Fujitsu Siemens Computers PRIMERGY econel 20 User manual

PRIMERGY
.com Operating Manual
PRIMERGY econel 20
English

Are there ...
... any technical problems or other questions which you would like to be clarified?
Please contact:
·your sales partner
·your sales outlet
Further information can be found in the "Safety, Warranty and Ergonomics" booklet.
The latest information on our products, tips, updates, etc., can be found on the internet under:
http://www.fujitsu-siemens.com

Herausgegeben von/Published by
Fujitsu Siemens Computers GmbH
Bestell-Nr./Order No.: A26361-K831-Z101-1-7619
AG 02/02
A26361-K831-Z101-1-7619
PRIMERGY econel 20 OPERATING MANUAL

PRIMERGY econel 20
Operating Manual
Introduction
Important notes
Preparing for Use
Operation
Troubleshooting and tips
System expansions
Technical data
Index
January 2002 edition

Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft
Corporation.
VESA and DPMS are trademarks of Video Electronics Standards Association.
PS/2 is a registered trademark of International Business Machines, Inc.
Pentium is a registered trademark of Intel Corporation, USA.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright ãFujitsu Siemens Computers GmbH 2001
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de

A26361-K831-Z101-1-7619
Contents
Introduction .....................................................................................................................................1
Notational conventions ......................................................................................................................1
Important notes ...............................................................................................................................3
Safety ................................................................................................................................................3
Manufacturer’s notes .........................................................................................................................3
Energy saving............................................................................................................................3
Disposal and recycling...............................................................................................................4
CE marking................................................................................................................................4
FCC Class B Compliance Statement .........................................................................................5
Transporting the server......................................................................................................................6
Cleaning the server............................................................................................................................6
Preparing for Use ............................................................................................................................7
Unpacking and Checking the Delivery ...............................................................................................7
Steps for initial setup .........................................................................................................................7
Setting up the server .........................................................................................................................8
Connect the monitor, mouse and keyboard .......................................................................................8
Connecting the keyboard ...........................................................................................................8
Connecting the mouse...............................................................................................................9
Connecting the server to the mains voltage .....................................................................................10
Initial switch-on: Software will be installed .......................................................................................12
Switching on monitor and server..............................................................................................12
Installing the software..............................................................................................................14
Connecting external devices............................................................................................................15
Connections on the system unit...............................................................................................16
Connecting external devices to the serial port..........................................................................17
Connecting external devices to the parallel port.......................................................................17
Operation .......................................................................................................................................19
Switching on the server ...................................................................................................................19
Switching off the server ...................................................................................................................20
Indicators on the system unit...........................................................................................................21
Keyboard .........................................................................................................................................22
Important keys and key combinations......................................................................................22
Working with floppy disks ................................................................................................................24
Settings in BIOS Setup....................................................................................................................24
Property and data protection............................................................................................................25
Anti-theft protection..................................................................................................................25
Access protection under Windows ...........................................................................................25
BIOS Setup security functions .................................................................................................26
Access protection with SICRYPT server Lock .........................................................................26
Troubleshooting and tips..............................................................................................................29
Installing new software ....................................................................................................................29
Power-on indicator remains unlit after you have switched on your device........................................29
The screen stays blank............................................................................................................30
No mouse pointer displayed on the screen......................................................................................31
The floppy disk cannot be read or written ........................................................................................31
Time and/or date is not correct ........................................................................................................32
Error messages on the screen.........................................................................................................32
Restoring the hard disk contents .....................................................................................................32
Tips .................................................................................................................................................32

Contents
A26361-K831-Z101-1-7619
System expansions....................................................................................................................... 35
Information about boards ........................................................................................................35
Opening the system unit ................................................................................................................. 36
Assembling the system unit ............................................................................................................ 37
Installing and removing a board ...................................................................................................... 37
Installing a board..................................................................................................................... 38
Removing a board................................................................................................................... 39
Installing and removing drives......................................................................................................... 40
Installing an accessible drive................................................................................................... 40
Removing an accessible drive................................................................................................. 42
Changing the floppy disk drive ................................................................................................ 43
Replacing a hard disk drive .....................................................................................................45
Extensions to the system board ...................................................................................................... 47
Upgrading main memory ......................................................................................................... 47
Replacing lithium battery ......................................................................................................... 47
Replacing processor................................................................................................................ 48
Technical data ............................................................................................................................... 49
Index .............................................................................................................................................. 51

