R.V.R. Elettronica SpA TLC2000 User manual

Manufactured by Italy
TLC2000
UserManual
LCD Version

TLC2000-UserManual
Version 1.0
© Copyright 2003
R.V.R.ElettronicaSpA
Via del Fonditore 2/2c - 40138 - Bologna (Italia)
Telefono: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.rvr.it
Allrightsreserved
PrintedandboundinItaly.Nopartofthismanualmaybereproduced,
memorized or transmitted in any form or by any means, electronic or
mechanic, including photocopying, recording or by any information
storageandretrievalsystem,withoutwrittenpermissionofthecopyright
owner.
File name: TLC2000_EN.p65
Version: 1.0
Date: 24/05/2003
Revision History
1.0 24/05//2003 New version J. Berti
Version Date Reason Editor

TLC2000
iManuale Utente Rev. 1.0- 24/05/03
Table of Contents
1. Preliminary Instructions 1
2. Warranty 3
3. First Aid 5
3.1 Treatment of electrical shocks 5
3.2 Treatment of electrical Burns 6
4. General Information 7
4.1 Configuration 8
5. Quick reference 11
5.1 Using the encoder 11
5.2 Quick reference of TLC system 12
6. System Status Enquiries 15
6.1 Local enquiries 15
6.2 Remote enquiries with remote control software 15
6.3 Remote enquiries with GSM modem + SMS 15
7. External Features 17
7.1 TLC2000 description 17
7.2 Change over card 20
7.3 Additional Standard Telemetry Card 24
7.4 Description of service connectors PIN 27
8. Identification and Access to modules 29
8.1 CPU card 29
8.2 Panel card 29
8.3 Telemetry card 30
8.4 Relay control card 31
8.5 Power supply 31
9. Card settings 33
9.1 Setting of the card internal address 33
9.2 Setting of the Dip-Switches 34
10. TLC2000 Software description 39
10.1 Flow Chart 39
10.2 GSet - General settings 40
10.3 Info - Information about system configuration 40
10.4 J.set - Optional settings 41
10.5 Alarm report 42
10.6 INP01, ..., N - Values of the boards inputs 43
10.7 OUT01, ..., N - Output Relais status 43
11. Test Board Description 45
11.1 The board 45
11.2 The meant of the clips 45
11.3 Digital/Analog Input 46

TLC2000
ii Manuale UtenteRev.1.0 -24/05/03
11.4 Rly Output 47
11.5 Connection to TLC 48
11.6 How to make the tests 48

TLC2000
1 / 50UserManual Rev.1.0 - 05/05/03
1. Preliminary Instructions
Thismanualiswrittenasageneralguideforthosehavingpreviousknowledgeand
experience with this kind of equipment, well conscious of the risks connected with
theoperationofelectricalequipment.
Itisnotintendedtocontaina complete statement of all safetyruleswhichshouldbe
observedbypersonnelinusingthisorotherelectronic equipment.
Theinstallation,useandmaintenanceof this piece of equipment involve risks both
forthepersonnel performingthemandforthe deviceitself,thatshallbe usedonlyby
trainedpersonnel.
R.V.R.Elettronica SpAdoesn’tassumeresponsibilityforinjuryor damageresulting
from improper procedures or practices by untrained/unqualified personnel in the
handlingofthis unit.
Pleaseobservealllocalcodes and fireprotectionstandardsintheoperationsof this
unit.
WARNING: alwaysdisconnect power before opening covers orremovinganypart
ofthisunit.
Useappropriategroundingprocedurestoshortoutcapacitorsandhighvoltagepoints
beforeservicing.
WARNING: thisdevicecan irradiate radio frequency waves, and ifit’snotinstalled
following the instructions contained in the manual and local regulations it could
generateinterferencesinradiocommunications.
This is a "CLASS A" equipment. In a residential place this equipment can cause
hash.Inthiscasecanberequestedtousertotakethenecessarymeasures.
R.V.R. Elettronica SpA reservesthe right to modifythedesignand/orthetechnical
specificationsoftheproductandthismanualwithout notice.

