R.V.R. Elettronica BRAVO-RX Parts list manual

1 - IF SAMPLER 10,7MHz OUT 0dBm
2 - POWER SUPPLY CORRECT OPERATION YELLOW INDICATOR
3 - PLL LOCK FREQUENCY CONTROL CORRECT OPERATION CIRCUIT GREEN INDICATOR
4 - PRESENCE OF RF SIGNAL AT PROPER LEVEL AND FREQUENCY AT INPUT RF CONNECTOR
GREEN INDICATOR
5 - EARPHONE LEVEL ADJUSTING
6 - MUTING TRESHOLD ADJUSTING
7 - EARPHONE 6,3 mm MONITORING JACK CONNECTOR
8 - 9 - THESE PUSHBOTTONS ALLOW TO SELECT ON LCD DISPLAY THE FOLLOWING MENU:
- display parameters
- password
- change of receiving frequency
10 - LCD MULTIMETER DISPLAY SHOWING:
- operational frequency
- deviation of receiving signal
- signal strenght
TITLETITLE
DATEDATE DRAWING NO.DRAWING NO.
FM LINK RECEIVER mod. BRAVO RX
front panel layout
12-2020 RVR Link Receiver front layout.cdr
FM STL RECEIVER
FRONT PANEL LAYOUT
11
22
33
44
55
6677
88
991010

MAINS 110-220 VAC AC FUSE 1A
INTERLOCK MPX OUT
MONO RF
INPUT
SCA 2 SCA 1
RANGE MHz
S.N.
CE !
1 - MAINS SUPPLY CONNECTOR
2 - AC FUSE 1A
3 - FAN
4 - DB 9 PIN INPUT / OUTPUT CONNECTOR FOR TELEMETRY ( opt.01 )
5 - BNC FEMALE FOR CONNECTION OF THE INTERLOCK LOOP -
THE CONNECTION GOES TO GROUND WHEN MUTE IS ON
6-7- BNC FEMALES FOR SUBCARRIERS OUTPUTS
8-9- SCA OUTPUT ADJUSTING LEVELS
10 - XLR FEMALE BALANCED MODE MONO AUDIO OUTPUT
11 - MONO OUTPUT ADJUSTING LEVEL
12 - BNC FEMALE FOR THE COMPOSITE MPX OUTPUT
13 - MPXOUTPUT ADJUSTING LEVEL
14 - N FEMALE FOR RF INPUT SIGNAL
I/O
RS232
FUSE
FUSE
11
22
334455
6677
8899
1010
1111
1212
1313 1414
FM LINK RECEIVER
REAR PANEL LAYOUT
TITLETITLE
DATEDATE DRAWING NO.DRAWING NO.
FM LINK RECEIVER mod. BRAVO RX
rear panel layout
12-2020 RVR Link Receiver rear side layout.cdr

BRAVO-RX
&
BRAVO-TX
USAGE INSTRUCTION

Connected a 50 Ωload or 50 Ωantenna to the RF output, connect the
equipment into a mains supply (100÷240 VAC) with earth point. The
transmitter equipment is factory pre-set to 0.0 W.
Switch ON the power switch and the yellow V POWER led will light.
The Display will show:
After 3 seconds the green PLL LOCK led will light and the Display will
show an increasing bar, after a further 5 seconds the green ON AIR led
will light and there will be output power.
At this point the Display will show the next parameter for the transmitter:
•Level Modulation (MOD > );
•Forward Power (FRW 5.0W);
•Reflected Power (RFL 0.1W);
instead for the receiver:
•Level Modulation (MOD > );
•Level Signal(50dBuV).
WAIT
SELECT
SET
WAIT
SELECT
SET
MOD >
FRW 8.0W RFL 0.0W
SELECT
SET

To display the frequency push the SET key.
In order to display the parameter push the SELECT key.
Display Password
The Password mode is factory set to enable, and is not possible change
this SET.
The default password is 1 2 3.
The WAIT of changing the password is as follows:
•Press for 3 seconds the SELECT key;
•Press the SELECT key for move the underscore character position at
the required digit, and press the SET key to confirm the digit.
Carry out the same operation for the two remaining digits.
•If the password is corrected press SET key to confirm, otherwise
press SELECT key to leave the choice.
PASSWORD
0 1 2 3 4 5 6 7 8 9
SELECT
SET
PASSWORD
0 1 2 3 4 5 6 7 8 9
SELECT
SET
*
PASSWORD
0 1 2 3 4 5 6 7 8 9
SELECT
SET
***
MOD >
SGN 50dBuV
SELECT
SET

If the password is not corrected an error is displayed:
After few seconds display will show again the parameters.
•When the password is corrected the display will show:
To change the password press the SET key.
To change the frequency press the SELECT key.
•For changing the password proceed at the same method for the
required password:
The confirmation password will be required.
If the password is corrected the display will show:
CONFIRM (Y/N) ?
N=SEL. Y=SET.
SELECT
SET
NEW PASS . = SEL .
NEW FREQ . = SET .
SELECT
SET
ERROR
PASSWORD
SELECT
SET
NEW PASSWORD
0 1 2 3 4 5 6 7 8 9
SELECT
SET
CONFIRMATION
0 1 2 3 4 5 6 7 8 9
SELECT
SET