A26361-K831-Z101-1-7619 1
Introduction
This operating manual tells you how to put your server into operation and how to operate it in daily
use. The Operating Manual applies for all configuration levels. Depending on the configuration level
chosen some of the hardware components described may not be available on your server. Please
observe the notes on your operating system.
You can incorporate operable drives (for example DAT drive) as well as other boards.
Depending on the configuration selected, the operating system is preinstalled on your hard disk (e.g.
Windows 2000).
Your server has a number of security features to ensure that no unauthorised persons can access
your data, for example, you can activate a screen saver with password protection. For example, you
can activate a screen saver with password protection. The security functions in the BIOS Setup also
allow you to protect your data by means of passwords. Systems with a SmartCard reader offer
additional protection.
Further information on this server is provided:
·in the "Safety, Warranty and Ergonomics" booklet
·in the operating manual for the monitor
·in the technical manual for the system board
·in the "BIOS Setup" manual
·in your operating system documentation
·in the information files (e.g. *.TXT,*.DOC,*.WRI,*.HLP)
i
Some of the manuals listed can be found on the "Drivers & Utilities" CD provided with
your computer. These manuals can be read and printed with Acrobat Reader, also
contained on the "Drivers & Utilities" CD.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!indicates information which is important for your health or for preventing physical damage.
i
indicates important information which is required to use the system properly.
ÊText which follows this symbol describes activities that must be performed in the order shown.
Text in this typeface indicates screen outputs.
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters or terms.

A26361-K831-Z101-1-7619 3
Important notes
In this chapter you will find information regarding safety which is essential to take note of when
working with your server. The manufacturer's notes contain helpful information on your server.
Safety
!Pay attention to the information provided in the "Safety, Warranty and Ergonomics"
booklet and to the following notes.
During installation and before operating the device, please observe the instructions on
environmental conditions in the chapter entitled "Technical data" as well as the
instructions in the chapter "Preparing for Use".
Please check whether the device is correctly set for the local power supply (see
"Preparing for Use" chapter).
The main switch and the ON/OFF switch do not disconnect the system unit from the
mains voltage. To completely disconnect the mains voltage, remove the power plug from
the grounded mains outlet.
Replace the lithium battery on the system board in accordance with the instructions in the
"System expansions - Replacing lithium battery" chapter.
Caution: components in the system can get very hot.
Manufacturer’s notes
Keep this operating manual together with your device. If you pass on the device to third parties, you
should include this manual.
Energy saving
When the server is delivered, some energy-saving functions are already set (see the technical
manual for the system board or the "BIOS Setup" manual).
·If you are not using your server, switch it off.
·In the BIOS Setup you may set further energy-saving functions for the server (see the technical
manual for the system board or in the manual "BIOS Setup").
·Depending on the operating system, you can set additional power-management features.
Energy saving under Windows 9x
The Screen Saver tab allows you to set further energy saving functions for your screen. Select the
following item in the menu: Start - Settings - Control Panel - Display - Display Properties - Screen Saver -
Energy saving features of monitor.
With the default setting Control Panel - Power - Advanced additional energy saving features of
Windows 9x are available.