TLC2000
2 / 50 UserManualRev.1.0 -05/05/03
This page was intentionally left blank

TLC2000
3 / 50UserManual Rev.1.0 - 05/05/03
2. Warranty
AnyproductofR.V.R. Elettronica is covered by a 24(twenty-four)monthwarranty.
Forcomponentsliketubesforpower amplifiers,theoriginalmanufacturer’swarranty
applies.
R.V.R. ElettronicaSpAextendstotheoriginalend-userpurchaserallmanufacturers
warranties which are transferrable and all claims are to be made directly to R.V.R.
perindicated procedures.
Warrantyshallnotinclude:
1 damagestakenplaceduringtheshipmentofthemachinetotheR.V.R.foreventual
repairs;
2 Anyunauthorizedrepair/modification;
3 Incidental/consequentialdamagesasaresult of any defect
4 Nominalnon-incidentaldefects
5 Re-shipmentcostsorinsuranceof the unit orreplacementunits/parts
Anydamagetothegoodsmustbereportedtothecarrier in writing on the shipment
receipt.
Anydiscrepancyor damage discoveredsubsequenttodelivery, shall be reportedto
R.V.R. Elettronica within5(five)daysfromdeliverydate.
Toclaimyourrightsunder this warranty,youshold follow thisprocedure:
1 Contact the dealer or distributor where you purchased the unit. Describe the
problemand,so that a possible easy solution canbedetected.
Dealers and Distributors are supplied with all the information about problems
that may occur and usually they can repair the unit quicker than what the
manufacturercoulddo.Veryofteninstallingerrorsarediscoveredbydealers.
2 Ifyourdealercannothelpyou,contactR.V.R.Elettronicaandexplaintheproblem.
Ifitisdecidedtoreturntheunittothefactory, R.V.R. Elettronica will mail you
aregularauthorizationwithallthe necessaryinstructionstosendbackthegoods.
3 Whenyoureceivetheauthorization,youcanreturntheunit. Pack it carefully for
theshipment,preferablyusingtheoriginalpackingandsealthepackageperfectly.
Thecustomeralwaysassumesthe risks of loss (i.e.,R.V.R.isneverresponsible
fordamageorloss),until the packagereachesR.V.R.premises.Forthisreason,
wesuggestyoutoinsurethegoodsforthewholevalue.Shipmentmustbeeffected
C.I.F. (PREPAID) to the address specified by R.V.R.’s service manager on the
authorization
DO NOT RETURN UNITS WITHOUTOURAUTHORIZATIONAS THEYWILLBE
REFUSED

TLC2000
4 / 50 UserManualRev.1.0 -05/05/03
4 Besuretoencloseawrittentechnical reportwherementionallthe problemsfound
andacopyofyouroriginalinvoiceestablishingthe startingdateofthewarranty.
Replacement and warranty parts may be ordered from the following address. Be
sure to include the equipment model and serial number as well as part description
andpartnumber.
R.V.R. Elettronica SpA
Via del Fonditore, 2/2c
40138 BOLOGNA
ITALY
Tel. [phone]

TLC2000
5 / 50UserManual Rev.1.0 - 05/05/03
3. First Aid
Thepersonnelemployedintheinstallation, useandmaintenanceof thedevice,shall
befamiliarwith theory and practice of first aid..
3.1 Treatment of electrical shocks
3.1.1 If the victim is not responsive
Follow theA-B-C's of basic life support
• Placevictimflatonhis backon a hard surface.
• Openairway:liftupneck,pushforeheadback(Fig.3-1).
• clearoutmouthifnecessaryandobservefor breathing
• if not breathing, begin artificial breathing (Figure 3-2): tilt head, pinch nostrils,
makeairtightseal,fourquickfullbreaths.Remembermouthtomouthresuscitation
must be commenced as soon as possible
Figure 3-1 Figure 3-2
• Check carotid pulse (Fig 3-3); if pulse is absent, begin artificial circulation
(Fig.3-4)depressing sternum (Fig. 3-5)
Figure 3-3 Figure 3-4 Figure 3-5
• Incaseofonlyonerescuer, 15 compressions alternated to two breaths.
• Iftherearetworescuers,therythmshallbeof one brath each 5 compressions.
• Do not interrupt the rythm of compressions when the second person is giving
breath.
• Call for medical assistance as soon as possible

