spray hose: (optional) Permits cleaning in remote areas.
23. Squeegee/vacuum hose: Vacuumizes squeegee. Note: keep free and clear of blockage.
24. Rear bumper: Offers squeegee system protection from damage.
25. Tank latch: Permits access to tank.
26. Tie down points: Location for tie down straps during transport.
27. Squeegee rollers: Help protect the squeegee.
28. Rear Tire: Solid Tire.
29. Adjustable cylindrical deck side Wipers: Controls water on turns by directing it to the squeegee.
30. Cylindrical Deck Access Door: Provides easy access to the decks belts & pulleys.
31. Charger Port: (Grey 175) Receives charger input. (Only use OEM charger provided)
32. Side Brooms: Extends the cleaning path up to walls.
33. Recovery tank: Holds approximately 68-gallons of dirty "recovery" water.
34. Drain saver: Prevents debris from clogging drain.
35. Foam protection screen: Used to protect vacuum motor from debris.
36. Vacuum screen box: Houses the stainless vac screen & shutoff ball.
37. Solution fill port: Holds approximately 68-gallons of clean water.
38. LCD screen: Lists functions and setting of the machine. (See page 9)
39. High water recovery light (red): Indicates when the recovery tank is nearly full.
40. Low solution light (yellow): Indicates when the solution tank is nearly empty.
41. Menu control: Scrolls through different options on the LCD display.
42. Scrub deck down pressure switch: Controls the pressure put on the scrub deck.
43. Squeegee switch: Raises and lowers the squeegee.
44. Scrub deck switch: Raises and lowers the scrub deck.
45. Solution control: (-) to reduce & (+) to increase flow of solution.
46. "Uni-touch" button: Activates brushes, squeegee, and solution flow simultaneously.
47. Forward/reverse switch (red): Controls the direction of the traction motor.
48. Spray jet (blue): (optional) Activates spray pump for remote spray wand.
49. Vacuum switch (white): (optional) For use with remote vacuumwand.
50. Econ Switch:
51. Key switch: Turns the main power on and off.
52. Circuit breaker: (15 amp) positive bus bar.
53. Circuit breaker: (15 amp) negative bus bar.
54. Circuit breaker: (10 amp) side broom motors.
55. Circuit breaker: (2 amp) side broom lift actuator.
56. Side broom (yellow): lifts and lowers side brooms which turn on automatically.
57. Suds switch:
58. Emergency stop: shuts machine down in a emergency

PAGE 9
1. Battery level indicator - Indicates the energy level remaining in the batteries. (Shown on all menu displays)
2. Scrubdeck down pressure gauge - Sets the down pressure on the brushes.
3. Vacuum on - Indicates the vacuum is "on".
4. Scrub motors on - Indicates the brush motors are "running".
5. Key switch hour meter - Tells you the total hours the machine has been on.
6. Scrub brush hour meter - Tells you the total hours the brush motors have been used.
7. Transport hour meter - Tells you the total hours the drive system has been used.
8. Error warning symbol - Indicates when there has been a diagnostic code error.
9. Diagnostic code - When the machine has detected an error it will display the warning symbol
and a diagnostic code which tells you what's wrong.
10. Water on - Indicates the solution flow is "on"
11. Solution level - Indicates the gallons per minute (G.P.M) 0 - 1.0 .
(For common error codes and descriptions see pages .)
LCD Screen Menu Displays
SCREEN #3 (Maintenance)
***Use green menu selection button on control panel to change screens***
SCREEN # 1 (Operator)
SCREEN W/ERROR CODE
1
9
8
1
5
6
7
4
111 3
10
2
11 2

PAGE 10
Machine Setup
Uncrating Machine and
Connecting Batteries
1. Carefully check the crate for any signs of
damage. Batteries are in the unit.
2. To uncrate the machine, remove banding
from around the crate. Take off the top and
sides and dispose of properly.
3. Remove banding from machine. Remove
the chocks around the drive wheels.
4. Turn all switches to the off position and
remove key.
5. Tip back seat to expose the battery
compartment and check to see that the
battery cables are connected.
A standard machine is equipped with (6) 6-volt,
deep cycle, 325 ah batteries, which form a 36
volt system. Maximum battery dimensions are
7-1/8"W x 12-1/4"L x 13-1/4"H.
6. Verify that all of the battery cables are
connected to the batteries tightly. Locate any
loose ones and connect to the open terminal.
Tighten with 9/16" wrench. (DO NOT OVER
TIGHTEN!) Batteries are heavy but easily
damaged. Put covers in place. (See picture to
the left)
7. Turn on main power switch and check the
battery condition meter to ensure correct
installation.
8. Fold down ramp, and drive machine off of
the base.
Notify the carrier immediately if concealed
damage is discovered.