Important notes Manufacturer’s notes
4A26361-K831-Z101-1-7619
Energy saving under Windows 2000
The Screen Saver tab allows you to set energy-saving functions for your screen. Select the following
item in the menu: Start - Settings - Control Panel - Display - Display Properties - Screen Saver - Energy
saving features of monitor.
With the default setting Control Panel - Power Options - Advanced additional power management
features of Windows 2000 are available.
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The device may be taken
back after use to be recycled, provided that it is returned in a condition that is the result of normal
use. Any components not reclaimed will be disposed of in an environmentally acceptable manner.
Devices protected by a 36 month warranty from Fujitsu Siemens meet the
requirements of the eco-label "Blauer Engel". The warranty starts on the day
of delivery (sale date) by Fujitsu Siemens Computers or a Fujitsu Siemens
affiliate.
The repair of a device displaying the eco-label is secured for at least 5
years from the date of purchase.
Further information about eco-label products can be found on the Internet
under www.blauer-engel.de.
Do not throw lithium batteries into the household waste. They must be disposed of in accordance
with local regulations concerning special waste.
If you have any questions about disposal of the batteries or system, please contact your local sales
outlet or:
Fujitsu Siemens Computers GmbH
Recyclingcenter
D-33106 Paderborn
Tel.: [phone]
Fax: [phone]
CE marking
The shipped version of this device complies with the requirements of the EEC directives
89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage directive".

Manufacturer’s notes Important notes
A26361-K831-Z101-1-7619 5
FCC Class B Compliance Statement
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital device,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-
Causing Equipment Regulations. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in strict accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
·Reorient or relocate the receiving antenna.
·Increase the separation between equipment and the receiver.
·Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
·Consult the dealer or an experienced radio/TV technician for help.
Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused
by unauthorised modifications of this equipment or the substitution or attachment of connecting
cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The
correction of interference caused by such unauthorised modification, substitution or attachment will
be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC rules.

Important notes Transporting the server
6A26361-K831-Z101-1-7619
Transporting the server
!Transport all parts separately in their original packaging or in a packaging which protects
them from knocks and jolts, to the new site. Do not unpack them until all transportation
manoeuvres are completed.
Never drop the monitor (risk of implosion)!
Cleaning the server
!Turn off all power and equipment switches and remove the power plug from the mains
supply.
Do not clean any interior parts yourself, leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
Ensure that no liquid enters the system.
Ensure that the ventilation areas of the system unit and the monitor are free.
Cleaning the system unit and the monitor
Wipe the system unit and monitor casing with a dry cloth. If particularly dirty, use a cloth that has
been moistened in mild domestic detergent and then carefully wrung out.
Cleaning the keyboard and the mouse
Use disinfectant wipes to clean the keyboard and the mouse.
The mouse mechanism and the mouse ball can be cleaned by removing the retaining ring on the
underside of the mouse.
i
Additional information can be found in the documentation for your keyboard and mouse.

A26361-K831-Z101-1-7619 7
Preparing for Use
!Please take note of the safety information in the "Important notes" chapter.
Unpacking and Checking the Delivery
It is recommended not to throw away the original packaging material! It may be required for
reshipment at some later date.
ÊUnpack all the individual parts.
ÊCheck the delivery for damage incurred during transportation.
ÊCheck whether the delivery agrees with the details in the delivery note.
Should you discover that the delivery does not correspond to the delivery note, notify your local
sales outlet immediately.
Steps for initial setup
First-time setup includes the connection of the monitor, mouse and keyboard to the system unit and
the setup of the supplied software.
i
External devices
If you have received other devices in addition to your server (e.g. a printer or a modem),
do not connect these until after the initial installation. The following sections contain a
description of how to connect these external devices: "Connecting external devices to the
serial port" and "Connecting external devices to the parallel port".
Drives and boards
If you have received drives or boards with your server, please do not install them until
after first-time setup. How to install drives and boards is described in the chapter "System
expansions".
Perform the following steps in the prescribed order:
1. Decide where you are going to use the server, and then set it up.
2. Connect the monitor, mouse and keyboard to the server.
3. Check the rated voltage of the server and connect it to the mains voltage.
4. Switch the server on and follow the instructions on the screen.