TLC2000
6 / 50 UserManualRev.1.0 -05/05/03
3.1.2 If victim is responsive
•Keepthemwarm
•Keep them as quiet as possible
•Loosentheirclothing (arecliningpositionisrecommended)
•Call for medical help as soon as possible
3.2 Treatment of electrical Burns
3.2.1 Extensive burned and broken skin
•Cover area with cleansheetor cloth
•Donotbreak blisters, remove tissue, remove adhered particles of clothing,or
applyanysalve orointment.
•Treat victim for shock as required.
•Arrangetransportationtoa hospital as quickly as possible.
•Ifarmsorlegs are affected keep them elevated
Ifmedicalhelp willnotbeavailablewithinanhourandthevictimisconsciousandnot
vomiting,givehima weaksolutionofsaltand soda: 1levelteaspoonfulofsalt and 1/
2levelteaspoonfulofbakingsodatoeachquartofwater(neither hot or cold).Allow
victim to sip slowly about 4 ounces (half a glass) over a period of 15 minutes.
Discontinuefluidifvomitingoccurs
DONOTgivealcohol
3.2.2 Less severe burns
• Applycool(noticecold)compressesusingthecleansedavailable cloth article.
•Do not break blisters, remove tissue, remove adhered particles of clothing, or
applysalveorointment.
•Applycleandrydressingifnecessary.
•Treat victim for shock as required.
•Arrangetransportationtoa hospital as quickly as possible
•Ifarmsorlegsareaffected keep them elevated.

TLC2000
7 / 50UserManual Rev.1.0 - 05/05/03
4. General Information
The devices of which the SCM-TLC system consists are all made in 19" 2U rack
containers,withtheexceptionoftheTLC300,whichis19" 1U size.
Entirelyassembledwith modulesfittedonthe baseofthedevice andconnectedwith
snap-infittingconnectors,theyareeasilyremoved, substituted and added.
Onthefront panelisacleargraphicaluserinterfacewhichallowsyouto readandset
theoperatingparameters; the entire system can be controlled usingasimpleknob
(encoder).
On the front panel there is also a set of LEDs, again depending on the preset
configuration,whichshowsystem status at aglance.
Ontherearpanelareall oftheconnectorstobeusedforconnectingthedevice tothe
variousstationcomponents.
TheSCM-TLCautomaticchangeoverandtelemetrysystemandrelativemanagement
softwareweredesignedto solveallofthoseproblems arising fromthemanagement
ofradiostationslocatedinareasthatarenoteasilyreachedorwhichwouldrequire
asignificantamountoftimeforthe operator to reach.
Thesystemhas thefollowingmainfunctions:
•managementof several radio stationsbyremoteconnection with a data-phone
modem;
•telemetrizationofall operatingparametersofthedevices presentineachstation;
•storageinthememoryof events which causedfaults;
•automaticchangeoverin "1+1" or "N+1" radio transmission systems.
Thissystemallows remotemanagementoftheradiostation,allowingtheoperatorto
interveneimmediatelyinthe event ofafault.
The great flexibility of the SCM-TLC system allows an increase in the number of
devices controlled or modification of the station layout at any time, without
necessitating radical changes in the management system, but simply adding
expansioncardswhichallowanincreaseinthenumberof operatingparametersthat
canbemanaged.
The SCM-TLC system was designed to operate at its best with all R.V.R. devices,
butcanalsofunctionwithdevicesnotmadebyR.V.R.,providedthattheymakethe
mainoperatingparametersavailableexternallybymeansofanalogsignalswithvalues
between 0 and +5V.
Themanagementsoftwarehasauser friendly interface and canbemanagedusing
anypersonalcomputer withtheWINDOWS™environment.