PAGE 11
Attaching Squeegee
1. Lower the squeegee mounting plate by
depressing the squeegee switch (A) to the
down position. (See picture below)
2. Loosen the four knobs (B) on the
squeegee and slide them into the slots in the
squeegee mounting plate. (See picture below)
3. Tighten the four knobs (B) and connect
vacuum hose (C) from the machine to the
squeegee.
(See picture below)
4. You may have to adjust the squeegee
pitch by turning the pitch adjustment knob (D).
(See picture below)
5. Note vac exhaust, dual vac out
*assists in drying (See picture above)
Removing Squeegee
1. With the squeegee in the down position, turn
key switch off & remove key.
2. Disconnect vacuum hose from squeegee and
loosen the (4) knobs.
3. Pull squeegee assembly rearward from the
lifting carrier.
4. Inspect or repair as necessary and reinstall.
Replacing or Rotate
Squeegee Blades
For safety: before leaving or servicing the
machine, stop on a level surface, turn off
machine, and remove key.
1. Remove the squeegee assembly from the
machine.
2. Loosen latch (E) and swing both retaining
straps away from squeegee to remove the
rear squeegee blade. (See picture at lower left)
3. To remove the front squeegee blade,
remove all the knobs (F) on the front of the
squeegee assembly, then remove the
retaining strap that secures the blade in place.
(See picture below)
4. Rotate the squeegee blades to new edge
position or replace as required.
5. Install blades on the locating pins of
squeegee assembly.
6. Reinstall squeegee retainer straps.
7. Retighten front knobs & rear latch.
A
DB
CE
F

PAGE 12
1. Turning adjustment knob clock-wise
(Tightening) will raise tips & lower center.
(See picture to the left)
2. This squeegee is adjusted too far back and
will not pick up on the corners. Note tips of the
blades are off the floor.
(See picture to the left)
3. This squeegee is adjusted just right with good
deflection across the entire rear blade.
(See picture to the left)
4. To adjust the squeegee trail wheels, first
loosen locking nut (A). Then turn the wheel
assembly clock-wise until it bottoms out against
the mounting plate and back it off (3) full turns.
This is a starting point for adjustment. Raise or
lower as needed. Retighten locking nut.
Adjusting Squeegee
1
A

PAGE 13
Leveling Scrubdecks
Leveling Disk Scrubdeck
1. Drive machine to a flat level surface and
turn machine off. (See picture to the left)
2. Deck should be raised off the floor.
3. With the shrouds off, measure from the ground
to a parallel surface on all four corners of the
scrubdeck. (See picture to the left)
3. If the measurements are not the same the
deck is not level and needs to be adjusted.
4. Loosen the (2) locking nuts (4) and adjust
the hexagonal arm (5).(See picture to the left)
5. Extending the adjustable arms raises the
front and lowers the rear of the scrubdeck.
Measure & Retighten. (See picture to the left)
Leveling Cylindrical
Scrubdeck
1. Drive machine to a flat level surface and
turn machine off.
2. Raise the deck off the floor.
3. Measure from the ground to a parallel edge
on all four corners of the scrubdeck.
4. If the measurements are not the same the
deck is not level and needs to be adjusted.
5. Loosen the locking nut (4) and turn the
hexagonal arm (5) on each side of the
scrubdeck to level it. (See picture to the left)
6. Extending the adjustable arm raises the
front and lowers the rear of the scrubdeck.
Measure & Retighten. (See picture to the left)
Measure from
deck to floor
Measure from
deck to floor
4
54 45
Measure from
deck to floor
Measure from
deck to floor

PAGE 14
***FOR CORRECT PAD APPLICATION , CALL YOUR LOCAL DEALER***
1. Turn "on" machine power.
2. Raise the scrub deck by depressing the
brush switch (A) to the ("0") position and turn
machine power "off". Disconnect batteries.
(See picture to the left)
3. Loosen knobs (B) and remove shrouds to access
scrub deck (See picture to the left)
4. Attach pads to pad drivers before connecting
pad drivers to motor hub. (See picture to the left)
5. Attach brushes or pads to motor hubs.
squeeze the scissor locking device (C) and lift
brush up on to the motor drive hub. Make
sure the scissors close and lock once the
brushes are on. (See picture to the left)
6. When brushes are attached put shrouds
back on machine and tighten knobs.
Attaching Disk Brushes/Pads
A
B
B
C

PAGE 15
1. The shroud must be adjusted correctly in order
to have proper water control during turns.
the front of the shroud should be slightly
higher than the rear. (See picture to the left)
2. To adjust shrouds loosen knobs (A) and
remove shroud. (See picture to the left)
3. Spin the RED shroud support (B) up or down to get
adjustments. (See picture to the left)
4. Once adjusted to the proper height put the shrouds
back on top of adjustment supports and tighten
knobs back down. (See picture to the left)
Adjusting Shrouds
A
BB

Adjusting Cylindrical Side Wipers
1. The cylindrical deck comes euipped with side wipers
for increased water control when turning.
(See picture to the left)
2. To adjust the side wipers, first loosen the locking nut
(A), then turn the adjusting screw (B) in to raise or out to
lower the height of the side wiper blade. The spring (C)
provides tension during adjustment.
(See picture to the left)
4. A properly adjusted side wiper will have slight blade
deflection on the floor when turning.
(See picture to the left )
PAGE 16
AB
C