Preparing for Use Setting up the server
8A26361-K831-Z101-1-7619
Setting up the server
!When installing your server, give consideration to the recommendations and safety notes
in the "Safety, Warranty and Ergonomics" booklet.
Set up the server only in its correct orientation. The points to observe are illustrated on the
following pages.
We recommend that you place your equipment on a surface with good anti-slip qualities.
In view of the multitude of different finishes and varnishes used on furniture, it is possible
that the rubber feet of the devices will mark the surface they stand on.
Do not expose the server to extreme environmental conditions (see chapter "Technical
data") and protect it from dust, humidity and heat.
Provide at least 200 mm of clearance on the left, in front of and behind the ventilator area
of the system unit to ensure adequate ventilation. Do not cover the ventilation areas of the
monitor and the system unit.
Do not place several system units one above the other.
Connect the monitor, mouse and keyboard
The ports for monitor, mouse and keyboard are on the rear and on the front of the system unit.
PS/2 keyboard port / purple PS/2 mouse port / green
Monitor port / blue USB port / black
Connecting the keyboard
Depending on the equipment level selected, your server will be supplied with a standard keyboard or
a USB keyboard.
Connecting standard keyboard
Use the supplied keyboard cable only.
ÊPlug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
ÊPlug the round keyboard cable connector into the port marked with this symbol on the
system unit.
Connecting USB keyboard
Use the supplied keyboard cable only.
ÊPlug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
ÊInsert the rectangular USB plug of the keyboard cable into the USB port on the system
unit.

Connect the monitor, mouse and keyboard Preparing for Use
A26361-K831-Z101-1-7619 9
Connecting the mouse
Depending on the equipment level selected, your server will be supplied with a PS/2 mouse or a
USB mouse.
Connecting a PS/2 mouse
ÊConnect the PS/2 mouse to the PS/2 mouse port on the system unit.
Connecting USB mouse
ÊConnect the USB mouse to the USB port on the system unit.
i
If you do not attach a mouse at the PS/2 mouse port , you can disable the mouse
controller in the BIOS Setup in order to free the IRQ12 for a different application.

Preparing for Use Connecting the server to the mains voltage
10 A26361-K831-Z101-1-7619
Connecting the server to the mains voltage
100 V - 127 V
200 V - 240 V
100 V - 127 V 200 V - 240 V
aa
a = Notch for inserting the screwdriver
If the power supply of your server does not have a slide-in or plug-in element for setting the rated
voltage, then your system automatically sets itself to the local rated voltage. If you have a server
with a slide-in or plug-in element, then you must match the set rated voltage to the local rated
voltage.
ÊCheck the voltage setting.
!Devices with main power switch:
The value indicated with an arrow must be compatible with the local rated voltage:
115 = 100 V to 127 V 230 = 200 V to 240 V
If the voltage setting is incorrect, then lift out the manual voltage adjuster with a
screwdriver (1), turn it to the required setting and reinsert it.
Devices without main power switch:
The visible value must agree with the local mains voltage:
115 = 100 V to 127 V 230 = 200 V to 240 V
If an incorrect mains voltage is set, push the slide switch all the way into the other
possible position with a pointed object.

Connecting the server to the mains voltage Preparing for Use
A26361-K831-Z101-1-7619 11
2
1
ÊPlug the system unit's power cable into the system unit (1) and then into the grounded mains
outlet (2).

Preparing for Use Initial switch-on: Software will be installed
12 A26361-K831-Z101-1-7619
Initial switch-on: Software will be installed
If the server is connected to a network, the network protocol is required as well as the user and
server details. Contact your network administrator if you have any questions about these settings.
When you switch on your server for the first time, the supplied software is installed and configured.
You should plan some time for this, as this process must not be interrupted.
!Once the installation has been started the server must not be switched off!
During installation the server may only be rebooted when you are requested to do so!
Otherwise the installation will be not be performed correctly. If a fault occurs during the
installation, the contents of the hard disk must be completely restored.
You may need the licence number for Windows during the installation. This number is located on a
sticker on your server.
Switching on monitor and server
ÊSwitch the monitor on (see the operating manual for the monitor).
ÊSwitch the server on. To do this, follow the instructions below.
i
Depending on the version, your server is equipped with a main power switch on the back
of the casing in addition to the power button on the front. This differentiates between the
ways to switch on both server versions.