TLC2000
8 / 50 UserManualRev.1.0 -05/05/03
4.1 Configuration
TheSCM-TLC system has twomaintypesof operation, within which theremaybe
variousversions,dependingonthe numberofdata acquisitioncardsfitted:automatic
changeover(1+1or N+1) and telemetry,orjust telemetry.
4.1.1 Automatic change over and telemetry
Twotypesofdevicescontrolthistypeofoperation:
•SCM1+1-LCD:automaticchangeoverbetweenthemaintransmitterandastand-
bytransmitter;supportsupto3additionaltelemetrycardsforatotalof30balanced
analoginputs,58digital/analoginputsand24relay outputs.
•SCM4+1-LCD:automatic change over among several main transmitters (upto
4)andastand-bytransmitter,automaticallyconfiguredtosubstitutethetransmitter
affected by the fault (the stand-by must have an external control for setting the
operatingfrequency);supports up to2additionaltelemetrycards, foratotalof27
balancedanalog inputs,52unbalanceddigital/analoginputsand16relay outputs.
4.1.2 Telemetry
Two devices are available for station telemetry, depending on complexity and the
numberofparameterstobe acquired:
•TLC300:includes2telemetrycards,foratotalof16balancedanaloginputs, 32
digital/analoginputsand16relayoutputs.
•TLC2000:supportsupto 6 additional telemetry cards, for a total of 48balanced
analoginputs,96unbalanceddigital/analoginputs and 48 relay outputs.
ThetablebelowsummarizesallpossibleSCM-TLCsystemconfigurations.

TLC2000
9 / 50UserManual Rev.1.0 - 05/05/03
Device Type Version bal. IN dig./an. IN OUT rly
SCM1-LCD SCM 1+1 & TLM T0 6 10 0
SCM1-LCD SCM 1+1 & TLM T1 14 26 8
SCM1-LCD SCM 1+1 & TLM T2 22 42 16
SCM1-LCD SCM 1+1 & TLM T3 30 58 24
SCM4/1-LCD SCM N+1 & TLM T0 11 20 0
SCM4/1-LCD SCM N+1 & TLM T1 19 36 8
SCM4/1-LCD SCM N+1 & TLM T2 27 52 16
TLC300 TLM T1 8 16 8
TLC300 TLM T2 16 32 16
TLC2000 TLM T0 (*) 0 0 0
TLC2000 TLM T1 8 16 8
TLC2000 TLM T2 16 32 16
TLC2000 TLM T3 24 48 24
TLC2000 TLM T4 32 64 32
TLC2000 TLM T5 40 80 40
TLC2000 TLM T6 48 96 48
(*)Externalcommunications managementonly.
The version's name depends on the number of additional telemetry cards and is
indicated by the number after the "T" (e.g.: T0 indicates that there are no telemetry
cards,T1indicates that one additional telemetry card is fittedandsoon).
SCM1+1\T0 SCM1+1\T1
SCM1+1\T2 SCM1+1\T3
SCM4+1\T0 SCM4+1\T1
SCM4+1\T2

TLC2000
10 / 50 UserManualRev.1.0 -05/05/03
TLC2000\T0 TLC2000\T1
TLC2000\T2 TLC2000\T3
TLC2000\T4 TLC2000\T5
TLC2000\T6
TLC300\T0 TLC300\T1
TLC300\T2