If the confirmation password is wrong the display will show:
IMPORTANT NOTE
! BE CAREFULLY !
Once the password is set, it must be remembered otherwise neither can
the frequency be changed or a new password entered.
Display Change of Frequency.
•Press 3 seconds the SELECT key and put the correct password, at
this point press again the SELECT key:
•Press the SELECT key to change the digit and press the SET key to
confirm the digit.
The underscore character move the position one place to the left.
STORED
NEW PASSWORD
SELECT
SET
ERROR
CONFIRMATION
SELECT
SET
NEW PASS . = SEL .
NEW FREQ . = SET .
SELECT
SET
FREQUENCY ?
MHz XXX.000
SELECT
SET

When the five digit is changed the further press SET key confirm the
new frequency.
At this operation follows the WAIT cycle and after this the display will
show the parameters:
After 7 minutes the display light switch off and the display will show:
MOD >
FRW 8.0W RFL 0.0W
SELECT
SET
R.V.R.
MHz XXX.000
SELECT
SET

Environmental conditions for the installation
Each equipment produced by our Company has been carefully designed
and tested in compliance with the European normative.
The reported marks placed in the rear panel and in the manual are
relevant to the tests realized on the equipment according to rigorous
safety criteria advised by the Country where the equipment will operate.
Some tests require that the equipment is able to stand specific very
severe environmental conditions for a brief period of time.
Although the equipment is actually able to operate properly even under
severe conditions they haven’t to be considered as regular and
therefore cannot be applied neither permanently nor for long periods.
The manufacturer has designed the equipment for lasting duration
provided it operates under correct environmental conditions.
In other words the equipment can stand extreme environmental
conditions for a limited period of time at the same time operating in
compliance with the quality figures advised in the technical data-sheet.
In case the equipment is expected to operate under very critical
conditions which have been previously advised by the end user upon
his request the design of the equipment will be then reconsidered to
make it suitable for the severe environmental conditions in order to save
the regular technical data.
The ambient where the equipment operates should be dry and with no
dust; the ambient temperature is supposed to be within the range
advised by the manufacturer.

No material such as a rope insulating material or clothing should cover
the equipment at any time. Make sure that no kind of materials or objects
can somehow reduce the regular cooling air flow through the equipment.
Before operating the equipment make sure that all the advises reported
in the manual are fully complied.
In this section the data concerning the minimum room where the
equipment should operate are intended as minimum figures sufficient to
keep the internal parts of the equipment perfectly cooled.
In case that in the same shelter more equipment are placed it will be
necessary installing an effective air condition system to ensure the
recommended operational conditions. It is understood that in case the
advised conditions are not complied the manufacturer will not be liable
for any inconveniences or damages that may occur as the warranty
conditions will be void.

Package description
Any equipment is always supplied by us inside a suitable package for a
safe freighting, to avoid damages to the equipment due to small shocks.
Basically, the package is a carton box sealed with adhesive tape with the
manufacturer brand name, then externally tighten by a wide plastic cord.
In case one or more sides of the box have a different tape with respect
to the original one, it means that the box has been opened during the
despatch operations; this should be reported in an attached sheet.
At the time of opening the package, if a damage of the equipment or if
something is missing, we recommend to fill up the form which is included
in the manual, and accurately describe the inconvenience.
Upon that, the manufacturer will check where the problem may have
occurred and will decide to grant the replacement and if due , the
correspondent refund.
Besides the equipment, the carton box package should include:
1) Polythene bag
2) Polystyrene bottom and cover
1
2
3
4
5

Small equipment or spare modules are usually supplied with the
following kind of package:
1) Carton box
2) Polythene bag
3) Polystyrene material to absorb mechanical shocks
1
2
3
4

Installing operations
The installation of any electrical equipment should be always made
by technical and specifically trained technicians, who are supposed
to be aware of the risks related to the connection to an electrical supply.
Before proceeding to the installation, it is mandatory to verify that the
general electrical supply is fully in compliance with the normative of the
Country where the equipment will operate.
In the rear panel of the equipment, the requested electrical features of
mains are reported.
The utmost attention should be devoted to the grounding
system of the mains: this grants the personal safety of the
technical personnel in case of stray currents due to static voltages
accumulated in the equipment.
Before proceeding to any operations, we strongly recommend to make
sure that an adequate and certified grounding system has been set.
In case of disregard of the above mentioned recommendations, the
manufacturer does not take any responsibilities about damages to
persons and materials.
nce the place where the equipment will be situated, it is important to
verify the compliance with some specific criteria.
Any materials or objects should be placed at a distance of at least 30cms
from the cooling air ducts of the equipment. This will assure the regular
cooling conditions of the heat-sink of the equipment.

