R3 ECHORING R3HM1000 User manual

R3 HEALTH MONITOR
User Manual
Support Tool for the EchoRing Ethernet Bridge
R3HM1000
Contact Information:
R3 – Reliable Realtime Radio Communications GmbH
Bismarckstraße 1012 www.echoring.com

http://echoring.com
Revision: UMR3HM1000TP220200929EN
© by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
Table of Contents
1 General Terms of Use of this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Please Observe the Following Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 Product Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Device Assembly and Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1 Use Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1.1 Channel Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1.2 Indepth Channel Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
© by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
© by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
1 General Terms of Use of this Document
It is the user’s responsibility to regularly confirm they have downloaded the latest version
of this manual, as R3 may edit, revise, or improve product documentation over time.
The user must ensure the product is used correctly according to this document’s guidelines,
in particular by observing all relevant standards and regulations.
This document, including all diagrams and illustrations, is copyrightprotected. Any and all
changes violate our Terms of Use.
© by R3 – Reliable Realtime Radio Page 1 of 8 1. General Terms of Use of this Document

http://echoring.com
Revision: UMR3HM1000TP220200929EN
2 Please Observe the Following Notes
Please observe and obey the following note formats and instructions throughout the docu
ment:
TIP — Text in this format is information explaining correct use of the product.
!
ATTENTION — Text in this format must be observed in order to avoid malfunction and/or even damage,
or to avoid security risks.
iEXAMPLE — Text in this format provides examples.
2. Please Observe the Following Notes Page 2 of 8 © by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
3 Product Description
The Health Monitor is a device that determines data traffic patterns and quality of signals
in a deployed wireless network. This allow the setup of a well operating wireless network.
© by R3 – Reliable Realtime Radio Page 3 of 8 3. Product Description

http://echoring.com
Revision: UMR3HM1000TP220200929EN
4 Product Specification
General
Model Panasonic Toughpad FZM1
Graphic Chip Intel® HD Graphics 615
Physical Dimensions (WxDxH) 203 mm x 18 mm x 132 mm
Weight Approx. 540g
Power Adapter Input: 100V 240V AC, 50Hz/60Hz
Output: 16V DC, 3.75A
Operating temperature 29°C to +60°C
Storage temperature 51°C to + 71°C
Scannable frequencies 5,725–5,875 MHz
Number of channels 5
4. Product Specification Page 4 of 8 © by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
5 Device Assembly and Usage
5.1 Use Device
5.1.1 Channel Overview
The device scans the wireless channels for active traffic in the supported frequency bands.
Statistics of each scanned channel are shown in the upper horizontal bar.
(A)
(B)
(C)
(A) ”Packets/sec” displays the number of packets, transmitted with a device over EchoRing,
in each channel.
(B) ”NonEchoring/sec” displays the number of other Wlanbased packets, not transmitted
over EchoRing, on that channel.
(C) ”Number of Nodes” displays the number of EchoRingcapable devices currently active
in the channel.
5.1.2 Indepth Channel Diagnostic
1. Click the channel with active EchoRing devices that you would like to monitor more
closely. Click the selected channel again to enter channel overview scanning of the
frequency band.
2. You now see two graphical elements: a topology graph with its devices to the left and
statics diagrams to the right.
5.1.2.1 Network’s Signal Strength
1. Click the ”Show SNR” toggle.
2. The topology now shows a graphical representation of the signal strengths between
devices in network.
© by R3 – Reliable Realtime Radio Page 5 of 8 5. Device Assembly and Usage

http://echoring.com
Revision: UMR3HM1000TP220200929EN
Each device in the topology has a circle around them. This circle is cut in sections which rep
resents each link to every other device in the network. The color of the section determines
the signal strength to each device.
Color SNR Meaning
Red < 40 dB
low chance of transmitting/receiving without interference
poor link quality
improvement is highly recommended
Orange 4080 dB
medium chance of transmitting/receiving without interference
medium link quality
improvement is recommended
Green > 80 dB
high chance of transmitting/receiving without interference
good link quality
improvement is not needed
Click on a specific device to investigate which respective link is to which device.
Arrows with a numerical value appear between devices displaying the links signal strength.
The signal strength does dynamically change since it is directly affected by objects in the
environment.
TIP — If possible, try improve SNR values by adjusting position of devices with poor signal strength or by
reconfiguring reliability parameters in network config, in order to make network more robust.
The SNR of all stations is also displayed in a graph to the right.
When clicking one device, the graph adjusts to compare the signal quality of the selected
device to the others.
5. Device Assembly and Usage Page 6 of 8 © by R3 – Reliable Realtime Radio

http://echoring.com
Revision: UMR3HM1000TP220200929EN
Select the ”Table” tab next to the graph to display the comparative SNR data in a table
format instead.
5.1.2.2 Traffic Patterns
1. On the diagram element to the right, scroll down to display a diagram of data packets.
2. Select a specific packet type to appear on the graph.
3. The “Accumulated” toggle displays the accumulated volume of the selected data type
that each station has sent to all other stations. As long as no station is selected,
disabling the “Accumulated” toggle is not possible.
Hover over the graph to see the specific number of packets sent from each station.
© by R3 – Reliable Realtime Radio Page 7 of 8 5. Device Assembly and Usage

http://echoring.com
Revision: UMR3HM1000TP220200929EN
Click on a station and disable the ”Accumulated” toggle the graph will now only show the
data sent from the selected station to all others.
Click on the ”Table” tab next to ”Graph” to display each station in a table. Symbols represent
each packet type, next to the number of sent packets.
Click on ”Legend” beneath the graph for a legend explaining the packet type for each
symbol.
To exist the indepth diagnostic of the chosen channel and return to frequency band scan
and channel overview, click on ”Scan” in the upper left corner of the screen.
5. Device Assembly and Usage Page 8 of 8 © by R3 – Reliable Realtime Radio