TLC2000
11 / 50UserManual Rev.1.0 - 05/05/03
5. Quick reference
Thepurposeofthischapter is to summarizethepointsthatshouldbeadhered to for
using the machines. Should any point not be fully comprehensible, such as how to
operatethemachinethe firsttime,thedescriptionof the operatingsystemshouldbe
readverycarefully.
5.1 Using the encoder
Theinteractionbetweentheuserandthecontrolsoftware of the device takes place
bymeansoftheencoder.
Thefollowingoperationsareperformedontheencoder:
•turning:to movethecursorup ordownonthedisplay;turnthe encodertotheleft
tomovethecursordown,totherighttomovethecursorup.Alsousedforincreasing
or decreasing the selected parameters (to the left to decrease the value, to the
right to increase it) and for selecting an item from a list of options
•pressing: press the button once when the cursor is pointing to the name of a
menu to access that menu, press the button when the cursor is pointing to a
parametertoaccess the change mode (the cursor beginstoblink).After having
changedaparameter,pressthebuttonto store the new value.
Afterhavingchangedaparameter, thecursorkeepsblinking foraboutthirtyseconds
waitingforconfirmation.Iftheuserdoesnotconfirm thechange,the machineemitsa
soundtowarn theuserthatthechange wasnotconfirmed.As such,thecursorstops
blinkingandpointstothe selected parameter.
Ruotare l’encoder verso sini-
straperspostareil cursorever-
so il basso, per decrementare
il valore di un parametro o per
selezionareunelementodiuna
Ruotarel’encoderversodestra
per spostare il cursore verso
l’alto, per incrementare il valo-
re di un parametro o per sele-
zionare un elemento di una li
Premere il pulsante una volta per entrare
nel menù desiderato, quindi una seconda
volta per modificare il parametro selezio

TLC2000
12 / 50 UserManualRev.1.0 -05/05/03
5.2 Quick reference of TLC system
5.2.1 Preliminary settings
Beforeusingtheequipmentwithamodemitisnecessarytoexecutesomeoperations:
• SettheDIP-SWITCH(seethe table);
• Modem type absent DIP 1 and 2 OFF;
• 9600bps serial speed DIP 3 OFF, DIP 4 ON;
• Address 1 DIP 5 ON.
• Serialconnectionthrough Collegamentoserialetramiteprogramma“TELECON”
esalvataggiodelleimpostazionidiconfigurazioneall’interno del TLC.
Description 123456781234567812345678
None
PSTN X
PAGER X
GSM X X
1200
2400 X
9600 X
19200 XX
Address XXXXXX
Iic board n° XXXXXX
Generic
Pj X
Vj X
0
+1 X
+2 X
+3 XX
+4 X
+5 XX
+6 XX
+7 XXX
D.all.stand X
D.all.gen X
Vis.allarm.rel X

TLC2000
13 / 50UserManual Rev.1.0 - 05/05/03
5.2.2 Alarm condition
Incaseofanalarm, the TLC limits to the remote and local signalling of thedamage
found.
5.2.2.1 Alarmtype0
Thistypeofalarmhappens on the climb foreheadofthevoltagepresentattheinput
correspondentonthe telemetrycard,comestherefore generatedanalarmmessage
thatcomesmemorizedlocallyand comes subsequently sended,throughamodem,
tothenumbersandinthe modalities indicated from the carried out programming.
5.2.2.2 Alarmtype1
Analogousthistypeofalarmhappensonthereductionforeheadofthevoltagepresent
attheinputcorrespondentonthetelemetrycard,comesthereforegeneratedanalarm
messagethatcomesmemorizedlocallyand comessubsequentlysended,through a
modem, to the numbers and in the modalities indicated from the carried out
programming.
5.2.2.3 Audiosignalmissing(PTX-LCD only)
Theaudiosignalpresencecontrol is carried outonlyiftheexciterofthetransmitters
is a PTX-LCD series exciter comes, therefore, generated an alarm message that
comesmemorizzatolocally and comessubsequentlysendedthrough modem tothe
numbersandinthemodalitiesindicated from the carried out programming.
5.2.2.4 I2Cbusalarms
Thecontrolonthepresenceofalarmscomes made only in the case ispresentLCD
equipments comes therefore generated a message alarm that comes memorized
locallyandcomessubsequentlysendedthrough amodemtothe numbersandinthe
modalitiesindicatedfrom the carried out programming.
5.2.2.5 Defaultcodes
Thecodesofalarmof default are reassumed in the table.
CODE Indicazione Significato
000 Forward Power Potenza diretta (lettura analogica)
001 Reflected Power Potenza riflessa (lettura analogica)
≥002 ≤011 Allarmi generali programmabili dall’utente
012 RISERVATO RISERVATO
013 No Audio Assenza del segnale audio
014 Mod Fault Avaria Moduli I2C
015 Restart Riavvio del sistema