Disregarding the above mentioned advises and recommendations will
bring damages to the internal components and risk of fire
Make sure that the equipment is placed in a stable and secure position,
to easily allow the access to the front panel and to the rear panel too.
This will permit in the future a simple and fast inspection of the
connections if they are necessary.
First, connect the transmitting antenna cable to the correspondent N type
male connector placed in the rear panel; then connect the receiving
antenna cable.
Eventually connect the included power cord to the female plug placed on
the rear panel and protected by a fuse, and then connect the other end
to the mains plug.

Maintenance and cleanness
Routine maintenance and cleanness can be exclusively done when the
equipment is not connected to the mains. Disregarding this caution, may
have the effect of serious problems to the personal safety.
For no reasons, the equipment should have any contacts with water or
other liquids.
To clean the equipment, only use a soft cloth. In case that much dust is
accumulated inside the equipment, use a vacuum cleaner or a dry and
soft brush to remove it.
The routine maintenance of the equipment is intended also as the
periodical control of the operational parameters, following the instructions
written in the chapter “putting in operation”.

Safety
Read this chapter carefully before installation and use of the equipment.
Introduction
The equipment described in this manual, has been designed for use
by properly trained personnel only.
Adjustment, maintenance and repair of the exposed equipment should
only be carried out by qualified personnel who are aware of hazards
involved.
Safety Precautions
or the correct and safe use of the equipment, it is essential that both
operating and servicing personnel follow generally accepted safety
procedures in addition to the safety precautions specified in this manual.
Specific warning and caution statements, where applicable, are found
throughout this manual. Note that warning and caution statements and/or
symbols are marked on the equipment as well.
This manual provides technical information important for safe operation
of the equipment.
Please refer to the relevant sections of the manual for technical
specifications, installation and operating instructions.
Special attention must be paid to the following issues:
 Protective grounding of the instrument is required for the ac-
cessible terminals to be safe.
(IEC 1010-1 Safety class I instrument)
 The actual environmental conditions must be checked
against the specification
 Mains voltage must be inside the specified range
The opening of covers or removal of parts, except those to
which access can be gained by hand, is liable to expose live
parts and terminals.

If adjustment, maintenance, or repair of the opened instrument
is unavoidable, it must only be carried out by a skilled person
who is aware of the hazards involved.
Caution and Warning Statements
Caution
Used to indicate correct operation or maintenance in order to prevent
damage to, or destruction of equipment or other property.
Warning
Used to indicate a potential hazard that requires correct procedures or
practices in order to prevent personal injury.
Impaired Safety Protection
Technical Specifications
This manual provides technical information important for safe operation
of the equipment.
Please refer to the Chapter Product Data for information regarding
technical specifications and the Chapter Installation and Operating
Instructions regarding instructions for use.

The equipment is designed for the following environmental
conditions:
Indoor use
Altitudes up to 2000 m
Temperatures between +5
o
C and +45
o
C
Maximum relative humidity of 95% for temperatures up to 20
o
C.
The equipment is equipped with a number of input and output terminals
as described in the Chapter Product Data.
The terminals are protected
from becoming hazardous live
by means of basic insulation
and protective screening.
Whenever it is likely that safe operation is impaired, the equipment must
be made inoperative and secured against unintended operation. The
appropriate servicing authority must be informed.
or example, safety is likely to be impaired if the equipment fails to
perform the intended measurements or shows visible damage.
WARNING: Protection provided by the equipment may be impaired, if
the equipment is used in a manner not specified by this manual.
ATT NTION
lectrostatic Sensitive Devices
All ICs and many other semi-conductors are susceptible to electrostatic
discharges ESD). Careless handling during repair can reduce lifetime
drastically.
When repairing, make sure that you are connected to the same potential
as the mass of the set via a wrist wrap with resistance. Keep
components and tools also at this potential.

Symbols
Symbol Colour: xplanation:
Red High voltage terminal: a terminal at
which a voltage, with respect to
another terminal or parts exists or
may be adjusted to 1000 V or
more. (High voltage > 1000 V).
Black/Yellow Live part shock risk of electric
shock.
Black/Yellow To preserve the instrument from
damage, the operator must refer to
an explanation in the instruction
manual.
White/Black Protective earth (grounding)
terminal.
~
Black Alternating current (placed on the
identification plate).
White/Green
On (supply - mains switch).
Off (supply - mains switch).

General safety recommendations
When connecting the equipment to the power, please follow these
important recommendations:
This product is intended to operate from a power source that will
not apply more than 10% of the voltage specified on the rear
panel between the supply conductors or between either supply
conductor and ground. A protective-ground connection by way
of the grounding conductor in the power cord is essential for
safe operation.
This equipment is grounded through the grounding conductor of
the power cord. To avoid electrical shock, plug the power cord
into a properly wired socket before connecting to the product in-
put or output terminals.
Upon loss of the protective-ground connection, all accessible
conductive parts (including parts that may appear to be insulat-
ing) can render an electric shock.
To avoid fire hazard, use only the fuse of correct type, voltage
rating, and current rating. Refer fuse replacement to qualified
service personnel.
To avoid explosion, do not operate this equipment in an explo-
sive atmosphere.
To avoid personal injury, do not remove the product covers or
panels. Do not operate the product without the covers and pan-
els properly installed.