TLC2000
14 / 50 UserManualRev.1.0 -05/05/03
5.2.3 Alarms signalling
TheTLCmarksthemalfunctioningsituationsinlocallyandinremote,sendingaseries
of messages with modalities that depend on the modalities indicated in the carried
outprogramming.
5.2.3.1 Localsignalling
• Ifsetup,itexcites the relay 8 of theAdditionalcard.
5.2.3.2 Remotesignallingwithtelephonemodem
• The TLC calls in sequence all the telephone numbers sets up to you and
communicates the code and alarm description (from the other part must be
connected a PC with the TELECON software in stand-by or a communication
programthatattended messagesfromthemodem).
• TheTLCrepeats the seriesofcallsforothers many timesandforallthe numbers
indicatestoyouinthecarried out programming.
5.2.3.3 RemotesignallingwithmodemGSM
• TheTLCcallsinsequence all thetelephonenumbersmemorizedinthememory
andcommunicatesthecodeand alarm description (from the other part must be
connected a PC with the TELECON software of telecontrollo in stand-by or a
programofattendedcommunicationinofmessages from the modem).
• TheTLCsendes the same message in SMS formattothenumbersmemorized
to you through the Serivce Center of GSM manager and repeats the series of
callsforothersmanytimesandforallthenumbersindicatesfromyouinthecarried
outprogramming.

TLC2000
15 / 50UserManual Rev.1.0 - 05/05/03
6. System Status Enquiries
6.1 Local enquiries
TheSCMand TLC2000 devicesindicatetheirstatus locally andconciselybymeans
oftheindicatorlights on the front panel. More detailed information canbeobtained
fromthesettingand configuration menus.
6.2 Remote enquiries with remote control software
APCwiththeTelecontelemetryandremotecontrolsoftwarecanbeused to obtain a
verydetailedviewofallsystem operating parameters and of all the settings both of
theequipmentandthedevicesconnectedtosaidequipment.
6.3 Remote enquiries with GSM modem + SMS
AnyGSMmobiletelephonecanbeusedtoquerythedeviceswiththissystem.The
devicewillrespondasoutlinedinthe tables in the sections below.
Beforequeryingthesystembymeans ofSMSmessages,youmustbeconnected by
meansofthe"TELECON"programandsetthenumberoftheselectedphoneService
Centeraswellasthetelephone numbers that can send thistypeofcommandtothe
devices.
6.3.1 List of SMS messages that can be sent to TLC devices
Inviare: Risposta:
INFO
TLC ID: 000 Nome Stazione
FWD 0%
RFL 0%
TX ON / TX OFF
Audio absent / present
Alarm Standard Disable / Alarm General Disable / All Alarm Disable / All
Alarm Enable
Alarm Present / Alarm Not Present
ALARM TLC ID: 000 Nome Stazione Lista Allarmi in memoria
TXONn TLC ID: 000 Nome Stazione TX is ON
TXOFFn TLC ID: 000 Nome Stazione TX is OFF
OUTONn TLC ID: 000 Nome Stazione OUT is ON / Out Not Exist
OUTOFFn TLC ID: 000 Nome Stazione OUT is OFF / Out Not Exist
OUTIMPn TLC ID: 000 Nome Stazione Impulse OK / Out Not Exist
RESETMOD
RESET TLC ID: 000 Nome Stazione ALL RESET

TLC2000
16 / 50 UserManualRev.1.0 -05/05/03
This page was intentionally left blank
